Dynam Turbojet User manual

Instruction Manual
Specification
Wingspan:1180mm
Fuselage Length:1080mm
Flying weight:1150g
Servo:9gX4
Battery:11.1v 2200mAh 20C Li-Po
ESC:40AX2
Motor:KV3300X2
Wing loading:63g/dm
2

1

2

RTF INCLUDING
3
RTF including:
fuselage
wing
elevator
landing gear
Vertical stabilizer
plastic parts set
Hardware
Elevator
edf set
glue
decal
balance charger
LI-Po battery (11.1V 2200mAh 20C)
transmitter
Adaptor
Cockpit
ESC

4
As shown,Insert the speed
controllers into fuselage.
As shown, Apply the foam glue on
the joiner of the left and right horizontal
stabilizer.
Insert the vertical stabilizer into
the fuselage.
As shown,Fix the EDF set on
fuselage with 3X40mm screw.
As shown,Glue the horizontal
stabilizer in place.
As shown,Fix the vertical stabilizer on
fuselage with 2.3X20mm screw.

5
Insert the direction pushrod into the
hold of quick-controller and tighten
clamp connectors.
As shown, Insert speed controller
wires into THR channel of receiver.
As shown,Fix the nose landing gear
on fuselage with 2.5X8mm screw.
As shown, Insert Z-bend of pushrod
into the hole of the nose landing gear.
As shown, Apply the foam glue to the
stuffing foam and insert it into fuselage
as shown.
As shown,Insert elevator pushrod into
the hold of quick-controller and tighten
clam connectors.
(Remark: The servo should be in center position)

6
18
Apply the foam glue on the joiner of the
left and right wings.
As shown,Apply the foam glue on the
plastic part and insert it in the main wing
as shown.
As shown,Apply the foam glue on the
joiner of the rear landing gear and push
it in the position.
As shown,Fix the wing on fuselage
with 6X50mm plastic screw.
As shown,Put the battery in position.
As shown,Connector the aileron servos
with Y wires.
Installing the Battery position.
As shown,Glue left and right main wings
together.
As shown, Apply the foam glue to the
stuffing foam and insert it into wing as
shown.
19 20

THROTTLE
RUDDER
ELEVATOR
AILERONS
airplane action
airplane action
airplane action
airplane action
control plane
movement
control plane
movement
Aileron
movement
7
STICK OPERATION
MODE 1 MODE 2 MOVEMENT
