VigorSwitch P2280x / G2280x
L2+ Managed Switch
Quick Start Guide
Version: 1.1
Firmware Version: V2.6.6
(For future update, please visit DrayTek web site)
Date: July 12, 2021

1
P
Pa ac ck ka ag ge e C Co on nt te en nt t
VigorSwitch P2280x (with PoE) VigorSwitch G2280x (without PoE)
Rack Mount Kit (brackets) &
Quick Start Guide
Console Cable
The type of the power cord depends on the country that the switch will be
installed.
UK-type Power Cord EU-type Power Cord
USA/Taiwan-type Power Cord AU/NZ-type Power Cord
If any of these items is found missing or damaged, please contact your local
supplier for replacement.

2
P
Pa an ne el l E Ex xp pl la an na at ti io on n
LED Status Explanation
On (Red) An alert for system failure due to overheating
or wrong voltage.
Monitor Off The device is in normal condition and running
normally.
Blinking
(Green) The power is over (>) 80% watts PoE power budget.
Alert
(for P2280x) Off The power is under (<) 80% watts PoE power
budget.
On (Green)
The switch finishes system booting and the
system is ready.
Blinking
(Green) The switch is powered on and starts system booting.
SYS
Off The power is off or the system is not ready /
malfunctioning.
On (Green)
The device is powered on and running
normally.
PWR Off The device is not ready or is failed.
On (Green) The port is supplied with PoE power.
Port 1 ~ 24
(PoE, for P2280x)
Off No PoE power is supplied on the port.
On (Green) The device is connected with 1000Mbps.
On
(Amber) The device is connected with 10/100Mbps.
Blinking The system is sending or receiving data
through the port.
Port 1 ~ 24
(GbE RJ45)
Off The port is disconnected or the link is failed.
Port 25 ~ 28 On (Green)
The device is connected with 1000Mbps.
Port 25 to 28
(SFP+)
Port 1 to 24 (GbE RJ45)
Port 1 to 24 (PoE)

3
On (Blue) The device is connected with 10Gbps.
On
(Amber) The device is connected with 10/100Mbps.
Blinking The system is sending or receiving data
through the port.
(SFP+)
Off The port is disconnected or the link is failed.
Interface Description
Port 1 ~ 24 (GbE RJ45)
Port 1 ~ 24 (PoE, for P2280x)
Port 1 to Port 24 can be used for Ethernet
connection and PoE connection, depending on
the device connected.
Port 25 ~ 28 (SFP+) Port 25 to Port 28 are used for fiber
connection.
Console Used to perform telnet command control.
Power inlet for AC input (100~240V/AC,
50/60Hz).
Note
The following limitation is suitable for VigorSwitch P2280x
Power Output --
IEEE 802.3af Max. 15.4W Output Supported
IEEE 802.3at Max. 30W Output Supported
PoE Power Budget –-
400 Watts (Max)

4
H
Ha ar rd dw wa ar re e I In ns st ta al ll la at ti io on n
This section will guide you to install the switch through hardware connection and
configure the switch’s settings through web browser.
Before starting to configure the switch, you have to connect your devices
correctly.
Note
Power the device to this switch and get 54V power source through
Cat. 5e Cable.
3
3. .1 1 N Ne et tw wo or rk k C Co on nn ne ec ct ti io on n
Use a Cat. 5e twisted-pair cable to connect a PoE device to the port (1~24)
of this switch.
The switch will supply power to PoE Device over the twisted-pair cable.
Please note that Power Device must comply with IEEE 802.3af/at.
Other PCs, servers and network devices can be connected to the switch using
a standard ‘straight through’ twisted pair cable.
(Take VigorSwitch P2280x as an example)

5
3
3. .2 2 R Ra ac ck k- -M Mo ou un nt te ed d I In ns st ta al ll la at ti io on n
The switch can be installed easily by using rack mount kit.
1. Fasten the rack mount kit on both sides of the VigorSwitch using specific
screws.
2. Then, install the VigorSwitch (with rack mount kit) on the 19-inch chassis by
using other four screws.

6
S
So of ft tw wa ar re e C Co on nf fi ig gu ur ra at ti io on n
In this section, we take VigorSwitch G2280x as an example:
Before using the switch, perform the following steps:
1. Set up a physical path between the configured the switch and a PC by a
qualified UTP Cat. 5e cable with RJ-45 connector.
If a PC directly connects to the switch, you have to setup the same subnet mask for
PC and the switch. Default values of the managed switch are listed as follows:
IP Address 192.168.1.224
Subnet Mask 255.255.255.0
DHCP Client Enabled (On)
Username admin
Password admin
2. After configuring correct IP address on your PC, open your web browser and
access switch's IP address.
The home page of VigorSwitch will be shown as below:

7
C
Cu us st to om me er r S Se er rv vi ic ce e
If the switch cannot work correctly after trying many efforts, please contact your
dealer for further help right away. For any questions, please feel free to send
e-mail to [email protected].
GPL Notice This DrayTek product uses software partially or completely licensed under
the terms of the GNU GENERAL PUBLIC LICENSE. The author of the software
does not provide any warranty. A Limited Warranty is offered on DrayTek
products. This Limited Warranty does not cover any software applications or
programs.
To download source codes please visit:
http://gplsource.draytek.com
GNU GENERAL PUBLIC LICENSE:
https://gnu.org/licenses/gpl-2.0
Version 2, June 1991
For any question, please feel free to contact DrayTek technical support at
[email protected] for further information.
B
Be e a a R Re eg gi is st te er re ed d O Ow wn ne er r
Web registration is preferred. You can register your Vigor router via
https://myvigor.draytek.com.
F
Fi ir rm mw wa ar re e & & T To oo ol ls s U Up pd da at te es s
Due to the continuous evolution of DrayTek technology, all switches will be regularly upgraded.
Please consult the DrayTek web site for more information on newest firmware, tools and
documents. https://www.draytek.com

8
