Dual Inventive RDI 3000 User manual

Quick start
RDI 3000

2
2
1B EF OR E Y O U S TA R T
1.1 What you need
•RDI 3000 and accessories
•User manual RDI 3000
•Certificate RDI 3000
•MTinfo 3000 app & login credentials

3
3
1.2 Safety
NOTE
Read all safety instructions in the
User manual RDI 3000.
NOTE
Risk of explosion.
For how to use the detonator, refer
to the manual of the detonator
manufacturer.
WARNING
Do not look directly into the LEDs
to avoid temporary blindness.
WARNING
Users with a pacemaker are not
allowed to use the RDI 3000.

4
4
2KE Y SWI TC H & DI SPL AY
2.1 Key switch
OFF: de-activated
(not on the track)
ON: activated
(placed on the track)
OPERATIONAL:
remote switching

5
5
2.2 Display
1. Cloud light
2. Activation button
3. Internal battery
indicator
4. Main battery
indicator
INDICATION
MEANING
Blue
Working properly
Red
Error or a low battery
Continuously illuminated
(red & blue)
Device is online
Fade-in-fade-out
(red & blue)
Device is offline

6
6
3I N ST AL L A TI O N
NOTE
Inspect the RDI 3000 before
installation.
NOTE
Perform the functional test after
installation.

7
7
3.1 Placing the RDI 3000
1. Always place
the RDI 3000
on the outside
of the track
and in between
two sleepers.
2. Place the
RDI 3000
sloping and
just below the
rail head.
3. Clamp the
RDI 3000 on
the rail head.

8
8
3.2 Securing the RDI 3000
1. Place the clamp
to the right
side of the key
switch.
If needed,
remove ballast
to create
space.
2. Tighten the
clamp with the
red allen key
until it is
fastened
securely and
cannot be
turned further.
3. Place the 4-
digit combi-
nation padlock,
facing down.

9
9
3.3 Placing the flag
WARNING
When deployed, the flag and the
LEDs of the RDI 3000 must be
visible to a train driver.
1. Turn the key to
OFF.
Place the flag
in the tube
next to the LED
block and
tighten the
wing nut.
2. Turn the key to
ON.
Check that the
flag and LEDs
are visible from
a train driver’s
perspective.

10
10
3.4 Functional test
1. Turn the key to
OFF.
Check the real-
time status in
the app.
2. Turn the key to
ON.
Check the real-
time status in
the app.
Repeat for
OPERATIONAL.
3. Check distance
detonator plate
and rail (1):
5 to 10 mm
Check visibility
(2,3) from the
train driver’s
perspective.

11
11
4MT IN FO 30 00 APP
ICON
MEANING
View messages sent by MTinfo 3000.
Refresh window.
4.1 Sign in

12
12
4.2 Select project

13
13
4.3 Switching
NOTE
•Switch the key to:
OPERATIONAL.
•Switching protection zones
on & off, consists of the
same steps.
1. Select pro-
tection zone.
2. Click button
‘On’ or ‘Off’.
3. Type ‘on’ or
‘off’.
4. Enter PIN.
5. Click button
‘Switch’.
6. Confirm.

14
14
5WARNING & ERR OR ME SSAGES
NOTE
For all warning & error messages,
check the User manual RDI 3000,
section ‘Troubleshooting’.
#
DESCRIPTION
SOLUTION
1027
An EEPROM
(memory) error
occurred.
Please try again. If
this does not solve
the issue, contact
Dual Inventive.
1114
Device is not
attached to the
track.
Check the position
of the device and try
again. If this does
not solve the issue,
contact Dual
Inventive.
1121
Self-test of the LEDs
failed.
Please try again. If
this does not solve
the issue, contact
Dual Inventive.
1122
Detonator is not in a
valid position.
Please check the
detonator and the
lever it is attached
to and try again. If
this does not solve
the issue, contact
Dual Inventive.

15
15
#
DESCRIPTION
SOLUTION
1123
Whole LED unit
defect.
Please try again. If
this does not solve
the issue, contact
Dual Inventive.
1127
The device has
detected that the
LED block is
positioned
incorrectly in
relation to the lever.
Please check the
RDI. It has detected
that the LED block is
positioned
incorrectly in
relation to the lever.
2001-
027
Internal battery
level is critical.
Please charge the
RDI or connect a
main battery to the
RDI.
2001-
028
Internal battery
level is empty.
Please charge the
RDI or connect a
main battery to the
RDI.
2001-
031
Main battery level is
critical.
Replace the battery.
2001-
032
Main battery level is
empty.
Replace the battery.
2001-
067
Two LED groups are
defect.
Please try again. If
this does not solve
the issue, contact
Dual Inventive.
2001-
068
One LED group
defect.
Please try again. If
this does not solve
the issue, contact
Dual Inventive.

16
16
[email protected]
www.dualinventive.com
Version 1.0 / © by Dual Inventive
