Drive DeVilbiss SWALL002 User manual

Wall Mounted
Shower Seat
User Manual
Drive DeVilbiss Healthcare Ltd, Heathfield Lane,
Birkenshaw, West Yorkshire, BD11 2HW
Tel: [phone] | Fax: [phone]
Email: [e-mail]
www.drivedevilbiss.co.uk
Your Drive DeVilbiss branded product is
warranted to be free of defects in materials and
workmanship for one year from date of purchase.
This device was built to exacting standards and
carefully inspected prior to shipment. This
warranty is an expression of our confidence in the
materials and workmanship of our products and
our assurance to the customer.
In the event of a defect covered by this warranty,
we will at our option supply parts or replace the
device.
This warranty does not cover device failure due
to owner misuse or negligence, or normal wear
and tear. The warranty does not extend to non-
durable components, such as rubber accessories,
castors and grips, which are subject to normal
wear and need periodic replacement.
If you have any queries or require full warranty
conditions, contact your Drive DeVilbiss stockist.
warranty details

introduction
The Drive DeVilbiss Folding Shower Seat is
available in two models. The SWALL002 is
constructed from aluminium and features height
adjustable legs for support.
The SWALL001 is constructed from sturdy
powder coated steel. Both models feature a HD
polyethylene seat with drainage holes and fold
away to the wall to save space when not
required.
installation
Both models must be permanently fitted to a wall
before use. They feature six 8mm diameter holes,
and should only be fitted by a competent person
and fastened to a wall which has the capacity to
withstand the vertical load and leverage applied
during use. Fasteners are not supplied because
the method of fixing will depend on material and
thickness of the wall. The person fitting the seat
will be able to supply suitable fasteners.
For the SWALL002, set the required leg height
before installing the plate to the wall. To set the
leg height pull out 'E' clip retaining the leg. Slide
the leg to the required position and reinsert the
'E' clip. Repeat for the other leg, ensuring before
legs are set to the same height.
cleaning and maintenance
Both models require minimal maintenance.
Periodically check the wall fasteners and pivot
points are secure.
To clean the seat, occasionally wipe the seat with
a soft cloth using a mild household detergent or
disinfectant and warm water. Do not use harsh
abrasives or bleach as these can cause damage
and/or discolouration.
shower seat safety
!The bath seat should only be used as an aid
for sitting. Do not stand on or misuse the
bath seat.
!Do not exceed the weight limit of the seat.
!Some users and children may require
supervision whilst using the bath seat.
specification
Model: SWALL001 - Maximum User Weight 115kg
Model: SWALL002 - Maximum User Weight 160kg
On both models, the seat is 48cm (19”) wide x
29cm (11”) deep and 12cm (5”) from the wall.
The height on the SWALL002 is 43 - 58cm
(17” - 23”) to the top of the seat.
The SWALL001
is illustarated
right:
