Dorel Asia DA7402 User manual

3-Pc Metal & Glass Dinette
(TAKEN FROM CARTON)
Lot number:
Date of purchase:
_______ / _______ / _______
NOTE:
THIS INSTRUCTION BOOKLET
CONTAINS IMPORTANT SAFETY
INFORMATION. PLEASE READ AND
KEEP FOR FUTURE REFERENCE.
DOREL ASIA
Model No:
DA7402
UPC CODE:
0-65857-17233-1
DO NOT RETURN PRODUCT TO THE STORE.
If a part is missing or damaged, contact our customer
service department. We will replace the part FREE of
charge.
Tel #: [phone]
E-Mail: [email protected]
Fax #: [phone]
NEED HELP!
CALL US FOR ASSISTANCE
1-800-295-1980
DO NOT RETURN PRODUCT TO STORE
E-MAIL:[e-mail]

* Ensure all parts and components are present before beginning assembly.
MAINTENANCE
Check bolts/screws periodically and tighten them if necessary.
LIMITED WARRANTY
WARNING: Should this product become damaged, and/or
components are broken or missing, DO NOT USE.
You can also order parts by writing to the address listed below. Please include the product
model number, color and a detailed description of the part.
Dorel warrants its product to be free from defects in material and workmanship and agrees to remedy any
such defect. This warranty covers 1 year from the date of original purchase. This warranty is valid only
upon presentation of proof of purchase. This is solely limited to the repair or replacement of defective
furniture components and no assembly labor is included. This warranty does not apply to any product
which has been improperly assembled, subjected to misuse or abuse or which has been altered or
repaired in any way. Any wearing, tearing, fading or splitting of the leather is not covered under the
warranty. This warranty gives you specific legal rights and you may also have other rights which vary from
State to State.
* DO NOT use power tools.
* CAUTION: Adult assembly required.
* Phillips head screw driver is not included.
CARE AND CLEANING
Dust this item regularly with a soft, lint-free cloth to prevent soil build up. Wipe away spills immediately to
prevent staining using a clean cloth dampened with water. Do not use liquid or abrasive cleaners on the
metal frame as this may damage the finish.
Dust the upholstery regularly with a clean, dry cloth to avoid soil build-up. A damp cloth may be used
occasionally to clean surface. Buff dry. Keep leather soft and supple by applying a leather care product
occasionally. Avoid contact with oil, furniture polish and varnish.
Canada H1G 3L1
E-MAIL: [email protected]
NOTES:
* Assemble on a soft, smooth surface to prevent damage to product finish.
* Assembly and handling may require two people.
* Estimated assembly time is 45 - 60 minutes.
CUSTOMER SERVICE
If you are missing parts or have any questions about this product, contact our customer
service representative first!
CALL 1-800-295-1980
Customer Service Department No. 413
12345 Albert-Hudon Boulevard, Suite 100
Montreal, Quebec

1 2 3
4 5
4 PCS
1 PC
RUBBER PAD
ALLEN KEY
BOLT
BOLT
WOOD SCREW
28 PCS
4 PCS
8 PCS
3-Pc Metal & Glass Dinette
DA7402
HARDWARE LIST
Ø1/4" X 1/2"
Ø1/4" X 1-3/8"
Ø3/16" X 1-3/8"

A B C
D E F
G H I
J
2 PCS
2 PCS
1 PC
TABLE FRAME
1 PC
2 PCS
2 PCS
1 PC
TABLE LEG
TABLE LEG
TABLE METAL SHELF
2 PCS
4 PCS
2 PCS
CHAIR FRONT RAIL
SEAT CUSHION
GLASS TOP
3-Pc Metal & Glass Dinette
DA7402
PARTS LIST
BACK FRAME
CHAIR LEG
CHAIR BOTTOM RAIL

3-Pc Metal & Glass Dinette
DA7402
STEP 1
Attach chair legs (B) to the back frame (A) with bolts (1) and Allen key (5).
NOTE: Do not fully tighten the bolts. Loose bolts will facilitate assembly in the
following steps.
A
B
C
1
11
11

STEP 2
3-Pc Metal & Glass Dinette
DA7402
Attach chair front rail (D) to the chair legs (B) with bolts (2) and Allen key (5).
Attach the chair bottom rail (C) to the chair legs (B) and chair back (A) with bolts (1).
Ensure that the chair front rail (D) goes smoothly into the two chair legs before
tightening the bolts (2).
Tighten all bolts installed in step 1 and 2.
2
A
B
C
1
11
11

STEP 3
3-Pc Metal & Glass Dinette
DA7402
Attach seat cushion (E) to the chair frame with wood screws (3) as shown. Use a
Phillips head screw driver (not included) to tighten the screws.
NOTE: Seat cushion (E) does not have pre-drilled holes. Wood screws (3) will make
their own holes in seat cushion (E).
Repeat steps 1- 3 to assemble the other chair.
3

STEP 4
3-Pc Metal & Glass Dinette
DA7402
Attach table legs (G & H) to the table frame (J) with bolts (1) and Allen key (5).
NOTE: Do not fully tighten the bolts. Loose bolts will facilitate assembly in the
following steps.
A
B
C
1
11
11

STEP 5
3-Pc Metal & Glass Dinette
DA7402
Attach table metal shelf (I) to the table legs (G & H) with bolts (1).
Use Allen key (5) to tighten all bolts installed in step 4 and 5.
Turn the table upright.
A
B
C
1
11
11

STEP 6
3-Pc Metal & Glass Dinette
DA7402
Insert the rubber pads (4) into the holes on the table frame (J) as shown below.
With the help of another person, gently place the glass top (F) on top of the rubber
pads (4).
4

That's it ! You've finished assembling your dining set.
3-Pc Metal & Glass Dinette
DA7402
CAUTION: This unit is intended for use only with the
products and/or maximum weights indicated. Use with other
products and/or products heavier than the maximum weights
indicated may result in instability or cause possible injury.
DO NOT RETURN PRODUCT TO THE STORE.
If a part is missing or damaged, contact our customer
service department. We will replace the part FREE of
charge.
Tel #: [phone]
E-Mail: [email protected]
Fax #: [phone]
NEED HELP!
CALL US FOR ASSISTANCE
1-800-295-1980
DO NOT RETURN PRODUCT TO STORE
E-MAIL:[e-mail]
Table Top
Maximum
Weight - 100 lbs Table Metal Shelf
Maximum Weight -
30 lbs

MODEL #: DA7402
PLEASE DO NOT RETURN THIS PRODUCT TO THE STORE
PLEASE CONTACT CUSTOMER SERVICE REPRESENTATIVES AT THE FOLLOWING
NUMBERS SHOULD THERE BE ANY MISSING OR DEFECTIVE PART(S).
Customer Service Fax Number 514-353-7819
Request Date:
Name:
Shipping Address:
Street & Number:
City & State:
Zip Code:
Day Time Phone Number:
(including area code)
Date & Place of Purchase:
Part(s) description and quantity: (Please be sure to list model number or SKN number)
Customer Service
Customer Service Phone Number 1-800-295-1980
Customer Service Representative Mailing Address:
Customer Service Department No. 413, 12345 Albert-Hudon Boulevard, Suite 100, Montreal, QC, Canada, H1G 3L1
Email: [email protected]
