Draper BBFC2 User manual

90478
EN
Original Instructions
Version 3 – September 2023
Read this manual in full before using this product and retain it for future use.
Always use the latest version of the manual. Please visit
drapertools.com/manuals for the latest version.
1. Intended Use
This multipurpose tester may be used to indicate the power levels of dry cell
1.5V batteries (AAA, AA, C, D and button type), 9V batteries (PP3 and 6LR61),
and to test household and automotive fuses, domestic lament bulbs with
bayonet tting, and push/screw-type torch light bulbs for continuity. Any other
application beyond the conditions established for use will be considered misuse.
Draper Tools accepts no responsibility for improper use of this product.
2. Specication
Stock No. 90478
Part No. BBFC2
3. HealthandSafetyInformation
Important: Read all the Health and Safety instructions before attempting to use
this product. Non-compliance may result in serious injury or death.
• Use this product ONLY as instructed in this manual.
• DO NOT attempt to open, dismantle or modify this product in any way.
• Use ONLY accessories and spare parts supplied by Draper Tools.
− DO NOT use any other leads with this product than those supplied.
Contact Draper Tools for replacement options if the leads
become damaged.
• Observe all standard precautions and good practice when working with live
electrical components and currents.
• Before every use, inspect the device for missing, broken, loose or corroded
parts and battery leakage.
− DO NOT use this product if it is damaged in any way; contact Draper
Tools to discuss repair and replacement options.
− If battery acid comes into contact with your skin, wash it o
immediately with plenty of clean water.
− If battery acid comes into contact with your eyes, ush them with plenty
of clean water and seek immediate medical attention.
• Ensure that the device is clean, dry and free from grease before use.
• DO NOT use this product if it exhibits abnormal behaviour and have it checked
by a qualied and authorised technician before next use.
• DO NOT exceed the maximum rated capacity per function for this device as it
may expose you to a shock hazard.
• DO NOT expose this product to excessive ambient temperature, high humidity,
ammable substances or environments that produce a strong magnetic eld.
• DO NOT use this this product around explosive gases, vapours or dust.
• DO NOT immerse this device in water or expose it to wet conditions.
• ALWAYS wear protective insulated gloves while using this product.
• Keep your ngers behind the guards at all times when using the probes.
• ALWAYS remove the contact cables from the device before accessing the
battery compartment.
• DO NOT operate this device with the battery compartment open or missing.
• NEVER insert the probe contacts into the device terminals.
• DO NOT apply any voltage to the probes.
• DO NOT short any of the tester terminals.
• NEVER test batteries that show evidence of leakage.
• ALWAYS ensure that batteries are tested using the correct polarity.
• NEVER test items using contacts that were not designed for that item.
• DO NOT abuse, mutilate or burn the battery.
• Remove the batteries when the product is stored for extended periods.
• Keep this product out of reach of children.
Important: When performing a continuity test, disconnect the power and allow
all capacitors to discharge before measurement.
WARNING! NEVER measure resistance across a voltage source or on a
powered circuit.
Delta International
Delta International BV
Oude Graaf 8
6002 NL
Weert
Netherlands
Draper Tools
Draper Tools Limited
Hursley Road, Chandler’s Ford
Eastleigh, Hampshire, SO53 1YF UK
Website: drapertools.com
Email: [e-mail]
Product Helpline: [phone]
Telephone Sales Desk: [phone]
General Enquiries: [phone]
General Fax: [phone]
© Published by Draper Tools Limited
BATTERY, BULB,
FUSE & CONTINUITY
TESTER
8. ExplanationofSymbols
WEEE – Waste Electrical &
Electronic Equipment
Do not dispose of Waste Electrical
& Electronic Equipment
in with domestic rubbish
Read the
instruction manual
Suitable for testing
1.5V and 9V batteries
Warning!
This product
emits noise
UK Conformity
Assessed
European conformity

90478
EN
Original Instructions
Version 3 – September 2023
Read this manual in full before using this product and retain it for future use.
Always use the latest version of the manual. Please visit
drapertools.com/manuals for the latest version.
1. Intended Use
This multipurpose tester may be used to indicate the power levels of dry cell
1.5V batteries (AAA, AA, C, D and button type), 9V batteries (PP3 and 6LR61),
and to test household and automotive fuses, domestic lament bulbs with
bayonet tting, and push/screw-type torch light bulbs for continuity. Any other
application beyond the conditions established for use will be considered misuse.
Draper Tools accepts no responsibility for improper use of this product.
2. Specication
Stock No. 90478
Part No. BBFC2
3. HealthandSafetyInformation
Important: Read all the Health and Safety instructions before attempting to use
this product. Non-compliance may result in serious injury or death.
• Use this product ONLY as instructed in this manual.
• DO NOT attempt to open, dismantle or modify this product in any way.
• Use ONLY accessories and spare parts supplied by Draper Tools.
− DO NOT use any other leads with this product than those supplied.
Contact Draper Tools for replacement options if the leads
become damaged.
• Observe all standard precautions and good practice when working with live
electrical components and currents.
• Before every use, inspect the device for missing, broken, loose or corroded
parts and battery leakage.
− DO NOT use this product if it is damaged in any way; contact Draper
Tools to discuss repair and replacement options.
− If battery acid comes into contact with your skin, wash it o
immediately with plenty of clean water.
− If battery acid comes into contact with your eyes, ush them with plenty
of clean water and seek immediate medical attention.
• Ensure that the device is clean, dry and free from grease before use.
• DO NOT use this product if it exhibits abnormal behaviour and have it checked
by a qualied and authorised technician before next use.
• DO NOT exceed the maximum rated capacity per function for this device as it
may expose you to a shock hazard.
• DO NOT expose this product to excessive ambient temperature, high humidity,
ammable substances or environments that produce a strong magnetic eld.
• DO NOT use this this product around explosive gases, vapours or dust.
• DO NOT immerse this device in water or expose it to wet conditions.
• ALWAYS wear protective insulated gloves while using this product.
• Keep your ngers behind the guards at all times when using the probes.
• ALWAYS remove the contact cables from the device before accessing the
battery compartment.
• DO NOT operate this device with the battery compartment open or missing.
• NEVER insert the probe contacts into the device terminals.
• DO NOT apply any voltage to the probes.
• DO NOT short any of the tester terminals.
• NEVER test batteries that show evidence of leakage.
• ALWAYS ensure that batteries are tested using the correct polarity.
• NEVER test items using contacts that were not designed for that item.
• DO NOT abuse, mutilate or burn the battery.
• Remove the batteries when the product is stored for extended periods.
• Keep this product out of reach of children.
Important: When performing a continuity test, disconnect the power and allow
all capacitors to discharge before measurement.
WARNING! NEVER measure resistance across a voltage source or on a
powered circuit.
Delta International
Delta International BV
Oude Graaf 8
6002 NL
Weert
Netherlands
Draper Tools
Draper Tools Limited
Hursley Road, Chandler’s Ford
Eastleigh, Hampshire, SO53 1YF UK
Website: drapertools.com
Email: [e-mail]
Product Helpline: [phone]
Telephone Sales Desk: [phone]
General Enquiries: [phone]
General Fax: [phone]
© Published by Draper Tools Limited
BATTERY, BULB,
FUSE & CONTINUITY
TESTER
8. ExplanationofSymbols
WEEE – Waste Electrical &
Electronic Equipment
Do not dispose of Waste Electrical
& Electronic Equipment
in with domestic rubbish
Read the
instruction manual
Suitable for testing
1.5V and 9V batteries
Warning!
This product
emits noise
UK Conformity
Assessed
European conformity

90478
EN
Original Instructions
Version 3 – September 2023
Read this manual in full before using this product and retain it for future use.
Always use the latest version of the manual. Please visit
drapertools.com/manuals for the latest version.
1. Intended Use
This multipurpose tester may be used to indicate the power levels of dry cell
1.5V batteries (AAA, AA, C, D and button type), 9V batteries (PP3 and 6LR61),
and to test household and automotive fuses, domestic lament bulbs with
bayonet tting, and push/screw-type torch light bulbs for continuity. Any other
application beyond the conditions established for use will be considered misuse.
Draper Tools accepts no responsibility for improper use of this product.
2. Specication
Stock No. 90478
Part No. BBFC2
3. HealthandSafetyInformation
Important: Read all the Health and Safety instructions before attempting to use
this product. Non-compliance may result in serious injury or death.
• Use this product ONLY as instructed in this manual.
• DO NOT attempt to open, dismantle or modify this product in any way.
• Use ONLY accessories and spare parts supplied by Draper Tools.
− DO NOT use any other leads with this product than those supplied.
Contact Draper Tools for replacement options if the leads
become damaged.
• Observe all standard precautions and good practice when working with live
electrical components and currents.
• Before every use, inspect the device for missing, broken, loose or corroded
parts and battery leakage.
− DO NOT use this product if it is damaged in any way; contact Draper
Tools to discuss repair and replacement options.
− If battery acid comes into contact with your skin, wash it o
immediately with plenty of clean water.
− If battery acid comes into contact with your eyes, ush them with plenty
of clean water and seek immediate medical attention.
• Ensure that the device is clean, dry and free from grease before use.
• DO NOT use this product if it exhibits abnormal behaviour and have it checked
by a qualied and authorised technician before next use.
• DO NOT exceed the maximum rated capacity per function for this device as it
may expose you to a shock hazard.
• DO NOT expose this product to excessive ambient temperature, high humidity,
ammable substances or environments that produce a strong magnetic eld.
• DO NOT use this this product around explosive gases, vapours or dust.
• DO NOT immerse this device in water or expose it to wet conditions.
• ALWAYS wear protective insulated gloves while using this product.
• Keep your ngers behind the guards at all times when using the probes.
• ALWAYS remove the contact cables from the device before accessing the
battery compartment.
• DO NOT operate this device with the battery compartment open or missing.
• NEVER insert the probe contacts into the device terminals.
• DO NOT apply any voltage to the probes.
• DO NOT short any of the tester terminals.
• NEVER test batteries that show evidence of leakage.
• ALWAYS ensure that batteries are tested using the correct polarity.
• NEVER test items using contacts that were not designed for that item.
• DO NOT abuse, mutilate or burn the battery.
• Remove the batteries when the product is stored for extended periods.
• Keep this product out of reach of children.
Important: When performing a continuity test, disconnect the power and allow
all capacitors to discharge before measurement.
WARNING! NEVER measure resistance across a voltage source or on a
powered circuit.
Delta International
Delta International BV
Oude Graaf 8
6002 NL
Weert
Netherlands
Draper Tools
Draper Tools Limited
Hursley Road, Chandler’s Ford
Eastleigh, Hampshire, SO53 1YF UK
Website: drapertools.com
Email: [e-mail]
Product Helpline: [phone]
Telephone Sales Desk: [phone]
General Enquiries: [phone]
General Fax: [phone]
© Published by Draper Tools Limited
BATTERY, BULB,
FUSE & CONTINUITY
TESTER
8. ExplanationofSymbols
WEEE – Waste Electrical &
Electronic Equipment
Do not dispose of Waste Electrical
& Electronic Equipment
in with domestic rubbish
Read the
instruction manual
Suitable for testing
1.5V and 9V batteries
Warning!
This product
emits noise
UK Conformity
Assessed
European conformity

4. Identication
(1) 1.5V battery test contacts
(2) 9V battery test contacts
(3) Fuse storage
(4) Battery compartment
(5) Continuity test probes
(6) Fuse test contacts
(7) Gauge
(8) Lightbulb test contacts
(9) Negative (black) probe
(10) Negative probe terminal
(11) Positive (red) probe
(12) Positive probe terminal
5. OperatingInstructions
Important: Before operating this product, read and understand all the safety
instructions listed in this manual.
5.1 InstallingtheBattery
Slide the battery cover away from the battery compartment (4) on the rear of
the device and connect a 9V PP3 or equivalent battery to the contacts according
to the correct polarity. Insert the battery into the compartment and reinstall
the cover.
Important: DO NOT operate this device without the battery compartment cover
in place.
5.2 Testing1.5VBatteries(AAA,AA,C,Detc.)
1. Position the lower 1.5V battery test contact (1)
as appropriate and insert the battery according
to the marked polarity (Fig. 1).
2. To read the battery level, observe the position of
the gauge (7) needle against the scale band
marked “1.5V”.
− Green: The battery level is good.
− Yellow: The battery level is low.
− Red: The battery level is very low and the
battery cannot be used.
5.3 Testing9VBatteries(6F22,006P,etc.)
1. Connect the battery to the 9V battery test
contacts (2) according to the marked polarity
(Fig. 2).
2. To read the battery level, observe the position of
the gauge (7) needle against the scale band
marked “9V”.
− Green: The battery level is good.
− Yellow: The battery level is low.
− Red: The battery level is very low and the
battery cannot be used.
5.4 TestingFuses
1. Place the fuse against the fuse test contacts (6)
(Fig. 3).
2. To read the state of the fuse, observe the
position of the gauge (7) needle against the
scale band marked “Test continuity”.
− Green: The fuse may be used in an
appropriate appliance.
− Red: The fuse is in an open circuit state.
5.5 TestingBulbs
1. Place the two bulb terminals against two of the
three lightbulb test contacts (8), depending on
the type of bulb (Fig. 4).
2. To read the state of the bulb, observe the
position of the gauge (7) needle against the
scale band marked “Test continuity”.
− Green: The bulb may be used in an
appropriate appliance.
− Red: The bulb is damaged and cannot
be used.
5.6 ContinuityTesting
1. Insert the probe connectors into the
terminals on the device:
− The negative (black) probe (9)
connects to the left (negative)
terminal (10).
− The positive (red) probe (11)
connects to the right (positive)
terminal (12).
2. Disconnect all power to the
circuit to be tested and discharge
all capacitors.
WARNING! NEVER measure
resistance across a voltage
source or on a powered circuit.
3. Connect the probes across the circuit to be tested, observing the
correct polarity.
4. An audible alarm will sound if the circuit resistance is <5,000Ω.
Important: If the resistance is between 5,000–10,000Ω, the alarm may or may
not sound.
6. ProductCare,StorageandDisposal
• Keep the product clean and free from dust, debris and grease.
• Use a dry cloth ONLY to clean the housing of this device.
CAUTION! DO NOT use abrasives, solvents or other aggressive
chemicals as these may damage plastic or insulated parts.
• Replace the probes IMMEDIATELY if they are damaged in any way or the
conductors are exposed; contact Draper Tools for replacement options.
• Remove the battery when storing the device for extended periods; it can be
stored in the battery storage compartment (4).
• Store the device in a cool, clean and dry environment, out of direct sunlight
and out of reach of children.
At the end of its working life, dispose of the product responsibly and in line with
local regulations. Recycle where possible.
• DO NOT dispose of this product with domestic waste; most local authorities
provide appropriate recycling facilities. [add WEEE symbol]
• DO NOT burn or mutilate batteries; this may release toxic or corrosive
substances. [add re symbol]
• Dispose of batteries separately and in accordance with local regulations.
7. Warranty
Should the tool develop a fault, return the complete tool to your nearest
distributor or contact Draper Tools directly. Proof of purchase must be provided.
If, upon inspection, it is found that the fault occurring is due to defective
materials or workmanship, repairs will be carried out free of charge. This warranty
covers parts and labour for 12 months from the date of purchase. However, if the
tools are hired out, the warranty period is 90 days from the date of purchase.
This warranty does not apply to any consumable parts, batteries or normal wear
and tear, nor does it cover any damage caused by misuse, careless or unsafe
handling, alterations, accidents, or repairs attempted or made by any personnel
other than the authorised Draper Tools repair agent.
Visit drapertools.com/warranty for full details.
Fig. 1
Fig. 2
Fig. 3
Fig. 4
Fig. 5
(6)
(1)
(12)
(1)
(4)
(2)
(10)
(3)
(5)
(8)
(7)
(11)
(9)

4. Identication
(1) 1.5V battery test contacts
(2) 9V battery test contacts
(3) Fuse storage
(4) Battery compartment
(5) Continuity test probes
(6) Fuse test contacts
(7) Gauge
(8) Lightbulb test contacts
(9) Negative (black) probe
(10) Negative probe terminal
(11) Positive (red) probe
(12) Positive probe terminal
5. OperatingInstructions
Important: Before operating this product, read and understand all the safety
instructions listed in this manual.
5.1 InstallingtheBattery
Slide the battery cover away from the battery compartment (4) on the rear of
the device and connect a 9V PP3 or equivalent battery to the contacts according
to the correct polarity. Insert the battery into the compartment and reinstall
the cover.
Important: DO NOT operate this device without the battery compartment cover
in place.
5.2 Testing1.5VBatteries(AAA,AA,C,Detc.)
1. Position the lower 1.5V battery test contact (1)
as appropriate and insert the battery according
to the marked polarity (Fig. 1).
2. To read the battery level, observe the position of
the gauge (7) needle against the scale band
marked “1.5V”.
− Green: The battery level is good.
− Yellow: The battery level is low.
− Red: The battery level is very low and the
battery cannot be used.
5.3 Testing9VBatteries(6F22,006P,etc.)
1. Connect the battery to the 9V battery test
contacts (2) according to the marked polarity
(Fig. 2).
2. To read the battery level, observe the position of
the gauge (7) needle against the scale band
marked “9V”.
− Green: The battery level is good.
− Yellow: The battery level is low.
− Red: The battery level is very low and the
battery cannot be used.
5.4 TestingFuses
1. Place the fuse against the fuse test contacts (6)
(Fig. 3).
2. To read the state of the fuse, observe the
position of the gauge (7) needle against the
scale band marked “Test continuity”.
− Green: The fuse may be used in an
appropriate appliance.
− Red: The fuse is in an open circuit state.
5.5 TestingBulbs
1. Place the two bulb terminals against two of the
three lightbulb test contacts (8), depending on
the type of bulb (Fig. 4).
2. To read the state of the bulb, observe the
position of the gauge (7) needle against the
scale band marked “Test continuity”.
− Green: The bulb may be used in an
appropriate appliance.
− Red: The bulb is damaged and cannot
be used.
5.6 ContinuityTesting
1. Insert the probe connectors into the
terminals on the device:
− The negative (black) probe (9)
connects to the left (negative)
terminal (10).
− The positive (red) probe (11)
connects to the right (positive)
terminal (12).
2. Disconnect all power to the
circuit to be tested and discharge
all capacitors.
WARNING! NEVER measure
resistance across a voltage
source or on a powered circuit.
3. Connect the probes across the circuit to be tested, observing the
correct polarity.
4. An audible alarm will sound if the circuit resistance is <5,000Ω.
Important: If the resistance is between 5,000–10,000Ω, the alarm may or may
not sound.
6. ProductCare,StorageandDisposal
• Keep the product clean and free from dust, debris and grease.
• Use a dry cloth ONLY to clean the housing of this device.
CAUTION! DO NOT use abrasives, solvents or other aggressive
chemicals as these may damage plastic or insulated parts.
• Replace the probes IMMEDIATELY if they are damaged in any way or the
conductors are exposed; contact Draper Tools for replacement options.
• Remove the battery when storing the device for extended periods; it can be
stored in the battery storage compartment (4).
• Store the device in a cool, clean and dry environment, out of direct sunlight
and out of reach of children.
At the end of its working life, dispose of the product responsibly and in line with
local regulations. Recycle where possible.
• DO NOT dispose of this product with domestic waste; most local authorities
provide appropriate recycling facilities. [add WEEE symbol]
• DO NOT burn or mutilate batteries; this may release toxic or corrosive
substances. [add re symbol]
• Dispose of batteries separately and in accordance with local regulations.
7. Warranty
Should the tool develop a fault, return the complete tool to your nearest
distributor or contact Draper Tools directly. Proof of purchase must be provided.
If, upon inspection, it is found that the fault occurring is due to defective
materials or workmanship, repairs will be carried out free of charge. This warranty
covers parts and labour for 12 months from the date of purchase. However, if the
tools are hired out, the warranty period is 90 days from the date of purchase.
This warranty does not apply to any consumable parts, batteries or normal wear
and tear, nor does it cover any damage caused by misuse, careless or unsafe
handling, alterations, accidents, or repairs attempted or made by any personnel
other than the authorised Draper Tools repair agent.
Visit drapertools.com/warranty for full details.
Fig. 1
Fig. 2
Fig. 3
Fig. 4
Fig. 5
(6)
(1)
(12)
(1)
(4)
(2)
(10)
(3)
(5)
(8)
(7)
(11)
(9)

90478
EN
Original Instructions
Version 3 – September 2023
Read this manual in full before using this product and retain it for future use.
Always use the latest version of the manual. Please visit
drapertools.com/manuals for the latest version.
1. Intended Use
This multipurpose tester may be used to indicate the power levels of dry cell
1.5V batteries (AAA, AA, C, D and button type), 9V batteries (PP3 and 6LR61),
and to test household and automotive fuses, domestic lament bulbs with
bayonet tting, and push/screw-type torch light bulbs for continuity. Any other
application beyond the conditions established for use will be considered misuse.
Draper Tools accepts no responsibility for improper use of this product.
2. Specication
Stock No. 90478
Part No. BBFC2
3. HealthandSafetyInformation
Important: Read all the Health and Safety instructions before attempting to use
this product. Non-compliance may result in serious injury or death.
• Use this product ONLY as instructed in this manual.
• DO NOT attempt to open, dismantle or modify this product in any way.
• Use ONLY accessories and spare parts supplied by Draper Tools.
− DO NOT use any other leads with this product than those supplied.
Contact Draper Tools for replacement options if the leads
become damaged.
• Observe all standard precautions and good practice when working with live
electrical components and currents.
• Before every use, inspect the device for missing, broken, loose or corroded
parts and battery leakage.
− DO NOT use this product if it is damaged in any way; contact Draper
Tools to discuss repair and replacement options.
− If battery acid comes into contact with your skin, wash it o
immediately with plenty of clean water.
− If battery acid comes into contact with your eyes, ush them with plenty
of clean water and seek immediate medical attention.
• Ensure that the device is clean, dry and free from grease before use.
• DO NOT use this product if it exhibits abnormal behaviour and have it checked
by a qualied and authorised technician before next use.
• DO NOT exceed the maximum rated capacity per function for this device as it
may expose you to a shock hazard.
• DO NOT expose this product to excessive ambient temperature, high humidity,
ammable substances or environments that produce a strong magnetic eld.
• DO NOT use this this product around explosive gases, vapours or dust.
• DO NOT immerse this device in water or expose it to wet conditions.
• ALWAYS wear protective insulated gloves while using this product.
• Keep your ngers behind the guards at all times when using the probes.
• ALWAYS remove the contact cables from the device before accessing the
battery compartment.
• DO NOT operate this device with the battery compartment open or missing.
• NEVER insert the probe contacts into the device terminals.
• DO NOT apply any voltage to the probes.
• DO NOT short any of the tester terminals.
• NEVER test batteries that show evidence of leakage.
• ALWAYS ensure that batteries are tested using the correct polarity.
• NEVER test items using contacts that were not designed for that item.
• DO NOT abuse, mutilate or burn the battery.
• Remove the batteries when the product is stored for extended periods.
• Keep this product out of reach of children.
Important: When performing a continuity test, disconnect the power and allow
all capacitors to discharge before measurement.
WARNING! NEVER measure resistance across a voltage source or on a
powered circuit.
Delta International
Delta International BV
Oude Graaf 8
6002 NL
Weert
Netherlands
Draper Tools
Draper Tools Limited
Hursley Road, Chandler’s Ford
Eastleigh, Hampshire, SO53 1YF UK
Website: drapertools.com
Email: [email protected]
Product Helpline: [phone]
Telephone Sales Desk: [phone]
General Enquiries: [phone]
General Fax: [phone]
© Published by Draper Tools Limited
BATTERY, BULB,
FUSE & CONTINUITY
TESTER
8. ExplanationofSymbols
WEEE – Waste Electrical &
Electronic Equipment
Do not dispose of Waste Electrical
& Electronic Equipment
in with domestic rubbish
Read the
instruction manual
Suitable for testing
1.5V and 9V batteries
Warning!
This product
emits noise
UK Conformity
Assessed
European conformity
