DV Systems C10 Installation manual

C1015-II-C
Jun ‘21
- 1 -
Please read this manual before
installing or using your Air
Compressor Unit. It contains
valuable information that will
help in the receiving,
installation, use, and
maintenance of the Unit.
Please keep this manual in a
safe place for future reference.
All of the information, policies, and
procedures in this reference manual apply
exclusively to DV Systems.
If you require assistance, please contact your local DV Systems Distributor or Authorized Service
center. You may contact the manufacturer directly as follows:
Phone: [phone]
Web: www.dvsystems.com
Email: [e-mail]
Contents: Page:
Quick Start ……………............................................. 2
Safety Precautions …………………………………… 4
Unpacking and Inspection …………………………... 5
Installation –Mechanical ……………………………. 6
Lubrication ……………………………………………. 8
Installation –Electrical ………………………………. 9
Start-up Procedures …………………………………. 12
Preventative Maintenance Schedule ………………. 13
Common Compressor Faults ………………..……… 15
Separator Filter & Refrigerated Air Dryer …………. 19
Trouble-Shooting Guide ……………………………… 22
Warranty ……………………………………………….. 25
C10 (T) (TD)
C15 (T) (TD)
C15VSD (T) (TD)
Rotary Screw
Air Compressor
Units
- - -
Installation
And
Start-up Data

C1015-II-C
Jun ‘21
- 2 -
18”
[458 mm]
Quick Start
Mechanical Installation.
(Refer to Page 6)
Lubrication. Rotation.
(Refer to Page 8) (Refer to Page 10)
The Unit must be located indoors, in a dry, clean,
cool, dust free, and well ventilated area.
Allow a minimum 18” (458 mm) around and 36”
(915 mm) above Unit.
The ambient temperature should be between
10°C and 40°C (50°F and 104°F).
Ensure that the floor under the Unit is smooth, level and
capable of bearing the weight of the Compressor.
If installed in a compressor room, ensure that the room is
adequately ventilated.
The unit must be anchored to the floor using isolator pads.
Note: Dimensions indicated are typical for
all variations of ‘C Series’ Units, ie
base-mounted and tank-mounted.
Correct
Oil Level
Before starting the Unit for
the first time, ensure there
is oil in the Reservoir.
The Unit is equipped with
the Sight Glass.
The oil level should be
close to the center of the
Oil Sight Glass, while at
rest.
Check the oil level after
the Unit has been at rest
for a minimum of 5
minutes.
Units are equipped with Advanced Phase
Detection feature which prevents Units
from rotating in the reversed direction.
An ‘E:0090 Phase Sequence’ Error will
appear on the Controller Screen if the
phase sequence is incorrect. If this
occurs, simply switch the incoming leads
‘L1’ and ‘L3’ at the Control Panel.
Reservoir
36”
[458 mm]
18”
[458 mm]
Fusible
Disconnect
Refer to
page 9 for
proper sizing
18”
[458 mm]
Unit
Nameplate
Model No.
Serial No.
Unit voltage
Installation Kit
IK515
Flex-Hose &
Vibration Isolators
(sold separately)

C1015-II-C
Jun ‘21
- 3 -
Quick Start (cont’d)
Unit Operation.
Shown below is the ‘CSC300’ Controller which regulates the operation of the Unit. It is used to start and stop the
Unit, and it provides information as to system pressure, temperature, etc.
Starting the Unit: Press the ‘Start’ Button.
Stopping the Unit: Press the ‘Stop’ Button
Caution:
1. Do not stop the Unit using the ‘Emergency Stop’ Button unless there is a danger to the product or of
personnel injury.
2. Do not stop the Unit by use of a disconnect or breaker.
Using the Emergency Stop Button, disconnect, or breaker to stop the Unit will not
allow the Unit to go through an unloading sequence, and could result in damage to
the Motor, Starter, or other electrical components. Damage caused in this manner
is not covered by the manufacturers Warranty.
Enter, Up, Down & Escape.
Used in the programming and changing
of operating parameters of the Unit.
Emergency Stop.
Will quickly shut the
Unit off. Is only to be
used in an
emergency.
Digital Readout.
Indicates Unit pressure,
temperature, etc.
Stop.
Causes the Unit to
enter ‘Idle’ mode
and then shut off.
Start.
Starts the Unit.

C1015-II-C
Jun ‘21
- 4 -
Safety Precautions
In order to operate the Compressor Unit safely and correctly, we have opted to use the following symbols to make
you aware of important points. These points relate to user safety and preventing equipment problems. Please pay
close attention to these sections.
The following hazards may occur during the normal use
of the equipment. Please read the following chart.
Area: Hazard: Safeguards:
What may occur if precautions are not
observed.
Tampering with the Unit while under Relieve all pressure from the Unit
full or partial pressure may cause an before attempting any repair or
explosion. maintenance work.
As the Unit starts and stops Shut off all power to the Unit before
automatically, serious injury may attempting to repair or maintain
result from working on the Compressor the Compressor.
with the power still in the 'on' position.
As the Unit starts and stops Shut off all power to the Unit before
automatically, do not come into attempting to repair or maintain
contact with moving parts. the Compressor.
Air compressed by the Unit is not Never breath untreated compressed
suitable for inhaling. It may contain air produced by the Compressor.
vapours harmful to your health. Do not direct air stream at body.
Compressor capable of pressures >50psi.
Compressor Air End, Motor, and Never touch the Air End, Motor, or
Tubing become hot when running. Tubing during or immediately after
Touching these areas may cause operation.
serious burns.
As the electrical components on the Do not install in hazardous locations.
Compressor are General Purpose, The Compressor must be a minimum
there is a potential for explosion, should of 20 feet (6.1 meters) from any source
vapours be present in the area. of potentially explosive vapours.
What to look for.
How to avoid the hazard.
20FT
6 . 1 m
Important safety Information.
A hazard that may cause
serious injury or loss of life.
Important information that
indicates how to prevent
damage to equipment, or how
to avoid a situation that may
cause minor injury.
Information that you should
pay special attention to.

C1015-II-C
Jun ‘21
- 5 -
Unpacking and Inspection
It is the responsibility of the receiver of the goods, either the Distributor or Customer, to ensure that the product
has been shipped in full, and has arrived in suitable condition. Damage to the product may not be visible at time
of off-loading, but may only become apparent upon unpacking or start-up.
Some areas to initially check are as follows:
a) Check for damage to the crating and/or packaging.
b) Check the exterior of the Cabinet for damage, either cosmetic or mechanical.
c) If there is mechanical damage, open the Cabinet to determine whether there is any internal
damage to the Unit.
Should there be damage to the product or shortages in shipment:
1) Stop any further unpacking or operation of the product.
2) Make note of the problem on the Freight Bill, should it concern a shortage or visible
damage to the product.
3) Should the damage be noticed only after the product has been received, contact the
transport company immediately to file a claim.
Depending on the problem, it may be wise to photograph the damage. Also, it may
be wise to discuss with the carrier representative the time allotted to give notice of loss
or damage to the product; there may be guidelines which limit timeframes of same.
4) Do not attempt further unpacking or operation of the product. Also, do not discard
any packing material used.
5) A Loss or Damage Claim must be submitted to the carrier and supported by the
following documents:
- Copy of Freight Bill of Lading
- Copy of the Invoice and Estimate to repair, in case of damage
- Damage Report
- Copy of photos, if applicable
Each DV Systems Air Compressor is carefully tested and
inspected before shipment. Though every attempt is made to
ensure the safe and complete shipment of our product, freight
damage or misplacement of goods may occur.
Shipments of DV Systems products are the property of the
Consignee when the products leave our facility. DV Systems Inc.
is not responsible for any damages or shortages caused to the
product after it has left our shipping dock.

C1015-II-C
Jun ‘21
- 6 -
When moving the Air
Compressor, the forklift or hand
lift forks go under the Unit from
the directions as indicated.
When lifting from position ‘A’,
use extended forks.
Please be advised that care
must be taken when moving and
positioning the Units as they are
top heavy.
The Compressor must not be operated in
a confined area where the heat from the
Unit cannot readily escape.
Installation –Mechanical
Moving of the Unit.
Location of the Unit.
Items to consider when installing the Unit are as
follows:
The Unit must be located indoors, in a dry, clean,
cool, dust free, and well ventilated area. If
possible, the Compressor should be located in
a separate room or area, away from the
general operations of the shop.
Allow a minimum of 18” (458 mm) around and 3
feet (915 mm) above the Unit for easy access
to the various sides, this being for both the
proper ventilation of the Unit and ease of
servicing.
Ensure that the floor under the Unit is smooth,
level and capable of bearing the weight of the
Compressor. The Compressor must sit
squarely on the floor.
Ensure that the Unit is anchored to the floor using
isolator pads.
If installed in a compressor room, ensure that the
room is adequately ventilated. (One
Horsepower produces approximately 2500
BTU/HR.) See Page 7.
The ambient temperature should be between
50°F and 104°F (10°C to 40°C).
If installing the Unit on a mezzanine, ensure that
the structure can safely support the weight of
the Unit. As well, the sound level of the Unit
may increase due to the harmonics created by
the structure; use Vibration Pads to lessen this.
When anchoring the Unit, ensure that there is
approx.. ¼” (0.75cm) between the Nut and the
Compressor Foot (as shown below). Do not
bolt down tightly.
Many common Compressor problems can be
attributed to the location or installation of the Unit.
Make sure the Unit is in a suitable location, and
installed correctly.
‘A’
Floor
Isolator
Pad
¼”(0.75 cm) Gap
Compressor
Foot

C1015-II-C
Jun ‘21
- 7 -
Installation –Mechanical (cont’d)
Shown below are items which assist in making a good installation. These are both intake and exhaust ductwork,
helping the Unit to a) draw in clean outside air and b) exhaust the warmer air away from the Unit. The warmer air
may be used, with the inclusion of a damper in the exhaust ducting, to warm the interior of the building during the
colder months of the year.
Intake and Exhaust Ducting

C1015-II-C
Jun ‘21
- 8 -
Lubrication
Oil Fill Port
Oil Drain Valve
Oil Drain Tube
Oil Reservoir
Initial Start-up.
Each Compressor Unit built is extensively tested at
the factory before shipment. The Unit is shipped with
the original oil in it as used for testing purposes.
Check the Oil level and for any Oil leaks on a daily
basis. This must be done when the Unit is off. Top up
the Oil level on a monthly basis.
Use only DV Systems ‘DEV-3000’ Synthetic Oil.
Subsequent Oil Changes.
Drain the existing oil from the Unit. (Please be
advised that the Unit cannot be drained fully of oil, as
some oil may remain in various components ie
Cooler, Tubing, etc.)
Fill the Oil Reservoir to the center of the Sight Glass,
as shown below. Do not under or overfill.
Use only DV Systems ‘DEV-3000’ Synthetic Oil,
available in both 1 US gallon (3.8 litre) jugs or 5 US
gallon (5 x 3.8 litre) pails. Any remaining oil may be
used for ‘top-ups’.
The ‘MK-C7-15-1’ Maintenance Kit includes:
(2) US Gallon (3.8 litre) Oil (‘DEV-3000-K1’)
(2) Oil Filter (’DSC-603’)
(1) Air/Oil Separator Filter (’DSC-302’)
(2) Air Filters (’DSC-001931’)
(1) In Line Filter (‘DSC-612)
(1) Scavenge Line Tube (‘DSC-382’)
Do not attempt to operate the Unit without
first checking whether there is oil in the Oil
Reservoir. Add oil as required. Serious
damage may result from use, however
limited, without oil.
Use of improper oil may negatively affect
Compressor performance or shorten Unit life.
Resulting problems are not covered by the
DV Systems Inc. Air Compressor Warranty.
Condensation (water) may form in the Oil
Reservoir with the oil. If this occurs, as the
water will tend to settle on the bottom of the
Reservoir, drain the water from the Reservoir
until you notice oil draining. Top up the
Reservoir with new oil using only the DV
Systems ‘DEV-3000’ oil.
Correct
Oil Level
Oil Filter
DSC-603
Air/Oil Separator Filter
DSC-302

C1015-II-C
Jun ‘21
- 9 -
Installation - Electrical
Ensure that all wiring, fusing, etc is done in a manner that meets with the appropriate codes and
regulations.
See the sales drawings and electrical schematic contained in this manual for information about Motor
nameplate amps, this is used to determine the appropriate Disconnect / Breaker and Wiring sizes.
Units equipped with Variable Speed Drives (VSDs) MUST use FAST-ACTING FUSES. Refer to the
table below for fuse sizes.
General Information.
It is your responsibility to ensure that the Compressor
Unit is electrically connected in a safe and correct
manner. Any electrical work should be carried out
by a competent Electrician, and be done in such
a way that it meets all applicable Codes and
Regulations.
Ensure that a suitable Fused Disconnect or Breaker
(by others than DV Systems) is installed in the
electrical supply before the Compressor Unit.
Ensure that a suitable Fused Disconnect or Breaker
is sized and installed according to the appropriate
local electrical codes.
Electrical wiring and conduit from the building supply,
through the Compressor Cabinet, and to the Switch
in the Compressor Control Panel, must be rated for
90°C (194 °F) or higher.
Failure to observe any of the above precautions could result in severe personal injury or death,
and/or damage to the Unit.
Failure to correctly connect the Compressor to
your building's electrical services may result
in serious personal injury or damage to the
equipment.
Install all covers and panels before applying
power to the Unit.
Failure to install proper fuse protection may
void the unit warranty.
Before servicing the Unit, ensure the power
source has been shut down and locked off.
Read and understand the information
contained in this manual before installing or
operating the Unit.
This product must be connected to a
grounded, metallic, permanent wiring system,
or an equipment-grounding terminal or lead on
the product.

Fusible Disconnects.
VSD Units:
Voltage
Fuse
Type
Fuse
Amp
DV Fuse
Part No.
DV Disconnect Kit
(Disconnect +
Fuses)
200
HSJ,
DFJ
60
F060
FD-060
230
50
F050
FD-050
460
25
F025
FD-025
575
20
F020
FD-020
Fixed Speed Units:
Use TIME-DELAY type fuse.
Max. Allowable Fuse =
1.75 x Motor Full Load Amp

C1015-II-C
Jun ‘21
- 10 -
The Electrician is to bring power to the Unit through the ¾” conduit hole located on the Right
Panel. The Electrical Panel is accessible by means of opening the Unit Front RH Panel as
shown at right.
3 terminal blocks are provided for main power hook-up
Installation –Electrical (cont’d)
Wiring must be done in a manner that the full Motor nameplate voltage +/- 5% is available at the Motor terminals
during start-up. Contact your local Distributor or Service Centre if additional information is needed.
The Warranty that exists on the Electric Motor is that of the original manufacturer. In the event of a Motor failure,
contact your DV Systems Distributor or Service Centre for the location of the nearest authorized Motor Service
Centre.
It is critical that the Motor and Air End in the Rotary Screw Unit be turning
in the correct manner. Irreparable damage will be done if the Unit rotates
in the opposite direction.
This unit is equipped with Advanced Phase Detection which prevents unit
from rotating in the reverse direction. If the following error is visible on the
Screen and the Unit will not start, simply switch power leads L1 and L3.
Press the ‘Reset’ key on the Controller to reset the error message.
E:0090 Phase Sequence
Note: If the Motor is replaced or Motor Leads are re-wired,
visually check for correct Motor Rotation before installing
the belts.
Electrical Connection.
Motors. Motors.
Motor/Air End Rotation.
Bring power to
Terminal Blocks
L1, L2, L3
Conduit
Opening
Protective
Earth
Connect ground wire to
Protective Earth terminal.
Bring power to L1,L2,L3.
See page 12 for start-up
procedures

C1015-II-C
Jun ‘21
- 11 -
AC Motor Maintenance Instructions
Cleaning.
To ensure that the Motor operates at optimum temperatures and provides years of trouble-free service,
periodically clean the outside of the Motor Housing of any build-up of dust, etc. Though it is not anticipated that, if
installed correctly and in a suitable environment, there should not be much build-up on the Motor, keeping the
Housing clean will allow the Motor to operate more efficiently.
Lubrication.
This is a ball bearing motor. The bearings have been lubricated at the factory. Motors that do not have regrease
capability are factory lubricated for the normal life of the bearings.
Noted below is a chart outlining the interval at which the Motor should be lubricated, this based on the Motor
horsepower. This must be part of a regular maintenance schedule.
Motor HP
Interval
Weight of Grease
Volume of Grease
in Hours
Ounces
Grams
Cubic Inch
Teaspoon
10
9,500
0.61
17.4
1.2
3.9
15
3,600
0.61
17.4
1.2
3.9
The above chart is based on a standard environment in which the Motor is operating of 40°C. For other
conditions, please multiply the Hour Interval from the chart above by the factor as indicated below.
Severity of Duty
Factor
Environmental Conditions
Standard
1.0
40°C (104°F), clean, little corrosion
Severe
0.5
50°C (122°F), moderate dirt, corrosion
Lubricant.
Motors are pre-greased, normally with Chevron SR #1-2. Equivalent and compatible greases are Texaco
Polystar, Shell Dolium R and Amoco Rykon Premium #2.

C1015-II-C
Jun ‘21
- 12 -
Initial Start-up
1) Remove the LH Front Access Panel, and ensure
that there is sufficient Oil in the Oil Reservoir.
Refer to the ‘Lubrication’ section (page 8) in this
manual for proper type and level of Oil.
2) Do a visual inspection of the Unit, and ensure
that all fasteners are sufficiently tightened. This
must be done, as some fasteners may become
loose in transit.
3) Place the Fused Disconnect / Breaker in the ‘On’
position. Check that there is power to the
Controller
Start-up Procedures
Unit Controls
Do not place any materials in close proximity
to the Compressor. Placing materials against
or close to the Unit will limit the cooling
required, and could lead to premature failure.
4) During normal operation of the Unit, keep the
Access Panels closed at all times.
5) Ensure the Ball Valve on the Unit is closed, press
the ‘Start’ Button, and run the Unit up to
maximum pressure. The Unit will run up to
approx. 145 psi (10bar), at which point the Motor
will continue to run but not compress air.
6) Once the Unit reaches 145 psi (10bar), it will idle
for 5 minutes and shut off. For VSD units, the
unit will idle for 2 minutes and shut off.
7) Open the Ball Valve slightly and allow the air to
bleed from the Tank. Once the pressure reaches
approx 125 psi (8.6bar), the Unit will start and
begin to compress air after a short delay. For
VSD units, this pressure is 135 psi (9.3bar).
8) Measure the amp draw as the Unit reaches
maximum pressure.
9) Close the Ball Valve, allow the Unit to reach
maximum pressure, idle, and shut off. Once off,
check the various fittings etc inside the Cabinet to
ensure there are no internal leaks.
10) Once you are confident that there are no internal
leaks, the Unit will be ready for normal use.
11) Register the Unit to Activate the Warranty by
completing the Warranty Registration form at:
gdg.gardnerdenver.com/DV-Rotary-Warranty
Shut off all power to the Compressor Unit
before attempting any repair or maintenance.
Adjusting the settings of the Controller could adversely affect
the performance of the Unit. Only those individuals with
knowledge of the Unit should make any adjustments.
Start Button
Allows the Unit to
start.
Stop Button
Use this to shut
the Unit off. Allows
the Unit to idle and
then stop after
several seconds.
Emergency Stop Button
Do not use to normally stop the Unit. To be used to
stop the Unit in emergencies only. Normal use will
damage electrical controls and Shaft Seal.

C1015-II-C
Jun ‘21
- 13 -
Preventative Maintenance Schedule
Noted on the following pages are general Maintenance guidelines based on average working conditions. Should
the Unit be worked under extreme conditions, please contact your DV Systems Distributor for further input. As
well, all maintenance/service work must be carried out by a qualified Technician.
The typical operating temperature of the Unit, this dependent on ambient temperatures, is between 70°C and
85°C (158°F and 185°F).
If the operating temperature of the Unit is too low (less than 70°C (158°F)):
condensation will build up in the system and mix with the oil, causing internal component problems in the
Unit
Change the ambient conditions to increase the operating temperature.
If the operating temperature of the Unit is too high (above 85°C (185°F)):
the oil will oxidize and lose its properties, this causing internal damage to components as well
to combat this, the oil must be changed more often than noted below.
When servicing the Air Compressor, shut off all
power to the Unit, and drain it of air pressure.
It is the responsibility of the Compressor owner
to ensure that a regular Maintenance Schedule
is followed.
Note: For Compressor Units used in an environment where the ambient temperature is above
32°C (90°F), the components marked with a ‘ # ’ (on the chart on the following page) must
be changed more frequently.
Regular Maintenance Items.
DV Systems offers a Maintenance Kit for your Unit,
namely:
MK-C7-15-1 10 to 15 HP ‘C-Series’ Units
Each Kit consists of the following items:
(2) DEV-3000-K1 1 Gal. of Synthetic Oil
(2) DSC-603 Oil Filter
(1) DSC-302 Air/Oil Separator Filter
(2) DSC-001931 Air Filter
(1) DSC-612 Inline Filter
(1) DSC-382 Scavenge Line Tube
Internal Access for Maintenance.
The internal components of the Unit are accessible for
servicing by way of removing the LH Front Panel.
The Belt access is by way of the LH Side Panel
Remove the plastic cap to change air/oil separator filter
.

C1015-II-C
Jun ‘21
- 14 -
Preventative Maintenance Schedule (cont’d)
Maintenance Item:
Daily
Maintenance Interval (in 000’s of Hours)
2
4
6
8
10
12
14
16
18
20
22
24
26
28
30
32
34
36
38
40
Compressor Room
Temperature
Inspect
Ambient Temperature should be between 10°C and 40°C (50°F and 104°F)
Cleanliness
Inspect
Air Compressor Unit
Check Oil Level
Inspect
Replace Oil # (See Note b)
(1)
X
X
X
X
X
Replace Oil Filter #
(2)
X
X
X
X
X
X
X
X
X
X
Replace Air / Oil Separator #
(3)
X
X
X
X
X
Replace Air Intake Filter #
(4)
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
Check Belt Tension
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
Replace Belts
X
X
X
X
X
Replace Tank Relief Valve
X
X
X
Replace Solenoid
(5)
X
X
X
X
X
Rebuild Intake Valve
(6)
X
X
X
X
X
Rebuild Thermo Valve
(7)
X
X
X
Rebuild Minimum Pressure Valve
(8)
X
X
X
X
X
Replace Scavenge Line Filter
(9)
X
X
X
X
X
Motor Bearing Lubrication
Refer to Motor Manufacturer’s Recommendations on Page 11
Notes: a) For Compressor Units used in an environment where the ambient temperature is above 32°C (90°F),
or b) where the Unit temperature runs regularly above 80°C (175°F), the components marked with a
‘#’ must be changed twice as often (example: in 4000 hours instead of 8000), and not as noted
above.
b) The DV Systems Oil used in the Rotary Screw Units is rated as an 8000 hour Oil. A complete Oil
change must be done every 8000 hours of Unit operation, or every 12 months, whichever occurs first.
Please refer to the Warranty on Page 25 for further information.
c) If a component, during a regular inspection, has proven to be defective or unfit for regular operation, it
must be repaired or replaced.
Parts and Repair Kits based on the above chart are as follows:
(1) Oil: DEV-3000-K1
(2) Oil Filter DSC-603
(3) Air / Oil Separator: DSC-302
(4) Air Intake Filter DSC-001931
(5) Solenoid DSC-001951
(6) Intake Valve Repair Kit DSC-001950
(7) Thermo Valve Repair Kit: DSC-111-1
Thermo Valve Brass Socket DSC-003059 (Not included in the kit)
(8) Minimum Pressure Valve Kit: DSC-410
(9) Scavenge Line In-Line Filter DSC-612
Air End Shaft Seal Kit DSC-002718
Control Panel Ambient Air Filter DSC-001447
VSD Control Panel Separation Foam DSC-002719 (VSD units only)
As noted previously, the ‘MK-C7-15-1’ Maintenance Kit includes the following items:
(2) DEV-3000-K1 1 Gal. of Synthetic Oil
(2) DSC-603 Oil Filter
(1) DSC-302 Air/Oil Separator Filter
(2) DSC-001931 Air Filter
(1) DSC-612 In-Line Filter
(1) DSC-382 Scavenge Line Tube

C1015-II-C
Jun ‘21
- 15 -
Common Compressor Faults
Common Faults.
Noted below are the most common Faults experienced.
‘CSC300’ Alarms.
There is an issue with the Unit, but it will still operate.
Code:
Description:
Most Common Items to Check:
A:0083
Motor phase imbalance
Check supply voltage, fuses and cable
A:0119
Delivery Pressure High
Solenoid not working, Intake Valve Orifice clogged, Transducer dirty or faulty, pressure changed
incorrectly, alternate external pressure source
A:0129
Delivery Temperature High
Ambient temp high, Unit dirty, low oil level, no air flow through Unit, Temp Sensor defective
A:2816
Power Failure Occurred
Press ‘Reset’ Button and restart Unit
A:4819
Routine Service Due
Service Unit and reset Service Timer (Page ‘P16’ on Controller)
A:4809
Grease Service Due
Service motor and reset Grease Service Timer (Page ‘P16’ on Controller)
‘CSC300’ Shutdown Errors.
There is an issue with the Unit, and the Unit will not operate until the Fault has been addressed.
Code:
Description:
Most Common Items to Check:
E:0010
Emergency
Emergency stop switch is pressed
E:0082
Motor Overload
Motor drawing high amps, low voltage, high pressure settings, low oil level
E:0083
Motor phase Imbalance
Check motor connections in the control panel and motor connection box
E:0090
Phase Sequence
Rotation of Motor wrong, sequence order of supply cable incorrect
E:0091-
0093
Phase L1/L2/L3 Fault
Check supply voltage, fuses and cable
E:0115
Delivery Pressure Sensor Fault
Transducer not making good electrical contact, or defective
E:0119
Delivery Pressure High
Solenoid Not working, Intake Valve Orifice clogged, Transducer dirty or faulty, pressure
changed incorrectly, alternate external pressure source
E:0125
Delivery Temp Sensor Fault
Temperature Sensor not making good electrical contact, or defective
E:0129
Delivery Temperature High
Ambient temp high, Unit dirty, low oil level, no air flow through Unit, Temp Sensor defective
E:0902
Anti-Rotation
Rotation of Main Motor wrong, Solenoid Valve not relieving pressure

C1015-II-C
Jun ‘21
- 16 -
Variable Speed Drive
Your DV Systems ‘C Series’ Rotary Screw Compressor Unit may have been equipped with a Vacon ‘Variable
Speed Drive’, or ‘VSD’. A Compressor with an integral VSD can handle the constant loads for an extended period
of time (running at close to 100% duty cycle), but it can also run at slower speeds to accommodate lower air
demands at other times of the day.
Variable Speed Drives can reduce the overall energy costs associated with operating the Compressor Unit by
simply controlling the speed of the Motor and Air End to match consumption. As Rotary Screw Compressors
using the variable speed technology match the varying air demands and therefore have the ability to impact your
energy consumption, some energy providers have offered rebates when these Units are purchased. Consult your
local energy provider to determine if this applies.
Shown below is a ‘C Series’ Unit with a Variable Speed Drive.
VSD Interface
The VSD Controller Interface is shown at right. It
provides a means of operating, monitoring, and adjusting
the parameters of the Variable Speed Drive.
Please note that adjustments to the parameters of the
Variable Speed Drive should be made only by qualified
Technicians, or with the guidance of factory trained
personnel. Incorrect adjustments will affect the
performance of the Unit, and could result in damage to
the Drive.
Variable Speed Drive
Control Panel


C1015-II-C
Jun ‘21
- 17 -
Variable Speed Drive (cont’d)
Operating Screen
Typical Drive Status Indicators on Screen

C1015-II-C
Jun ‘21
- 18 -
Fault
Code
1 Over-current. Current too high in Motor Cable. Check loading.
Check Motor.
Check Cables.
2 Over-voltage. The DC link voltage has exceeded the limits.
- too short a deceleration time Make deceleration time longer.
- high voltage spikes in supply Check input voltage.
3 Ground Fault. Insulation failure in Motor or wiring. Check Motor wires and Motor.
8 System Fault. - component failure Reset the fault and restart the Unit.
- faulty operation
13 Frequency Converter under Heatsink temperature is below -10°C.
temperature.
14 Frequency Converter over
Heatsink temperature is over 90°C. Check the amount and flow of cooling air.
temperature. Overtemperature warning is issued when the heatsink Check the heatsink for dust.
temperature exceeds 85°C. Check the ambient temperature.
Ensure the switching frequency is not too high
in relation to ambient temperature and motor
load
15 Motor stalled. Motor stall protection has tripped. Check Motor and load.
16 Motor over-temperature. Motor is overloaded. Decrease motor load.
17 Motor under-load. Motor under-load temperature has tripped. Check load.
22 EEPRON checksum fault. Parameter save fault. Should the fault re-occur, contact the Distributor.
- faulty operation.
- component failure.
25 Microprocessor watchdog - faulty operation. Reset the fault and restart the Unit.
fault. - component failure. Contact Distributor.
31 IGBT temperature IGBT Inverter Bridge overtemp protection has detected too Check loading.
(hardware). high a short term overload current. Check motor size.
Make identification run.
32 Fan cooling. Cooling Fan of frequency converter does not start when Contact Distributor.
ON command is given.
50 Analogue Input Iin < 4mA. Current at the analogue input is less than 4 mA. Check the current loop circuitry.
- control cable is broken or loose.
- signal source has failed.
52 Keypad communication The data connection between the control keypad and the Check keypad connection and possible keypad cable.
fault. frequency converter is broken.
54 Slot fault. Defective option board or slot. Check board and slot.
Contact the nearest Vacon Distributor.
56 PT100 board temperature Temperature limit values set for the PT100 board Find the cause of temperature rise.
fault. parameters have been exceeded.
Fault
Possible Causes:
Corrective Measures:
Variable Speed Drive (cont’d)
Common VSD Fault Codes
Noted below are the most common fault codes that may appear on the VSD. For a more thorough list, please
check the manual which deals exclusively with the Vacon Variable Speed Drive and which accompanied the Unit.

C1015-II-C
Jun ‘21
- 19 -
Separator Filter and Refrigerated Air Dryer
Your Unit may be equipped with a Separator Filter and an ‘ASD Series’ Refrigerated Air Dryer Unit as indicated
below. These items are located in the compressed air lines after the air is compressed but before it enters the Air
Receiver. This allows for what is termed a ‘dry’ Tank.
*Drains will discharge automatically under pressure. It is recommended that pneumatic drain tubes be anchored
and filtered as per your local municipality regulations.
More detailed information concerning the Dryer Unit is included in the Dryer manual. The information contained in
this manual is a ‘quick reference’ only.
To Air
Receiver
Dryer Controls.
On/Off
Button
From Air
End
LED’s for
Compressor,
Drain, and Fan
Test/Programming
Buttons
Unit Model and
Serial Numbers
Refrigerated
Air Dryer
Readout
Power Cord
115V
Pressurized
Moisture Drain*
Pressurized
Moisture Drain*
Separator
Filter

C1015-II-C
Jun ‘21
- 20 -
Separator Filter and Refrigerated Air Dryer (cont’d)
The Dryer will operate as follows:
Pressing the ‘On/Off’ Button for 3 seconds will start the Unit
There is a time delay of up to 2 minutes before the Refrigerant Compressor starts.
The Condenser Fan will start approx. 30 seconds there-after.
The Fan will not normally run at full speed, this indicated by a flashing LED
The readout will initially show ambient temperature indicated by 3 horizontal bars on the readout
Once the Fan and Compressor start, the dew point of the Unit will decrease to approx. 1°C, this indicated
by 1 or no horizontal bars.
Once at approx. 1°C, the Fan will stop, only to be called to run again once the temperature increases to
approx. 5°C
Pressing the ‘On/Off’ Button (when the Unit is operating) will run the Fan at full speed for several
seconds, after which the Unit will stop. (The LED will be on continually while the Fan runs at full speed.)
As well as showing the dew point, the readout may indicate several fault codes as suggested below.
The readout will indicate a variety of ‘fault codes’, the most common being as follows:
Motors.
Typical Dryer Operation.
Typical Fault Codes.
Energy Saving Mode.
The Dew Point has been running at below -1°C for over 6
minutes.
The Unit will automatically restart operation at 6°C.
Temperature Probe Alarm.
The Temperature Probe is not working properly. It may
not be connected to the Board, or the Probe may be
defective.
Replace the Probe if necessary.
High Temperature Alarm.
The Dew Point has been running at above 12.5°C for
over 6 minutes. The Unit must be manually turned off and
on.
The fault could be caused by a dirty radiator, high
ambient temperature, a faulty Fan, or a faulty refrigerant
Compressor, to name only a few.
