Dorel Asia WM3669 User manual

(TAKEN FROM CARTON)
Model No:
DOREL ASIA
UPC CODE:
0-65857-15761-1
NOTE:
THIS INSTRUCTION BOOKLET
CONTAINS IMPORTANT SAFETY
FAUX MARBLE TOP
DINING SET
WM3669
INFORMATION. PLEASE READ AND
KEEP FOR FUTURE REFERENCE.
_______ / _______ / _______
LOT NUMBER:
DATE OF PURCHASE:
DO NOT RETURN PRODUCT TO THE STORE.
If a part is missing or damaged, contact our customer service
department. We will replace the part FREE of charge.
Tel #: [phone]
E-Mail: [email protected]
Fax #: [phone]
NEED HELP!
CALL US FOR ASSISTANCE
1-800-295-1980
DO NOT RETURN PRODUCT TO STORE
E-MAIL:[e-mail]

*Ensure all parts and components are present before beginning assembly.
CUSTOMER SERVICE
If you are missing parts or have any questions about this product, contact our customer service representative first!
You can also order parts by writing to the address listed below. Please include the product model number, color and
a detailed description of the part.
E-MAIL: [email protected]
Customer Service Department No. 413
12345 Albert-Hudon Boulevard, Suite 100
Montreal, Quebec
Canada H1G 3L1
CALL 1-800-295-1980
* Read all instructions completely before assembly.
* Do not use power tools.
* Phillips head screw driver is not included.
* CAUTION: Adult assembly required.
CARE AND CLEANING
WARNING
* Assembly and handling may require two people.
* Estimated assembly time is 45 - 60 minutes.
*Assemble on soft, smooth surface to prevent damage to product finish.
LIMITED WARRANTY
Dorel Asia warrants its product to be free from defects in material and workmanship and agrees to remedy
any such defect. This warranty covers 1 year from the date of original purchase. This warranty is valid only
upon presentation of proof of purchase. This is solely limited to the repair or replacement of defective
furniture components and no assembly labor is included. This warranty does not apply to any product which
has been improperly assembled, subjected to misuse or abuse or which has been altered or repaired in any
way.Any wearing, tearing or fading of the fabric is not covered under the warranty. This warranty gives you
specific legal rights and you may also have other rights which vary from State to State.
Check bolts/screws periodically and tighten them if necessary.
WARNING: Should this product become
damaged, and/or components are broken or
missing, DO NOT USE.
Dust table regularly with a soft, dry cloth to prevent soil build up. A dampened cloth may be used occasionally to
clean the surface. Dry immediately and buff lightly, following the grain. Avoid using harsh cleaners and abrasive
products. Use coasters to prevent the formation of moisture rings and trivets to protect from hot items. Cover
extension leaves (if applicable) with a soft protective fabric before storing. Do not slide objects across the surface -
always lift them. Wipe away spills immediately off the seat fabric to prevent staining. Use a cloth dampened with
water or a professional product to clean the fabric. Always test an inconspicuous area first. Allow upholstery to dry
and brush lightly. Keep away from heat to avoid glazing, melting or scorching.
MAINTENANCE

FAUX MARBLE TOP DINING SET
WM3669
PHILLIPS
HEAD SCREW
- 16 PCS
CHAIR FRONT
RAIL- 4 PCS
TABLE TOP-
1 PC

STEP 1
NOTE: Do not fully tighten bolts. Loose bolts will help you to assemble other parts in
the following steps.
FAUX MARBLE TOP DINING SET
WM3669
Attach left leg (B) and right leg (C) to the back frame (A) with hex socket head bolts (1).
Use Allen key (3) to tighten bolts.
A
B
C
1
1
1
3

STEP 2
Attach chair front rail (D) to left leg (B) and right leg (C) with hex socket head bolts (1).
Use Allen key (3) to tighten bolts.
NOTE: Do not fully tighten bolts. Loose bolts will help you to assemble other parts in
the following steps.
FAUX MARBLE TOP DINING SET
WM3669
1
D
1
1
1
3
C
B

Attach seat cushion (E) to left leg (B) and right leg (C) with Phillips head screws (2)
using a Phillips head screwdriver (not included).
Fully tighten all bolts and screws previously installed in steps 1, 2 and 3.
Repeat step 1 to step 3 to assemble the other three chairs.
FAUX MARBLE TOP DINING SET
WM3669
STEP 3
CB
2
2
2
2
2
E
CB
2
2
2
2
2
E

STEP 4
Attach table legs (F) to table top (H) with hex socket head bolts (1).
Use Allen key (3) to tighten bolts.
NOTE: Do not fully tighten bolts. Loose bolts will help you to assemble other parts in
the following steps.
FAUX MARBLE TOP DINING SET
WM3669
1
F
H
111
13

STEP 5
Attach table tube base (G) to table legs (F) with hex socket head bolts (1).
Use Allen key (3) to tighten bolts.
NOTE: Fully tighten all bolts installed in steps 4 and 5.
FAUX MARBLE TOP DINING SET
WM3669
1
G
111
1
H
FFFF
3

STEP 6
Turn the table upright.
FAUX MARBLE TOP DINING SET
WM3669

That's it ! You've finished assembling your dining set .
FAUX MARBLE TOP DINING SET
WM3669
CAUTION: This unit is intended for use only with the
products and/or maximum weights indicated. Use with other
products and/or products heavier than the maximum weights
indicated may result in instability or cause possible injury.
DO NOT RETURN PRODUCT TO THE STORE.
If a part is missing or damaged, contact our customer service
department. We will replace the part FREE of charge.
Tel #: [phone]
E-Mail: [e-mail]
Fax #: [phone]
Product
Maximum
Weight
50 lbs
NEED HELP!
CALL US FOR ASSISTANCE
1-800-295-1980
DO NOT RETURN PRODUCT TO STORE
E-MAIL:[e-mail]

MODEL #: WM3669
PLEASE DO NOT RETURN THIS PRODUCT TO THE STORE
PLEASE CONTACT CUSTOMER SERVICE REPRESENTATIVES AT THE FOLLOWING
NUMBERS SHOULD THERE BE ANY MISSING OR DEFECTIVE PART(S).
Customer Service Fax Number 514-353-7819
Request Date:
Name:
Shipping Address:
Street & Number:
City & State:
Zip Code:
Day Time Phone Number:
(including area code)
Date & Place of Purchase:
Part(s) description and quantity: (Please be sure to list model number or SKN number)
Customer Service
Customer Service Phone Number 1-800-295-1980
Customer Service Department No. 413, 12345 Albert-Hudon Boulevard, Suite 100, Montreal, QC, Canada, H1G 3L1
Customer Service Representative Mailing Address:
C
B
D
E
A
B
B
B
Email: [email protected]
