RP Baghouse Dust Collector
RP and RPH (All Welded)
Installation and Operation Manual
Installation, Operation, and Service Information
This manual contains specic precautions related to worker safety. The hazard alert image denotes safety
related instructions and warnings in this manual. DO NOT install, operate, or perform maintenance on this
collector until you have read and understood the instructions, precautions and warnings contained within this
manual.
IOM AG8658001 (ENG)
Revision 1
English
Master Language

Donaldson Company, Inc.
2
The Safety Alert Symbol indicates a hazardous situation which, if not avoided could
result in death or serious injury. Obey all safety messages following this symbol to
avoid possible injury or death. The possible hazards are explained in the associated
text messages.
NOTICE indicates a potential situation or practice which is not expected to
result in personal injury, but which if not avoided, may result in damage to
equipment.
This manual has been supplied to assist with the installation, operation and maintenance for
the collector purchased. Please read the manual before installing, operating, or performing
maintenance on the collector as it contains specic precautions for worker safety. It is the
owner’s responsibility to ensure that this manual is available for use by installers, operators and
maintenance personnel that will be working with this collector. This manual is the property of the
owner and should be left with the collector when installation has been completed. DO NOT operate
this collector until you have read and understood the instructions and warnings located in the
installation and operation manual.
For additional copies of this manual, contact Donaldson Torit.
IMPORTANT NOTES

RP_RPH Baghouse
3
Contents
IMPORTANT NOTES......................................................................................................................................................................2
1 Safety Communication..............................................................................................................................................................4
2 Product Description...................................................................................................................................................................6
Standard Equipment...........................................................................................................................................................7
Options andAccessories..................................................................................................................................................10
3 Operation.................................................................................................................................................................................12
Typical Collector Operation Sequence.............................................................................................................................14
4 Product Service.......................................................................................................................................................................15
Filter Replacement...........................................................................................................................................................16
Troubleshooting................................................................................................................................................................20
AppendixA- Installation................................................................................................................................................................22
Installation........................................................................................................................................................................23
Location and Site Selection.......................................................................................................................................23
Delivery and Inspection.............................................................................................................................................23
Lifting Information......................................................................................................................................................24
Support Installation....................................................................................................................................................25
Inlet Scroll Installation............................................................................................................................................25
High Inlet Installation .............................................................................................................................................25
Platform and Ladder Installation................................................................................................................................26
Cleaning MechanismAssembly andAdjustment.......................................................................................................27
PD Pump...................................................................................................................................................................29
Electrical Wiring.........................................................................................................................................................30
Perfect Pulse Controller Installation (PLC)................................................................................................................30
Filter Installation........................................................................................................................................................33
PulseAlignment.........................................................................................................................................................36
Optional Equipment..........................................................................................................................................................37
PlantAir Kit................................................................................................................................................................37
Magnehelic®Gauge ................................................................................................................................................38
Rotary Valve and Transition.......................................................................................................................................39
Explosion Vent...........................................................................................................................................................40
Sprinkler Coupling.....................................................................................................................................................40
Flood Valve Installation..............................................................................................................................................40
Start-up / Commissioning.................................................................................................................................................41
Decommissioning.............................................................................................................................................................42
Product Information..........................................................................................................................................................43
Service Notes...................................................................................................................................................................44
Donaldson IndustrialAir Filtration Warranty..............................................................................................................................47
Magnehelic®is a registered trademark of Dwyer Instruments, Inc.

4
Donaldson Company, Inc.
Improper operation of dust collectors and/or dust control systems may contribute to conditions in a work area or
facility which could result in severe personal injury, and product or property damage.All dust collection equipment
should be used only for its intended purpose and should be properly selected and sized for its intended use.
Process owners have important responsibilities relating to identifying and addressing potential hazards in their
processes. When the potential for handling combustible dust exists within a process the process owner should
include combustion hazards in their risk management activities and should comply with applicable codes and
standards related to combustible dust.
Electrical installation must be performed by a qualied electrician.
This equipment is not designed to support site ducts, piping, or electrical services.All ducts, piping, or electrical
services must be adequately supported to prevent injury and/or property damage.
Site selection must account for wind, seismic zone, and other load conditions.
Equipment may reach peak sound pressure levels above 80 dB (A). Noise levels should be considered when
selecting collector location.
Most dusts present safety and health hazards that require precautions. Wear eye, respiratory, head and other
protection equipment suitable for the type of dust.
Some components may be heavier than they appear. Use appropriate lifting methods to avoid personal injury and/or
property damage.
1 Safety Communication

RP_RPH Baghouse
5
Combustible Dust Hazards
Among other considerations, the current NFPAstandards require owners whose processes involve potentially combustible
materials to have a current Dust HazardAnalysis, which can serve as the foundation for their process hazard mitigation strategy.
Mitigation may include but is not limited to:
• Prevention of all ignition sources from entering any dust collection equipment.
• Selection and implementation of re and explosion mitigation, suppression, and isolation strategies appropriate for the
risks in their process.
• Development and use of work practices to maintain safe operating conditions, and to ensure combustible dust does not
accumulate within their plant or process equipment.
Donaldson designs, manufactures, and sells industrial air ltration products for a wide variety of applications. Some applications
may include processes or materials with inherent re and explosion hazards. Donaldson is neither an expert nor a certied
consultant in re, spark, or explosion detection, suppression, or control. Donaldson does not provide engineering consulting
services related to process or dust hazard analyses, or code and standard compliance. Complying with applicable codes and
standards and managing the risks associated with the process or materials remains the responsibility of the process owner/
operator. Donaldson may provide referrals to consultants, suppliers of equipment or services related to the detection and/
or mitigation of sparks, res and/or explosions, but Donaldson does not assume responsibility for any such referrals, nor does
Donaldson assume any liability for the tness of a mitigation strategy or product for a particular installation or application. The
process owner’s nal selection of dust collectors and risk mitigation strategies should be based on the outcome of a Dust Hazard /
Process HazardAnalysis performed by the process owner.Although early engagement of a dust collector supplier provides helpful
insights on the availability and features of various products, process owners should consult with a combustible dust expert and/or a
process safety expert before making actual product and mitigation strategy selections.
Donaldson recommends that all industrial air ltration system designs be reviewed and approved by an expert consultant who is
responsible for the integrity of the system design and compliance with applicable codes and standards. It is the process owner’s
responsibility to understand the risks in their process and mitigate those risks in accordance with all applicable laws, regulations
and standards, including those published by the NFPA. Donaldson also recommends that proper maintenance and housekeeping
procedures and work practices be evaluated, developed, and followed to maintain any industrial air ltration products in safe
operating condition.
Many factors beyond the control of Donaldson can affect the use and performance of Donaldson products in a particular
application, including the conditions under which the product is used. Since these factors are uniquely within the user’s knowledge
and control, it is essential the user evaluate the Donaldson products to determine whether the product is t for the particular
purpose and suitable for the user’s application. All products, product specications, and data (airow, capacity, dimensions, or
availability) are subject to change without notice, and may vary by region or country.

6
Donaldson Company, Inc.
The Rugged Pleat (RP) Baghouse is a continuous duty dust collector with pleated lters designed to handle applications with
heavy dust loads. Continuous-duty means the lters can be pulse cleaned on-line without interrupting airow through the collector.
The cleaning system logic monitors the arm location and ensures pulses are delivered directly on the centerline of lters to
optimize cleaning with all lters being cleaned every four minutes.
The cylindrical collector housing design features an all-welded construction in standard sizes from 70 to 272 lter with 60-inch
pleated bags available in various media types. The collector housing design can include a SuperSep™ low body inlet or an upper
body radial high inlet with replaceable wear inserts.
The SuperSep™ inlets are typically used for heavy non-abrasive dust handling applications. These inlet styles allow the majority
of the incoming dust to cyclonically separate. The heavier dust is directed downward into the hopper while the lighter dust is
passed through air straightening vanes to evenly distribute the air and entrained dusts over the lters for nal separation.
The upper body radial style high inlet is typically used on highly abrasive dust type applications. This style of inlet is located in
the lter housing section below the tubesheet and directs the incoming dust particles into a replaceable impaction zone then
downward around the lters and into the hopper. This ow path reduces abrasion and assists the cleaning system by supporting
an airow pattern that encourages the dislodged dust pulsed off the lters to move downward into the hopper. Bafes in the inlet
keep dusts from directly abrading on the lter bodies.
RP Baghouses come standard with a walk-in Clean-Air Plenum (CAP). Filters, pulse and drive components can be serviced on
the clean air side of the collector within the walk-in plenum.Access to the CleanAir Plenum is provided by an optional ladder and
platform system.
The RP Baghouse collector is ideal for applications in the woodworking, grain and mining industries where it effectively handles
high-volume, high dust-load applications.Additional applications include cement, chemical and food processing applications.
The RP Baghouse is typically used in applications between 10,000-55,000 cfm.
Sizes are available for lower airow applications with any of the following conditions or requirements:
• Heavy dust load
• No compressed air available
• Around collector required for sanitary reasons
• High pressure or vacuum requirement
• Arequirement for a single discharge hopper.
Operations involving higher temperatures, humidity, or air stream chemistry may require customized collector design options.
Contact Donaldson Torit for design assistance.
2 Product Description
Intended Use
Rating and Specication Information
General rating and specication information can be found in the product literature provided with the collector and is available on the
Donaldson website. For specic load values for a collector, see the Specication Control Drawing shipped with the collector.

RP_RPH Baghouse
7
Standard Equipment
All welded collectors can be lifted from the truck to the prepared site.
Platform and Ladder
Access ladder to the platform and door to enter the Clean Air Plenum for maintenance such as lter changes, mechanical work on
the pulse arm and drive and pulse system, and electrical work on the pulse system.
Hopper Access Cover
Access cover which when removed allows access to the DirtyAir Plenum (DAP).
SuperSep™ Inlet
Atangentially oriented inlet where the dirty air enters the DirtyAir Plenum. Various features in the inlet section promote the dropout
of dust through cyclonic action and bafing to reduce dust loading to the lters and features above the inlet reduce air rotation or
spin to improve the distribution of air to the lters.
High Inlet
Anon-cyclonic inlet designed for abrasive dusts.
Outlet
Located on the CleanAir Plenum and where the clean air exits the collector and typically is routed to the fan.
Hopper Outlet
The hopper outlet is a singular outlet on the DirtyAir Plenum where the separated dust exits the collector and is routed to be
disposed of via bin, pneumatic conveyor, screw conveyor, or other means.Arotary airlock is typically used to isolate the dust
collection system from the dust disposal system.
Hopper Transition
Atransition from the typical outlet to a variety of dust disposal device options available through Donaldson or other Manufacturers.
Collector Body
The combination of the Dirty and CleanAir plenums represents the total collector body.
Leg Pack
Leg structure supports the collector body at an elevation to accommodate various dust disposal devices and systems which can be
congured to meet customer needs.
Positive Displacement (PD) Pump
Positive Displacement air pump which supplies air to the pulse system typically at 7.5psig. Using a PD pump for the pulse system
reduces the cost of the compressed air and reduces issues related to remote supplied compressed air dew points and supply
issues.
CAP
Clean Air Plenum where ltered air enters after passing through the lters as it travels to the outlet.
Cleaning System
Single pulse valve system with a rotary arm that pivots around the center of the collector efciently allowing for the cleaning of
all lters directly on the centerline of each lter. The single valve design reduces the maintenance typical of multi valve and multi
bank systems.

8
Donaldson Company, Inc.
Tubesheet
Metal panel the lters are sealed against to separate the Dirty Air and Clean Air Plenums of the collector. Through holes are cut to
mount lters.
Spoke
Radial line from the center of the tubesheet through lter openings at the outer most ring. All of the lters fall on these radial lines
allowing the lters to be pulsed.
Filter Assembly
Includes pleated lter media attached to a soft polymer cuff and/or metal pan that mounts into the tubesheet with a radial seal
and an expanding insert that presses in and locks down to seal the lter assembly against dust bypass. The lter assembly
incorporates both a venturi geometry and tertiary holes to improve the pulse cleaning characteristics.
Clean Air Plenum (CAP) Door
Access door from the platform to allow entry into the CleanAir Plenum for service and inspection.
Dirty Air Plenum (DAP)
DirtyAir Plenum where dust laden process air enters the body of the dust collector through the inlet.As air enters it goes through a
preseparation stage and then airow straightening before it reaches the lters. This allows the majority of the dust to drop out into
the hopper and the airow to be evened out before it gets to the lters.
Hopper
Discharge point for dust that has been preseparated and pulsed off of the lters.
Filter
Consists of a soft polymer cuff and/or metal pan, an internal structure, pleated lter media, and an end cap of either polymer or a
potted metal cap. Filters dust from the airstream on the outside of the lter before entering the DAP.
Reservoir Tank
Central tank which holds compressed air supplied by PD pump for pulsing. The tank is the mounting point for the drive package
and pulsing components.
Arm Drive
Consists of a gearbox, motor, tensioner, sprockets, and chain. This rotates the arm around the centerline of the collector to
distribute the pulses around the tubesheet.
Arm Assembly
A “Tee” or “L” shaped assembly with nozzles along the bottom to pulse air directly into the centerline of the lter openings. The Arm
Assembly rotates around the centerline of the collector.
H Frame
An “H” shaped structure that supports the pulse system.

RP_RPH Baghouse
9
Pulse Solenoid
This converts an electrical signal from the timer to the mechanical release of air from the secondary diaphragm for a prescribed
duration during each pulse.
Diaphragm Primary
The large diaphragm mounted directly to the air tank under the large cast aluminum cap. This is actuated by the secondary
diaphragm and releases compressed air to the arm assembly and pulse the lters.
Diaphragm Secondary
The small diaphragm mounted between the solenoid and primary diaphragm. This is actuated by the solenoid and triggers release
of compressed air by the primary diaphragm.
Sensor Switch and Target
Asensor switch and targeting magnet that work in combination to provide the controller both arm position and speed to ensure
proper pulse alignment and proper timing between pulses.
Cleaning Logic
Using signals from the Sensor Switch and Target, the Cleaning Logic Controller sets the time delay between pulses and adjusts
pulse duration to ensure all lters are pulsed on their centerline within four minutes, while avoiding situations where a lter is
cleaned adjacent to a recently cleaned lter.
Helix
Spiral strip starting at the inlet and spiraling down to the top of the hopper at 180 deg. Helps encourage small particulate
preseparation and prevent dust migration upward towards the lter section.
Strakes
Two at perpendicular surfaces in the lower hopper that disrupt the cyclonic action to improve dropout and terminate the cyclonic
action before entering the dust disposal system.
EvenFlow Ba󰀪es™
Engineered vanes which reduce the cyclonic swirl of the airow and provide more uniform ow into the Dirty Air Plenum section
containing the lters.

10
Donaldson Company, Inc.
Options and Accessories
Explosion Vent
Panel designed to vent gasses to avoid catastrophic failure in the event of a pressure upset condition.
Magnehelic®Gauge
Simple mechanical gauges that measure differential pressure. May be passive mechanical versions or digital, may include
electrical contacts and user adjustable setpoints.
Optional RP Control Panels
These options cover the sequencing of the related motors. They also provide a HMI Interface.
Optional Control Panels PerfectPulse™ Cleaning
System RP Controller RP Control Panel
Stand-alone Controller for Entire Collector X
Integrated Controller for Remote Collectors X
NEMA 12 Enclosure X X
HMI Interface X X
PLC Controller X X X
Pulse Logic X X X
Motor Starters X
VFD X
Motor and Device Monitoring X X
Sensor Switch and Target X X X
Customer Supplied Control System X
Customer Supplied Motor Starters X

RP_RPH Baghouse
11
Hopper Transition
Atransition from the standard round opening to optional dust disposal accessories.
Live Bottom Hopper
Short section of screw conveyor with a round to rectangle transition that handles tough dusts that bridge easily.
Rotary Airlock (RAL)
Used to isolate the dust collection system pressure from atmosphere. Options include exible wipers, NFPA rated valves,
Pneumatic conveying ready valves, and high clearance valves for tough to handle dusts.
Screw Conveyor
Can be mounted directly to the hopper outlet with the addition of an RALat the discharge. Useful for loading bulk containers while
maintaining a shorter overall height.
Sprinkler Coupling
Can be used by the customer if adding sprinklers is desired.
Flood Valve
An optional means to allow water evacuation. Some method of water evacuation must be provided if a water based extinguishing
system is installed on the collector..
Plant Air Kit
Used instead of PD pump when use of plant compressed air is preferred.

12
Donaldson Company, Inc.
3 Operation
Electrical work during installation, service or maintenance must be performed by a qualied electrician and comply
with all applicable national and local codes.
Turn power off and lock out all power before performing service or maintenance work.
Turn compressed air supply off, bleed and lock out lines before performing service or maintenance work.
Check that the collector is clear and free of all debris before starting.
Do not install in classied hazardous atmospheres without an enclosure rated for the application.
The RP Baghouse cleaning system consists of two opposing arms which rotates around the center of the collectors CAP. This
system uses medium pressure air (7.5 PSI) generated by a PD pump typically located at ground level to charge a holding tank.
The system has a 2 stage diaphragm valve set to provide the pulse air when a solenoid is activated.
The solenoid activation is controlled by a pulse controller which calculates the position of the arm using a proprietary system to
determine the position of the arm based on a xed sensor. This allows the pulse to be oriented directly into the centerline of the
lter to deliver the most effective pulse possible all while properly distributing the pulses around the entirety of the tubesheet to
eliminate wasted pulses. Refer toAppendixAfor pulse system alignment instructions.
Tangential Inlet Operation
During normal operation of an RP Baghouse with a tangential inlet, dust-laden air enters the dirty-air inlet.The tangential inlet
induces a cyclonic action which pre-seperates the majority of the particulate from the dirty airstream. During this process the
dirty air passes by the helix and hopper strakes causing further dropout of particulate. As the airow transitions upward within the
collector, the airow straighteners reduce the cyclonic action, straightening and distributing the airow to the lter elements above.
The remaining particulate is separated from the airstream by the pleated lter bags. The clean ltered air continues on through the
CAP and is either exhausted to the ambient air or returned to the facility. The dust left behind forms a “cake” on the outside of the
lters.
As the dust “cake” becomes thicker and less permeable, the pressure drop across the lter rises. To reduce and maintain pressure
drop across the lter bags, a pulse cleaning system is employed.
High Inlet Operation
During normal operation of an RP Baghouse with a high inlet, dust-laden air enters the dirty-air inlet.The high inlet section
contains bafes that prevent the abrasion of lters by directing the incoming dust particles into a replaceable impaction zone then
downward around the lters and into the hopper. This ow path reduces abrasion and assists the cleaning system by supporting
an airow pattern that encourages the dust dislodged when the lter is pulsed to move downward into the hopper. Bafes in the
inlet keep dusts from directly abrading on the lter bodies.

RP_RPH Baghouse
13
Collector Operation
SuperSep™
inlet system
dirty-air inlet
dirty-air inlet
PD pump PD pump
clean-air outlet
pleated
lter access
door
pleated lter
EvenFlow™
bafes
helix
hopper pleated
lter
hopper
clean-air
outlet
high body
inlet
pleated
lter access
door
PerfectPulse™
cleaning system
PerfectPulse™
cleaning system
Normal Operation with SuperSep Inlet Normal Operation with High Body Inlet

14
Donaldson Company, Inc.
Typical Collector Operation Sequence
Start-Up
Verify the process system is ready for operation and all alarm conditions are cleared prior to starting the collector.
1. Start waste dust systems.
a. Pneumatic conveying, compactor, RAL or screw conveyor
b. Look for upset conditions upon start/waiting to clear/monitor for dust accumulation
2. Start pulse system.
a. Cleaning arm drive
b. Pulse logic
c. PD pump
3. Start main blower.
Shut-Down
1. Shut off main blower.
Slowly ramping down airow will allow accumulated dust to drop into the hopper gradually while the
collector continues cleaning. An abrupt reduction in airow may result in one large release of dust from
the lters which may plug the hopper discharge.
2. Stop pulse system (pulse with no airow for a short period of time in order to get better dust discharge and to reduce dust
buildup prior to restarting system).
3. Stop waste dust system once system is clear (continue running until no additional material discharge is noted).
*Reference control panel IOM for control specic startup instructions.
*

RP_RPH Baghouse
15
4 Product Service
1. Monitor the physical condition of the collector and repair or replace any damaged components.
Routine inspections will minimize downtime and maintain optimum system performance. This is particularly important on
continuous-duty applications.
2. Monitor pressure drop across lters.
3. Abnormal changes in pressure drop may indicate a change in operating conditions and possibly a fault to be corrected.
Check the following items at the recommended intervals shown below.
DAILY-WEEKLY
Item Typical Condition
Pressure Drop Between 1-in and 6-in
PD Pump Pressure Peak should be 7.5PSI
PD Pump Lubrication Level Above line in sight glass
PD Pump Filter No heavy soiling noted
CleanAir Outlet No visible dust discharge
MONTHLY - QUARTERLY
Item Typical Condition
CAP Condition Interior is clean and all lters seated
Tangential inlet No signicant wear spots
High Inlet bafe No signicant wear spots
Solenoid and diaphragm Pulse operates periodically without squeal and strong pulse tone
Access door seals Door seals intact, remains pliable, with no indication of air bypass
Cleaning arm drive Operates smoothly with no noise
Cleaning arm drive chain Clean and properly tensioned
PD pump drive Belts are intact and don’t squeal
Arm gearbox oil Gearbox oil level is at the proper level and not excessively dirty
Explosion vents Vents are intact and not leaking
RotaryAirlock (RAL) or discharge device No air bypass during operation and no unusual noises
Motor rotation direction Matches indicating arrows
If any items are not matching typical condition refer to the troubleshooting and service section. This list is not an all inclusive preventative maintenance schedule and site
specic equipment, regulations and conditions. This list is only meant to be an end user reference to develop a site specic preventative maintenance schedule.
During service activities there is some potential for exposure to the dust in the collector. Most dusts present safety
and health hazards that require precautions. Wear eye, respiratory, head and other protection equipment suitable for
the type of dust when performing any service activities.
Use appropriate access equipment and procedures. Note the standard collector is not equipped with access
platforms unless noted on the specication drawings.
LOCK-OUT all energy sources prior to performing any service or maintenance on the equipment.
Electrical service or maintenance work must be performed by a qualied electrician and comply with all applicable
national and local codes.

16
Donaldson Company, Inc.
1. Grasp lter insert and pull to remove.
Most dusts present safety and health hazards that require precautions. Wear eye, respiratory, head and other
protection equipment suitable for the type of dust.
Use proper safety and protective equipment when removing contaminants and lters.
Dirty lters may be heavier than they appear. Use appropriate lifting methods to avoid personal injury and/ or property
damage.
Turn power off and lock out all power before performing service or maintenance work.
Do not operate with missing or damaged lters
Filter Replacement
2. Grab the corner of the lter ange and pull to release one side.
3. Once the one side is released, the lter may need to be tipped back to the other side to release.
These photos are with a clean system where no dust was present. Wear proper PPE for dust present on the lters.

RP_RPH Baghouse
17
4. Once released the lter can be removed and disposed of properly.
5. Slowly lower the lter through the tubesheet hole.
6. Gently seat the lter ange against the tubesheet.

18
Donaldson Company, Inc.
7. Visually inspect the insert and replace if wear or damage are noted.
8. Tip one side of the insert into the lter opening.
9. Push down on the other side of the insert to seat it against the lter ange.
10. Once all parts are seated, the lter is installed properly.

RP_RPH Baghouse
19
11. If the insert is not properly seated (see below), press down on the dislodged portion. The insert may need to be taken out and
put back in.
12. If the lter is not seated completely against the tubesheet (see below), the insert will need to be taken out and the lter pressed
down. Once the lter is properly seated, the insert can be reinstalled.
X
X
ü
X
X

20
Donaldson Company, Inc.
Problem Probable Cause Remedy
Fan blower and motor
do not start Improper motor wire size Rewire using the correct wire gauge as specied by
national and local codes.
Not wired correctly Check and correct motor wiring for supply voltage. See
motor manufacturer's wiring diagram. Follow wiring
diagram and the National Electric Code.
Collector not wired for available
voltage Correct wiring for proper supply voltage.
Input circuit down Check power supply to motor circuit on all leads.
Electrical supply circuit down Check power supply circuit for proper voltage. Check for
fuse or circuit breaker fault. Replace as necessary.
Damaged motor Replace damaged motor.
Fan blower and motor
start, but do not stay
running
Incorrect motor starter installed Check for proper motor starter and replace if necessary.
Access doors are open or not
closed tight Close and tighten access doors. See Filter Replacement.
Hopper discharge open Check that dust container is installed and properly sealed.
Damper control not adjusted
properly Check airow in duct. Adjust damper control until proper airow is achieved and the blower motor’s amp draw is
within the manufacturer’s rated amps.
Electrical circuit overload Check that the power supply circuit has sufcient power to
run all equipment.
Clean-air outlet
discharging dust Filters not installed correctly See Filter Installation.
Filter(s) damaged or worn Replace lters as necessary. Use only genuine Donaldson
replacement parts. See Filter Replacement.
Insu󰀩cient airow Fan rotation backwards Proper fan rotation is clockwise when viewed from the
motor side or counterclockwise when viewed through the
inlet cone. See Preliminary Start-Up Check.
Access doors open or not closed
tight Check that all access doors are in place and secured. Check that the hopper discharge opening is sealed and
that dust container is installed correctly.
Fan exhaust area restricted Check fan exhaust area for obstructions. Remove material
or debris. Adjust damper ow control.
Filters need replacement Remove and replace using genuine Donaldson
replacement lters. See Filter Replacement.
Troubleshooting
