Donner DEP-10 User manual

DEP-10
DIGITAL PIANO
INSTRUCTION MANUAL
数码钢琴使⽤说明书

Thank you for purchasing this digital piano. We will be committed ourselves to providing
better service for you.
©Please read this instruction carefully before playing this piano.
©Please keep it in an appropriate way for future reference.
Function & Specifications
HalfWeighted
HammerKeys
Multi-Media MP3 Player
With MP3 player function, it could play the full role of music entertainment.
88 Hammer KeysHalf Weighted
88 Half Weighted Hammer Keys give you the real touch
of playing the piano.
Earphone Socket
Exterior with double-earphone socket are convenient for playing without affecting
others.
1

1.Piano Connection Interface Panel
Double-Earphone
Socket
100V-220V
ACSocket
①
②
③
④
⑤
⑥
2.Earphone Interface
⑦
⑧
①Socket Power Line
② Audio Output
③ Audio Input
④ Sustain Pedal Socket
⑤ Pedals Socket
⑥smission Socket USB Tran
⑦ MP3 Socket
2
Connect computer,
smart phone ,tablet PC
Soft 
Sostenuto Sustain
Operation

1. As figure shows, connect the power line when using. One end is inserted into the power outlet on the
controller plate at the bottom of piano. The other end is inserted into a 100V-220V household socket.
2. Please unplug the power line and reserve it in an appropriate way when it is not used for a long time.
1. Power Line Socket
2. Audio Output
The product has tenuto pedal function. Please use pedal according
to your needs when playing.
4. Sustain Pedal Socket
Insert the pedal plug into the round jack at the back of the piano and
put through the triple pedals function with speaker effect.
The order is as follows: Soft, Sostenuto , ;Sustain
Single pedal is optional. (Third Point)
5. Pedals Socket
The product can be connected with computer by USB transfer interface. You can learn or play the
keyboard to play, compose, store and operate other functions by the pre-installed music software on the
computer. Edited music or accompaniments built in the music software can be played by the digital piano
which is connected to the software or performed along with accompaniments.
6. USB Transmission Socket
7. MP3 Socket
The connection of headphones will cut off the output of the piano built-in speaker for not disturbing
others when performing.
This product is designed with 2 earphone sockets which you can insert double earphones.
8. Double-Earphone Socket
Soft Sostenut oSustain
3. Audio Input
It supports external large speaker equipment by audio output plug.
External sound source can be connected to electric piano to play by audio input plug.
1. Insert the flash disk with MP3 format songs into "USB plug" and play MP3 songs in 3 seconds or so.
2. By pressing the MP3 Control " " button, MP3 songs can be paused or replayed.
3. Press once the control button of MP3 Control " " or " " lightly to select previous or next MP3 songs.
4. Adjust the volume of songs by long pressing the MP3 Volume " " or " " control button.
ŸThe peak value of sound needs the control of main volumelever.
Attention!
●Only support songs with MP3 format.
Operation
3

BODY
PEDAL
MUSIC STAND
1. Slightly install the music stand into the groove of the piano body.
2. Insert pedal into the pedal jacks on the back of the body.
After the installation is done, plug in the
power supply and start your music journey.
(Power Outlet is on the back of the body.)
POWEROUTLET
①
②
③
PEDALJACK
Installation
4

Increase or decrease the volume by adjusting the volume slider to the desired position.
1. Switch on the “POWER”, then start to play the piano.
2. Please switch off the power supply when it is not played.
lThe processor chips of this product is complex, which is similar to computer system. Sometime the situation that it doesn’t response may
happen. Please turn off the power and turn it on, it will be back to normal.
1. Press the “Tone/Rhythm/Demo” button, and meanwhile press the one corresponding “black & white key” in the Song Zone to choose to play different songs.
2. Press the “Tone/Rhythm/Demo” button, and meanwhile press the “white key d3” to play all the songs in a loop.
3. Press the “Tone/Rhythm/Demo” button, and meanwhile press the “white key A2” to pause.
A BD E F G A BC D E F G A BC D E F G A BC D E F G A BC D E F G A BC D E F G A BC CD E F G
D1E1F1G1A1B1ABC D E F G a bc d e f g 1 1 1 1 1 1 1 2 2 2 2 2 2 2 3 3 3 3 3 3 3 4 4 4 4 4 4 4 5
c d e f g a b c d e f g a b c d e f g a b c d e f g a b c
Song Zone Play Songs In a Loop
1.PlayingthePiano 2.VolumeAdjustment 3.PlayingtheSong
A B C
A2B2C1
Pause
Operation Guide
Key
Demo
Lazy Birds
Look, the Little Balloon
is Flying!
The End of the City
Skater Boy
Galbero Rondo
Key Key Key Key Key
Demo Demo Demo Demo Demo
Jingle Bells
I’ll Be Waiting for You in
the Valley
Ace Ventura: Pet Detective
Santa Claus Is Coming To Town
The Ball
Minuets G Minor
Stringer Nocturne
When A child is Born
Ave Maria
Moonlighting
Plus volts Dance
Gypsy Hungarian Dances
Looking At The Shore
Vision Of Love
Old Black Joe
Mosses
Summer Fantasy 
Romantic Love
Daisy’s Dog
Old Mardoald
The Wheels On the Bus
The Girl From Ipanema
The Old Gray Mare 
Regh
It’s Beginning To
Look A Lot Like
Christmas
5

Double Tone
A BD E F G A BC D E F G A BC D E F G A BC D E F G A BC D E F G A BC D E F G A BC CD E F G
D1E1F1G1A1B1ABC D E F G a bc d e f g 1 1 1 1 1 1 1 2 2 2 2 2 2 2 3 3 3 3 3 3 3 4 4 4 4 4 4 4 5
c d e f g a b c d e f g a b c d e f g a b c d e f g a b c
Tone Zone
Rhythm Group
Rhythm Zone
4. Tone Selection
1. Press the “Tone/Rhythm/Demo” button, and meanwhile press the one
corresponding “white b3-b4” on the Tone Zone to play different
instruments tones. 2. Press the “Tone/Rhythm/Demo” button, and meanwhile press the
“white a3” to turn on/off Double Tone function.
lWhen you switch on the power supply, the default is “Acoustic Piano” tone.
5. Rhythm Selection
1. Press the “Tone/Rhythm/Demo” button, and meanwhile press the one
corresponding “black & white keys” on the Rhythm Zone to play different
rhythms. 2. Press the “Tone/Rhythm/Demo” button, and meanwhile press the
“black & white keys” on the Rhythm Group to switch 4 groups of different
rhythms. 3. Press “Rhythm” button, and meanwhile press “white A2” to pause.
1
RhythmRhythmRhythmRhythmRhythmRhythmRhythmRhythm
Disco 4
Disco 5
Rap
Techno 1
Techno 2
Dance 1
Dance 2
Dance 3
Dance 4
Dance 5
Dance 6
Dance 7
Dance 8
Dance 9
Dance 10
Samba 1
16 Beat 10
Funk 1
Funk 2
Funk 3
Funk 4
Funk 5
Funk 6
Funk 7
Funk 8
Funk 9
Funk 10
70s Disco 1
70s Disco 2
Disco 1
Disco 2
Disco 3
POP 1
POP 2
POP 3
POP 4
POP 5
POP 6
POP 7
POP 8
POP 9
POP 10
Rock 1
Rock 2
Rock 3
Rock 4
Rock 5
Rock 6
Rock 7
Rock 8
Rock 9
Rock 10
Slow Rock 1
Slow Rock 2
Slow Rock 3
Glam Metal 1
Glam Metal 2
Glam Metal 3
Punk Rock 1
Punk Rock 2
Punk Rock 3
8 Beat 1
8 Beat 2
8 Beat 3
8 Beat 4
8 Beat 5
8 Beat 6
8 Beat 7
8 Beat 8
8 Beat 9
8 Beat 10
16 Beat 1
16 Beat 2
16 Beat 3
16 Beat 4
16 Beat 5
16 Beat 6
16 Beat 7
16 Beat 8
16 Beat 9
Samba 2
Samba 3
Samba 4
Samba 5
Samba 6
Samba 7
Samba 8
Samba 9
Samba 10
Country 1
Country 2
Country 3
Country 4
Country 5
Country B allad
Country Shuffle1
Country Shuffle2
Country Swing
Country Two-Step
Jazz 1
Jazz 2
Jazz 3
Jazz 4
Jazz 5
Jazz Ballad
Jazz Waltz
Jazz Band
Swing Jazz
Cool Jazz
5/4 Beat 1
5/4 Beat 2
Ragtime 1
Ragtime 2
Blues 1
Blues 2
Blues 3
Blues 4
Big B and 1
Big Band 2
Big B and 3
Dixieland 1
Dixieland 2
Fusion
H awaii
Guaracha
Charlestion
Macarena
Musette
Acoustic Grand Piano
Bright Acoustic Piano
Electric Grand Piano
Chorus Piano
Harpsichord
Vibrating Harp
Church Organ
Strings Ensemble
Key
A B C
A2B2C
Tone
Pause
Key Key Key Key Key Key Key Key
Operation Guide
6

6.Tempo Adjustment
A BD E F G A BC D E F G A BC D E F G A BC D E F G A BC D E F G A BC D E F G A BC CD E F G
D1E1F1G1A1B1ABC D E F G a bc d e f g 1 1 1 1 1 1 1 2 2 2 2 2 2 2 3 3 3 3 3 3 3 4 4 4 4 4 4 4 5
c d e f g a b c d e f g a b c d e f g a b c d e f g a b c
+Tempo Adjustment- Chord
Chord Keys Zone Synchronize
When playing rhythms, press “EFFECT” button and meanwhile press “white G/A” to adjust the tempo of rhythm.
7.Chords
1. When playing rhythms, press “EFFECT” button and meanwhile press “white c4”, play rhythms and chords with one finger in the left chord keys
zone (1-34 keys from left).
Press “EFFECT” button and meanwhile press “white c4” to stop playing the rhythms or chords.
2. When playing rhythms, press “EFFECT” button and meanwhile press “white d4”, play rhythms with multi-fingers in the left chord keys zone (1-34
keys from left).
8.Synchronized Startup
You can set this product so that when you play chord accompaniment on the keyboard, you can start playing rhythm at the same time.
1. In the state of chord, press “EFFECT” button, and meanwhile press “white e4”, enter synchronous start standby state.
2. Play the chord (1-34 keys from left) and the accompaniment and chord will begin to play.
3. To cancel the synchronization state, press the "EFFECT" button, and meanwhile press the "white e4" button, you can stop.
C
1
A B
A2B2C
Operation Guide
7

9.Dynamics Response Switch 10.Metronome Switch
1. Press the “EFFECT” button and press “ white G1” meanwhile to turn ON/ OFF the Metronome Switch.
2. Press the “EFFECT” button and press “ white A1-D” meanwhile in the Beat Selection zone to choose the types of beat, 4 types at total.
3. Press the “EFFECT” button and press “ white G-A” meanwhile in the Tempo Adjustment zone to adjust the tempo of metronome.
11.Effect Control
1. Press the “EFFECT” button and press “ white d1” meanwhile in the Tone Effect zone to turn ON/OFF the Trill effect.
2. Press the “EFFECT” button and press “ white e1” meanwhile in the Tone Effect zone to turn ON/OFF the Suspension effect.
3. Press the “EFFECT” button and press “ black #d1” meanwhile in the Tone Effect zone to turn ON/OFF the DSP effect.
+Tempo Adjustment-
Dynamics Switch
A BC D E F G A BC D E F G A BC D E F G A BC D E F G A BC D E F G A BC D E F G A BC CD E F G
1D1E1F1G1A1B1ABC D E F G a bc d e f g 1 1 1 1 1 1 1 2 2 2 2 2 2 2 3 3 3 3 3 3 3 4 4 4 4 4 4 4 5
c d e f g a b c d e f g a b c d e f g a b c d e f g a b c
Beat Selection
Metronome Switch
Tone Effect
A B
A2B2C
Press the “EFFECT” button and press “white C1” meanwhile, to turn ON / OFF dynamics response.
●The default is “ON”.
Operation Guide
8

12.Recording
Recording function includes record and play the playing music. There are two tracks.
Track 1 Record & Play:
l1. Press the “EFFECT” button and press “white B2” meanwhile on the Track 1, start to record the track 1.
l2. When you play on the keyboards or step on the pedal, which starts to record the notes.
l3. Press “EFFECT” again and press “white B2” on the Track 1 to stop the track 1 recording.
l4. Press the “EFFECT” button and press “white C1” meanwhile on the Track 1, start to play the track 1 recorded notes.
Track 1 Record & Play:
l1. Press the “EFFECT” button and press “white D1” meanwhile on the Track 2, start to record the track 2.
l2. When you play on the keyboards or step on the pedal, which starts to record the notes.
l3. Press “EFFECT” again and press “white D1” on the Track 2 to stop the track 2 recording.
l4. Press the “EFFECT” button and press “white E1” meanwhile on the Track 2, start to play the track 2 recorded notes.
Track 1 & 2 Simultaneous Playing:
lPress “EFFECT” and “white F1” meanwhile , to play the reconded notes on the track 1 & 2 simultaneously.
Storage capacity is about 5000 characters. Storage content includes foot pedal operation and notes transformation. For example, when the amount of
pedal operation increases, the number of keyboard symbols played decreases relatively.
A B A BC D E F G A BC D E F G A BC D E F G A BC D E F G A BC D E F G A BC D E F G A BC CD E F G
A2B2C1D1E1F1G1A1B1ABC D E F G a bc d e f g 1 1 1 1 1 1 1 2 2 2 2 2 2 2 3 3 3 3 3 3 3 4 4 4 4 4 4 4 5
c d e f g a b c d e f g a b c d e f g a b c d e f g a b c
Track 1
Track 2
Play All
Operation Guide
9

13.Transpose
The Transpose function can change the tone of the playing keyboard without changing the finger movement of the keyboard.
Ÿ1. Press the “Transpose " button and meanwhile press the "white g3" to turn on and off the Transpose function.
Ÿ2. Press the “Transpose " button and meanwhile press the "black & white f2-f3" in the Transpose zone to change the tone of the playing
keyboard.
A BC D E F G A BC D E F G A BC D E F G A BC D E F G A BC D E F G A BC D E F G A BC CD E F G
C1D1E1F1G1A1B1ABC D E F G a bc d e f g 1 1 1 1 1 1 1 2 2 2 2 2 2 2 3 3 3 3 3 3 3 4 4 4 4 4 4 4 5
c d e f g a b c d e f g a b c d e f g a b c d e f g a b c
Transpose Switch
Transpose Selection
1. Insert the flash disk with MP3 format songs into "USB plug" and play MP3 songs in 3 seconds or so.
2. By pressing the MP3 Control " " button, MP3 songs can be paused or replayed.
3. Press once the control button of MP3 Control " " or " " lightly to select previous or next MP3 songs.
4. Adjust the volume of songs by long pressing the MP3 Volume " " or " " control button.
ŸThe peak value of sound needs the control of main volumelever.
14.MP3 Player
Attention!
●Only support songs with MP3 format.
A B
A2B2
10
Operation Guide

1PCS
1PCS
1PCS
1PCS
Power
Digital Paino
Music Stand
Instruction
Name Quantity
Specifications
Keys: 88
Range:A2~C5
Model: Portable Piano
Intonation:≤3cents
Output Power:≥25W x 2
Parameters: DC 12V 3A 50/60Hz
Appendix
Accessories List
11

ProductCare
The product should not be exposed excessively to the direct sunlight, placed near the air
conditioner or extremely hot places.
3.Don’t use paint, diluent or similar chemicals to clean it.
Wet a soft towel with weak solution and detergent and wring it out until it dries. Clean the
product with this towel.
4.No shaking and collision.
The product should be moved carefully. Violent shake and collision are prohibited to avoid
damaging the shell or internal electronic components.
This product may cause video or audio interference to the reception of TV and radio. If this
happens, it should be removed from the radio or TV products.
2.No use near Tv or radio.
1.Avoid heat, dampness, or direct sunlight.
Conscientiously do a good job in the maintenance and protection of this product. It plays an
important role in prolonging the service life and reducing faults.
12

PowerAdapter
Sign
Warning
Attention
This sign indicates that, if you ignore the flag and the wrong operation of this product, there is
a potential risk of injury or other financial damage caused by personnel.
Logo example
This product can be supplied by standard indoor wall socket. Please use only the power cord
specified by this product. When you do not use, please be sure to turn off the power supply. If
you do not use it for a long time, please pull out the power cord and keep it properly.
In order to ensure that you use this product safely and correctly, prevent damage to the user
and other people and the financial issue. The specification and the product are marked with a
series of safety signs. All kinds of signs and their meaning are as follows:
This triangle mark indicates that the user should pay attention to the matters.( Left case
shows “Be careful electric shock.”)
The circular sign painting a slash said prohibited matters.The logo shows the specific
content of the ban. (Left case shows “No Disassemble”.)
Black dots indicate matters must be complied with. Icon in this sign indicates the
specific content that must be followed. (Left case shows “The power plug must be
pulled out of the socket.”)
This sign indicates that, if you ignore the flag and error operation of this product, there is a fire
hazard or serious injury to personnel.
Precautions
13

Warning
Smoke, odor, overheating
When the product is smoking,
emitting odors or overheating, continue
use may lead to the danger of fire and
electric shock. In the event of such a
situation, the following operations shall
be carried out immediately.
ŸTurn off the power supply.
ŸPull the plug from the power
outlet.
ŸContact your agency.
Improper use of power supply leads
to danger of fire and electric shock
must observe the following
precautions.
ŸSpecial power lines specified for
this product must be used.
ŸAn AC power source with output
voltage within the household
rated voltage must be used.
ŸIt is not allowed to overload the
power socket and the power
extension line.
Improper handling of power lines
may result in damage or rupture, which
may cause the danger of fire and
electric shock. The following
precautions must be observed:
ŸDo not place heavy objects on the
power line or make them heated.
Ÿ Do not attempt to transform the
power cord or bend it too much.
Ÿ Do not twist or pull the power
cord.
ŸIf the power cord or plug is
damaged, replace the power cord
of the same type.
Do not use wet hands to touch the
power cord and plug, otherwise there
is a risk of electric shock.
ŸPlease use the power lines in the
place where the water will not be
spilled. Water has the risk of fire
and electric shock.
ŸNever put a vase or any other
container with water on this
product. Water has the risk of fire
and electric shock.
ŸDo not let the minors contact
plug and power line or a
connecting plate. The minors
have less knowledge of
electricity safety which may
cause danger of electric shock.
Improper use of power lines has the
risk of fire and electric shock hazard.
The following precautions must be
observed.
ŸDo not place the power cord near
the furnace or other heat sources.
ŸUnplug the power cord from the
power outlet. The plug body must
be grasped.
ŸPlug the power cord into the
power socket.
ŸBefore connecting or cutting off
the power cord, make sure that
the power is off.
ŸThe power cord should be
removed from the electrical outlet
of the wall before a thunderstorm
occurs or traveling or before other
long leave.
ŸAt least once a year, unplug the
power cord from the wall outlet
and clean the dust around the
plug.
Power line
Warning
14
Precautions

Don’t burn this product
Do not put this product into the fire
otherwise it will cause the burning of
wood products and the explosion of
the internal electronic components.
There is a danger of fire and personnel
injury.
Water and foreign matter
Water and other liquids and (metal) into
this product has the risk of causing fire
and electric shock. The following
operation should be performed
immediately when the above situation
occurs.
1. Turn off the power supply.
2. If the power cord is used for power
supply, it will be pulled off from the
wall of the power outlet.
3. Contact your dealer.
Dismantling and rebuilding
Do not disassemble this product or
transform it in any way. Otherwise it
will be hazardous to electrical shock,
burns or other personal injury. All
internal inspection, adjustment and
maintenance operations should be
entrusted to your dealer.
Drop or impact
Plastic bag
Do not let any person put the plastic
bag on the head or put in the mouth.
Otherwise there is the risk of
suffocation families with children
should pay special attention to that.
Keep the distance with the
product and support.
Climb the body or its support is in
danger of tipping or damage.
The children’s families should pay
special attention to.
Display
You should avoid placing this
product on an uneven surface or any
other unstable place. Otherwise, it
will cause it falling and a risk of
injury to the person.
Product movement
Before moving this product, you
must first pull off the wall of the
power outlet, the power cord plug
and pull off all other cables and
connecting wires. Otherwise there
will be damage to the line, resulting
in fire and electric shock hazard.
Clean
Before you clean this product, you
must first remove the power cord
from the wall outlet, otherwise there
is a risk of fire and electric shock.
Interface
The interface of this product can only
be connected to the specified
equipment and devices. The
connection of non designated
equipment or devices have the risk of
fire and electric shock.
This product is subject to the risk of
fire and electric shock after falling or
being subjected to a strong impact.
The operation should be performed
immediately following the above
mentioned situation.
1. Turn off the power supply.
2. If the power cord is used for power
supple, it should be pulled off.
3. contact your dealer.
P a r a m e t e r s :
15
Precautions

This product shouldn’t be put in the following places. Otherwise there will be a
risk of fire or electric shock.
Ÿ1. High temperature or dusty places.
Ÿ2. Kitchen or other places with oil fumes.
Ÿ3. A place where direct sunlight is irradiated. Do not expose to excessive heat
or moisture environment .
Location selection
Do not play music at high volume for long periods of time. Special attention
should be paid when using the headphones. Too high volume may damage your
hearing.
Volume
Do not place heavy objects on this product otherwise the top will be overloaded
causing the product or the object falling and the risk of injuring persons.
Heavy objects
Correct assembly of the support
The incorrect assembly of support will make it overturned, causing the product
dropping and the risk of injuring personnel.
Therefore, it is necessary to carry out the instructions in accordance with the
instructions to ensure that the product is properly installed.
If the fuse breaks, there may be short circuit or voltage instability in the product.
Professionals are required to identify and replace them, otherwise there is a risk
of fire or electric shock.
Replace the fuse
16
Precautions

AFTER-SALESSERVICE
WARRANTYCARD
Warranty Provisions:
MaintenancePoint:
ContactNumber:
1. If failure occurs in the normal use of this product, from the date of purchase (invoice
date) you can enjoy _______ day’s free warranty service.
2.The failure occurs during the warranty period, the warranty card and the shopping
note must be shown in maintenance time.
3.Free warranty will not be provided in the following cases:
A. The same warranty card and shopping notes cannot be provided at the same time.
B. The purchase date of the bill is altered.
C. The damage caused by improper use of user.
D. The fault caused by fire, flood, earthquake, lightning and other irresistible factors.
E. The failure caused by unauthorized removal.
4. After the expiration of guarantee period, our company is responsible for the
maintenance but charge a fee as appropriate.
17

Maintenance Record
Date Maintenance Record Maintenance Man
18
