Dostmann Electronic P700-EX User manual

Dostmann electronic GmbH
Waldenbergweg 3b
D-97877 Wertheim-Reicholzheim
Tel.: ++49 (0)9342 / 30890
Fax: ++49 (0)9342 / 30894
Precision Measuring Instrument
P700-EX/P705-EX/P750-EX/P755-EX/P755-
LOG-EX
Operation manual
DOSTMANNelectronic
Version 30/03/2021
DOSTMANN electronic

Manual
List of Contents
I. Safety Advice
II. Handling
1. Setting to work
2. On/off button, Display
3. Changing units from °C to °F
4. Recalling memory data (MAX, MIN, Hold)
5. Delete Memory
6. Difference temperature
7. Auto-Off-function
8. Memory setup (Lo6)
III. Calibration
1. Introduction Calibration
1.1Option 1: calibration by code
1.2Option 2: calibration by physical references
IV.Battery check and Battery change
1. Battery check
2. Battery change
V. Fault Finding
VI. Maintenance
VII. Guarantee
VIII. Ex-data
IX. Technical data
.
.page 1

.
.page 13
I. Safety Advice
The following operating instructions contain and
precautionary advice which for the described conditions,
must be taken into consideration to guarantee safe
operation.
For Operation in explosion-prone areas
1.) Test centre: TÜV Nord Cert GmbH
2.) By operating the instrument in explosion-prone areas
all standards must be kept:
A) Only use batteries which are approved by the
manufacturer.
B) It is not allowed to use a power pack.
C) It is not allowed to use the USB port.
D) It is only allowed to use Pt100-probes which are
supplied from the manufacturer for use in
hazardous areas.
E) If there is any reason to suspect that the safety of
the equipment has been affected then it must be
immediately withdrawn from use and precautionary
measures taken in order to prevent any further use
of the equipment in hazardous area until such time
that all necessary checks and repairs have been
carried out.
F) It is not allowed to open the instrument in
hazardous areas.
G) The battery must not be changed within the
hazardous area.
H) The battery cover must be locked by a srew.
I) The following temperatures depending on the
temperature class are admissible at the measuring
point (measuring probe).
By operating in non explosion-prone areas the valid
temperature range is according to instrument’s range
of the manual. The maximum ambient temperature for
the instrument is 40°C. .
.page 2
temperature class
temperature of test point
T4
135°C
T3
185°C
T2
280°C
T1
430°C

II. Handling 1. Setting to work
Before switching on the instrument connect the probe/s to the
instrument.
2. On/off button
By operating the ON/OFF-key the instrument switched on or off.
After switching on the instrument indicates a full segment test for
1,5 sec., afterwards the display shows for appr. 1,0 sec. the
setup of the calibration menu(Coff or hex-code of the sensor).
Then starts operating in measurement mode indicating the actual
measurement category (for example: temperature). All
instruments display the measurement value of channel 1 on the
top display line(big display line). Directly below you will see the
tendency bargraph. The second channel our 2-channel
instruments you will see on the bottom line(small display line).
3. Changing units from °C to °F
To change the measuring unit push [ENTER/MENUE]. Use the
up and down keys [] to select Unit. Push again
[ENTER/MENUE]. On the left corner of the display appears a
small 1, which indicates the selected channel. For changing the
channel use the up and down keys []. Push [ENTER/MENUE]
to confirm. On the right corner of the display appears °C or °F, or
%rH, td or gm³(depending on the selected probe). Use the up
and down keys [] again to adjust the requested measuring
unit and push [ENTER/MENUE] to confirm. Push [ESC] to be
back in the measuring mode.
MENUE
Unit Choo PrEn CAL Lin2 Prob
4. Speicherabfrage
After pushing first time the key [HOLD MAX MIN AVE] the actual
value will be hold on the top display line(big display). Pushing
again the key [HOLD MAX MIN AVE], the saved maximum-,
minimum and average value will be displayed in the bottom
display line(small display).
page 3
Notes
page 12

VIII. Ex-data
Certificate of Conformity TÜV 13 ATEX 117115 X
Certification II 2 G Ex ib IIB T4 Gb
CE-Conformity 0044
IX. Technical data
Measuring
channel 1-2
Pt100 4-wire
Temperature
range
-200°C .. 800°C
Resolution
(P750/P755)
(P755Log)
P700-/P715)
0,01°C from –200°C ... +199,99°C
0,1°C from +200°C ... +800°C
0,1°C complete range
Accuracy(P750/
P755, P755Log)
(P700/P705)
(P710/P175)
0,03°C from-50°C ... 199,99°C,
0,05°C from –200°C ... –50°C
otherwise 0,05% of reading
+0,1°C from -100°C..200°C
+0,1% remaining range
+0,2°C from -40°C..200°C
+0,5°C from 201°C..1000°C
+1,0°C remaining range
Working
temperature
0°C ... 40°C
Display
2-line LCD
Housing
ABS
Dimensions
(LxWxH)
200 x 93 x 44 mm
Weight
390 g
Power supply
9 V Alcaline batteries according IEC 6LR61
Typ (6LR61)
3V Litihum CR 2032
Approved
batteries 9V
Approved
batteries 3V
Page 11
Varta LONGLIFE Power 4922 ( Varta)
Varta Industrial Pro 4022 ( Varta )
Duracell Plus Power ( Duracell )
Varta Professionell Electronic CR 2032 ( Varta )
Camelion CR 2032 ( Camelion )
Duracell CR 2032 ( Duracell )
Arcas CR 2032 ( Arcas )
Note for 2-channel instruments: First the MAX-MIN-AVE-
values of channel 1 will be displayed –afterwards the
values of the channel 2 will be displayed. Is there only one
probe on a 2-channel instrument we suggest to deactivate
the channel without probe(menu CHoo).
5. Clearing the memory (MAX MIN AVE)
Press [CLEAR] key once to erase the stored maximum,
minimum and average from memory. On the display
appears Clr. –After erasing the memory the instrument
automatically switches back to measuring mode indicating
the actual measured value again.
6. Difference temperature [T1 –T2]
To display the difference temperature push
[ENTER/MENUE]. Use the up and down keys [] to
select Lin2. Push again [ENTER/MENUE]. On the right
corner of the display appears a T1-T2. Use the up and down
keys [] to adjust the requested selection. Push
[ENTER/MENUE] to confirm. Push [ESC] to be back in the
measuring mode. MENUE
Unit Choo PrEn CAL Lin2 Prob
7. AUTO OFF - function
EAoF = Enable Auto-off
dAoF = Disable Auto-off
Press [ESC/AUTO-OFF] key once. On the display appears
EAoF. Now the instrument switch off automatically after
appr. 30 minutes. Press [ESC/AUTO-OFF] key again. On
the display appears dAoF. Now the Auto-Off-function is
deactivated.
Note: After switching off and on the instrument, the Auto-
Off function is automatically activated.
.
.page 4

8. Memory setup(Lo6)
Push [ENTER/MENUE] and use the up and down keys [] to
select Lo6. Push [ENTER/MENUE] to confirm. Use the up and
down keys [] again to start [on] or Stop [off] the logger. Push
[ENTER/MENUE] to confirm. Use the up and down keys []
again to select between automatic storage [Auto] or manually
operated storage [SPot]. Push [ENTER/MENUE] to confirm].
Use the up and down keys [] again to select between to add
on data [Add] and creating a new file[nLo6]. Push
[ENTER/MENUE] to confirm]. By selected automatic storage at
the end you have to select the time interval:
1 S 1 second
5 S 5 seconds
10 S 10 seconds
20 S 20 seconds
30 S 30 seconds
1 M 1 minute
2 M 2 minutes
5 M 5 minutes
10 M 10 minutes
20 M 20 minutes
By selected manually operated storage you are able to save the
measurement by pressing ESC by each time.
Push [ENTER/MENUE] to confirm. Push [ESC] to revert back to
the measuring mode.
page 5
page 10

V. Error codes
By displaying the following error codes the instrument support the
operation of the instrument.
Error Meaning
Open no probe or wrong probe is connected
Hex R environment temperature below working
temperature
VI. Maintenance
- For cleaning the instrument please do not use
aggressive cleanser, but use mild cleanser and
afterwards wipe the instrument by a dry or wet piece of
cloth.
- Please store the measuring instrument in a dry and clean
place.
- Avoid any force like shocks or pressure to the
instrument.
- Do not use force to stick the probe or interface plugs in.
The interface plug is different from the probe plug.
VII. Guarantee
With regular use guarantee lasts 12 months for the instruments
and 6 months for the probes and sensors. Opening of the
instruments leads to expiration of guarantee.
page 9
III. Calibration
Despite high quality manufacturing techniques, each probe
is slightly different from specified standards. To eliminate
inaccuracies caused by exchanging or ageing of probes,
the instrument offer easy calibration functions which
guarantee that the system accuracy is always as good as
if the instrument was specifically calibrated to the
individual probes in our laboratory.
The instruments offer three calibration options:
1) Standard characteristic curve (e.g. Pt100-resistance
according DIN IEC 751)
2) Calibration by code (2 x four digit code) is equivalent
to a 2-point calibration
The code is marked clearly by a label on each
standard probe.
3) Calibration by physical standard references (1-point,
2-point or 3-point calibration)
1. calibration handling
To calibrate the instrument with sensor push
[ENTER/MENUE]. Use the up and down keys [] to
select CAL. Push again [ENTER/MENUE]. On the left
corner of the display appears a small 1, which indicates
the selected channel. For changing the channel use the up
and down keys []. Push [ENTER/MENUE] to confirm
MENUE
Unit Choo PrEn CAL Lin2 Prob
1.1 Calibration by code / OP1
Use the up and down keys [] to select the requested
calibration option. Push [ENTER/MENUE] to confirm.
Use the up and down keys [] to select oP1. Push
[ENTER/MENUE] to confirm. On the bottom of the display
appears a very small 1, after this number a four digit
number(Hex-Code/0..F) is displayed. For changing the
number use the up key []. For stepping to the next
number use the down key []. Is the requested number
complete push [ENTER/MENUE] to confirm. Now on the
bottom of the display appears a very small 2, after this
number a second four digit number is displayed. For
changing the number please follow the manual as before.
Push [ESC] to be back in the measuring mode.

Note: After confirming oP1 by pushing [ENTER/MENUE] the
function oP1(calibration by code) is activated, even though you
leave the menu by pressing[ESC].
CAL
oFF oP2 oP1
1.2 Physical calibration
Use the up and down keys [] to select oP2. Push
[ENTER/MENUE] to confirm.
On the bottom of the display appears 1 P. For changing between
a 1-Point 1 P, 2-Point 2 P or 3-Point 3 P - calibration use the up
and down keys []. OP2
1P 2P 3P
Example of a 1-Point calibration:
Push [ENTER/MENUE] to confirm. On the display appears Go.
After the displayed measuring value is stabile push
[ENTER/MENUE]. Appr. 2 seconds later in the first display line
appears P1 (measuring value 1), in the second display line
appears dP. (standing for decimal point).
Use the up and down keys [] to select the number of digits after
decimal point.
dP. = two decimal digits
dP . = one decimal digit (decimal point is jumping one digit to the
right)
Push [ENTER/MENUE] to confirm. On the second line of the
display appears Si -.
Use up and down keys [] to select the requested sign.
Si _ = reference standard shows a negative measuring value (below
0,00C°)
Si _׀= reference standard shows a positive measuring value (above
0,00C°)
Push [ENTER/MENUE] to confirm. On the second line of the display
appears Fd 0.
Use up and down keys[] to select the requested range:
Fd 0 = below 100,00°C
Fd 1 = above 100,00°C
Push [ENTER/MENUE] to confirm. On the display appears 00.00. For
changing the value use the up key []. For stepping to the next number
use the down key []. Is the requested value complete push
[ENTER/MENUE] to confirm.
Push [ESC] to be back in the measuring mode.
page 7
IV. Battery check and Battery changing
1. Battery check
By showing the „BAT“ segment the instrument indicates,
that the battery has to be exchanged. After showing the
„BAT“ segment the instrument allows appr. 1 hour of
further measuring.
2. Battery changing
The exchange of this maintenance element may only be
carried out outside of the hazardous area. Take care and
ensure that when changing the battery, that only those in
the listed operating instructions are used. The use of any
other type of battery is strictly forbidden in that it will
invalidate the Ex-data certification. In order to open the
battery compartment first remove the screw of the battery
case. After exchanging the battery, refit and tighten the
screw of the battery case in order to use the equipment in
the hazardous area.
Attention: By closing the battery compartment please be
attend not to damage the battery cable.
.
.page 8
