Donaldson Torit TBV-2 User manual

IOM 4939000
Revision 6
Installation
and Operation Manual
Bin Vent
Models TBV-2, TBV-4, and TBV-6
Installation,
Operation, and
Service Information
This is the safety alert
symbol. It is used to
alert you to potential personal
injury hazards. Obey all safety
messages that follow this symbol to
avoid possible injury or death.
Illustrations are for reference only
as actual product may vary. This manual is property of the owner. Leave with the unit when set-up and start-
up are complete. Donaldson Company reserves the right to change design and
specifications without prior notice.

Donaldson Company, Inc.
2
Combustible materials such as buffing lint, paper, wood, metal dusts, weld fume, or flammable coolants
or solvents represent potential fire and/or explosion hazards. Use special care when selecting, installing,
and operating all dust, fume, or mist collection equipment when such combustible materials may be
present in order to protect workers and property from serious injury or damage due to a fire and/or
explosion.
Consult and comply with all National and Local Codes related to fire and/or explosion properties of
combustible materials when determining the location and operation of all dust, fume, or mist collection
equipment.
When combustible materials are present you must consult with an expert in fire extinguishing and/or
explosion protection systems, who is also familiar with the local codes, for support and guidance on the
selection and installation of an appropriate fire and/or explosion protection system.
DO NOT allow sparks, cigarettes or other burning objects to enter the hood or duct of any dust, fume,
or mist collection equipment as these may initiate a fire or explosion of any combustible materials
accumulated in the collector.
Improper operation of a dust, fume, or mist control system may contribute to conditions in the work area
or facility that could result in severe personal injury and product or property damage. Check that all
dust, fume, or mist collection equipment is properly selected, installed, and operated for its intended use.
This manual contains specific precautionary statements relative to worker safety. Read this manual
thoroughly and comply as directed. Instruct all personnel on the safe use and maintenance procedures related
to this equipment. Discuss any questions on the application, use, or maintenance of this equipment with a
Donaldson Torit representative.
For optimum collector performance, use only Donaldson Torit replacement parts.
Application of Fume Control Equipment

Bin Vent, Models TBV-2, TBV-4, and TBV-6
3
Magnehelic and Photohelic are registered trademarks
of Dwyer®Instruments, Inc.
Data Sheet
Model Number _______________________________ Serial Number__________________________________
Ship Date ____________________________________ Installation Date________________________________
Customer Name______________________________________________________________________________
Address _____________________________________________________________________________
_____________________________________________________________________________
Filter Type _____________________________________________________________________________
Accessories _____________________________________________________________________________
NOTICE
DANGER indicates a hazardous situation which, if not avoided, will result in
death or serious injury.
WARNING indicates a hazardous situation which, if not avoided, could result in
death or serious injury.
CAUTION, used with the safety alert symbol, indicates a hazardous situation
which, if not avoided, could result in minor or moderate injury.
NOTICE is used to address practices not related to personal injury.
Contents
Data Sheet...............................................................3
Description..............................................................4
Purpose and Intended Use .......................................5
Operation................................................................6
Filter Cleaning...................................................... 6
Inspection on Arrival...............................................7
Installation Codes and Procedures...........................7
Installation..............................................................7
Site Selection ........................................................7
Unit Location ....................................................... 7
Rigging Instructions ................................................8
Suggested Tools & Equipment..............................8
Hoisting Information ...........................................8
Standard Equipment................................................9
Ship Loose Items .................................................. 9
Pre-Installation ....................................................9
Filter Installation for TBV Insertable..................10
Solid-State Timer Installation .............................12
Compressed Air Installation ............................... 14
Magnehelic Gauge .............................................. 16
Preliminary Start-Up Check...................................18
Start-Up ................................................................18
Service Information...............................................18
Operational Checklist ........................................18
Filter Element Removal ...................................... 18
Filter Element Installation .....................................20
Optional Equipment..............................................21
Photohelic Gauge ...............................................21
Delta P Control ....................................................23
Description......................................................... 23
Operation........................................................... 23
Delta P Plus Control..............................................24
Operation........................................................... 24
Power Pack Assembly......................................... 25
Weather Hood ...................................................27
Exhaust Damper ................................................27
Plenum Silencer .................................................. 28
Troubleshooting....................................................29

Donaldson Company, Inc.
4
TBV Internal View
roof panel/door
outlet hole/power hole
blower pack
with motor
venturi
hold down collar
hand knob
filter hold
down collar
filter element
flange
solenoid valve
enclosure
air manifold
assembly
air valve
tool-less quick
release pipe coupler
lifting lugs
t-handle lifting latch
slide bar linkage
roof support
blow pipe
Description
Torit Bin Vents (TBVs) apply cartridge technology
to a continuous-duty dust collection system,
offering significant advantages. They are designed
specifically for silo, storage bin and conveyor
transfer applications. Standard models include both
the Insertable-mounted cabinet and the Plenum-
mounted cabinet, with each available in three filter
configurations: a two (2) filter unit (TBV-2), a
four (4) filter unit (TBV-4) and a six (6) filter unit
(TBV-6). All standard TBVs include Donaldson
Torit® Ultra-Web® filters with continuous air
pulse-jet cleaning. This provides for a highly efficient
self-cleaning filtration system ensuring long filter life
and a reduced maintenance schedule. The TBV was
designed for simple filter service and maintenance
with a “tool-less” approach. The unit incorporates
top-side (clean air plenum) filter cartridge removal
and replacement, making it unnecessary to enter
the silo or storage container. No tools are needed
for the quick release pipe couplers when replacing
filters. This reduces the risk of contamination of
the customer product stored in the silo/storage
container.
The filter elements in the TBV are the key to
efficient, long life operation. With the high efficiency
filtration from this dust collector, exhaust air can
often be recirculated to the factory. To ensure high
efficiency operation, always use genuine Torit-Built®
replacement filter elements for your TBV.

Bin Vent, Models TBV-2, TBV-4, and TBV-6
5
Purpose and Intended Use
Misuse or modification of
this equipment may result in
personal injury.
Do not misuse or modify.
The Torit Bin Vent is used to vent displaced air
and contain valuable and/or harmful products
in bins or silos. As materials are conveyed to a
bin by various means (mechanical, gravity, and
pneumatic), air inside the enclosed bin is displaced.
The process by which excess air is removed is called
bin venting. The most common industries for the
TBV are food/agriculture such as grain and process/
manufacturing such as chemical/pharmaceutical,
cement, wood, foundries (clay, sand, additives), and
waste treatment. The most common dusts are lime,
cement, carbon, plastics, and wood.
Combustible materials such as buffing lint, paper, wood, metal dusts, weld fume, or
flammable coolants or solvents represent potential fire and/or explosion hazards. Use
special care when selecting, installing, and operating all dust, fume, or mist collection equipment
when such combustible materials may be present in order to protect workers and property from
serious injury or damage due to a fire and/or explosion.
Consult and comply with all National and Local Codes related to fire and/or explosion properties
of combustible materials when determining the location and operation of all dust, fume, or mist
collection equipment.
Standard Donaldson Torit equipment is not equipped with fire extinguishing or explosion protection
systems.

Donaldson Company, Inc.
6
Unit Operation (Model TBV-4 shown)
Operation
During normal operation, contaminated or dust-
laden air enters the TBV through the cabinet opening
at the bottom of the unit, which is fastened to the
silo or storage container. The dust-laden incoming
air is collected on the outside surface of the filter
elements. As the dust cake collects on the outside
filter surface, gravity and air pulse-jet cleaning force
the dust to drop back into the storage bin. The
clean, filtered air flows up through the center of the
filter elements and passes through the venturi into
the clean air plenum, where it finally exits through
the clean air outlet. The clean air outlet can be
configured with a blower fan or a weather hood
side-mounted to the rear of the unit. Another option,
depending on the customer product being stored, is
to recirculate the clean air back into the work area
via duct work.
Filter Cleaning
The filter elements are cleaned automatically and
continuously during operation. Only a few filters
are off-line for pulse-jet cleaning at any given time.
A solid state timer controls the cycle of pulse-jet
cleaning. Solenoid-operated diaphragm valves open
in sequence, introducing jets of high pressure air into
venturis located above the filter element cartridges.
The resulting reverse airflow initiates the cleaning
cycle, which dislodges the dust accumulated on the
outside of the filter media, while the remaining filter
elements in the unit continue the filtration process.
... .. ..... ..... ....
..... ..... ... ......
... .. .. ... ... .. .... ..
.. .. ... .. .... .. ... ....
... .. .... ... .... .. .....
...... .... ... .. ... .... ...
.. .... ... .... .... .... ..
... . . ... ...
... . ..... ..
..... ... ...
.... .. . ... .....
... ... .... ..
.. ...... ... .. ... .... ... .. ..
.... ... .. ... .. .... . .....
... . ..... ...... .. ... ...
..... .... ..... .. .. ......
...... .... ...... .. .. ...
.... ..... .. ... .. ...
.. .. ....... .. . .... ...
... .... ... .. ... ...
... ... .... ...
... .. ..... ..... ....
..... ..... ... ......
... .. .. ... ... .. .... ..
.. .. ... .. .... .. ... ....
... .. .... ... .... .. .....
...... .... ... .. ... .... ...
.. .... ... .... .... .... ..
... . . ... ...
... . ..... ..
..... ... ...
.... .. . ... .....
... ... .... ..
.. ...... ... .. ... .... ... .. ..
.... ... .. ... .. .... . .....
... . ..... ...... .. ... ...
..... .... ..... .. .. ......
...... .... ...... .. .. ...
.... ..... .. ... .. ...
.. .. ....... .. . .... ...
... .... ... .. ... ...
... ... .... ...
... .. ..... ..... ....
..... ..... ... ......
... .. .. ... ... .. .... ..
.. .. ... .. .... .. ... ....
... .. .... ... .... .. .....
...... .... ... .. ... .... ...
.. .... ... .... .... .... ..
... . . ... ...
... . ..... ..
..... ... ...
.... .. . ... .....
... ... .... ..
.. ...... ... .. ... .... ... .. ..
.... ... .. ... .. .... . .....
... . ..... ...... .. ... ...
..... .... ..... .. .. ......
...... .... ...... .. .. ...
.... ..... .. ... .. ...
.. .. ....... .. . .... ...
... .... ... .. ... ...
... ... .... ...
... .. ..... ..... ....
..... ..... ... ......
... .. .. ... ... .. .... ..
.. .. ... .. .... .. ... ....
... .. .... ... .... .. .....
...... .... ... .. ... .... ...
.. .... ... .... .... .... ..
... . . ... ...
... . ..... ..
..... ... ...
.... .. . ... .....
... ... .... ..
.. ...... ... .. ... .... ... .. ..
.... ... .. ... .. .... . .....
... . ..... ...... .. ... ...
..... .... ..... .. .. ......
...... .... ...... .. .. ...
.... ..... .. ... .. ...
.. .. ....... .. . .... ...
... .... ... .. ... ...
... ... .... ...
clean air plenum
dust falls back into silo / storage bin
venturi
blow pipe
high pressure air
for pulse cleaning
diaphragm
air valve
air manifold
assembly
solenoid valve
enclosure
filter element
dust / particulate
laden air
(dust) dirty air inlet
clean air
outlet / vent

Bin Vent, Models TBV-2, TBV-4, and TBV-6
7
Inspection on Arrival
1. Inspect unit on delivery.
2. Report any damage to the delivery carrier.
3. Request a written inspection report from the
Claims Inspector to substantiate claim.
4. File claims with the delivery carrier.
5. Compare unit received with description of
product ordered.
6. Report incomplete shipments to the delivery
carrier and your Donaldson representative.
7. Remove crates and shipping straps. Remove
loose components and accessory packages before
lifting unit from truck.
Installation Codes and Procedures
OSHA may have requirements
regarding recirculating filtered
air in your facility. Consult with the
appropriate local authorities to ensure
compliance with all codes regarding
recirculating filtered air.
Safe and efficient operation of the unit depends on
proper installation.
Authorities with jurisdiction should be consulted
before installing to verify local codes and installation
procedures. In the absence of such codes, install unit
according to the National Electric Code, NFPA No.
70-latest edition.
A qualified installation and service agent must
complete installation and service of this equipment.
All shipping materials, including shipping covers,
must be removed from the unit prior to, or during
unit installation.
Failure to remove shipping
materials from the unit will
compromise unit performance.
NOTICE
Installation
Site Selection
The unit can be located in the top of storage silos
and bins, or integrated into hoods for material
handling equipment such as belt conveyors and
bucket elevators or process equipment such as
blenders and crushers.
Wind, seismic zone, and other live-load conditions
must be considered when designing the mounting
flange and hood supports for the collector. Reference
the Rating and Specification Information section.
Provide appropriate clearance from heat sources and
interference with utilities.
Unit Location
When hazardous conditions or materials are present,
consult with local authorities for the proper location
of the unit.
Mounting flanges and hood supports must be
capable of supporting the entire weight of the unit
plus the weight of the collected material, piping, and
ductwork. Reference the Rating and Specification
Information.
Locate the unit to ensure the shortest and straightest
inlet- and outlet-duct length, easy access to electrical
and compressed-air connections, and routine
maintenance.

Donaldson Company, Inc.
8
Rigging Instructions
Failure to lift the collector
correctly can result in severe
personal injury or property damage.
Do not lift unit by the door handle.
Use appropriate lifting equipment and
adopt all safety precautions needed for
moving and handling the equipment.
A crane or forklift is recommended for
unloading, assembly, and installation of the
collector.
Location must be clear of all obstructions,
such as utility lines or roof overhang.
Suggested Tools & Equipment
Crane or Forklift Lifting Slings/Chains
Clevis Pins Socket Wrenches
End Wrenches Pipe Sealant
Hand Drill / Drill Bits
Hoisting Information
Use all lifting points provided.
Use clevis connectors, not hooks, on lifting slings.
Use spreader bars to prevent damage to unit’s casing.
Check the Specification Control drawing for weight
and dimensions of the unit, subassemblies, and
components to ensure adequate crane capacity.
Allow only qualified crane operators to lift the
equipment.
Refer to applicable OSHA regulations and local
codes when using cranes, forklifts, and other
lifting equipment.
Lift unit and accessories separately, and assemble
after unit is in place.
Use drift pins to align holes in mounting flanges
during installation.
Electrical Wiring
Electrical installation must
be performed by a qualified
electrician and comply with all applicable
national and local codes.
Turn off / lock out electrical power sources
before performing service or maintenance
work.
Do not install in classified hazardous
atmospheres without an enclosure rated for
the application.
All electrical wiring and connections, including
electrical grounding, should be made in accordance
with the National Electric Code, NFPA No. 70-latest
edition.
Check local ordinances for additional requirements
that apply.
The appropriate wiring schematic and electrical
rating must be used. See unit’s rating plate for
required voltage.
If the unit is not furnished with a factory-mounted
disconnect, an electric disconnect switch having
adequate amp capacity shall be installed in
accordance with Part IX, Article 430 of the National
Electrical Code, NFPA No. 70-latest edition. Check
unit’s rating plate for voltage and amperage ratings.
Refer to the wiring diagram for the number of wires
required for main power wiring and remote wiring.

Bin Vent, Models TBV-2, TBV-4, and TBV-6
9
Standard Equipment
Ship Loose Items
Items shipped loose with the TBV may include:
• Blower/Motor Pack*
• FilterCartridges*
• Magnehelic/PhotohelicGauge
• SolidStateTimerControlBox
• PlenumSilencer
• DamperAssembly
*In general, Torit Bin Vents are shipped without
the blower/motor packs installed (shipped loose) to
better protect the equipment during transit. Filter
cartridges are shipped installed in the TBV plenum
models. In the TBV insertable models, the filter
cartridges are shipped loose to avoid crushing the
portion of the filters that extend below the bottom
of the cabinet.
Pre-Installation
The TBV is not designed as a “stand alone” unit.
Rather, it is designed to be a filtration/ventilation
component of a larger system, such as a silo or
bin container. The open bottom of the bin vent is
intended for roof mounting applications. Some
preparation work is required before installing the
unit. A hole must be cut into the silo or storage bin
to the correct dimensions.
Ensure the silo or storage bin is
reinforced to properly support
the weight of the TBV. Failure to do so
may result in a collapse causing personal
injury/and or property damage.
See the Specification Control Drawing for footprint
dimensions and weights.

Donaldson Company, Inc.
10
Filter Installation for TBV Insertable
The filter cartridges in the TBV insertable model
extend past the bottom of the cabinet when
installed. The filter cartridges would be crushed and
damaged under the weight of the collector if they
were shipped installed; therefore, they are shipped
loose and installed at the customer site once the unit
has been installed into a permanent location.
See the Filter Element
Installation section for plenum
models.
The TBV insertable-model must already be
installed in a permanent location before the
installation of the filter cartridges into the
unit.
1. Unpack the filter cartridges from each box,
which contains a filter element, a filter crank
rod, a rubber-backed washer and a steel
grounding tab.
2. Open the TBV top roof access door to its fully
open position (small notch on bar).
Failure to open the door
properly could result in
personal injury. Ensure the door is in the
correct open position.
Once the roof is secured, reach inside the clean
air plenum of the unit and disconnect the
blowpipes by pulling back the levers of the quick
release pipe couplers. Stow the blowpipes in an
upright position by inserting them into the slots
provided at the rear of the unit.
3. Reach down inside the clean air plenum of the
unit and halfway unscrew all the black hold-
down knobs. Reach down inside the venturi,
grasp the collar bracket and twist to the right
(clockwise) until the filter hold-down collar
clears all four screw studs. Pull up and remove
the filter hold-down collar assembly from the
clean air plenum.
4. Place the new filter element end-cap down
(gasket-side up). Slide the filter hold-down collar
down inside the open end of the filter element
until it stops. Lay the filter element on its side.
NOTICE
venturi 1/4-in nut
1/4-in flat
washer
collar bracket
1/4-in bolt
rubber-back
washer
filter crank
rod
quick nut
assembly
filter
hold-down
collar
filter
element
steel
grounding
tab
Filter / Venturi Assembly
5. Slide the steel grounding tab on to the filter
crank rod, followed by the rubber-backed
washer, rubber side up and away from the crank
handle.
6. Slide the filter crank rod through the hole in the
filter element end cap and up through the filter
cartridge. Align the filter crank rod end with the
quick-nut assembly located in the center of the
hold-down collar bracket and screw together
until the filter cartridge forms an air-tight seal
against the filter hold-down collar.
7. Insert the complete filter/venturi assembly back
into the clean air plenum until the hold-down
collar is flush with the bottom of the clean air
plenum (tubesheet). Rotate the assembly to the
left (counterclockwise) until all four screw studs
are engaged.
8. Tighten all block hold-down knobs until secure.
Reconnect the blowpipes using the quick release
pipe couplers.
9. Grasp the roof access door with one hand and
with the other pull up on the bottom of the
roof support slide bar to disengage the locked
position. Lower the roof access door until it is
closed. Secure it by twisting the T-handle latches
on top of the roof.

Bin Vent, Models TBV-2, TBV-4, and TBV-6
11
collar bracket
hold down knob
filter/venturi
assembly
TBV door/hood
access
roof support
slide bar
blow pipe
clean air
plenum
tool-less
quick
release
pipe
coupler
notch
TBV Filter Installation

Donaldson Company, Inc.
12
Solid-State Timer Installation
The standard control panel includes a solid-state
timer used to control the filter cleaning system.
Install the control box and customer-supplied fan
starter switch in a convenient location. Install
conduit and wire to the unit.
The solid-state timer requires
a 105 to 135-Volt customer-
supplied power supply. Failure to comply
may result in personal injury and/or
property damage.
1. Using the wiring diagram supplied, wire the
blower motor, blower-motor starter, solid-state
timer, and solenoid valves. Use appropriate wire
gauge for rated amp load as specified by local
codes.
2. Plug the program lug into the pin that
corresponds to the number of solenoid valves
controlled.
3. With power supply ON, check the operation
of the solenoid valves. The valves should open
and close sequentially at factory set 10-second
intervals.
4. If a Photohelic® gauge or similar device is used
to control the solid-state timer and the jumper
on the pressure switch portion of the timer is
removed, the solenoid valves pulse only when
the differential pressure reaches the high-pressure
setpoint. The valves continue to pulse until the
low-pressure setpoint is reached.
Fan Starter Control Box
Disconnect
1FU
2FU
3FU
208-230V
60 Hz/3Ph
IL1
IL2
IL3
1M 1OL 1T1
1T2
1T3
230V
115V
H1 H2
H3 H4
X1 X2
stop
star
1M
1M
1TGS
fan
motor
OFF time ON time
program
pins program lug
pressure
switch
timing
logic
power
supply control
logic
4FU, 3A
105 to 135 V
50-60 Hz
solenoid
valves
L1 L2
COM
1 2
L1
L2
L3
Disconnect, fuses, low voltage blower starter, and 1TGS switch are customer-supplied.
Wiring by others
Wiring by factory
Solid-State Timer Wiring Diagram

Bin Vent, Models TBV-2, TBV-4, and TBV-6
13
Solenoid Connection
The unit is equipped with 115-Volt solenoid valves
that control the pulse-cleaning valves, which clean
the filters.
Wire the solenoids to the solid-state timer following
the wiring diagram supplied with the unit. Filter life
and cleaning operation will be affected if not wired
correctly.
Timer and Solenoid Specifications
Power to the solid-state timer is supplied to
Terminals L1 and L2, which operate in parallel with
the blower starter’s low-voltage coil. On blower
start-up, power is supplied to the timer and the
preset OFF time is initiated. At the end of the OFF
time, the timer energizes the corresponding solenoid
valve to provide the ON time cleaning pulse for one
diaphragm valve and then steps to the next until all
filters have been cleaned.
To pulse when the blower is OFF, install a toggle
switch as shown on the Solid-State Timer Wiring
Diagram. When the toggle switch is ON, the timer
receives power and energizes the solenoid valves’
pulse-cleaning operation even though the blower is
turned OFF.
Input
105-135V/50-60Hz/1Ph
Output Solenoids
The load is carried and turned ON and OFF by
the 200 watt maximum-load-per-output solid-state
switch.
Pulse ON Time
Factory set at 100-milliseconds, or 1/10-second.
Do not adjust pulse ON
time unless the proper test
equipment is available. Too much or too
little ON time can cause shortened filter
life.
NOTICE
Pulse OFF Time
Factory set at 10-seconds, adjustable from 1 to
1.5-second minimum to maximum 60 to 66-second.
Operating Temperature Range
-20° F to 130° F
Transient Voltage Protection
50 kW transient volts for 20-millisecond duration
once every 20 seconds, 1% duty cycle.
Solenoid Valves
110 to 120-Volt AC coil with NEMA 4 rated DIN
socket rated at 15 watts includes a 1/2-in conduit
fitting. The solenoid valve is part of an integral
diaphragm valve assembly. DB-2000 is equipped
with 3/4-in solenoid valves and DB-3000 with 1-in
solenoid valves.
Compressed-Air
Set compressed-air supply at 90-psig. The timer is
factory set to clean one filter or set of filters every
10-seconds.
Do not set compressed-air
pressure above 100-psig.
Component damage will occur.
NOTICE

Donaldson Company, Inc.
14
Compressed Air Installation
Turn compressed-air supply
OFF and bleed lines before
performing service or maintenance work.
The compressed-air supply
must be oil and moisture free.
Contamination in the compressed air used
to clean filters will result in poor cleaning,
cleaning valve failure or poor collector
performance.
Purge compressed-air lines to remove debris
before connecting to the unit’s compressed-
air manifold.
1. Remove the 1-in pipe cap from unit’s air
manifold and connect the compressed-air supply
line. Use thread-sealing tape or pipe sealant on
all compressed-air connections.
2. Install a customer-supplied shut-off valve, bleed-
type regulator with gauge, filter, and automatic
condensate valve in the compressed-air supply
line.
All compressed-air components
must be sized to meet the
maximum system requirements of 0.86 cu
ft/pulse at 90-psi supply pressure.
Do not increase supply pressure above
100-psi. Component damage can result.
NOTICE
NOTICE

Bin Vent, Models TBV-2, TBV-4, and TBV-6
15
solid state control timer box
(3-pin timer panel)
*low voltage (120 VAC)
magnetic starter (blower motor)
hood access door
lifting lugs (4)
diaphragm valve
air manifold
solenoid enclosure
*air line to manifold
*air regulator
*air filter (bleed type)
*lock-out
shut-off valve
*air supply line
magnehelic gauge
blower/motor
(power pack)
*power supply
disconnect switch
*electrical motor
connection
*solenoid valves
electrical connection
*automatic
condensate valve
T-handle -
quick latch
*Items not supplied with Torit Bin Vent.
Compressed Air and Component Connections

Donaldson Company, Inc.
16
Magnehelic Gauge
The Magnehelic is a differential pressure gauge used
to measure the pressure difference between the clean-
and dirty-air plenums and provides a visual display
of filter change requirements. The high-pressure
tap is located in the dirty-air plenum and the low-
pressure tap is located in the clean-air plenum.
The pressure taps for this gauge are factory installed.
For units being installed in remote locations, such
as on top of silos and storage containers, it is
recommended to mount the gauge at ground level
adjacent to the control box and motor start switch.
1. Choose a convenient, accessible location on or
near the unit for mounting that provides the best
visual advantage.
If unit is equipped with factory-installed pressure
taps, skip to Step 5.
2. Before drilling, place a piece of non-combustible
cloth over the filter opening in the clean-air
plenum to protect the filters from drilling chips.
3. Place a piece of wood behind the drill location
in the dirty-air plenum to protect the filters from
damage by the drill bit.
4. Mount the pressure tap hardware on the clean-
air plenum panel. Mount the pressure tap with
the tee inside the dirty-air plenum.
5. Plug the pressure ports on the back of the gauge
using two, 1/8-in NPT pipe plugs supplied.
Install two, 1/8-in NPT male adapters supplied
with the gauge into the high- and low-pressure
ports on the side of the gauge. Attach the
mounting bracket using three, #6-32 x 1/4-in
screws supplied.
6. Mount the gauge and bracket assembly to the
supporting structure using two self-drilling
screws.
7. Thirty-five feet of plastic tubing is supplied
and must be cut in two sections. Connect one
section of tubing from the gauge’s high-pressure
port to the pressure fitting located in the dirty-
air plenum. Connect remaining tubing from
the gauge’s low-pressure port to the fitting in
the clean-air plenum. Additional tubing can be
ordered from your representative.
8. Carefully remove the cloth protecting the filters.
Close access doors and tighten securely by hand.
9. Zero and maintain the gauge as directed in the
manufacturer’s Operating and Maintenance
Instructions provided.

Bin Vent, Models TBV-2, TBV-4, and TBV-6
17
1/8-in NPT x 90°
male elbow
clean-air plenum
3/8-in flat washer
1/8-in NPT coupling
mounting bracket
#6-32 x 1/4-in mounting screws
support structure
mounting surface
Magnehelic gauge
high-pressure port
low-pressure port
two, 1/8-in NPT
adapters
plastic tubing
two, 1/8-in NPT pipe plugs
two, self-drilling screws
1/8-in NPT x 90° male elbow
dirty-air plenum drill location
3/8-in flat washer
1/8-in NPT adapter
1/8-in NPT x 90° elbow
static pressure tee
Magnehelic Gauge Installation

Donaldson Company, Inc.
18
Preliminary Start-Up Check
1. Check all electrical connections for tightness and
contact.
2. Check for and remove all loose items in or near
the inlet and outlet of the unit.
3. Check that all remote controls are wired into the
control system and all service switches are in the
OFF position.
4. Check that all optional accessories are installed
properly and secured.
5. Check that hopper discharge is open and the
storage container is sealed, if equipped.
6. Turn power ON at source.
7. Turn the compressed-air supply ON. Adjust
pressure regulator for 90-psi.
8. Turn the fan motor ON then OFF to check
for proper rotation by referencing the rotation
arrow located on the motor’s mounting plate.
Do not look into fan outlet to
determine rotation. View the
fan rotation through the back of the motor.
Check that the exhaust plenum is free of
tools or debris before checking blower/fan
rotation.
Stand clear of exhaust to avoid personal
injury.
To reverse rotation, single-phase power supply:
Follow manufacturer’s instructions on the
motor’s nameplate.
To reverse rotation, three-phase power supply:
Turn electrical power OFF at source and switch
any two leads on the output-side of the fan-
motor starter.
9. Adjust the blower/fan for proper airflow by
adjusting the volume control damper on the
blower/fan discharge, if equipped.
Excess airflow can shorten
filter life, cause electrical
system failure, and blower motor failure.
NOTICE
Start-Up
1. Turn compressed-air supply ON. Adjust
regulator to 90-psi.
2. Turn blower fan motor ON.
3. Adjust airflow using the airflow control damper,
if equipped.
Service Information
Turn power off / lock out
electrical power sources before
performing service or maintenance work.
Turn compressed air supply OFF and
bleed lines before performing service or
maintenance work.
Operational Checklist
1. Monitor overall performance of the collector.
2. Monitor exhaust.
3. Monitor pressure drop across filters.
4. Monitor dust disposal.
Filter Element Removal
Place filter part-number
label (supplied with each
replacement filter) over the filter part
number listed on the unit’s rating plate.
1. After compressed air supply and electrical power
have been turned off, open the roof access door
of the TBV unit to its fully open position. Make
sure that the small notch on the roof support
slide bar drops down and locks into position,
securing the roof access panel.
Failure to open the door
properly could result in
personal injury. Ensure the door is in the
correct open position.
2. Reach inside the clean air plenum of the unit
and disconnect the blowpipes by pulling back
the levers of the quick-disconnect pipe couplers.
Stow the blowpipes in the upright position by
inserting them into the slots provided at the rear
of the unit.
3. Reach down inside the clean air plenum of the
unit and halfway unscrew all the black hold-
NOTICE

Bin Vent, Models TBV-2, TBV-4, and TBV-6
19
down knobs. Reach down inside the venturi
and grasp the collar bracket; twist it to the right
(clockwise) until the filter hold-down collar
clears all four screw studs. Pull up and out to
remove the filter element assembly from the unit.
4. Carefully turn the filter element assembly upside
down (venturi-side down). Turn the filter crank
counterclockwise until completely unscrewed
from the quick-nut assembly located in the
center of the collar bracket. Once loosened, pull
the filter crank out through the filter end cap
until clear of the filter assembly.
5. Turn the filter element assembly venturi-side up
again and grasp the filter hold-down collar. Pull
the filter hold-down collar up to break the gasket
seal between the filter and collar. The filter
element is now free and can be replaced with a
new filter.
collar bracket
hold down knob
filter/venturi
assembly
TBV door/hood
access
roof support
slide bar
blow pipe
clean air
plenum
tool-less
quick
release
pipe
coupler
notch
TBV Filter Installation

Donaldson Company, Inc.
20
Filter Element Installation
See the Filter Installation
for TBV for first time filter
installation for insertable models.
1. Place the new filter element end-cap down
(gasket-side up). Slide the filter hold-down collar
insidetheopenofthefilterelementuntilitstops.
2. Slide the steel grounding tab through the filter
crank rod, followed by the rubber-backed
washer, rubber side up and away from the crank
handle.
3. Slide the filter crank rod through the hole in the
filter element end cap and up through the filter
cartridge. Align the filter crank rod end with the
quick-nut assembly located in the center of the
hold-down collar bracket and screw together
until the filter cartridge forms an air-tight seal
against the filter hold-down collar.
4. Insert the complete filter/venturi assembly back
into the clean air plenum until the hold-down
collar is flush with bottom of the clean air
plenum (tubesheet). Rotate the assembly to the
left (counterclockwise) until all four (4) screw
studs are engaged.
5. Tighten all black hold-down knobs until secure.
Reconnect the blowpipes using the quick release
pipe couplers.
6. Grasp the roof access door with one hand and
pull up on the bottom of the roof support slide
bar with the other to disengage the locked
position. Lower the roof access door until closed
and secure by twisting the T-handle latches on
the top of the roof.
NOTICE
venturi 1/4-in nut
1/4-in flat
washer
collar bracket
1/4-in bolt
rubber-back
washer
filter crank
rod
quick nut
assembly
filter
hold-down
collar
filter
element
steel
grounding
tab
Filter / Venturi Assembly
