About this Manual
Thank you for selecting this Emergency Lighting Inverter System (ELI). It provides you with perfect
protection for connected loads and equipment. This manual contains Important instructions that
should be followed during maintenance of the DSPM Uninterruptible Power Supply. It includes im-
portant safety and maintenance instructions for operating the Emergency Lighting Inverter System.
If you should have any problems with the Emergency Lighting Inverter System, please refer to this
manual and/or call technical support.
Your DSPM Uninterruptible Power Supply is designed to provide reliable protection from power
disturbances for many years. Please be sure to follow the manufacturers instructions to ensure op-
timum performance of the equipment. This manual contains descriptions of all controls and indica-
tors required to operate the DSPM Uninterruptible Power Supply. Please read this manual carefully
and retain it for future reference.
To the best of our knowledge and at the time written, the information contained in this document is
technically correct and the procedures accurate and adequate to operate this instrument in compli-
ance with its original advertised specications. While every precaution has been made to ensure
accuracy and completeness in this manual, DSPM assumes no responsibility and disclaims all lia-
bility for damages resulting from the use of this information or for any errors or omissions.
This instrument is designed to prevent accidental shock to the operator when properly used. How-
ever, no engineering design can render safe an instrument which is used carelessly. Therefore, this
manual must be read carefully and completely before making any measurements. Failure to follow
directions can result in a serious or fatal accident.
How to use this Manual
This manual is designed for ease of use, giving the user easy and quick reference to information. This manual uses notice
icons to draw attention to the user important information regarding the safe operation and installation of the UPS. The
notice icons used in this manual are explained below, and should be taken into account and adhered to whenever they
appear in the text of this manual.
Technical Assistance
Safety Recommendations: If any problems are encountered while following this manual, DSPM assistance and
correspondence is recommended. For technical support or help with any questions not covered in the manual, contract.
