DITEC DAB105 User manual

Ditec DAB105
Swing doors
(translation of the original instructions)
Technical Manual
www.ditecautomations.com
IP2159EN • 2021-07-05
Last version of this manual

2
IP2159EN
Contents
Key
Subject Page
General safety precautions 3
EC Declaration of Incorporation 4
1. Technical specifications 5
2. Standard installation 6
3. Dimensions 7
4. Main components 8
5. Installation 9
5.1 Preliminary checks 9
5.2 General information 9
5.3 Installation examples 10
5.4 Removing the cover 10
6. Automation with articulated arm. 11
6.a DAS805PSA 11
6.b DAB805PSAF (for applications on fire doors) 11
Automation preparation and fastening (Left-hand opening) 11
Automation preparation and fastening (right-hand opening) 13
6.a.1 Fixing the arm DAB805PSA 15
6.b.1 Fixing the arm DAB805PSAF 16
7. Automation with sliding arm DAB805PLA 17
Automation preparation and fastening (left-hand opening) 17
Automation preparation and fastening (right-hand opening) 20
7.1 Fixing the sliding arm DAB805PLA 23
8. Connecting to the electricity supply 24
9. Electrical connections DAB105CU 25
9.1 Commands 25
9.2 Outputs and accessories 26
9.3 Adjustments 27
Trimmer 27
Dip-switch 28
9.4 Signals 28
9.5 Alarms (RED ERROR LED) 28
10. Extension unit DAB905ESE (optional) 29
10.1 Commands 29
10.2 Outputs and accessories 31
10.3 Adjustments 32
Trimmer 32
Dip-switch 32
Jumper 32
11. Extension unit DAB905ESE (optional) 33
11.1 Commands 33
11.2 Outputs and accessories 34
11.3 Adjustments 34
Trimmer 34
Jumper 35
11.4 Signals 35
12. Start-up 36
12.1 Adjusting the door stop 36
12.2 Lock kick microswitch 37
12.3 Auto-learn – automatically sets back and latch check 37
12.3.1 One push / two pushes on the LEARN BUTTON (LRN) 38
12.3.2 Double doors 38
12.4 General adjustment 38
13. Pre-configured parameters 39
14. Advanced settings available on the control panel version indicated, or subsequent versions 40
14.1 Increased thrust force on closure when an electric lock is fitted 40
14.2 Management of electric lock / electric strike power supply 40
15. Door requisites for “Low Energy” use 41
16. Example of an application with a standard control panel 42
17. Example of an application with optional extension units 42
18. Synchronized doors (DAB905SYN) 42
18.1 Settings 43
19. Example of installation of synchronized doors (DAB905SYN) 44
20. Interlocked automations 45
21. Routine maintenance plan 45
22. Troubleshooting 46
23. Signs 47
This symbol indicates instructions or notes regarding safety, to which special attention must be paid.
This symbol indicates useful information for the correct functioning of the product.

3
IP2159EN
General safety precautions
This installation manual is intended for qualified personnel only •Installation, electrical connections and
adjustments must be performed by qualified personnel, in accordance with Good Working Methods and
in compliance with the current regulations • Read the instructions carefully before installing the product.
Wrong installation could be dangerous • Before installing the product, make sure it is in perfect condition •
The packaging materials (plastic, polystyrene, etc.) should not be discarded in the environment
or left within reach of children, as they are a potential source of danger • Do not install the
product in explosive areas and atmospheres: the presence of inflammable gas or fumes represents
a serious safety hazard • Make sure that the temperature range indicated in the technical specifica-
tions is compatible with the installation site • Before installing the motorization device, make sure
that the existing structure, as well as all the support and guide elements, are up to standards in
terms of strength and stability. Verify the stability and smooth mobility of the guided part, and make
sure that no risks of fall or derailment subsist. Make all the necessary structural modifications to
create safety clearance and to guard or isolate all the crushing, shearing, trapping and general haz-
ardous areas • The motorization device manufacturer is not responsible for failure to observe Good
Working Methods when building the frames to be motorized, or for any deformation during use •
The safety devices (photocells, safety edges, emergency stops, etc.) must be installed taking into
account the applicable laws and directives, Good Working Methods, installation premises, system
operating logic and the forces developed by the motorized door or gate • The safety devices must
protect against crushing, cutting, trapping and general danger areas of the motorized door or gate.
Display the signs required by law to identify hazardous areas. Each installation must bear a visible
indication of the data identifying the motorized door or gate • Before connecting the power supply,
make sure the plate data correspond to those of the mains power supply. An omnipolar disconnec-
tion switch with a contact opening distance of at least 3mm must be fitted on the mains supply.
Check that there is an adequate residual current circuit breaker and a suitable overcurrent cutout
upstream of the electrical installation in accordance with Good Working Methods and with the laws
in force • When requested, connect the motorized door or gate to an effective earthing system that
complies with the current safety standards • Before commissioning the installation to the end user,
make sure that the automation is adequately adjusted in order to satisfy all the functional and safe-
ty requirements, and that all the command, safety, and manual release devices operate correctly •
During installation, maintenance and repair operations, cut off the power supply before open-
ing the cover to access the electrical parts • The protection cover of the operator must be
removed by qualified personnel only.
The electronic parts must be handled using earthed antistatic conductive arms. The manu-
facturer of the motorization declines all responsibility if component parts not compatible with
safe and correct operation are fitted • Only use original spare parts for repairing or replacing
products • The installer must supply all information concerning the automatic, manual and emer-
gency operation of the motorized door or gate, and must provide the user with the operation and
safety instructions.
ATTENTION! Important safety instructions.
Please follow these instructions carefully. Failure to observe the information given in this manual
may lead to severe personal injury or damage to the equipment.
Keep these instructions for future reference.
This manual and those for any accessories can be downloaded from www.ditecautomations.com.

4
IP2159EN
EC Declaration of Incorporation
We:
ASSA ABLOY Entrance Systems AB
Lodjursgatan 10
SE-261 44 Landskrona
Sweden
Declare under our sole responsibility that the type of equipment with name:
Ditec DAB105 swing door operator
Comply with the following directives and their amendments:
2006/42/EC Machinery Directive (MD), particularly the following essential health and safety requirements: 1.1.2, 1.1.3, 1.2.1,
1.2.2, 1.2.3, 1.2.4.2, 1.2.6, 1.3.9, 1.4.3, 1.7.2, 1.7.3, 1.7.4, 1.7.4.1, 1.7.4.2.
2014/30/EU Electromagnetic Compatibility Directive (EMCD)
2011/65/EU Restriction of hazardous substances (RoHS 2)
2015/863/EU Restriction of hazardous substances (RoHS 2 Amendment)
Harmonised European standards that have been applied:
EN 60335-1:2012+A11:2014 EN ISO 13849 -1:2015 EN 61000 -6-2:2005
EN 60335-2-103:2015 EN 16005:2012/AC:2015 EN 61000 -6-3:2007+A1:2011
Other standards or technical specifications that have been applied:
IEC 60335-1:2010, IEC 60335-2-103:2011, EN 1634-1:2008
EC type examination or certificate issued by a notified or competent body concerning the equipment:
RISE SC0250-14
The manufacturing process ensures the compliance of the equipment with the technical file.
The equipment must not be used until the final installed automatic entrance system has been declared in compliance with the
machine directive 2006/42/EC.
Responsible for technical file:
Matteo Fino
Business Area PGA
Ditec S.p.A.
Largo U. Boccioni, 1
21040 Origgio (VA)
Italy
Signed for and on behalf of ASSA ABLOY Entrance Systems AB by:
Place Date Signature Position
Origgio 2021-07-05 Matteo Fino President B.A. PGA
Signature
Ma
a
a
a
a
a
Ma
a
a
a
a
a
a
a
a
a
a
a
a
a
a
a
a
a
a
a
a
a
a
a
a
a
a
a
a
tt
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
eo
F
in
n
n
in
n
n
n
n
in
n
n
n
n
n
n
n
n
n
n
i
n
n
n
n
i
o
