THE WebDT 310
ENGLISH 8
BASIC OPERATION GUIDE
WebDT 310
signage dtri com
DT Research, Inc.
2000 Concourse Drive, San Jose, CA 95131 http://www.dtresearch.com
Copyright © 2010, DT Research, Inc. All Rights Reserved.
DT Research and WebDT are registered trademarks of DT Research, Inc.
Mobile Tablet
INTRODUCTION
Thank you for acquiring the latest addition to DT
Research’s line of tablet devices—the WebDT 310.
Featuring a slim yet robust magnesium alloy enclosure,
the two-pound WebDT 310 with 10.4” TFT display is powered by
the AMD Geode™ LX 800 processor, offering optimal combinations of
performance and power savings. An external battery expansion option provides
approximately 3-4 hours of additional battery operation for up to six hours of
mobile usage.
The WebDT 310 is available in Windows®CE, Windows®XP Embedded, or Windows®
XP Tablet PC operating systems. Each software operating system features web
browser, client/server computing software, media player, accessories, and
applications support.
PACKAGE CONTENTS
WebDT 310 with Internal Battery Pack, Stylus, Grips, and Screen Cover•
AC-DC Power Adapter with Power Cord•
Basic Operation Guide•
Major options, depending on conguration:
Desktop Charging Cradle with DC-in•
Power Jack, Ethernet/USB Ports External Battery Charger Kit•
External Battery Pack• Carrying case•
SPECIFICATIONS
Display 10.4” Hi-Brite TFT LCD with resistive touch and
outdoor-viewable option
Display Resolution 1024 x 768 (XGA)
Processor AMD Geode™ LX 800
Memory (ash) 64MB – 16GB
Memory (RAM) 256MB; 512MB; 1GB
Software
Operating Systems
Windows®CE; Windows®XP Embedded;
Windows®XP Tablet PC Edition
Storage Internalashmodule;60GBHDD
Stylus Non-electronic tip
Protective Grips Two rubber bumpers with optional adjustable hand
strap, adds drop protection
Wireless Interface Integrated 802.11; Bluetooth
Input and Control
Buttons
Seven (7) front buttons; One Power (left edge);
Internal battery control switch
Input/Output Ports
12V DC-in Jack; Microphone-In; Headset jack;
(2) USB 2.0 Ports;
Optional: VGA port
Enclosure Magnesium-Aluminum alloy
AC/DC adapter Input: 100-240VAC, 1.2A; Output: 12VDC, 3.5A
Power Cords North America, EU, UK
Battery Packs
(Lithium-Ion)
Internal (14W, 2000 mAh);
optional external (28W 3900 mAh, 0.5 lb) and
optional tethered pouch (72W, 1 lb)
Desktop Charging
Cradle
Optional: Pass-through for power; Ethernet, USB 2.0
ports
Charging Cradle Optional: Aluminum parking stand
Dimensions (H x W x D) 8.3 x 10.3 x 0.8 (in); 210 x 261 x 18 (mm)
Base Weight 2.05 lbs (0.93 kg)
Regulatory FCC Class B, CE, UL, RoHS compliant
Operating
Temperature 0° – 40°C
Humidity 0% – 90% non-condensing
* If your WebDT 310 contains MSR or scanner module, please refer to the POS
module operation guide for detailed operation.
BOG050410DT310ENG

THE WebDT 310
ENGLISH 23ENGLISH
USB Ports (2)
Button Functions (with Windows XP Operating System)
BUTTON DESCRIPTION ACTION
First in group of three Programmable
Second in group of three Programmable
Third in group of three Programmable
First in group of four Programmable, launch soft (on-screen)
keyboard (default)
Second in group of four
Launch SAS (Secure Attention Sequence)
Generate Ctrl+Alt+Del keys to invoke the
securitywindowsdenedunderWindowsXP
Third in group of four
Programmable,
Change display orientation (portrait/land-
scape) (default)
Fourth in group of four Programmable, system utility menu (default)
Power Button
Push/release typically enters Standby mode,
or Push/release exits Standby mode or restarts
device (software dependent)
Push and hold (over 4 seconds) invokes
hardware shutdown
Note: Buttons 1–4, 6 and 7 may be re-programmed through a Button Manager utility.
The WebDT 310 (with Windows XP)
PC Card Slot
Bluetooth LED
Battery/Power LED
Wireless LED
DC Power
Input
Stylus
Battery and Power Meter
Microphone
Headphone Jack
Microphone Jack
VGA
Calibration
Button Management
Wireless Network Settings
Internal
Battery
Switch
(back
panel)
Power
Button
Removable
Protective Bumpers
Power/Battery LED Status:
Blue indicates the battery is 25% to 100% charged•
Blinking blue indicates the battery is charging•
Orange indicates that the battery is between 11% to 25%•
Blinking Orange indicates that the battery is below 10%•
Precautions
A
• lways exercise care when operating and handling the WebDT 310.
D
• o NOT apply excessive pressure to the display screen.
W
• e recommend using the Stylus provided to keep the screen clean.
A
• void prolonged exposure of the display panel to any strong heat source.
Wherever possible, the WebDT 310 should face away from direct light to
reduce glare.
I
• f the AC-DC power adapter is used to recharge or power the device, do
NOT use any AC-DC adapter other than the one provided with the device or
acquired from the manufacturer or its partners.
I
• n the unlikely event that smoke, abnormal noise, or strange odor is present,
immediately power off the WebDT 310 and disconnect all power sources.
Report the problem to your device provider immediately.
N
• ever attempt to disassemble the WebDT 310, as this will void the warranty.
THE WebDT 310
Basic Features
The WebDT 310 wireless tablet integrates a bright and responsive touch display,
two USB ports, a VGA port, and embedded networking elements such as
wireless LAN and Bluetooth. The primary device is complemented by a suite of
accessories, including battery expansion, docking cradles, and carrying cases, for
a comprehensive user experience.
A WebDT 310 typically integrates an 802.11b/g or 802.11a/b/g wireless LAN (WLAN)
adapter that may connect to other wireless devices or access points. If your WebDT
310 does not come with such a network adapter, please consult your device
provider to establish the desired network connectivity.

THE WebDT 310
ENGLISH 45ENGLISH
OPERATION
Internal Battery Switch
To prevent battery drain during shipping and extended storage, the internal
battery may be turned off. To turn on the internal battery, push the battery
button switch (on the back panel) to the “up” position (see page 2 for photo).
The internal battery pack has to be turned on for it to operate, be charged, and
for the optional external battery pack to function.
Powering ON and OFF
To activate the WebDT 310, push and quickly release the Power Button to the
left of the front bezel. The display will come on in a few seconds. To put the
WebDT 310 in Standby mode, push and quickly release the Power Button. To
turn the WebDT 310 off for extended storage, power off the device safely using
any software function that “shuts down computer” provided in the software
operating system.
NOTE: The battery packs shipped with your device may be low in power—please
use the AC-DC adapter with the WebDT 310 when setting up the device for the
rsttimetofullychargetheinternalbatterypack.Youmaychargetheexternal
battery pack with it attached to the WebDT 310, or with the optional external
battery charger kit.
NOTE: When the battery pack(s) is (are) charging, the blue-colored Battery LED
should blink slowly. If plugging in the AC-DC adapter does not trigger this blinking
activity and the LED stays dark, the battery pack(s) may have been drained
substantially. Try unplugging/replugging the AC-DC adapter to the WebDT 310
a few times to activate the charging process.
NOTE: To conserve power, use (push and quick release) the Power Button to
putthedevicein“Standby”modewhilenotinuse.Pushingbrieyonthesame
button will wake up the system within seconds.
NOTE: Avoid using the Power Button (“hold 4+ seconds” feature) to turn off the
device—this form of hardware shutdown is intended to be a means of recovery
from device lockups, and not as normal operation.
Start Up
If the power up (from Standby or otherwise) is successful, the appropriate interface
will be displayed after a launch sequence of several seconds. The wireless LAN
connection may take 10-15 seconds to be established.
Conguring the WebDT 310
The device may be congured using the utilities and methods dictated by
the software operating system. The WebDT 310 should be congurable for
variouspropertiessuchasuserproles,networkfeatures,andseveralsystem
elements.
Calibration
The touch display for the WebDT 310 is calibrated before shipping. In the
eventthatthecalibrationhasbeenmodiedorisunsatisfactory,therespec-
tive calibration routines (e.g., PenMount (PM) for Windows XP) to calibrate
the touch interface may be used. Such applications are typically executed
through touch input via Stylus or through mouse click via a USB mouse.
Wireless Networking
Wireless LAN
The WebDT 310 is often delivered with an embedded (user-inaccessible)
802.11a/b/g WLAN adapter equipped with a hidden custom antenna. This
embedded interface is supplemented by a user-accessible PCMCIA slot for use
with third-party network adapters or peripherals.
T
• hrough the support of typical WLAN adapters, the WebDT 310 should be
able to detect all 802.11 access points in the vicinity for you to select the
access point of your choice for connection.
T
• he SSID and WEP (if enabled) parameters on the WebDT 310 and the ac-
cess points have to match. The SSID is case-sensitive and it is recommended
that you enable WEP encryption (or advanced alternatives) for secure
access.
W
• hen WEP is enabled, you may need to consult your network administrator
oryournetworkingequipmentliteraturetoproperlycongureassociated
settings such as Authentication mode, etc.
R
• efer to the access point operating manuals for setting up the 802.11
access points.

THE WebDT 310
ENGLISH 67ENGLISH
Bluetooth
The WebDT 310 features a built-in Bluetooth adapter that operates on the
MicrosoftWindowsBluetoothprotocol.TheBluetoothcongurationapplication
is invoked from the System Tray or from the Control Panel for Windows XP.
Under Windows CE, it can be executed from the Control Panel. Follow the
instructionsandoptionsprovidedwithintheapplicationtocongureand
invoke Bluetooth connectivity with the corresponding peripherals.
NOTE: Bluetooth devices or accessories that are not compatible with the
Microsoft Windows Bluetooth protocol may not work with the WebDT 310.
Button Management
Where supported by software, many of the hard buttons on the WebDT 310
are programmable to perform a function of the user’s choice. The exception
is the Power Button and the SAS Button. To activate the button re-assignment
application, invoke the Button Agent application, e.g., in Windows XP
Embedded .
Brightness Control
Where supported by device rmware and software, a hard button may be
engaged to manipulate the display brightness. Press the System Menu button
(Button 7) on the front of the WebDT 310. The System screen will display a
Brightness control section with up and down arrows that can be activated with
the stylus.
Battery and Power Management
The WebDT 310 is equipped with an internal Li-Ion battery pack that is capable
of supporting approximately 1.5–2 hours of continuous operation. The period of
continuous operation can be extended by approximately 3–4 hours with the
external battery pack that clips (hot-pluggable) onto the back of the device.
The period between battery recharges can be signicantly lengthened by
putting the device into Standby mode through the Power Button (see Buttons
Function Table) whenever the device is not in use. Depending on the operating
software,theWebDT310mayalsobeconguredtoentervariouspower-saving
modes via the Power Button or through timed entry.
Desktop Cradle
The WebDT 310 is complemented by an optional Desktop Cradle for support,
pass-through charging, and connection to a range of USB peripherals, including
keyboard and mouse. The Cradle offers the following interfaces: a DC-in port for
the AC-DC adapter, an Ethernet port, and USB ports. Always seat the WebDT 310
securely onto the cradle. The cradle must be powered by the AC-DC adapter
for the Ethernet and USB ports to function. The battery packs on the WebDT 310
may be recharged by connecting the AC-DC adapter directly to the DC-in port
on the WebDT 310 or through the DC-in port on the Desktop Cradle while the
WebDT 310 is docked to the Cradle.
USING THE WebDT 310
Memory conguration
The WebDT 310 is available in various memory congurations. They currently
rangefrom:64MBto8GBofashmemoryand256MB,512MB,or1GBofRAM.
Peripherals Support
Through its USB ports, the WebDT 310 supports a wide range of USB-based
peripherals. These peripherals are applicable for software installation,
applications storage, data storage, and system software recovery and updates.
The WebDT 310 is equipped with a built-in VGA port, allowing displayed content
to be mirrored on an external display for clear, shared viewing. The WebDT 310
is also compatible with custom mountable cradle options. These securable and
mountable cradles provide an interface to VESA mounts and arms, and to ports
that may include USB, Ethernet and pass-through power.
Remote Management
Dependingonsoftwareconguration,theWebDT310canbecentrallymanaged
for asset monitoring and for software control. Please consult your device
provider.
