Dorel Asia WM6095 User manual

Model No:
WM6095
UPC CODE:
NOTE:
THIS INSTRUCTION BOOKLET
CONTAINS IMPORTANT SAFETY
INFORMATION. PLEASE READ AND
KEEP FOR FUTURE REFERENCE.
Lot number:
(TAKEN FROM CARTON)
___________________
DOREL ASIA
0-65857-16300-1
Date of purchase:
_______ / _______ / _______
SWIVEL GLIDER
DO NOT RETURN PRODUCT TO THE STORE.
If a part is missing or damaged, contact our customer service
department. We will replace the part FREE of charge.
Tel #: [phone]
E-Mail: [email protected]
Fax #: [phone]
NEED HELP!
CALL US FOR ASSISTANCE
1-800-295-1980
DO NOT RETURN PRODUCT TO STORE
E-MAIL:[e-mail]

*
*
*
*
*
*
WARNING: Should this product become
damaged, and/or components are broken or missing,
DO NOT USE.
Dorel Asia warrants its product to be free from defects in material and workmanship and agrees to
remedy any such defect. This warranty covers 1 year from the date of original purchase. This
warranty is valid only upon presentation of proof of purchase. This is solely limited to the repair
or replacement of defective furniture components and no assembly labor is included. This
warranty does not apply to any product which has been improperly assembled, subjected to
misuse or abuse or which has been altered or repaired in any way. Any wearing, tearing or fading
of the fabric is not covered under the warranty. This warranty gives you specific legal rights and
you may also have other rights which vary from State to State.
CARE AND CLEANING
Dust regularly with a soft, dry cloth to prevent soil build up. Wipe away spills immediately to
prevent staining. Use a cloth dampened with water or a professional product to clean the fabric.
Always test an inconspicuous area first. Allow upholstery to dry and brush lightly. Keep away
from heat to avoid glazing, melting or scorching.
MAINTENANCE
Check bolts/screws periodically and tighten them if necessary.
NOTES
Ensure all parts and components are present before beginning assembly.
Assemble on a clean, smooth surface to prevent damage to product finish.
DO NOT use power tools.
CAUTION: Adult assembly required.
LIMITED WARRANTY
Assembly and handling will require two people.
Estimated assembly time: 8 minutes.
CUSTOMER SERVICE
If you are missing parts or have any questions about this product, contact our customer service
representative first!
CALL 1-800-295-1980
You can also order parts by writing to the address listed below. Please include the product model
number, color and a detailed description of the part.
Customer Service Department No. 413
12345 Albert-Hudon Boulevard, Suite 100
Montreal, Quebec
Canada H1G 3L1
E-MAIL: [email protected]

HARDWARE LIST
1 2
SPRING WASHER
6 PCS
4
PARTS LIST
HEX SOCKET HEAD BOLT
FLAT WASHER
SWIVEL GLIDER
WM6095
Ø12.5 X 1.2mm
Ø5/16" X 63mm
Ø25 X 1.8mm
LEFT ARM
RIGHT ARM
1 PC
CHAIR BACK
6 PCS
6 PCS
ALLEN KEY
1 PC
1 PC
1 PC
1 PC
1 PC
SEAT BASE
SEAT CUSHION
A
B
C
E
D
3

STEP 1:
SWIVEL GLIDER
WM6095
Place all parts on a clean, smooth surface.
Attach left arm (A) to chair back (C) by inserting the metal bracket on left arm (A) into the metal
glide on chair back (C). Push the left arm (A) with a downward force to secure it into place.
Repeat this step to attach right arm (B) to chair back (C).
A
B
C

STEP 2:
Turn the assembled unit upright.
SWIVEL GLIDER
WM6095
Gently turn the assembled unit upside side down and open the fabric lining underneath chair back (C).
Secure the chair back (C) to the left arm & the right arm (A & B) with flat washers (2), spring washers
(3) and hex socket head bolts (1).
Use Allen Key (4) to tighten the bolts.
Place the fabric lining back into place.
A
B
C
A
B
C
①②③

STEP 3:
Place the assembled unit onto the seat base (D). Open the fabric lining underneath seat base (D).
Place the fabric lining back into place.
SWIVEL GLIDER
WM6095
Secure the assembled unit to the seat base (D) with flat washers (2), spring washers (3) and hex
socket head bolts (1). Use Allen key (4) to tighten the bolts.
A
B
D
C
①②③
A
B
D
C

STEP 4:
Place the seat cushion (E) onto the chair.
SWIVEL GLIDER
WM6095
E

SWIVEL GLIDER
WM6095
CAUTION: This unit is intended for use only with the products
and/or maximum weights indicated. Use with other products and/or
products heavier than the maximum weights indicated may result in
instability or cause possible injury.
Congratulations! You've finished assembling your swivel glider.
RETURN PRODUCT TO THE STORE.NOTDO
If a part is missing or damaged, contact our customer service
department. We will replace the part FREE of charge.
Tel #: [phone]
E-Mail: [email protected] Fax #: [phone]
Dust regularly with a soft, dry
cloth to prevent soil build up.
Wipe away spills immediately
to prevent staining. Use a cloth dampened with water or a
professional product to clean the fabric. Always test an
inconspicuous area first. Allow upholstery to dry and brush
lightly. Keep away from heat to avoid glazing, melting or scorching.
NEED HELP!
CALL US FOR ASSISTANCE
1-800-295-1980
DO NOT RETURN PRODUCT TO STORE
E-MAIL:[e-mail]

MODEL #: WM6095
PLEASE DO NOT RETURN THIS PRODUCT TO THE STORE
PLEASE CONTACT CUSTOMER SERVICE REPRESENTATIVES AT THE FOLLOWING
NUMBERS SHOULD THERE BE ANY MISSING OR DEFECTIVE PART(S).
Request Date:
Name:
Shipping Address:
Street & Number:
City & State:
Zip Code:
Day Time Phone Number:
(including area code)
Date & Place of Purchase:
Part(s) description and quantity (Please be sure to list model number or SKN number):
Customer Service Department No. 413, 12345 Albert-Hudon Boulevard, Suite 100, Montreal, QC, Canada, H1G 3L1
Customer Service
Customer Service Phone Number 1-800-295-1980
Customer Service Fax Number 514-353-7819
Customer Service Representative Mailing Address:
Email: [e-mail]
C
B
D
E
A
B
B
B
