PED4000 D, PED5000 D Series Exit Device
Premium Delayed Egress
Installation Instructions

2
Premium Delayed Egress
Installation Instructions
PED4000 D, PED5000 D Series Exit Device
FM574 01/23
Copyright © 2023 ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole or in part without
the express written permission of ASSA ABLOY Access and Egress Hardware Group, Inc. is prohibited.
For installation assistance contact Corbin Russwin
1-800-543-3658 • [e-mail]
TOC Table of Contents
1 Panic and Fire Rated Devices.....................................................4
a Checklist ........................................................................4
b Required Components ..........................................................4
c Optional Components ...........................................................4
d Electrical Specifications..........................................................4
2 Insert and PC Board Assembly ...................................................5
3 DIP Switch Settings ..............................................................6
4 Device Mounting ................................................................8
5 Wire Routing .................................................................. 10
6 Installation of Insert Asssembly to Device ...................................... 21
7 Harness Wiring Reconfiguration ............................................... 22
8 Input/Output Connector Designations ......................................... 23
9 ElectroLynx System ............................................................ 26
10 ElectroLynx Wiring Options Overview with QC12 Hinge........................ 27
11 System Wiring Examples ElectroLynx QC8 Hinge ............................ 28
12 System Wiring Examples ElectroLynx QC12 Hinge ........................... 30
13 Field Wiring Door Prep ........................................................ 32
14 Operating Instructions......................................................... 33
15 Additional Options Non ElectroLynx Wiring.................................... 34

3
Premium Delayed Egress
Installation Instructions
FM574 01/23
Copyright © 2023 ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole or in part without
the express written permission of ASSA ABLOY Access and Egress Hardware Group, Inc. is prohibited.
For installation assistance contact Corbin Russwin
1-800-543-3658 • [e-mail]
PED4000 D, PED5000 D Series Exit Device
TOC Table of Contents
16 BOCA 15 Second Delay BC-59_ & BOCA 30 Second Delay BC-59_ ............... 34
17 NFPA 101 Requirements: 30 Second Delay BC-59_ Suffix ....................... 34
18 Troubleshooting............................................................... 35
Caution: Do not change factory applied finishes.
NOTE:
• Wiring method must be in accordance with CSA C22.1, Canadian Electrical Code, Part I, Safety Standard for
Electrical Installations, Section 32; and CAN/ULC-S524 Installation of Fire Alarm Systems.
WARNING
This product can expose you to lead which is known to the state of California to cause cancer and birth defects
or other reproductive harm. For more information go to www.P65warnings.ca.gov.

4
Premium Delayed Egress
Installation Instructions
PED4000 D, PED5000 D Series Exit Device
FM574 01/23
Copyright © 2023 ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole or in part without
the express written permission of ASSA ABLOY Access and Egress Hardware Group, Inc. is prohibited.
For installation assistance contact Corbin Russwin
1-800-543-3658 • [e-mail]
1Panic and Fire Rated Devices
1. Check device for shipping damage prior to installation and make sure all parts are on hand.
2. Identify options provided with device.
3. Identify model, type and hand of trim if applicable (see exit device and trim instructions for reversing hands).
4. Contact hardware supplier if device is damaged or missing parts.
aChecklist
bRequired Components (Numbered list correlates with numbers in Figure 1)
cOptional Components (Numbered list correlates with numbers in Figure 1)
1. 24VDC UL Listed Regulated and Filtered Power Supply with Fire Alarm Interface (recommend Securitron BPS 24-1 or
24-2 (UL294 Listed), depending on requirements). Power supply is NOT to be used in UL603 Burglar Alarm System.
2. Power transfer UL or ULC listed (8 or 12 wire depending on system) ElectroLynx QC8 or QC12, Securitron (EPT) or
equivalent.
3. Sign (MUST BE INSTALLED ON DOOR ABOVE DEVICE).
NOTE: The delayed egress system is to be installed in accordance with NFPA 101.
dElectrical Specifications*
• Input Voltage: 24VDC +/- 15% (20.4 - 27.6VDC)
regulated/filtered
• Power Consumption @ 24VDC:
60 - 70 mA (typical) Disarmed
280 -340 mA (typical) Armed
320 - 830 mA (typical) Delayed Egress Initiated
70 - 90 mA (typical when arming)
Output Relays: Form C, 1 Amp 24VDC
Operating Temp: -40°C to 66°C (-40°F to 150.8°F)
*Follow Local Electrical Codes for Wiring.
NOTE: Components shown do not reflect all possible applications. Refer to other system wiring diagrams within
this manual. Consult manufacturer for special applications.
Figure 1
6.
4.
PUSH UNTIL ALARM
SOUNDS. DOOR CAN BE
OPENED IN 15 SECONDS.
3.
5.
1.
8.
7.
9.
115 VAC
800 mA
60 Hz
Fire
Alarm
Circuit
Req’d
Or
2.
4. Remote Annunciator
5. Door Position Switch (DPS)
6. Standard Trim
7. Electrified Trim
8. Device and Trim Cylinder
51
2
3
4
67
8

5
Premium Delayed Egress
Installation Instructions
FM574 01/23
Copyright © 2023 ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole or in part without
the express written permission of ASSA ABLOY Access and Egress Hardware Group, Inc. is prohibited.
For installation assistance contact Corbin Russwin
1-800-543-3658 • [e-mail]
PED4000 D, PED5000 D Series Exit Device
Figure 2
Cylinder Nut
Activator Leg
Circuit Board Assembly
Indicator Light (LED)
Arming Switch Activator
Lens Cover
1-1/8” (29mm) Mortise
Cylinder 1000-118-A07
(Order seperately)
Order Separately
1-1/8”
29mm
A07 Cam
Assembly steps for non-factory-keyed orders:
1. Insert cylinder through the cylinder support piece in the rail insert with keyway
horizontal and toward the closest end of the rail insert.
Typical Mortise Cylinder
1000-118-A07
3. Secure parts in place with cylinder nut. Be certain arming switch activator sits around flange in the cylinder
support piece to allow rotation of activator.
4. Insert circuit board assembly into rail insert over cylinder and switch activator. Ensure the fingers of the arming
switch activator straddle the switch mounted to the circuit board. Press down until it snaps into all four slots in the
rail insert.
5. Verify assembly by rotating key counter-clockwise and clockwise. Key should move freely and arming switch should
trip for both rotation directions. If key does not rotate freely, verify arming switch activator is properly seated on
cylinder support piece.
2. Slide arming switch activator over cylinder and onto the cylinder support piece. Notch in arming switch activator
keys over the stop feature in cylinder support.
Cylinder and Collars
• Use standard 1-1/8” mortise cylinder
with A07 cam, no collar. Corbin
Russwin #1000-118-A02 collar is not
required.
• Use Corbin Russwin spacer 370F29 for
optional 1-1/4” long cylinder.
• Use Corbin Russwin spacer 370F31 for
optional 1-1/2” long cylinder.
P5 connector - Plug this into
the end bracket’s metal tab
P1 P2
P3
Figure 3
2 Insert and P.C. Board Assembly

6
Premium Delayed Egress
Installation Instructions
PED4000 D, PED5000 D Series Exit Device
FM574 01/23
Copyright © 2023 ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole or in part without
the express written permission of ASSA ABLOY Access and Egress Hardware Group, Inc. is prohibited.
For installation assistance contact Corbin Russwin
1-800-543-3658 • [e-mail]
2 Insert and P.C. Board Assembly, continued
NOTES:
• Factory keyed orders will be shipped assembled.
• Prior to insert assembly, device must be cut to proper length to prevent damage to circuit board - 36" device cannot
be field cut. A maximum of 6" can be cut from a 48" device.
S2
1 Nuisance Audible
2 Nuisance Delay
8 DPS Bypass
3 Nuisance Delay
4 Reset Delay
5 Reset Delay
6 Armed LED Color
7 RAC
3DIP Switch Settings
S2-1: Nuisance Audible may be selected ON (default) or OFF
PCBA DIP SWITCH VIEW
S2-8: Switch must be set ON (default) to Bypass when an external
Door Position Switch (DPS) is NOT used, and OFF when an
external DPS is used.
S2-2 and S2-3: Nuisance Delay time may be selected 0 (Immediate),
1 (default), 2 or 3 seconds
S2-4 and S2-5: Reset Delay time may be selected 5, 10 (default), 20 or
40 seconds
S2-6: Cover Armed LED Color is Red (default) when ON and Green when OFF
S2-7: Re-arm After Closing (RAC)* (see below)
S2 Dip Switch - Default Settings
S2 Dip SW 1 2 3 4 5 6 7* 8
OFF (UP) OFF OFF OFF
ON (DOWN) ON ON ON ON ON

7
Premium Delayed Egress
Installation Instructions
FM574 01/23
Copyright © 2023 ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole or in part without
the express written permission of ASSA ABLOY Access and Egress Hardware Group, Inc. is prohibited.
For installation assistance contact Corbin Russwin
1-800-543-3658 • [e-mail]
PED4000 D, PED5000 D Series Exit Device
Nuisance Delay (seconds)
0 1 2 3
S2-2 OFF OFF ON ON
S2-3 OFF ON OFF ON
Reset Delay (seconds)
5 10 20 40
S2-4 OFF OFF ON ON
S2-5 OFF ON OFF ON
S2-6 OFF Cover Armed LED Color is Green
ON Cover Armed LED Color is Red (default)
S2-7 OFF* Momentary egress mode 5, 10, 20 or 40 seconds. Device will immediately
Rearm After Closing (RAC) door, if closed before selected time expires or
it will enter alarm mode, if time expires with door open (default).
See other details*
ON** 40 seconds momentary egress mode is extended indefinitely, if the door
is left open. Then the device immediately Rearms after Closing (RAC)
door. See other details**
S2-8 OFF External DPS is wired to device
ON DPS Bypass, external DPS is NOT wired to device (default)
3DIP Switch Settings, continued
*With S2-7 OFF (S2-4 and S2-5 set for 5, 10, 20 or 40sec), if door/DPS is open after selected time the alarm will sound. Close door to
reset and rearm device using cylinder key or remote reset signal.
**S2-7: When an external DPS is used and switch S2-7 ON, and 40 second reset delay (S2-4 and S2-5) are set ON, after activation of
momentary egress by cylinder key switch or external remote reset signal, if the Door/DPS is open beyond 40sec the device will remain
in momentary egress mode indefinitely and shall not enter alarm mode; then once the Door/DPS is closed it will rearm immediately.
If door/DPS is opened then closed before selected time expires, the device will rearm immediately.
If DPS is not used, is bypassed with S2-8 ON, the door will rearm immediately after 5, 10, 20 or 40 sec whether the door is open or
closed, with either S2-7 ON or OFF.
Ensure eight S2 Dip Switches are set per application before moving on to the next page of instructions.
Default

8
Premium Delayed Egress
Installation Instructions
PED4000 D, PED5000 D Series Exit Device
FM574 01/23
Copyright © 2023 ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole or in part without
the express written permission of ASSA ABLOY Access and Egress Hardware Group, Inc. is prohibited.
For installation assistance contact Corbin Russwin
1-800-543-3658 • [e-mail]
4Device Mounting
1. Refer to installation instructions included with device and trim for complete door and frame preparations. Refer to
template for wire access hole location.
2. Feed wires from power transfer through wire access hole in door. (Figure 4)
ElectroLynx System Default Wiring Options for DEED QC12 Hinge (12 wires)
Pluggable 8-pin & 4-pin connectors. Default wiring shown.
42
3 1
1
75
64
3
2
8
4-pin
8-pin
Rail to Hinge Harness
(with 8-pin, 4-pin, & 26-pin connectors )
ElectroLynx Field
Wiring Termination
Options
(12 wires max)
8, Yellow (RAR NC)
4, Tan (SEC NO) QC12 HingePremium Delayed Egress
Rail Assembly
Door Harness
3" Typical
QC12 Hinge Pigtail
or
15' Frame Harness
26-pin
Must connect to metal tab
on exit device end bracket
Door Harness
3" Typical
QC12 Hinge
QC12 Hinge Pigtail
or
15' Frame Harness
Premium Delayed Egress
Device
Pluggable 8-pin and
4-pin connectors
RR
EI
DS
(RAR COM)
(SEC COM)
VDC
RR
(EI)
DS
(RAR COM)
8, Yellow (RAR NC)
(SEC COM)
4, Tan (SEC NO)
NOTES:
• Wires must be protected from abrasion.
• For use with Class II circuits only.
Figure 4

9
Premium Delayed Egress
Installation Instructions
FM574 01/23
Copyright © 2023 ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole or in part without
the express written permission of ASSA ABLOY Access and Egress Hardware Group, Inc. is prohibited.
For installation assistance contact Corbin Russwin
1-800-543-3658 • [e-mail]
PED4000 D, PED5000 D Series Exit Device
4Device Mounting, continued
7. Do not install end cap until device has been wired and tested for operation (See wiring diagrams).
Figure 3
3 When required, mount outside trim to door
(see trim installation instructions).
4. Unthread screw and remove dogging slope bracket (Figure 3).
5. Pull the mount rail cover back to expose front end of the carrier/push
assembly (Figure 4).
6. Install chassis on door. Leave chassis screws loose. Insert rail onto chassis. Pin bracket to slot in chassis lift arm
(Figure 5).
7. Slide the mount rail back to the front and replace the dogging slope bracket and screw (Figure 6).
Figure 5
Figure 4
Figure 6
Note: For additional instructions on hardware install, refer to
mechanical instructions.

10
Premium Delayed Egress
Installation Instructions
PED4000 D, PED5000 D Series Exit Device
FM574 01/23
Copyright © 2023 ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole or in part without
the express written permission of ASSA ABLOY Access and Egress Hardware Group, Inc. is prohibited.
For installation assistance contact Corbin Russwin
1-800-543-3658 • [e-mail]
5Wire Routing
PED4600
OVERVIEW
M91 Connection
Step 1. Install mortise lock. Route wire
as shown.
M93 Lever Monitoring
(if applicable)
M91 Connection
Electric Trim
(If applicable)
Step 2. Route trim wires as shown.
M93 Lever Monitoring
(if applicable)
Electric Trim
(If applicable)
Electric Trim
(If applicable)
M91 Connection
M93 Lever Monitoring
(if applicable)
Step 3. Install chassis and rail.
Make wire connections.
Step 4. Pull back excess wire
through rail. Route wires as
shown. Install wire clip.
Wire Clip

11
Premium Delayed Egress
Installation Instructions
FM574 01/23
Copyright © 2023 ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole or in part without
the express written permission of ASSA ABLOY Access and Egress Hardware Group, Inc. is prohibited.
For installation assistance contact Corbin Russwin
1-800-543-3658 • [e-mail]
PED4000 D, PED5000 D Series Exit Device
5Wire Routing - continued
PED4800
OVERVIEW
Electric Trim
(If applicable)
M93 Lever Monitoring
(if applicable)
M91 Connection

12
Premium Delayed Egress
Installation Instructions
PED4000 D, PED5000 D Series Exit Device
FM574 01/23
Copyright © 2023 ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole or in part without
the express written permission of ASSA ABLOY Access and Egress Hardware Group, Inc. is prohibited.
For installation assistance contact Corbin Russwin
1-800-543-3658 • [e-mail]
5Wire Routing - continued
Step 2. Route wires through chassis
as shown and secure chassis to door.
Step 3. Install rail. Step 4. Make wire connections.
Electric Trim
(If applicable)
M93 Lever Monitoring
(if applicable)
Step 1. Route wires as shown and secure trim to door.
Step 5. Pull back excess wire
through rail. Route wires as
shown. Install wire clips.
PED4800
M91 Connection

13
Premium Delayed Egress
Installation Instructions
FM574 01/23
Copyright © 2023 ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole or in part without
the express written permission of ASSA ABLOY Access and Egress Hardware Group, Inc. is prohibited.
For installation assistance contact Corbin Russwin
1-800-543-3658 • [e-mail]
PED4000 D, PED5000 D Series Exit Device
5Wire Routing - continued
PED4200
OVERVIEW
Step 3. Pull additional wire slack through rail
from insert end and tuck latch bolt monitor
(M91) connection into chassis.
Step 2. Secure trim. Make M91 connection.
Step 1. Install chassis to rail.
Route wires through door as shown.
Electric Trim
(If applicable)
M93 Lever Monitoring
(if applicable)
M91 Connection

14
Premium Delayed Egress
Installation Instructions
PED4000 D, PED5000 D Series Exit Device
FM574 01/23
Copyright © 2023 ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole or in part without
the express written permission of ASSA ABLOY Access and Egress Hardware Group, Inc. is prohibited.
For installation assistance contact Corbin Russwin
1-800-543-3658 • [e-mail]
5Wire Routing - continued
PED5800
OVERVIEW
Electric Trim
(If applicable)
M93 Lever Monitoring
(if applicable)
Electric Trim
(If applicable)
M91 Connection

15
Premium Delayed Egress
Installation Instructions
FM574 01/23
Copyright © 2023 ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole or in part without
the express written permission of ASSA ABLOY Access and Egress Hardware Group, Inc. is prohibited.
For installation assistance contact Corbin Russwin
1-800-543-3658 • [e-mail]
PED4000 D, PED5000 D Series Exit Device
5Wire Routing - continued
M91 Connection
Electric Trim
(If applicable)
M93 Lever Monitoring
(if applicable)
Step 1. Route wires as shown and
secure trim to door.
Step 2. Install chassis (Section 4) and route wires
through chassis as shown.
Main Slide & Roller
Step 3. Install rail. Step 4. Make wire connections. Step 5. Snap trim jumper to clip
and route excess wire as shown.
Step 6. Tuck wire connections along side of
main slide. Pull back excess wire through rail.
PED5800
ELECT TRIM
(IF APLICABLE)

16
Premium Delayed Egress
Installation Instructions
PED4000 D, PED5000 D Series Exit Device
FM574 01/23
Copyright © 2023 ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole or in part without
the express written permission of ASSA ABLOY Access and Egress Hardware Group, Inc. is prohibited.
For installation assistance contact Corbin Russwin
1-800-543-3658 • [e-mail]
5Wire Routing - continued
PED5400
OVERVIEW
Electric Trim
(If applicable)
M93 Lever Monitoring
(if applicable)
M91 Connection

17
Premium Delayed Egress
Installation Instructions
FM574 01/23
Copyright © 2023 ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole or in part without
the express written permission of ASSA ABLOY Access and Egress Hardware Group, Inc. is prohibited.
For installation assistance contact Corbin Russwin
1-800-543-3658 • [e-mail]
PED4000 D, PED5000 D Series Exit Device
5Wire Routing - continued
Step 1. Install chassis and rail (Section 4). Route trim wires
from rail under brass lift lever as shown.
Step 2. Make M91- connection.
M93-Lever Monitoring
(if applicable)
Electric Trim
(If applicable)
M91- Connections
Step 3. Route trim wires through chassis and door as shown. Step 4. Make trim wire connections and secure trim to door.
Pull back excess wire through rail.
M93- Lever Monitoring
(if applicable)
Electric Trim
(If applicable)
Brass lift lever
PED5400

18
Premium Delayed Egress
Installation Instructions
PED4000 D, PED5000 D Series Exit Device
FM574 01/23
Copyright © 2023 ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole or in part without
the express written permission of ASSA ABLOY Access and Egress Hardware Group, Inc. is prohibited.
For installation assistance contact Corbin Russwin
1-800-543-3658 • [e-mail]
5Wire Routing - continued
M93 Lever Monitoring
(If applicable)
Step 3. Connect wires and secure trim to door.
PED5200
OVERVIEW
M91 Connection
Electric Trim
(If applicable)
Optional Trim
Wire Route
M93 Lever Monitoring
(if applicable)
Electric Trim
(If applicable)
Step 1. Install chassis and rail. Step 2. Route trim wires through chassis and
door as shown above.
Step 2A. Additional view
Electric Trim
(If applicable)

19
Premium Delayed Egress
Installation Instructions
FM574 01/23
Copyright © 2023 ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole or in part without
the express written permission of ASSA ABLOY Access and Egress Hardware Group, Inc. is prohibited.
For installation assistance contact Corbin Russwin
1-800-543-3658 • [e-mail]
PED4000 D, PED5000 D Series Exit Device
5Wire Routing - continued
PED5600
OVERVIEW
M93 Lever Monitoring
(if applicable)
Electric Trim
(If applicable)
M91 Connection
Step 2. Install chassis and connect M91
jumper at chassis.
Step 3. Install rail to chassis.
Step 1. Install mortise lock. Route
wire as shown.

20
Premium Delayed Egress
Installation Instructions
PED4000 D, PED5000 D Series Exit Device
FM574 01/23
Copyright © 2023 ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole or in part without
the express written permission of ASSA ABLOY Access and Egress Hardware Group, Inc. is prohibited.
For installation assistance contact Corbin Russwin
1-800-543-3658 • [e-mail]
5Wire Routing - continued
Step 6. Pull back excess wire through rail.
Step 4. Make wire connections.
Electric Trim
(If applicable)
M93 Lever Monitoring
(if applicable)
M91 Jumper
Step 5. Secure trim to door.
Step 6. Pull back excess wire through rail.
PED5600
