MODEL:DSC20
Deluxe Steam Mop
USER MANUAL
Page 2
SAVE THESE INSTRUCTIONS
ØThis product is designed for domestic use only.
ØDo not use outdoors.
ØDo not leave steamer unattended while turned on. Unplug the electrical cord
when not in use and before servicing.
ØDo not allow the steam mop to be used as a toy. Close attention is necessary
when used near children, pets or plants.
ØThe appliance is not intended for use by young children or infirm persons.
ØYoung children should be supervised to ensure that they do not play with the
appliance.
ØNever direct steam towards people, animals, plants, or equipment containing
components.
ØDo not immerse the steamer in water or other liquids.
ØDo not use if cord or plug is damaged. If steamer is not working as it should,
has been dropped, damaged, left outdoors, or immersed in water, return it to
before continuing use. If the supply cord is damaged,
it must be replaced by .
ØDo not pull or carry by cord, use cord as a handle, close a door on the cord,
or pull cord around sharp edges or corners. Keep cord away from heated
surfaces.
ØDo not use extension cords or outlets with inadequate current carrying
capacity.
ØUnplug after use. Do not unplug by pulling on cord. To unplug, grasp the plug,
not the cord.
ØDo not handle plug or steam cleaner with wet hands or operate without shoes.
ØDo not insert any objects into openings. Do not use with any opening
blocked.
ØDo not use without floor cloth in place.
ØDo not use on stairs.
ØStore your steamer indoors in a cool, dry area.
ØKeep your work area well lit.
ØNever put cleaning detergents or chemical into the Steamer. This will make
the operation unsafe and damage the unit.
ØUse only as described in this manual. Use only manufacturer's recommended
accessories.
electrical
a
qualified service engineer
a qualified service engineer
IMPORTANT SAFEGUARDS
When using an electric appliance, basic precautions should always be followed,
including the following:
READ ALL INSTRUCTIONS BEFORE USING THIS STEAM CLEANER
WARNING: DANGER OF SCALDING
To reduce the risk of fire, electric shock, or injury:
Page 3
DESCRIPTION
Thank you and congratulations for choosing the Steam vortex floor mop. This
Steamer is a modern way of cleaning that is effective and far more hygienic
than conventional methods.
The Steamer achieves a high degree of hygienic and degreasing cleansing
power by converting water into steam. it use a micro fibre floor cloth to
enhance absorbency. When contact is made with floor surfaces, dirt and
grime can be eliminated in a matter of seconds.
Since the Steamer uses the active power of steam without the use of
detergents or soap, it is environmentally friendly.
The Steamer does not require distilled water. Residents in areas with hard
water can use distilled water for better performance.
When used correctly the Steamer can kill dust mites and some types of
bacteria, such as salmonella and E-coli.
To disinfect a specific area, position the steamer over the area for a minimum
of eight seconds. The steam temperature will reach approximately 100 C
(212 F). Use this procedure to disinfect floors near: bathroom sanitary ware,
kitchen counters, pet sleeping areas, etc.
This appliance must be grounded. Use only the proper type outlet when
plugging in the appliance, do not attempt to override the earth wire feature.
The following information is provided for service by a qualified electrician only:
Rated voltage:220-240V,50Hz, 1500W.
KEY FEATURES OF Deluxe Steam Mop
A) STEAMER HANDLE
B) TRIGGER
C) QUICK RELEASE CORD WRAP
D) CARRY HANDLE
E) WATER TANK
F) SCALE FILTER
G) STEAMER BODY
H) POWER INDICATING LED
I) LOWER CORD WRAP
J) POWER CORD
K) STEAMER HEAD
L) CLOTH PAD
M) CARPET GLIDER(OPTIONAL ACCESSORY)
Page 4
INSTRUCTIONS FOR USE
The Steamer is designed to thoroughly clean floor surfaces, such as marble,
ceramic, stone, linoleum, sealed hard wood floors and sealed laminate
flooring.
WARNING: ON SURFACES THAT HAVE BEEN TREATED WITH WAX, THE
WAX MAY BE REMOVED BY THE HEAT AND STEAM ACTION. DO NOT USE ON
UNSEALED WOOD FLOORS OR LET UNIT STAND ON ANY WOOD FLOOR FOR
AN EXTENDED PERIOD OF TIME. THIS COULD CAUSE THE WOOD GRAIN TO
RISE. IT IS THEREFORE RECOMMENDED THAT A SAMPLE CLEANSING BE
CARRIED OUT ON AN ISOLATED AREA OF THE FLOOR. IT IS ALSO
RECOMMENDED THAT YOU CHECK THE USE AND CARE INSTRUCTIONS OF
THE SURFACE FROM THE FLOOR MANUFACTURER TO ENSURE SUITABILITY
TO STEAM CLEANING.
For first time use of the machine, please hold onto the switch to allow the water
to get pumped to the steam chamber. The pump will make a louder noise during
this initial operation.
HOW TO ASSEMBLE AND USE
1) Attach steamer head to steamer body.
2) Secure steamer head with the small Philips Head Screw until is fully
tightened.
3) Insert steamer handle down into the steamer body.
4) Screw the Large Philips Head screw through the opening at the back of
steamer body into the rear of the steamer handle and tighten until secure.
5) Place the steamer head in Cloth Pad, and secure the Pad by pulling the
cord while pressing on Toggle.
Page 5
6)Remove Water tank by lifting straight up and away from the unit. Unscrew
the water tank cap and remove the insert assembly. Fill with cool tap water,
and replace the insert assembly tightening the cap. Place the Water Tank on
the unit.
7) Twist the Quick Release Cord Wrap clockwise to unwrap the Power Cord
completely and plug into a power supply.
8) The LED will illuminate when the steamer is connected to power socket.
Please wait for 20 seconds (heat up period) before pressing trigger. The
steam unit is now ready for use.
NOTE: It is recommended that another high wattage appliance is not operated
on the same circuit to avoid a circuit overload.
9) Slowly pass over surface to be cleaned while pressing trigger to emit
steam. It is recommended to sweep or vacuum floor prior using the steamer.
CAUTION: TO SANITIZE AN AREA OF YOUR FLOOR, LEAVE THE
STEAMER OVER THE AREA FOR A MINIMUM OF 8 SECONDS, BUT NO
LONGER THAN 15 SECONDS. LEAVING THE STEAMER STATIONARY
FOR A LONGER PERIOD THAN RECOMMENDED MAY CAUSE THE
BUILD UP OF A PALE RESIDUE. THIS RESIDUE CAN BE REMOVED BY
USING A DECALCIFYING PRODUCT OR WITH A FEW DROPS OF
VINEGAR. (SEE TROUBLESHOOTING GUIDE)
WARNING!
Do not use on velvet or dralon fabrics. If in doubt try on a small area that
does not show and consult fabric manufacturers cleaning instructions.
BAG CONTAINING RUBBER O RINGS.
The two large ORings can be used to replace the two ORings on the
water tank if deemed necessary. Smear a small amount or petroleum
jelly onto the Orings to aid sealing. The small Oring can be used as a
replacement on the scale filter spigot.
Page 6
WARNING: NEVER RUN THE STEAMER WITHOUT WATER. NEVER
DIRECT STEAM AT ANY PERSON OR ANIMAL. USE STEAMER ON
SEALED HARD FLOOR ONLY.
10) When steamer stops emitting steam, after approximately 20 minutes of
use, simply remove the Water tank, refill, and continue cleaning.
11) When you finish your cleaning, unplug Power cord from outlet, empty the
Water tank, carefully remove the Cloth Pad from Steamer Head, wind Power
Cord around the Cord Wrap and store it upright in a dry area or hang by the
storage hook.
CAUTION: THE CLOTH PAD MAY BE VERY HOT.
Instructions for use of Carpet Glider Accessory
Please ensure micro fiber cloth is attached as outlined previously.
Place carpet glider on the floor in an upright position with the triangular flat
surface facing downwards.
Place Floor Steamer head on the glider as illustrated
The Carpet Glider is now ready for use.
IMPORTANT
The Carpet Glider is designed not to be fixed to the floor head for safety
reasons including the preventing burns
The carpet glider is designed for use on soft carpeted areas only. It is not
designed for use on hard floor surfaces.
Page 7
TROUBLESHOOTING GUIDE
CAUTION: PRIOR TO TROUBLESHOOTING ISOLATE THE UNIT BY
REMOVING THE CORD FROM THE POWER SOCKET.
PROBLEM REMEDY
Ensure Steamer power cord is correctly
plugged into power outlet.
Ensure circuit breaker is operational.
Try operating the steamer from another
power outlet.
LED is not on.
Caused by leaving the floor steamer in the
same position for too long.
Can be removed with household white vinegar
or a decalcifying product.
Alternatively reheat the area for one minute
and residue should be removed.
CAUTION: Do not overheat area.
Pale residue left on
the floor
Ensure the water tank has correct level
of water.
CLEANING AND MAINTENANCE
CAUTION: PRIOR TO CLEANING OR MAINTENANCE ISOLATE THE
UNIT BY REMOVING THE CORD FROM THE POWER SOCKET. DO NOT
IMMERSE THE UNIT IN WATER.
1) The micro fibre cloth can be machine washed in hot water and tumbled dry.
2) Wipe the steamer with a soft cloth.
The Steamer should only be used with its own specially developed floor cloths
and Filter (spare Cloth Pads and Filters are available from your retailer)
No Steam
After Sales Service.
Warranty: This product is warranted to the original user for 12 months from
date of purchase free from manufacturing defect at time of purchase. The
product is intended for domestic use. Please keep your receipt or other
evidence of purchase showing date of purchase, as this must be produced in
the event of a claim.
To claim under this warranty, or for other repair or assistance with this product,
please contact Domotec Customer Service Department by phoning 01844
698516.
DOMOTEC HOME APPLIANCES LIMITED. Contact
[email protected] www.innovationideas.co.uk
Tel: 01844 698516
This electrical appliance complies with directive 2002/96/EC (Waste
Electrical and Electronic Equipment----WEEE).
The meaning of the crossed-through waste bin symbol on the appliance
is that the product must be disposed of separately to other household
waste at the end of the useful life of the appliance. The user is
responsible for delivering the appliance to an appropriate collection
centre at that time.
Appropriate separate collection for environment-friendly treatment and
recycling prevents or reduces harmful effect on the environment and
human health. You can obtain information on available collection
services in your area by contacting your local Council waste collection
department, or the retailer from which you bought the appliance.
Domotec Home Appliances is an "Innovation Home Products Ltd"quality
brand.
