Dynacord EB DPC User manual

Dynacord | EB DPC
EB DPC
www.dynacord.com
▪Transparent cover – reliable method of preventing
accidental actuation
▪Installed LED – optical visualization with maximum
efficiency and operational reliability
▪Internal monitoring – the feed line is monitored for
short-circuits and interruptions
The EB DPC is an optional button for installation in the
DPC 8000 series call stations. For more information,
see the DPC operating instructions and the IRIS-Net
documentation.
Parts included
No. Component
1 Button element with cover
1 Preconfigured 4-pin connecting cable
1 Label sheet
1 Technical information
Installation/configuration notes
Labeling
1. Remove button (1) from holder (2)
2. Remove red undersection (3) from button cover (5)
with a sharp object (such as a knife)
3. Insert label sheet (4) into button cover (5)
4. Re-assemble the button element, including the label
sheet, and mount in the holder

Assembly (based on DPC 8015)
1. Disconnect the call station from all connectors
2. Unscrew call station baseplate (1)
3. Unplug the connection cable from CN1 plug
connector (2)
4. Prepare installation location (3). Use a sharp object
(knife, scriber, or similar) to carefully punch through
and cut out the pre-cut rectangle on the back
housing. Perform any follow-up work that may be
required to the installation location (e.g. filing)
5. Mount the button into the installation location and
press down evenly
6. Depending on whether the right/middle/left
installation location will be used, plug ribbon cable
(4) into plug connector CN201/CN202/CN203 on the
circuit board
7. Plug connecting cable (2) back into CN1
8. Re-attach the call station baseplate
9. Attach the connections
10. Configure the button in IRIS-Net
Ordering information
EB DPC
Order number F01U101089
2 | EB DPC

3 | EB DPC
Represented by:
Germany:
EVI Audio GmbH
Sachsenring 60
94315 Straubing
Germany
www.dynacord.com
© Bosch Security Systems 2013 | Data subject to change without notice
Document Number | Vs1 | 19. Mar 2013
