Doyon DOMIX45 Operator's manual

DOMIX45
DOMIX45DOMIX45
DOMIX45
Water Doser Mixer
USER’S INSTRUCTION MANUAL
CODE 2600201
CODE 2600201 CODE 2600201
CODE 2600201 Rev. 01
Rev. 01 Rev. 01
Rev. 01 -
--
- 18.01.2011
18.01.201118.01.2011
18.01.2011

Manual Code 2600201
DOMIX45 – Rev.06 - 02.09.2014 3/32
Fig. 1 (Descrizione esterna della macchina; Machine overview)

Manual Code 2600201
DOMIX45 – Rev.06 - 02.09.2014 4/32
Fig. 2 (Layout collegamenti idraulici; Layout hydraulic connections)
Boiler Rete
Cold water mains
Réseau
Kaltwasser-Anschluß
Caldera Cañería del agua
fría
Rete Re rigeratore
Cold water mains Re rigerator
Réseau Ré rigérateur
Kaltwasser Wasserkühler
C. del agua ría Re rigerador
Boiler Re rigeratore
Re rigerator
Ré rigérateur
Wasserkühler
Caldera Re rigerador
Rete Cold water mains Réseau Kaltwasser-Anschluß Cañería del agua ría

Manual Code 2600201
DOMIX45 – Rev.06 - 02.09.2014 5/32
Fig. 3 ( chema Elettrico; Wiring Diagram)

Manual Code 2600201
DOMIX45 – Rev.06 - 02.09.2014 6/32
Fig. 4 (Dimensioni; Dimensions)

Manual Code 2600201
DOMIX45 – Rev.06 - 02.09.2014 7/32
INDICE / INDEX
1- TECHNICAL FEATURES................................................................................ 9
1.1. DESCRIPTION ........................................................................................................ 9
2- MANUAL INTERPRETATION ...................................................................... 10
3- PRELIMINARY INSPECTION ...................................................................... 10
4- BASIC RULES OF SAFETY .......................................................................... 10
5- MANUFACTURER DECLARATION ............................................................. 11
5.1. ARRANTY ......................................................................................................... 11
5.2. UNPACKING ....................................................................................................... 11
5.3. STORAGE ............................................................................................................ 11
6- INSTALLATION .......................................................................................... 12
- UNIT OPERATION ..................................................................................... 14
7.1. START-UP ............................................................................................................. 14
7.2. MANUAL OPERATION ........................................................................................ 14
7.3. RECIPES SETTING ................................................................................................. 15
7.4. RECIPES DOSING ................................................................................................ 15
7.5. SPECIAL FUNCTIONS .......................................................................................... 15
8- ERRORS .................................................................................................... 16
8.1. L ITRES - COUNTER ERROR ............................................................................................ 16
8.2. P ROBE E RROR ......................................................................................................... 16
8.3. P O ER F AIL ........................................................................................................... 16
8.4. S OLENOID VALVE LEAKING ........................................................................................ 17
9- MAINTENANCE INSTRUCTIONS ............................................................... 1
10- USELESS DEVICE DISPOSAL ...................................................................... 18
11- CERTIFICATIONS ...................................................................................... 18
12- TROUBLESHOOTING ................................................................................. 19
1- CARATTERISTIQUES TECHNIQUES ............................................................ 20
1.1. DESCRIPTION (V OIR E RRORE . L' ORIGINE RIFERIMENTO NON È STATA TROVATA .) ............ 20
2- INTERPRETATION DU MANUEL ................................................................. 21
3- INSPECTION PREVENTIVE ........................................................................ 21
4- REGLES FONDAMENTALES DE SECURITE ................................................. 21
5- DECLARATION DU CONSTRUCTEUR ........................................................ 22
GARANTIE ...................................................................................................................... 22
DEBALLAGE ................................................................................................................... 22

Manual Code 2600201
DOMIX45 – Rev.06 - 02.09.2014 8/32
ENTREPOSAGE .............................................................................................................. 22
6- INSTALLATION .......................................................................................... 23
- FONCTIONNEMENT ................................................................................. 25
7.1. ALLUMAGE A PARTIR D’UN APPAREIL ETEINT .................................................... 25
7.2. FONCTIONNEMENT MANUEL ............................................................................. 25
7.3. RECETTES ............................................................................................................. 26
7.4. DOSAGE RECETTE............................................................................................... 26
7.5. FONCTIONS SPECIALS ........................................................................................ 26
8- ERREURS ................................................................................................... 2
8.1. E RREUR DANS LE COMPTE DE LA QUANTITE ................................................................... 27
8.2. S ONDE EN PANNE .................................................................................................... 27
8.3. C HUTE DE TENSION .................................................................................................. 27
8.4. P ERTE D ’ EAU DE L ’ ELECTROVANNE ............................................................................. 28
9- ENTRETIEN ................................................................................................ 28
10- RECYCLAGE DES APPAREILS QUI NE SONT PLUS UTILISES ...................... 29
11- CERTIFICATIONS ...................................................................................... 29
1. DEFAUTS DE FONCTIONNEMENT ET SOLUTIONS ..................................... 30
13- PEZZI DI RICAMBIO / SPARE PARTS / PIECES DE RECHANGE ................. 31

Manual Code 2600201
DOMIX45 – Rev.06 - 02.09.2014 9/32
1- TECHNICAL FEATURES
Power supply (see machine rating plate) 208-240V AC or 110-127V AC
Mains requency 50/60 Hz
Total absorbed power 25 VA
Installation category ll
Environmental conditions Indoor use only
Temperature range 5 ÷ 50°C (40 ÷ 120°F)
Relative humidity range 0 ÷ 95%
Hydraulic inlet connections 1/2”
Hydraulic outlet connections 16 mm
Maximum temperature at inlet 65°C (149°F)
Operating regulation range 2 ÷ 60°C (36 ÷ 140°F) precision +/- 1%
Maximum inlet pressure 5 bar (72,5 psi)
Minimum inlet pressure 1 bar (14,5 psi)
Max ratio between the two entry pressures 1 : 5
Maximum batch 999,9 L; 99 lb + 15 oz; 999,9 lb
Dosing precision ± 1% (min batch: 5L)
Flow rate at 1 bar and 20°C 18 L/min (40 lb/min)
Flow rate at 5 bar and 20°C 40 L/min (88 lb/min)
Internal probe Thermo-resistor PT1000 typeA
External probe Thermo-resistor PT1000 typeA
Memory 80 programmable recipes
Supply use 250 V – T250 mA retarded @ 230 V
250 V – T630 mA retarded @ 115 V
Pump control use 250 V – F6,3 A
Protection Rating IP 42
1.1. DESCRIPTION
(See Fig. 1)
1. Ball-taps with OR gasket.
2. OR gasket-type unions or an easier installation.
3. Stainless steel double mesh ilters or water impurities.
4. No-return valves.
5. External temperature probe.
6. Regulation knob or temperature setting, with re erence scale.
7. Supply plug, with use and spare, and remote pump control plug, with use and
spare.
8. Display showing the water quantity selected, still to be delivered (during the dosing),
or already delivered (a ter pressing [STOP/C]).
9. Display or the internal electronic thermometer and the set temperature.
10. Display or the external electronic thermometer and the programs.
11. Key to move rom temperature to quantity and vice versa.
12. [STOP/C] and [START] keys.
13. Delivery hose.
14. By-pass connection.
15. Membrane keyboard or the data entry.
16. Series o unction control lights.

Manual Code 2600201
DOMIX45 – Rev.06 - 02.09.2014 10/32
2- MANUAL INTERPRETATION
All parts o the text that are important to the sa ety o people and objects are written in
bold. The purpose o this manual is to provide the user, the installer and the maintenance
technician with all the technical in ormation required or the installation, use and ordinary
maintenance operations to guarantee a long machine li e.
Should any spare parts be required, only original components should be used. Requests
or SPARE PARTS or INFORMATION relating to the unit must be made to the distributor or
the nearest technical assistance centre, quoting the MODEL and MACHINE SERIAL
NUMBER shown on the technical characteristics label.
The meaning of this symbol (used both on the machine and in this manual) is:
Danger, electric shock risk.
The meaning of this symbol (used both on the machine and in this manual) is:
Caution, please refer to attached documentation.
The meaning of this symbol (used both on the machine and in this manual) is:
Operation prohibited.
3- PRELIMINARY INSPECTION
Inspect the unit as soon as it has been received.
Carefully check that all the components are on the packing list or invoice.
Promptly advise of any damage caused during transportation and send a claim to the
courier without delay.
VERY IMPORTANT: the manufacturer shall not be held liable for whatever damage to the
unit during transportation.
4- BASIC RULES OF SAFETY
The use o the device is prohibited or children and persons with disabilities who are
not assisted.
It is prohibited to touch the device i you are bare oot and with body parts wet or
damp.
Any cleaning operation is prohibited be ore it has disconnected the unit rom the
mains.
Not modi y the sa ety devices or setting without the manu acturer permission.
It is prohibited detach, twist the wires even i it is disconnected rom the mains.

Manual Code 2600201
DOMIX45 – Rev.06 - 02.09.2014 11/32
It is prohibited to open it without having previously disconnected rom the mains.
It is prohibited to disperse and leave to the reach o children the packaging. It can
be potentially dangerous.
5- MANUFACTURER DECLARATION
THE MANUFACTURER DECLINES ANY LIABILITY WHATEVER FROM ANY DAMAGE
DERIVING FROM IMPROPER USE OF THE MACHINE AND/OR USE OF THE MACHINE IN
ENVIRONMENTAL CONDITIONS THAT ARE NOT ADMITTED.
5.1. WARRANTY
The manu acturer, through its authorised distributors, warrants the repair or ree
replacement o any part o this product that happens to break down due to de ective
material or workmanship within one year rom delivery thereo , but not rom improper or
incorrect use, in compliance with the conditions outlined here below.
Materials that are subject to normal wear and tear such as pipes and tubing are excluded
rom this warranty. Any aulty products must be returned to the manu acturer, or to an
authorised distributor at the customer’s expense ollowing agreement or the goods to be
collected by courier. Any repairs or modi ications must be carried out solely by the
manu acturer or its authorised distributors or ollowing explicit authorisation by the
manu acturer or its authorised distributors. Any products that have been subjected to
improper or incorrect use or have been purposely or accidentally damaged or
overloaded are excluded rom this warranty. The manu acturer shall not be held
responsible or any warranty whatever given by anyone, including its distributors, in the
name and on behal o the manu acturer that does not all within the terms outlined in this
warranty clause, unless otherwise speci ically approved in writing by the manu acturer.
5.2. UNPACKING
Unpack all parts with care and check the presence and good condition o all
components.
Store the packaging so that it can be used to return the component, i necessary.
At the end o the equipment’s li e, dispose o the packaging material in compliance with
local regulations. Pay particular attention to the expanded polystyrene protections. The
outer box is in corrugated cardboard and can be recycled.
5.3. STORAGE
This product has a long shel -li e. Nevertheless, a ter storage care must still be taken to
make sure that all parts unction correctly.

Manual Code 2600201
DOMIX45 – Rev.06 - 02.09.2014 12/32
6- INSTALLATION
Fundamental operations relating to lifting, transportation, installation, start-up,
maintenance and repair work must be carried out only by qualified personnel.
Disconnect the electrical power supply when carrying out any of the above.
A further 2 fuses, specifically for the pump and logic board, are also fitted inside the
machine and can also be replaced when needed.
The installation must be carried out by skilled personnel under the supervision o a quali ied
person. All electrical connections must comply with the local requirements at the place o
installation. The machine must be earthed and protected against short circuits and
overloads.
In case o hard water (with high lime scale content = hardness in French degrees higher
than 25 ÷ 30, or 250 ÷ 300 ppm) it is necessary to employ an ion exchange water so tener.
This unit must be calibrated so as to maintain a residual hardness ranging between 5 and
10 French degrees (50 ÷ 100 ppm). The use o electronic water so teners is not advised,
since their e icacy has not been proved yet.
Fix the doser-mixer on the wall at a height rom the loor o 1350 ÷ 1550 mm, using the our
wall plugs supplied. The 90° wall plug hook is supplied to provide support or the water
delivery outlet elbow.
Do not place other machines below the device.
Arrange the water inlet tubing as shown in the lay-out diagrams, Fig. 2, mounting the ball
taps (1) at the end o the pipes (black lever = cold on the right and red lever = warm on
the le t). Provide to insulate thermically the inlet pipes to obtain the best per ormances.
It is recommended to perform links as short as possible from the chiller / boiler to the
DOMIX, avoiding going through the pipes near sources of heat such as the ovens.
Per orm a purge o all pipes to eliminate waste processing, which could damage the
equipment.
Connect the ball taps to the doser-mixer by means o the "O" ring gasket type unions (2).
Insert the delivery hose (13) into its housing.
Connect the by-pass (14) to a drain by means o the supplied tube.
Absolutely forbidden to enter directly into the bypass (14) a fixed pipe to ensure the
possibility of disassembly for maintenance.

Manual Code 2600201
DOMIX45 – Rev.06 - 02.09.2014 13/32
Check that the voltage and frequency correspond to those shown on the unit data
tag. Make sure that the electrical installation complies with the local electrical
connection and safety regulations.
Connect to the proper power supply using the supplied lying socket, itted with a three
core cable min. section 3x1,5mm². An external switch is help ul.
For the eventual pump remote control, use the supplied lying socket to connect the
remote control switch o the pump(s). The use o such a pump is necessary when one o
the two inlet pressures is less than 1 bar, or example when using unpressurized water
heaters or re rigerators.
NOTICE: in the case of water chiller equipped with a surge tank with pressure switch, this
must be by-passed and the pump must be controlled directly by the Doser, through a
power relay.
The pump command plug on the device has the ollowing wiring diagram (clean contact,
digital output, no tension output):
Fig. 5 (pump control wiring diagram)
This is a normally open (NO) clean contact that closes when the unit requires chilled
water. So it doesn’t supply any tension.
It is recommended to use it to cut phases with current not higher than the amperage
indicated in the igure.
The equipment is itted with an auxiliary precision electronic thermometer with a mobile
probe (5), usable at distances up to 5 metres.
Temperature readout on the display is continuous (10), except when the program number
appears.
The machine is also equipped with a complete diagnostics system, which allows to quickly
identi y any improper installation or breakage, by means o a description o the ault on
the display.

Manual Code 2600201
DOMIX45 – Rev.06 - 02.09.2014 14/32
- UNIT OPERATION
.1. START-UP
Switch on the doser-mixer using the external switch (or by plugging in the lying socket).
The irst displays appearing at the switching on re er to the sel -test. The displays show the
model and the microprocessor so tware version.
At the end o the sel -test the displays show:
−The quantity of the last discharge.
−Internal temperature.
−External temperature.
.2. MANUAL OPERATION
Press the key ollowed by [00] (the yellow led (MANUAL) lights up and the quantity
display lashes).
Select the required water quantity. I only the quantity has to be stored, press [START].
I the operator needs to store also the temperature, by pressing the key the lashing
moves to the temperature display, which can be set.
In case o error, in the quantity or in the temperature, press the [STOP/C] key and reselect.
ATTENTION: the setting of the temperature in the model Domix45 (referred to in this
manual) has only the purpose of storage. It has no influence on the regulation and on the
by-pass operation. It must be performed manually by acting on the ball valve (14).
Press [START] to execute the batch.
First o all the remote pump control is activated, the RUN solenoid valve opens and the
corresponding led lights up; the central display (9) shows the actual discharge
temperature and the display (8) indicates the decreasing quantity.
Adjust the water temperature using the knob (6), checking it on the electronic
thermometer (9). In case o correction, wait a ew seconds be ore intervening, so as to
allow the temperature to stabilize.
To ensure optimum operation the warm water temperature must be at least 18°F higher
than the required delivery water temperature and the cold water should be at least 9°F
lower. Low temperatures (under 50 ÷ 60°F) may be obtained only using a re rigerator.
ATTENTION: the graduated scales are indicative. They suffer from the temperature of the
water input. The scale "red" indicates the temperature of the mixed output when you use
NETWORK+HOT. The scale "blue" indicates the temperature of the mixed output when you
use CHILLED+NETWORK. They have been obtained with temperatures of 3°C (refrigerated),
18°C (net) and 65°C (warm).
To manually stop water delivery at any time press the [STOP/C] key. In the display (8) the
quantity o delivered water lashes; to resume the dosage, press again the [START] key;
otherwise pressing again the [STOP/C] key the memory is cancelled and a di erent
quantity can be set.
To modi y quantity and/or temperature in memory, press directly the key and proceed
as or the irst data entry.
To obtain the same water dosage in successive operations, simply press the [START] key, as
the doser-mixer is provided with a memory. In the case o power ailure during dosing the
data are not lost; when power is restored simply repress the [START] key to complete the
dosing operation.

Manual Code 2600201
DOMIX45 – Rev.06 - 02.09.2014 15/32
.3. RECIPES SETTING
Set the program number (ex. P01, P02 etc.) appearing on the lower display (10) (PROG.
led lights up) and then the desired water quantity, appearing on the upper display (8).
To store also the temperature, press the key and then proceed as or manual
operation.
Warning: recipe numbers from 1 to 9 must always be set using the format: 01, 02, etc.
It is possible to exit rom a recipe setting dosing the recipe itsel (press [START]), setting a
new recipe (press XX), or automatically a ter 6 seconds: in all these cases the recipe is
stored.
ATTENTION: the setting of the temperature in the model Domix45 (referred to in this
manual) has only the purpose of storage. It has no influence on the regulation and on the
by-pass operation. It must be performed manually by acting on the ball valve (14).
.4. RECIPES DOSING
To recall a recipe, enter the desired number ( or example P28), which is shown or 3
seconds on the lower display (10), while the upper displays show the relevant quantity and
temperature. Press [START] to carry out the dosing. I modi ications are required, set the
new quantity and/or temperature as explained above.
To stop water delivery manually at any time press the [STOP/C] key. A ter that on the
display (8) the delivered water quantity lashes; to resume dosing press again the [START]
key, otherwise, pressing the [STOP/C] key, the quantity is cleared and it is possible to set a
new quantity.
.5. SPECIAL FUNCTIONS
Recipes memory viewer
Pressing or 3 seconds the key, the device shows the succession o the recipes stored in
memory (PROG. led is lashing in this phase). At the end o the sequence (or by pressing
[STOP/C] any time) the machine comes to the normal unction.
Free batch
It is possible to per orm a special recipe controlling only the temperature, by means o the
special program [P99].
On the upper display appears [FrEE], the central display shows the water temperature
while the bottom shows the external temperature.
With the [START] and [STOP/C] keys the solenoid-valve opens and closes.
To exit, digit a new recipe or [P00].
This unction may be use ul also in case o a liter-counter ailure.

Manual Code 2600201
DOMIX45 – Rev.06 - 02.09.2014 16/32
8- ERRORS
All error messages are accompanied by lashing wordings and an intermittent acoustic
signalling. The last one can be stopped with the [STOP/C] key. Using the [START] key the
error message is cancelled and the delivery starts again. On the contrary, the double
[STOP/C] command cancels the delivery. The possible error messages are listed here
below.
8.1. Litres-counter error
E r r. L
DISPLAY 1
I no pulses come rom the litre counter, a ter 15” the message “Err.L” appears on the
display. The message is cancellable with the [STOP/C] key and the machine turns into a
temporary state where on the upper display is shown the delivered quantity. By pressing
the [START] key the delivery continues, by pressing the [STOP/C] the machine turns into idle
state.
For relative troubleshooting see paragraph 12-.
8.2. Probe Error
2 4. 2
P r. E
2 . 2
DISPLAY 2
The “Pr.E” message appears on the display re erred to the damaged or wrongly
connected probe. The machine is not blocked and it’s possible to be operated.
In the meantime, i the internal probe is broken, use the external probe to check that the
temperature is correct. For relative troubleshooting see paragraph 12-.
8.3. Power Fail
t E n S
F A I
DISPLAY 3

Manual Code 2600201
DOMIX45 – Rev.06 - 02.09.2014 17/32
I there is a tension all during a water delivery, at the ollowing switch-on the message
“tEnS FAI” appears on the display. The message is cancellable with the [STOP/C] key and
the machine turns into a temporary state where on the upper display is shown the
delivered quantity. By pressing the [START] key the delivery continues, by pressing the
[STOP/C] the machine turns into idle state.
8.4. olenoid valve leaking
L E A K
E. V.
DISPLAY 4
It could happen that the solenoid valve doesn’t close properly with some water leaking. In
this case the ollowing message appears: “LEAk E.V.” This kind o error doesn’t lock the
device. The user can operate the machine, but i the problem is not solved the alarm will
appear again.
To cancel the alarm the [STOP/C] key must be pressed.
For relative troubleshooting see paragraph 12-.
In the installer parameters it is also possible to deactivate the control.
9- MAINTENANCE INSTRUCTIONS
•Per orm periodic cleaning o the external ilters (3). The requency depends on the
impurities present in the pipes.
•To clean the external sur ace o the doser-mixer, use a so t sponge and water or a
neutral detergent; or more resistant grime, use alcohol or turpentine.
•No direct jets o water on the device.
•Clean the internal membrane o solenoid valve regularly (6 months), particularly i
the water contains a high quantity o lime-scale.
•When switching o the doser-mixer, set always the temperature regulation knob (6)
to its mid position, to allow a minimum number o moves in the mixer valve,
particularly when deliveries at the same temperature are carried out.
•Check periodically the litre-counter error, using a high precision scale.
The use of non-original spare parts is strictly prohibited.
The code or the spare parts are located in the Tab. 1.

Manual Code 2600201
DOMIX45 – Rev.06 - 02.09.2014 18/32
10-USELESS DEVICE DISPOSAL
The used package may be disposed through regular disposal treatment centres. It is
made only o non polluting materials, recyclable as secondary prime materials. The
device, accessories and batteries included, does not belong to the domestic disposals
category, due it’s made o valued materials which could be recycled and reused. The
European Directory 2002/96/CE about electric and electronic devices disposal (RAEE)
prescribes the separate collection o the electric and electronic devices respect to the
mixed urban disposals or their urther recovery, reuse and recycle. Don’t dispose the
electric and electronic devices together with domestic disposals or through the regular
disposals collection services. The EU countries require the use o separate collection
services. Be in ormed about your local separate collection services or electric and
electronic devices disposal showing this symbol:
11-CERTIFICATIONS

Manual Code 2600201
DOMIX45 – Rev.06 - 02.09.2014 19/32
12-TROUBLESHOOTING
PROBLEM CAUSE SOLUTION
The unit doesn’t
switch on
The power use in the logic
board is burnt.
Disconnect the power and replace
the use.
“Err.L” message There is no water coming rom
the chiller.
Check the inlets.
RUN or BY-PASS obstructed. Check the outlets.
Litre-counter damaged. Call the Service.
Other. Call the Service.
Low low-rate Inlets ilters obstructed. Clean the ilters.
Plant problems. Call the Service.
Dosing error Solenoid valve slowly closing. Call the Service.
Litres counter bad calibrated. Call the Service.
“Pr.E” probes
errors
Probes damaged. Call the Service.
“LEAK E.V.”
message
RUN or/and BY-PASS valves
doesn’t close properly.
Call the Service.

Manual Code 2600201
DOMIX45 – Rev.06 - 02.09.2014 20/32
1- CARATTERISTIQUES TECHNIQUES
Tension (voir la plaque de l’appareil) 208-240V AC ou 110-127V AC
Fréquence 50/60 Hz
Puissance absorbée 25 VA
Catégorie d'installation ll
Conditions environnementales Uniquement utilisation à l’intérieur
Plage de température 5 ÷ 50°C (40 ÷ 120°F)
Plage d’humidité relative 0 ÷ 95%
Raccordements eau 1/2”
Écoulement d’eau
Tuyau 16 mm en plastique de qualité
alimentaire avec courbes en acier
inoxydable
Température maximum de l’eau à l’entrée 65°C (149°F)
Plage de réglage de température 2 ÷ 60°C (36 ÷ 140°F) précision +/- 1°C
Pression maximum d’entrée de l’eau 5 bars (72,5 psi)
Pression minimum d’entrée de l’eau 1 bar (14,5 psi)
Rapport maximum entre les pressions à
l’entrée 1 : 5
Dosage maximal 999,9 L; 99 lb + 15 oz; 999,9 lb
Précision dans le dosage ± 1% (décharge min: 5L)
Débit eau à 1 bar et 20°C 18 L/min (40 lb/min)
Débit eau à 5 bars et 20°C 40 L/min (88 lb/min)
Sonde intérieure Thermorésistance PT1000 Classe A
Sonde extérieure Thermorésistance PT1000 Classe A
Mémoire 80 recettes
Fusible pour l’alimentation 250 V – T250 mA retardé @ 230 V
250 V – T630 mA retardé @ 115 V
Fusible pour télécommande pompe 250 V – F6,3 A
Indice de protection IP 42
1.1. DESCRIPTION (Voir Errore. L'origine riferimento non è stata trovata.)
1. Vannes à sphère
2. Goulottes O-R pour aciliter le montage
3. Filtres double grillage inox pour les impuretés
4. Vannes de non-retour
5. Sonde externe
6. Poignée de réglage de la température
7. Fiche de courant avec usible et rechange et iche pour le contrôle d’une pompe
avec usible et rechange
8. Display des litres ormés, encore à déverser (pendant le dosage) ou déjà déversés
(après avoir appuyé sur STOP).
9. Display du thermomètre électronique interne et de la température sélectionnée
10. Display du thermomètre électronique externe et des programmes
11. Touche pour sélectionner la température ou la quantité, et vice-versa
12. Touches STOP/C et START
13. Tuyau de déversement
14. Raccordement de by-pass
15. Clavier à membrane pour l’introduction des données
16. Série de témoins
