Draper VS4 User manual

34278
EN
Original Instructions
Version 2 – June 2023
Read this manual in full before using this product and retain it for future use.
Always use the latest version of the manual. Please visit
drapertools.com/manuals for the latest version.
1. Intended Use
This product is designed for detecting the presence of AC voltages in outlets,
switches, cables and small electrical components without contact with the
circuit. It can also be used to locate breakages in electrical wiring.
Any other application will be considered misuse. Draper Tools accepts no
responsibility for improper use of this product.
2. Specication
Stock No. 34278
Part No. VS4
Detection capability
Voltage 100–600V AC
Frequency 50, 60Hz
Power 2 x AAA batteries
Appliance standard CAT III 1,000V*
Safe ambient operating temperature -10 to 50°C
Max. ambient humidity
0–30°C 95%
30–40°C 75%
40–50°C 45%
*This product is designed to protect against transient overcurrent from
equipment in xed installations, such as installation panels, feeders,
short branch circuits and lighting systems in large buildings.
3. HealthandSafetyInformation
Read all the Health and Safety instructions before attempting to use this product.
Non-compliance may result in serious injury or death.
WARNING!
Contact with live circuits can result in severe electrical shock.
• ONLY trained and competent personnel may operate this device.
• Use this product ONLY as instructed in this manual.
• Observe all standard precautions and good practice when working with live
electrical currents.
• Inspect the product for damage before every use, particularly the detector tip.
− DO NOT use this product if it is damaged in any way or if there is evidence
of battery leakage.
− If battery acid comes into contact with your skin, wash it o immediately
with plenty of clean water.
− If battery acid comes into contact with your eyes, ush them with plenty of
clean water and seek immediate medical attention.
• Ensue that the device is clean, dry and free from grease before use.
• Check that the detector is operating correctly before each use by testing a
known voltage.
• DO NOT use this product if it exhibits abnormal behaviour and have it checked
by a qualied and authorised technician before next use.
• NEVER use this product to test for the presence of voltages that may be
greater than the rated capability of this device as it may expose you to a
shock hazard.
• Assess any specic additional risks to the operator before each use.
• ALWAYS wear protective insulated gloves while using this product.
• Keep your ngers behind the guard at all times during use.
• DO NOT expose this product to ambient conditions exceeding the rated
safe ranges.
• DO NOT use this this product around explosive gases, vapours or dust.
• DO NOT immerse this device in water or expose it to wet conditions.
• DO NOT abuse, mutilate or burn the battery.
Delta International
Delta International BV
Oude Graaf 8
6002 NL
Weert
Netherlands
Draper Tools
Draper Tools Limited
Hursley Road, Chandler’s Ford
Eastleigh, Hampshire, SO53 1YF UK
Website: drapertools.com
Email: [e-mail]
Product Helpline: [phone]
Telephone Sales Desk: [phone]
General Enquiries: [phone]
General Fax: [phone]
© Published by Draper Tools Limited
NON CONTACT
VO LTAG E
TESTER

34278
EN
Original Instructions
Version 2 – June 2023
Read this manual in full before using this product and retain it for future use.
Always use the latest version of the manual. Please visit
drapertools.com/manuals for the latest version.
1. Intended Use
This product is designed for detecting the presence of AC voltages in outlets,
switches, cables and small electrical components without contact with the
circuit. It can also be used to locate breakages in electrical wiring.
Any other application will be considered misuse. Draper Tools accepts no
responsibility for improper use of this product.
2. Specication
Stock No. 34278
Part No. VS4
Detection capability
Voltage 100–600V AC
Frequency 50, 60Hz
Power 2 x AAA batteries
Appliance standard CAT III 1,000V*
Safe ambient operating temperature -10 to 50°C
Max. ambient humidity
0–30°C 95%
30–40°C 75%
40–50°C 45%
*This product is designed to protect against transient overcurrent from
equipment in xed installations, such as installation panels, feeders,
short branch circuits and lighting systems in large buildings.
3. HealthandSafetyInformation
Read all the Health and Safety instructions before attempting to use this product.
Non-compliance may result in serious injury or death.
WARNING!
Contact with live circuits can result in severe electrical shock.
• ONLY trained and competent personnel may operate this device.
• Use this product ONLY as instructed in this manual.
• Observe all standard precautions and good practice when working with live
electrical currents.
• Inspect the product for damage before every use, particularly the detector tip.
− DO NOT use this product if it is damaged in any way or if there is evidence
of battery leakage.
− If battery acid comes into contact with your skin, wash it o immediately
with plenty of clean water.
− If battery acid comes into contact with your eyes, ush them with plenty of
clean water and seek immediate medical attention.
• Ensue that the device is clean, dry and free from grease before use.
• Check that the detector is operating correctly before each use by testing a
known voltage.
• DO NOT use this product if it exhibits abnormal behaviour and have it checked
by a qualied and authorised technician before next use.
• NEVER use this product to test for the presence of voltages that may be
greater than the rated capability of this device as it may expose you to a
shock hazard.
• Assess any specic additional risks to the operator before each use.
• ALWAYS wear protective insulated gloves while using this product.
• Keep your ngers behind the guard at all times during use.
• DO NOT expose this product to ambient conditions exceeding the rated
safe ranges.
• DO NOT use this this product around explosive gases, vapours or dust.
• DO NOT immerse this device in water or expose it to wet conditions.
• DO NOT abuse, mutilate or burn the battery.
Delta International
Delta International BV
Oude Graaf 8
6002 NL
Weert
Netherlands
Draper Tools
Draper Tools Limited
Hursley Road, Chandler’s Ford
Eastleigh, Hampshire, SO53 1YF UK
Website: drapertools.com
Email: [e-mail]
Product Helpline: [phone]
Telephone Sales Desk: [phone]
General Enquiries: [phone]
General Fax: [phone]
© Published by Draper Tools Limited
NON CONTACT
VO LTAG E
TESTER

34278
EN
Original Instructions
Version 2 – June 2023
Read this manual in full before using this product and retain it for future use.
Always use the latest version of the manual. Please visit
drapertools.com/manuals for the latest version.
1. Intended Use
This product is designed for detecting the presence of AC voltages in outlets,
switches, cables and small electrical components without contact with the
circuit. It can also be used to locate breakages in electrical wiring.
Any other application will be considered misuse. Draper Tools accepts no
responsibility for improper use of this product.
2. Specication
Stock No. 34278
Part No. VS4
Detection capability
Voltage 100–600V AC
Frequency 50, 60Hz
Power 2 x AAA batteries
Appliance standard CAT III 1,000V*
Safe ambient operating temperature -10 to 50°C
Max. ambient humidity
0–30°C 95%
30–40°C 75%
40–50°C 45%
*This product is designed to protect against transient overcurrent from
equipment in xed installations, such as installation panels, feeders,
short branch circuits and lighting systems in large buildings.
3. HealthandSafetyInformation
Read all the Health and Safety instructions before attempting to use this product.
Non-compliance may result in serious injury or death.
WARNING!
Contact with live circuits can result in severe electrical shock.
• ONLY trained and competent personnel may operate this device.
• Use this product ONLY as instructed in this manual.
• Observe all standard precautions and good practice when working with live
electrical currents.
• Inspect the product for damage before every use, particularly the detector tip.
− DO NOT use this product if it is damaged in any way or if there is evidence
of battery leakage.
− If battery acid comes into contact with your skin, wash it o immediately
with plenty of clean water.
− If battery acid comes into contact with your eyes, ush them with plenty of
clean water and seek immediate medical attention.
• Ensue that the device is clean, dry and free from grease before use.
• Check that the detector is operating correctly before each use by testing a
known voltage.
• DO NOT use this product if it exhibits abnormal behaviour and have it checked
by a qualied and authorised technician before next use.
• NEVER use this product to test for the presence of voltages that may be
greater than the rated capability of this device as it may expose you to a
shock hazard.
• Assess any specic additional risks to the operator before each use.
• ALWAYS wear protective insulated gloves while using this product.
• Keep your ngers behind the guard at all times during use.
• DO NOT expose this product to ambient conditions exceeding the rated
safe ranges.
• DO NOT use this this product around explosive gases, vapours or dust.
• DO NOT immerse this device in water or expose it to wet conditions.
• DO NOT abuse, mutilate or burn the battery.
Delta International
Delta International BV
Oude Graaf 8
6002 NL
Weert
Netherlands
Draper Tools
Draper Tools Limited
Hursley Road, Chandler’s Ford
Eastleigh, Hampshire, SO53 1YF UK
Website: drapertools.com
Email: [e-mail]
Product Helpline: [phone]
Telephone Sales Desk: [phone]
General Enquiries: [phone]
General Fax: [phone]
© Published by Draper Tools Limited
NON CONTACT
VO LTAG E
TESTER

• Remove the batteries when the product is stored for extended periods.
• DO NOT attempt to repair this device; it contains no user-serviceable parts.
• Keep this product out of reach of children.
4. Identication
1. Battery cap
2. Detector tip
3. Guard
4. Pocket clip
5. Torch
6. Torch power button
5. InstallingtheBatteries
This product requires two AAA batteries (supplied).
To install the batteries, lift the pocket clip (4) to release the the battery cover and
insert the batteries according to the polarity marked on the side of the device.
Replace the battery cap and tighten it securely.
Important: DO NOT mix old and new batteries.
6. Operation
Important: Test the device on a known voltage before EVERY use. If the device
does not respond as expected, replace the batteries and/or test on another
known voltage. If it continues to operate abnormally, have the unit replaced or
repaired. DO NOT continue to use the device.
When the device detects a voltage at 100–600V AC (50/60Hz), the detector tip (2)
ashes and an audible “beep” is heard.
Important: Maintain a rm and comfortable grip to ensure maximum sensitivity
of the tool.
To test for AC voltage in an outlet, switch, cable or other component, position the
detector tip into the socket or in close proximity to the component.
To locate a break in a live conductor, trace the wire using the detector tip until the
voltage is no longer detected. The point at which the device stops responding
indicates the location of the break. To nd a break in a neutral conductor,
connect a load between live and neutral before tracing the wire.
Important: Lack of response from the device does NOT guarantee that a voltage
is not present. Test the wiring from all sides as the live wire may be shielded from
the detector by other conductors.
The following conditions may cause the device not to respond when a voltage
is present:
• The cable is armoured or in conduit, or the insulation is too thick.
• The cable is concealed by panels or metallic enclosures.
• The voltage is DC.
• The device is positioned too far from the voltage.
• The voltage is less than 90V.
• The operator’s grip on the device is too loose.
To operate the torch (5), press the torch power button (6) once for “on” and again
for “o”.
7. ProductCareandDisposal
This product contains no user-serviceable parts. DO NOT attempt to repair or
service this device. If the device is damaged or functioning incorrectly,
contact Draper Tools for repair and replacement options.
Clean the product using a dry cloth ONLY.
CAUTION! DO NOT use solvents or other aggressive materials as
they my damage plastic or insulated parts.
Store this product in a cool, clean and dry environment, out of direct sunlight
and out of reach of children.
Important: Remove the batteries from the device before storing it for
extended periods.
At the end of its working life, dispose of the product responsibly and in line with
local regulations. Recycle where possible.
• DO NOT dispose of this product with domestic waste; most local authorities
provide appropriate recycling facilities.
• DO NOT burn or mutilate batteries; this may release toxic or corrosive
substances.
• Dispose of batteries separately and in accordance with local regulations.
8. Warranty
Should the tool develop a fault, return the complete tool to your nearest
distributor or contact Draper Tools directly. Proof of purchase must be provided.
If, upon inspection, it is found that the fault occurring is due to defective
materials or workmanship, repairs will be carried out free of charge. This warranty
covers parts and labour for 12 months from the date of purchase. However, if the
tools are hired out, the warranty period is 90 days from the date of purchase.
This warranty does not apply to any consumable parts, batteries or normal wear
and tear, nor does it cover any damage caused by misuse, careless or unsafe
handling, alterations, accidents, or repairs attempted or made by any personnel
other than the authorised Draper Tools repair agent.
Visit drapertools.com/warranty for full details.
9. Symbols
Read the
instruction
manual
Warning!
Do not
incinerate or
throw onto re
Use on
50/60Hz
voltages
Use on
100-600V
voltages
Safe ambient
operating
temperatures
Transient over
Class II
appliance
WEEE –
Waste Electrical &
Electronic Equipment
Do not dispose of Waste Electrical
& Electronic Equipment
in with domestic rubbish
UK Conformity
Assessed
European
conformity
(2)
(3)
(5)
(4)
(6)
(1)

• Remove the batteries when the product is stored for extended periods.
• DO NOT attempt to repair this device; it contains no user-serviceable parts.
• Keep this product out of reach of children.
4. Identication
1. Battery cap
2. Detector tip
3. Guard
4. Pocket clip
5. Torch
6. Torch power button
5. InstallingtheBatteries
This product requires two AAA batteries (supplied).
To install the batteries, push up the battery cap (1) to the outside of the locked
position, then push it up again and insert the batteries according to the polarity
marked on the side of the device. Replace the battery cap and tighten it securely.
Important: DO NOT mix old and new batteries.
6. Operation
Important: Test the device on a known voltage before EVERY use. If the device
does not respond as expected, replace the batteries and/or test on another
known voltage. If it continues to operate abnormally, have the unit replaced or
repaired. DO NOT continue to use the device.
When the device detects a voltage at 100–600V AC (50/60Hz), the detector tip (2)
ashes and an audible “beep” is heard.
Important: Maintain a rm and comfortable grip to ensure maximum sensitivity
of the tool.
To test for AC voltage in an outlet, switch, cable or other component, position the
detector tip into the socket or in close proximity to the component.
To locate a break in a live conductor, trace the wire using the detector tip until the
voltage is no longer detected. The point at which the device stops responding
indicates the location of the break. To nd a break in a neutral conductor,
connect a load between live and neutral before tracing the wire.
Important: Lack of response from the device does NOT guarantee that a voltage
is not present. Test the wiring from all sides as the live wire may be shielded from
the detector by other conductors.
The following conditions may cause the device not to respond when a voltage
is present:
• The cable is armoured or in conduit, or the insulation is too thick.
• The cable is concealed by panels or metallic enclosures.
• The voltage is DC.
• The device is positioned too far from the voltage.
• The voltage is less than 90V.
• The operator’s grip on the device is too loose.
To operate the torch (5), press the torch power button (6) once for “on” and again
for “o”.
7. ProductCareandDisposal
This product contains no user-serviceable parts. DO NOT attempt to repair or
service this device. If the device is damaged or functioning incorrectly,
contact Draper Tools for repair and replacement options.
Clean the product using a dry cloth ONLY.
CAUTION! DO NOT use solvents or other aggressive materials as
they my damage plastic or insulated parts.
Store this product in a cool, clean and dry environment, out of direct sunlight
and out of reach of children.
Important: Remove the batteries from the device before storing it for
extended periods.
At the end of its working life, dispose of the product responsibly and in line with
local regulations. Recycle where possible.
• DO NOT dispose of this product with domestic waste; most local authorities
provide appropriate recycling facilities.
• DO NOT burn or mutilate batteries; this may release toxic or corrosive
substances.
• Dispose of batteries separately and in accordance with local regulations.
8. Warranty
Should the tool develop a fault, return the complete tool to your nearest
distributor or contact Draper Tools directly. Proof of purchase must be provided.
If, upon inspection, it is found that the fault occurring is due to defective
materials or workmanship, repairs will be carried out free of charge. This warranty
covers parts and labour for 12 months from the date of purchase. However, if the
tools are hired out, the warranty period is 90 days from the date of purchase.
This warranty does not apply to any consumable parts, batteries or normal wear
and tear, nor does it cover any damage caused by misuse, careless or unsafe
handling, alterations, accidents, or repairs attempted or made by any personnel
other than the authorised Draper Tools repair agent.
Visit drapertools.com/warranty for full details.
9. Symbols
Read the
instruction
manual
Warning!
Do not
incinerate or
throw onto re
Use on
50/60Hz
voltages
Use on
100-600V
voltages
Safe ambient
operating
temperatures
Transient over
Class II
appliance
WEEE –
Waste Electrical &
Electronic Equipment
Do not dispose of Waste Electrical
& Electronic Equipment
in with domestic rubbish
UK Conformity
Assessed
European
conformity
(2)
(3)
(5)
(4)
(6)
(1)

34278
EN
Original Instructions
Version 2 – June 2023
Read this manual in full before using this product and retain it for future use.
Always use the latest version of the manual. Please visit
drapertools.com/manuals for the latest version.
1. Intended Use
This product is designed for detecting the presence of AC voltages in outlets,
switches, cables and small electrical components without contact with the
circuit. It can also be used to locate breakages in electrical wiring.
Any other application will be considered misuse. Draper Tools accepts no
responsibility for improper use of this product.
2. Specication
Stock No. 34278
Part No. VS4
Detection capability
Voltage 100–600V AC
Frequency 50, 60Hz
Power 2 x AAA batteries
Appliance standard CAT III 1,000V*
Safe ambient operating temperature -10 to 50°C
Max. ambient humidity
0–30°C 95%
30–40°C 75%
40–50°C 45%
*This product is designed to protect against transient overcurrent from
equipment in xed installations, such as installation panels, feeders,
short branch circuits and lighting systems in large buildings.
3. HealthandSafetyInformation
Read all the Health and Safety instructions before attempting to use this product.
Non-compliance may result in serious injury or death.
WARNING!
Contact with live circuits can result in severe electrical shock.
• ONLY trained and competent personnel may operate this device.
• Use this product ONLY as instructed in this manual.
• Observe all standard precautions and good practice when working with live
electrical currents.
• Inspect the product for damage before every use, particularly the detector tip.
− DO NOT use this product if it is damaged in any way or if there is evidence
of battery leakage.
− If battery acid comes into contact with your skin, wash it o immediately
with plenty of clean water.
− If battery acid comes into contact with your eyes, ush them with plenty of
clean water and seek immediate medical attention.
• Ensue that the device is clean, dry and free from grease before use.
• Check that the detector is operating correctly before each use by testing a
known voltage.
• DO NOT use this product if it exhibits abnormal behaviour and have it checked
by a qualied and authorised technician before next use.
• NEVER use this product to test for the presence of voltages that may be
greater than the rated capability of this device as it may expose you to a
shock hazard.
• Assess any specic additional risks to the operator before each use.
• ALWAYS wear protective insulated gloves while using this product.
• Keep your ngers behind the guard at all times during use.
• DO NOT expose this product to ambient conditions exceeding the rated
safe ranges.
• DO NOT use this this product around explosive gases, vapours or dust.
• DO NOT immerse this device in water or expose it to wet conditions.
• DO NOT abuse, mutilate or burn the battery.
Delta International
Delta International BV
Oude Graaf 8
6002 NL
Weert
Netherlands
Draper Tools
Draper Tools Limited
Hursley Road, Chandler’s Ford
Eastleigh, Hampshire, SO53 1YF UK
Website: drapertools.com
Email: [email protected]
Product Helpline: [phone]
Telephone Sales Desk: [phone]
General Enquiries: [phone]
General Fax: [phone]
© Published by Draper Tools Limited
NON CONTACT
VO LTAG E
TESTER
