Dometic SANIPOTTIE 970 Series User manual

1
970 SERIES PORTABLE TOILETS
ASEOS PORTÁTILES SERIE 970
TOILETTES PORTABLES, SERIE 970
INSTRUCTION MANUAL
EN . . . 1-7
MANUAL DE INSTRUCCIONES
ES . . .8-13
MODE D’EMPLOI
FR . . 14-20
972
, 974, 974MSD
975
, 975MSD,
976
PORTABLE TOILETS

2
970
SERIES PORTABLE TOILETS
EN
NO.
PART NUMBER
DESCRIPTION
1
385311528
Air pump
2
385311529
Seat cover and seat
3
385311530
Water cap
4
385311531
Bowl assembly
5
385311532
Discharge spout cap

3
6
385311533
Discharge spout assembly
972, 974, 975, 976
7
385311534
385311535
Holding tank assembly (tan)
Holding tank assembly (gray)
2.6 gal./9.8 L - 972, 974, 974MSD
8
385311536
385311537
Holding tank assembly (tan)
Holding tank assembly (gray)
5.0 gal./18.9 L - 975, 975MSD, 976
9
385311538
385311539
Locking handle (tan) Locking
handle (gray)
972, 974, 974MSD, 975, 975MSD, 976
10
385311564
Mounting brackets
974, 974MSD, 975, 975MSD
11
385320006
MSD fitting
974MSD
12
385320007
MSD fitting
975MSD
OPERATION
Prepare toilet for use
1. CAUTION! With seat lid closed, pull
flush handle to open slide valve, then push
to close. This relieves air pressure that may
be created in lower holding tank due to
changes in temperature or altitude.
2. Remove water cap and fill upper tank until it
reaches about 1 inch (25 mm) below
opening. Replace cap.
3. Pull flush handle to open slide valve.
4. Pour deodorant directly into lower tank,
then close slide valve.
CAUTION! Never pour deodorant into
bowl with slide valve closed.
5. Stroke air pump about 15 times or until air
emits through relief valve on water cap.
CAUTION! Do not over-pressurize
upper tank by covering relief valve. Do
not pressurize upper tank when
disconnected from lower tank.
1. CAUTION! BEFORE EACH USE, with 2. Pull flush handle to release waste into seat lid
closed, pull flush handle to open lower tank. slide valve, then push to close. This 3. Push
flush button to rinse bowl. Push flush relieves air pressure that may be created handle to
close slide valve.

4
970
SERIES PORTABLE TOILETS
Empty holding tank
1. When tank level indicator shows “full,” 3. Rotate discharge spout away from tank, empty
the lower tank. and open vent on top of holding tank.
2. Pull up on rear latch to separate upper tank Empty tank.
from lower tank. Carry lower tank to autho- 4. If water is available, rinse lower tank before
INSTALLATION
BE SURE TO READ INSTRUCTIONS COMPLETELY BEFORE INSTALLING PORTABLE TOILET.
Models 974, 975
1. Place toilet on level floor in desired location. Mark
floor at front of toilet, then set toilet aside. Pull
locking handle out of toilet (located at bottom front of
toilet).
2. Align mounting template with mark on floor.
3. Use center punch to mark fastener hole locations for
brackets. Set template aside.
4. Drill pilot holes with 3/32-in. (2.4 mm) drill bit. Align
centers of bracket slots with the drilled holes. With
supplied fasteners, attach brackets to floor so that
they can be slid with little effort.
5. Position toilet into the mounting brackets and insert
the locking handle into front of toilet. The toilet
should be securely held in position by the brackets. If
toilet is not secure, adjust back brackets and/or front
bracket until toilet is secure.
6. Once the brackets are properly positioned, remove
locking handle and set toilet aside. Firmly tighten
fasteners to secure the brackets in place.
7. Position toilet into mounting brackets and reinsert the
locking handle.
Models 974MSD, 975MSD WARNINGS
Dometic marine toilet systems must be installed
according to Dometic’s recommended
procedures. Equipment damage, injury to
personnel or death could result from improper
installation. DOMETIC CORPORATION
ACCEPTS NO RESPONSIBILITY OR LIABILITY
FOR DAMAGETO EQUIPMENT, OR INJURY OR
DEATH TO PERSONNEL THAT MAY RESULT
FROM IMPROPER INSTALLATION, SERVICE
OR OPERATION OF THIS PRODUCT.
WARNING!
HAZARD OF FLOODING –If the toilet
system is connected to ANY through-the-hull
970
SERIES
TOILET
MOUNTING BRACKETS
LOCKING
HANDLE

5
fittings, properly installed seacocks MUST be
installed in all piping connected to through-thehull
fittings. Seacocks MUST be easily accessible to
all users of the toilet system or secondary valves
fitted in hoses where they are easily accessible.
ALWAYS close seacocks when toilet system is not
in use (even if boat is unattended for a brief period.
All valves MUST be full bore valves and marine
quality. Screw-to-close gate valves are not
recommended. Failure to comply can result in
flooding which can cause loss of property and life.
WARNING!
HAZARD OF FLOODING –If toilet is
connected to ANY through-the-hull fittings, ALL
flexible hoses must be of marine sanitation quality
and must be secured to ANY fittings (such as
those at seacock, vented loop or toilet) with two
stainless steel, worm-drive hose band clamps at
each connection. Connections MUST be checked
frequentlyfor integrity.Failuretocomplycan result
in flooding which can cause loss of property and
life.
WARNING!
HAZARD OF FLOODING –If toilet rim
is below the waterline at ANY time (during any
conditions of heel, load or trim) and is connected
to ANY through-the-hull fittings, properly
positioned ventilated (vented) loops MUST be
installed in discharge piping to prevent potential
back siphonage of seawater into the boat. Failure
to do so can result in flooding which can cause
loss of property and life.

6
970
SERIES PORTABLE TOILETS
Hose ID
Discharge
1.5 inch/38 mm
Vent
.625 inch/16 mm
INSTALLATION (continued)
Models 974MSD, 975MSD (continued) A
1. Complete steps 1-6 on page 4. Be sure to allow 2-3/4 in./ 70
mm clearance between back of toilet and wall for MSD fittings,
discharge and vent hose assembly.
2. Remove discharge spout from top of holding tank by turning it
counterclockwise until it unlocks (see illustration A) and pulling
it out of tank.
3. Lubricate two small O-rings on discharge fitting with silicone
grease and attach discharge elbow adapter to discharge
fitting. Secure adapter in place with plastic
tie-wrap (see illustration B).
4. Lubricate large O-ring on discharge fitting and insert discharge
fitting assembly into holding tank. Rotate it so that discharge
and vent fittings point away from tank (see B illustration C).
5. Using hose clamp, attach 1.5-inch (25 mm) ID discharge hose
over end of elbow adapter. Make sure discharge hose(s)
connect securely to all discharge fittings.
6. Using hose clamp, attach 5/8-inch (16 mm) ID vent hose to
vent
fitting.
Make sure vent hose connects MSD
DISCHARGE
FITTING fitting.
C
PLUMBING SPECIFICATIONS
Tie-wrap
Discharge elbow adapter
Discharge fitting
Vent fitting
securely to through-hull vent
HOLDING
TANK
MOUNTING BRACKETS

7
MARINE SANITATION REGULATIONS
All boats with fixed toilets in U.S. waters and in the
waters of some other countries are required to have an
operable, permanently installed marine sanitation device
(MSD). Series 970 MSD models, when permanently
installed in a boat, are holding tank or Type III systems
as defined by the U.S. Coast Guard. Type III systems
permit operation of the toilet without direct discharge of
untreated waste after every flush. Type III systems can
be discharged at marina dockside pump-out stations or,
if in coastal waters, a minimum of three miles offshore.
Overboard discharge capability must remain secured
while within the three-mile limit. If an overboard
discharge pump is activated by a keyed switch in the
toilet compartment, the key must be removed at all times
except when discharge pump is operating and in the
process of vessel operation.
Sewage from any source should not be discharged
directly into our waters. If you are interested in learning
more about this issue, please visit our website at
www.DometicSanitation.com.
This symbol appears on the discharge fitting of MSD
models.
CLEANING AND MAINTENANCE
Cleaning
For most effective cleaning, use SeaLand®Toilet Bowl Cleaner. It’s intended for use
with all Dometic toilets. If you cannot find it in your area, contact Dometic for your
nearest dealer. If it is not available, you can also use most non-abrasive bathroom
and toilet bowl cleaners (Bar Keeper's Friend®spray cleaner, Clorox®toilet bowl
cleaner, SaniFlush®toilet bowl cleaner, etc.). Follow label instructions.
Maintenance SeaLand®Cleaner
16-oz. bottle If
flush handle becomes difficult to pull, lubricate slide valve seals with Part No. 379314016 silicone spray.
WINTERIZING
Use
When using the Dometic portable toilet in cold or winter weather, the addition of nontoxic antifreeze
designated for potable water systems provides safe winter protection. Use amounts specified on
container that are safe for use with 4 gallons (15 l) of water.
NOTE: Never use alcohol-based or automotive-type antifreeze in freshwater systems.
Storage
To store Dometic portable toilet during the winter:
1. Empty freshwater tank and holding tank.
2. Make sure all water is cleared from freshwater tank’s water lines by pressurizing tank and
pushing flush button until no water enters bowl.
A small amount of water may remain in bottom of freshwater tank but will be harmless during winter
storage.)
CONVENIENCE PRODUCTS
These SeaLand products are specially developed to work best in Dometic portable toilets. There are
no better holding tank deodorizers and rapid-dissolving tissues available.

8
970
SERIES PORTABLE TOILETS
SeaLand®SeaLand®
Clean ‘n Green NATURAL
Bowl Cleaner/ Liquid Deodorant
Tank Deodorant 32-oz. bottle 12-2 oz. drop-in
pouches Part No.
Part No. 379512602 379114032
SeaLand®
Rapid-Dissolving
Toilet Tissue
Four 500-sheet rolls
Part No. 379441204
DIMENSIONS
All dimensions may
vary ± 3/8-inch
(10mm).
CUSTOMER SERVICE
There is a strong, worldwide network to assist in
servicing and maintaining your sanitation
system. For the Authorized Service Center near
you, please call from 8:00 a.m. to 5:00 p.m. (ET)
Monday through Friday.
You may also contact or have your local dealer
contact the Parts Distributor nearest you for quick
response to your replacement parts needs. They
carry a complete inventory for the SeaLand
product line.
Telephone: [phone] U.S.A. and Canada Fax: [phone] U.S.A. and Canada
330-496-3211 International 330-496-3220 International
Web site: www.DometicSanitation.com
Toilet
System
Deodorant Charge
Charging
Procedure
Liquid
Granulated
or Toss-in
Packet
Portable
toilet
See
directions
on
deodorant
container
One 2 oz.
(57 g)
packet with
1 pint (.47 l)
of water
Add
directly
to waste
holding
tank
972
, 974, 974MSD
975
, 975MSD,
976

9
ONE-YEAR LIMITED WARRANTY
Dometic Corporation warrants, to the original purchaser only, that this Dometic portable toilet, if used for personal,
family or household-like purposes, and if installed according to Dometic’s recommended procedures, is free from
defects in material and workmanship for a period of one (1) year from the date of purchase.
If this Dometic product is placed in commercial or business use, it will be warranted, to the original purchaser only, to
be free of defects in material and workmanship for a period of ninety (90) days from the date of purchase.
Dometic reserves the right to replace or repair any part of this product that proves, upon inspection by Dometic, to be
defective in material or workmanship. All labor and transportation costs or charges incidental to warranty service are
to be borne by the purchaser-user.
EXCLUSIONS
IN NO EVENT SHALL DOMETIC BE LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES, FOR
DAMAGES RESULTING FROM IMPROPER INSTALLATION, OR FOR DAMAGES CAUSED BY NEGLECT,
ABUSE, ALTERATION, FOREIGN OBJECTS DEPOSITED IN THE TOILET, OR USE OF UNAUTHORIZED
COMPONENTS. THIS INCLUDES FAILURES WHICH MAY RESULT FROM NOT FOLLOWING THE
WINTERIZATION OR CLEANING PROCEDURES AS DESCRIBED IN THIS MANUAL. ALL IMPLIED
WARRANTIES, INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR ANY
PARTICULAR PURPOSE, ARE LIMITED TO A PERIOD OF ONE (1) YEAR FROM DATE OF PURCHASE.
IMPLIED WARRANTIES
No person is authorized to change, add to, or create any warranty or obligation other than that set forth herein. Implied
warranties, including those of merchantability and fitness for a particular purpose, are limited to one (1) year from the
date of purchase for products used for personal, family or household-like purposes, and ninety (90) days from the
date of purchase for products placed in commercial or business use.
OTHER RIGHTS
Some states do not allow limitations on the duration of an implied warranty, and some states do not allow exclusions
or limitations regarding incidental or consequential damages; so, the above limitations may not apply to you. This
warranty gives you specific legal rights, and you may have other rights which vary from state to state. To obtain
warranty service, first contact your local dealer from whom you purchased this product.

Dometic Group is a customer-driven, world-leading provider of leisure products for the caravan, motorhome,
automotive, truck and marine markets. We supply the industry and aftermarket with a complete range of air
conditioners, refrigerators, awnings, cookers, sanitation systems, lighting, mobile power equipment, comfort and
safety solutions, windows, doors and other equipment that make leisure life more comfortable away from home.
Dometic Group supplies a wide range of workshop equipment for service and maintenance of built-in air
conditioning. Dometic Group also provides specially designed refrigerators for hotel rooms and offices, for
transport and storage of medical products, and for storing wine.
Our products are sold in almost 100 countries and are produced mainly in wholly owned production facilities
around the world. The number of employees is 6,000.
El Grupo Dometic es una empresa orientada al cliente, líder mundial en el suministro de productos innovadores
para caravanas, autocaravanas, automóviles, camiones y la industria náutica. Proveemos a fabricantes y a
distribuidores con una completa gama de aires acondicionados, frigoríficos, toldos, cocinas, sistemas
sanitarios, iluminación, equipos móviles de abastecimiento energético, soluciones para mayor seguridad y
confort, ventanas, puertas y demás equipamiento para hacerle la vida fuera del hogar más cómoda.
El Grupo Dometic suministra también equipamiento para talleres para el servicio y mantenimiento de aire
acondicionado integrado. El Grupo Dometic ofrece así mismo frigoríficos específicamente diseñados para
habitaciones de hotel y oficinas, para el transporte y conservación de productos médicos así como bodegas
para vinos.
Nuestros productos se venden en cerca de 100 países y se producen principalmente en nuestras fábricas
ubicadas alrededor del mundo. Contamos con una plantilla de 6.000 empleados.
Le Groupe Dometic, à l’écoute des clients est leader mondial dans la fourniture d’équipements et produits de
confort destinés aux marchés des véhicules de loisirs, de l’automobile, du transport routier et de la plaisance.
Nous offrons aux constructeurs ainsi qu’à la deuxième monte, une gamme complète de climatiseurs,
réfrigérateurs, auvents, produits de cuisson, sanitaires, éclairages, solutions en énergie, produits de confort et
de sécurité, fenêtres, portes et autres équipements qui rendent la vie plus agréable lors des déplacements. Le
Groupe Dometic fournit une gamme complète d’équipements de climatisation destinés aux ateliers de montage
et réparation. Le Groupe Dometic développe aussi des réfrigérateurs pour l’hôtellerie, les bureaux, les
collectivités, ainsi que pour le transport et la conservation des vins et des produits médicaux.
Nos produits sont vendus dans près de 100 pays et fabriqués principalement dans nos propres usines partout
dans le monde. Le Groupe emploie aujourd’hui 6000 personnes.
® Registered; ™ Trademark of Dometic Corporation
® Marca comercial registrada de Dometic Corporation
MD Marques déposées de Dometic Corporation
© Dometic Corporation
600345649 10/10
20
DOMETIC CORPORATION
SANITATION DIVISION
13128 SR 226 | PO BOX 38 | BIG PRAIRIE, OHIO 44611 USA
www.DometicSanitation,com
