Dynapac CA152STD User manual

DYNAPAC
CA152
Box 504, SE-371 23 Karlskrona, Sweden
Phone: [phone], Fax: [phone]
www.dynapac.com
M152EN3
MAINTENANCE

19
ILF015WO1

Vibratory Roller
CA152
Maintenance
M152EN3,December2003
Diesel engine:
CA152: Cummins 4B 4.5
These instructions apply from:
CA152 PIN (S/N) *64X21600*
Reservation for alterations.
Printed in Sweden
The CA152 is one of Dynapac’s light vibratory rollers. It is available in STD, D (smooth
drum) and P, PD (padfoot) versions respectively. The P, PD version has its greatest
range of application on cohesive material and disintegrated rock.
All types of base courses and sub-bases can be compacted, and the interchangeable drums, from
D to PD and vice versa, provide even greater versatility in the choice of application.
This manual describes the cab and safety-related accessories.
Other accessories, such as the compaction meter, tachograph and field computer, are
described in separate instructions.
KEEP THIS MANUAL FOR
FUTURE REFERENCE

2CA152 M152EN3
Read through the entire manual before
starting any maintenance operations.
Ensure good ventilation (air extraction) if the
diesel engine is run indoors.
If the engine cover’s gas struts are
disengaged and the cover is raised to its
upper position, block the cover so that it
cannot fall down accidentally.
It is important that the roller is maintained correctly to
ensure proper function. It should be kept clean so that any
leakage, loose bolts and loose connections can be
discovered in time.
Make a habit of walking round the roller to check it every
day before starting the first shift – including under the
machine. This is often the easiest way of discovering any
leakage.SPARE A THOUGHT FOR THE
ENVIRONMENT! Do not let oil, fuel and other
environmentally hazardous substances contami-
nate the environment.
This manual contains instructions for periodic attention
which should normally be carried out by the roller operator.
There are additional instructions relating to the
diesel engine, for which the manufacturer’s
instructions are detailed in the engine manual.
This is found under a separate flap in the roller’s
product binder.
CONTENTS
Safety instruction – Personal Safety
Special caution – Machine or component damage
WARNING SYMBOLS
GENERAL
CALIFORNIA
Proposition 65 Warning
Diesel engine exhaust and some of its
constituents are known to the State of
Californiatocausecancer,birthdefects,
andotherreproductiveharm.
Page
Lubricants and symbols ...................................................3
Technical specifications............................................... 4-6
Maintenance schedule .....................................................7
Maintenance Measure..................................................8, 9
Every 10 operating hours (daily) ...............................10-12
Every 50 operating hours (weekly) ...........................13-16
Every 250 operating hours (Monthly) ........................17-19
Every 500 hours of operation (Every three months) 20, 21
Every 1000 operating hours (Every six months) ......22-24
Every 2000 operating hours (Every year).................25-28
Long-term storage..........................................................29
Special instructions ........................................................30
Electrical system, fuses, relays ................................31-33

3CA152 M152EN3
LUBRICANTS AND SYMBOLS
ENGINE OIL Shell Rimula SAE 15W/40 or equivalent
ambientairtemperature API Service CH-4 (CG-4)
-10°C – +50°C (14°F - 122°F)
HYDRAULIC FLUID
ambientairtemperature Shell Tellus Oil TX68 or equivalent
-10°C – +40°C (14°F - 104°F)
ambientairtemperature Shell Tellus Oil T100 or equivalent
above +40°C (above 104°F)
BIODEGRADABLE Shell Naturelle HF-E46
HYDRAULIC FLUID When it leaves the factory, the machine may be filled
with biologically degradable fluid. The same type of
fluid must be used when changing or topping off.
TRANSMISSION OIL
ambientairtemperature Shell Spirax SAE 80W/90, HD API, GL-5
-15°C – +40°C (5°F - 104°F)
ambientairtemperature Shell Spirax HD85W/140 or equivalent
above +40°C (above 104°F)
DRUM OIL
ambientairtemperature Shell Spirax SAE 80W/90, HD API, GL-5
-15°C – +40°C (5°F - 104°F)
ambientairtemperature Shell Spirax HD85W/140 or equivalent
above +40°C (above 104°F)
GREASE SKF LGHB2 (NLGI Class 2) or equivalent for
articulated joint. Shell Retinax LX2 or equivalent
for other lubrication points.
FUEL See the engine manual
COOLANT GlycoShell or equivalent
mixed 50/50 with water Anti-freeze protection down to about -41°C (-42°F).
Always use high-quality lubricants, in the quantities specified. Excess
grease or oil can promote overheating, resulting in premature wear.
When driving in extremely high or low ambient tempe-ratures,other lubricants are
needed. Refer to the chapter entitled “Special Instructions” or contact Dynapac.
Engine, oil level Tire pressure
Engine,oil filter Air filter
Hydraulic fluid tank, level Battery
Hydraulic fluid filter Recycling
Transmission, oil level Fuelfilter
Drum, oil level Coolant, level
Oil for lubrication

4CA152 M152EN3
TECHNICAL SPECIFICATIONS
Weights & dimensions CA152STD CA152D CA152P CA152PD
Operating mass with ROPS, EN500, kg (lbs) 7180 7330 7530 7680
(15,829) (19,639) (16,601) (16,932)
Operating mass without ROPS, kg (lbs) 6850 7000 7200 7350
(15,102) (15,432) (15.873) (16,204)
Operating mass with cab, kg (lbs) 7400 7550 7750 7900
(16,314) (16,645) (17,086) (17,417)
Length, standard-equipped roller, mm (in) 4776 4776 4871 4871
(188) (188) (192) (192)
Width, standard-equipped roller, mm (in) 1852 1852 1852 1852
(73) (73) (73) (73)
Height, with ROPS, mm (in) 2784 2784 2825 2825
(110) (1110) (111) (111)
Height, without ROPS, mm (in) 2051 2051 2066 2066
(81) (81) (81) (81)
Height, with cab, mm (in) 2815 2815 2857 2857
(111) (111) (112) (112)
Vibration data CA152STD CA152D CA152P, PD
Static linear load kg/cm (pli) 21,5 (120.4) 22,4(123.76) -
Amplitude(High) mm (in) 1,7 (0.07) 1,7 (0.07) 1,7 (0.07)
Amplitude (Low) mm (in) 0,8 (0.03) 0,8 (0.03) 0,9 (0.03)
Frequency(High amplitude) Hz (vpm) 29 (1740) 29 (1740) 29 (1740)
Frequency (Low amplitude) Hz (vpm) 40 (2400) 40 (2400) 40 (2400)
Centrifugal force
(Highamplitude) kN (lb) 100 (22,500) 100 (22,500) 125 (28,101)
Centrifugal force
(Lowamplitude) kN (lb) 94(21,150) 94(21,150) 118(26,550)
Tires (all-weather)
Tire dimensions............................. 420/70 B24 (Std type) 14,9-24T461 8 ply (Tractor type)
Tire pressure................................. 110 kPa (1,1 kp/cm2) (16 psi) 180 kPa (1,8 kp/cm2) (26 psi)
Electrical system
Battery........................................... 12 V, 170 Ah
Alternator....................................... 14 V, 95 A
Fuses ............................................ See under heading “Electrical System”
Fluid volumes Litres (gal or qts)
Rear axle:
- Differential ....................................................7 l (7.4 qts)
- Planetary gears............................................0,8 l (0.8 qts) /each side
Drum ............................................................10,5 l (11.1 qts)
Hydraulic reservoir.......................................52 l (13.7 gal)
Oil in hydraulic system.................................18 l (4.8 gal)
Lubrication oil, diesel engine ........................10 l (10.6 qts)
Coolant, diesel engine ..................................20 l (21.1 qts)
Fuel tank ....................................................225 l (59.4 gal)
The tires can be optionally filled with fluid, (extra weight up to 350 kg/tire,
770 lbs/tire). When servicing, bear this extra weight in mind.

5CA152 M152EN3
TECHNICAL SPECIFICATIONS
Airconditioner(Optional) The system described in this manual is of the ACC
type (Automatic Climate Control), ie, a system that
maintains the set temperature in the cab, on condition
that windows and doors are kept closed.
Refrigerant designation: HFC-R134:A
Weight of refrigerant when newly filled CA152=1600
gram
Tightening torque
Hydraulic system
Boltdimension: M20 (P/N 50 02 26)
Strength category: 8.8
Tighteningtorque: 330 Nm (243 lbf.ft)
(for Dacromet treated)
ROPS
Opening pressure, MPa (psi)
Drive system 38,0 (5,500)
Charge system 2,0 (290)
Vibration system 33,0 (4,800)
Steering system 18,0 (2,600)
Brake disengagement 1,4 (200)
Tightening torque in Nm (lbf.ft) for oiled, bright
galvanized bolts tightened with a torque wrench.
M STRENGTH CLASS
thread 8.8 10.9 12.9
M6 8,4(6.2) 12(8.9) 14,6(10.8)
M8 21(15.5) 28(20.7) 34(21.1)
M10 40(15.5) 56(41.3) 68(25.1)
M12 70(51.6) 98(72.3) 117(86.3)
M16 169(124.7) 240(177) 290(213.9)
M20 330(243.4) 470(346.7) 560(413.1)
M24 570(420.4) 800(590.1) 960(708.1)
M30 1130(833.5) 1580(1165.4) 1900(1401.4)
M36 1960(1445.7) 2800(2065.3) –
ROPS bolts must always be tightened dry.

6CA152 M152EN3
The vibration values are measured in conformance
with the driving mode described in EU directive
2000/14/EC on EU equipped machines, on soft
polymer material with vibration switched ON and
the operator’s seat in transport mode.
Whole-body vibration is measured at less than the
action value of 0.5 m/s2specified in EU directive
2002/44/EC. (The limit value is 1.15 m/s2.)
Hand/arm vibration is measured at less than the
action value of 2.5 m/s2specified in the same
directive. (The limit value is 5 m/s2.)
CA152 105 84 80
CA152LN 102 – 79
The acoustic values are measured in conformance with EU directive
2000/14/EC on EU-equipped machines, on soft polymer material
with vibration switched ON and the operator’s seat in transport
mode.
Acoustic values
Model Guaranteed
acoustic
power level
dB(A) LwA
Acoustic
pressure level,
operator’s ear
(platform)
dB(A) LpA
Acoustic
pressure level,
operator’s ear
(cab)dB(A)
LpA
Noise level can vary when driving on different
courses and with different seat positions.
Vibrations – Drivers seat
(ISO 2631)
Vibration levels may vary when driving on
different courses and with different seat
positions.
TECHNICAL SPECIFICATIONS

7CA152 M152EN3
MAINTENANCE SCHEDULE
Fig. 1 Service and maintenance points
1 2 3 4 5 6 7 8 9 10 37 11 12 13
26 25 24 22 23 21 20 19 36 35 34 18 17 16 15
14
33
32
31
30
29
28
27
38
39
1. Radiator grille
2. Oil level, diesel engine
3. Fuel filter
4. Air filter
5. Engine cover, hinges
6. Hydraulic fluid tank, sightglass
7. Bleeding filter
8. Hydraulic fluid filters (2 filters)
9. Drainage, hydraulic fluid reservoir
10. Hydraulic fluid, filler
11. Fuse-box
12. Drum oil, filling, 2 fillers
13. Drum gearbox
14. Scrapers
15. Drum oil, level plugs, 2 pcs.
16. Rubber elements and attachment
screws
17. Steering joint
18. Steering cylinder
19. Flywheel casing, hydraulic pumps
20. Wheel nuts
21. Tires, pressure
22. Rear axle, differential
23. Rear axle, planetary gears, 2 pcs.
24. Rear axle suspension, 2 sides
25. Oil filter, diesel engine
26. Drainage, fuel tank
27. Diesel engine mountings, 4 pcs.
28. Feed pump, fuel
29. Diesel fuel, filler
30. Battery
31. Radiator
32. Hydraulic fluid cooler
33. Drive belts, cooling, alternator
34. Steering chain
35. Seat bearing
36. Steering chain
37. Forward/Reverse lever
38. Fresh air filter
39. Air conditioner
= Optional

8CA152 M152EN3
MAINTENANCE MEASURE
Periodic maintenance shall be carried out at the
specified intervals, that is to say either every day,
every week etc., or after the specified number of opera-
ting hours, whichever comes first.
Always first remove all exterior dirt before
filling up fluids etc., and before checking oil
and fuel levels, and also when lubricating with
grease or oil.
The engine manual specifies additional ser-
vice/maintenance instructions which relate to
the diesel engine.
Item. in Measure See page Comments
fig. 1
Before the day’s first start
14 Check scraper setting 10
1 Check for free circulation of cooling air 11
31 Check coolant level 11 Seeenginemanual
2 Check diesel engine oil level 11 Seeenginemanual
29 Top up fuel tank 12
6 Check fluid level in hydraulic tank 12
Check brakes 12
Every 10 operating hours (daily)
Item. in Measure See page Comments
fig. 1
Check that hoses and couplings are not leaking
7 Clean the filter element of the air cleaner 13 Replace as required
17 Lubricate steering joint 14
18 Lubricate the steering cylinder brackets 14
20 Check the wheel-nuts are tightened 15
21 Check tire pressure 15
39 Inspect the air conditioning 15 Optional
- Lubricate the strike-off blade bearings. 16 Optional
After the first 50 hours of operation change only the drum oil and all the oil filters.
Every 50 operating hours (weekly)

9CA152 M152EN3
MAINTENANCE MEASURE
Item. in Measure See page Comments
fig. 1
23 Check the oil level in rear axle/planetary
gearing 17
15 Check the oil level in drum 17
32 Clean the radiators 18
20, 24 Inspect and tighten bolted joints 18 Applies only to new and
repaired components
16 Inspect rubber elements and bolted joints 18
30 Inspect the battery 19
Inspect the air conditioning 19 Optional
Every 250 operating hours (monthly)
Item. in Measure See page Comments
fig. 1
8 Change the hydraulic fluid filters 22
9 Drain condensate from hydraulic tank 22
26 Drain condensate from fuel tank 23
4 Replace air cleaner main filter 23
22 Change oil in rear axle differential 23
23 Change oil in rear axle planetary gears 24
38 Replace the fresh air filter in the cab 24 Optional
Check diesel engine valve clearance Seeengine manual
33 Check belt tension for drive belt system Seeengine manual
Every 1000 operating hours (every six months)
Item. in Measure See page Comments
fig. 1
9, 10 Change fluid in hydraulic tank 25
12, 15 Change oil in roller 25
37 Lubricate Forward/Reverse control 26
Overhaul air conditioning 27 Optional
Every 2000 operating hours (every year)
Item. in Measure See page Comments
fig. 1
3 Replace fuel filter Seeengine manual
5 Lubricate controls and joints 20
3 Replace fuel pre-filter 20
25 Change engine oil and oil filter 20 See enginemanual
36 Lubricate the steering chain 21 Optional
35 Lubricate the seat bearing 21 Optional
7 Check bleeder filter on hydraulic tank 22
Every 500 operating hours (every three months)

10 CA152 M152EN3
Never work under the roller with the engine
running. Park on a level surface. Block the
wheels securely.
It is important to consider movement of the
drum when the machine turns, ie, the scrapers
can be damaged or wear of the drum may
increase if adjustment is made closer than the
values stated.
If necessary, adjust distance to the drum as follows:
the scraper is integrated with the beam.
Loosen the four screws (2) on the frame side, then ad-
just the beam to about 20 mm (0.8 in) from the drum.
Tighten the screws.
EVERY 10 OPERATING HOURS (DAILY)
Scrapers –
Check/Adjust
Fig.2 Scrapers
1. Scraper beam
2. Screws
1
2
Soft scrapers (Optional)
Loosen the screws (2) and adjust to light contact
against the drum. Tighten the screws.
2 1 1 2
Fig.4 Scrapers
1. Scraper blade
2. Screws
Fig.3 Scrapers
1. Scraper blade
2. Screws
CA 152 P, PD
Loosen the four screws (2) on the frame side, then ad-
just the beam to about 25 mm (1 in) between the teeth
and the drum.
Tighten the screws.
1
2

11CA152 M152EN3
1
1
EVERY 10 OPERATING HOURS (DAILY)
13
2
Park the machine on a level surface. The
engine should be switched off and the
parking brake engaged during all inspec-
tion and adjustment operations on the
machine, unless otherwise stated.
Watch out for contact with hot engine
parts and the hot radiator when the oil
dipstick is being removed. There is a risk
of burn injuries.
The dipstick is located on the engine’s right side.
Pull up the dipstick (1) and check that the oil level is
between the upper and lower marks. For further details,
refer to the engine manual.
Check that the diesel engine has free circulation of
cooling air through the grille in the engine compartment.
Press the button on the hood lock (1) to open, and
raise the engine hood to its fully open position. Ensure
that the red safety catch on the left gas-spring is en-
gaged.
If the engine cover’s gas struts are disen-
gaged and the cover is raised to its upper
position, block the cover so that it cannot
fall down accidentally.
Check that level of the coolant is between the max. and
min. marks.
Danger of scalding. Take great caution if
the radiator cap must be opened while the
engine is hot. Wear protective gloves and
goggles.
Fill with a mixture of 50% water and 50% anti freeze.
See lubricant specification and in the engine manual.
Flush the system every other year and
change the coolant. Ensure also that air can
flow unrestricted through the radiator.
Diesel engine
– Check oil level
Fig.7 Engine compartment
1. Oil dipstick
Air circulation – Check
Fig.5 Grille
1. Hood lock
Fig.6 Radiator
1. Max. level
2. Min. level
3. Filler cap
Coolant level – Check

12 CA152 M152EN3
Refuel daily with diesel fuel up to the lower edge of the
filler pipe (1). Follow the engine manufacturer’s
specification with regard to the quality of diesel fuel.
Switch off the diesel engine. Short-circuit
(press) the filler gun against a non-insula-
ted part of the roller before refuelling, and
against the filler pipe (1) while refuelling.
Never refuel while the engine is running,
do not smoke, and avoid spilling fuel.
See the engine manual with regard to quality of diesel fuel.
The tank holds 225 litres (59.4 gal).
EVERY 10 OPERATING HOURS (DAILY)
1
2
12
1
Fig.8 Fuel tank
1. Tank cap
Fuel tank – Filling
Hydraulic reservoir
– Check fluid level
Brake function – Check
Fig.10 Controlpanel
1. Reserve-/parking brake knob
2. Forward/reverse lever
Fig.9 Hydraulic fluid reservoir
1. Sight glass
2. Filler pipe
Check operation of the brakes as follows:
Drive the roller slowly forward.
Push the reserve/parking brake knob (1); the warning
lamp on the instrument panel should light and the roller
should stop.
After testing the brakes, set the forward/reverse lever
(2) in neutral.
Pull up the reserve-/parking brake knob.
The roller is now ready for operation.
Position the roller on a level surface and check that the
sight glass reading (1) is between the max. – min.
marks. Top off with hydraulic fluid according to the lu-
bricant specification if the level is too low.

13CA152 M152EN3
Replace or clean the air cleaner’s main filter if
the warning lamp on the instrument panel lights
up when the diesel engine is operating at full
speed.
Undo the three locking braces (1). Then pull off the
cover (2) and pull out the main filter (3).
Do not remove the safety filter (4).
If the main filter is to be cleaned, compressed air at
max. 5 bar (72 lbs/sq in) pressure should be used.
Blow up and down along the paper creases on the in-
side of the filter.
Hold the nozzle at least 2–3 cm (0.8-1.2 in) away from
the paper creases so that the paper does not tear un-
der the pressure of air.
Use protective goggles when working with
compressed air.
Dry the inside of the cover (2) and filter housing (5).
Check that the hose clamps between the filter
housing and inlet hose are tightened and that
they do not leak. Check the entire length of the
hose all the way to the engine.
Once the main filter has been cleaned a maxi-
mum of 5 times, it must be replaced.
EVERY 50 OPERATING HOURS (WEEKLY)
Main filter – Cleaning with
compressed air
Fig. 12 Main filter
23
Fig. 11 Air cleaner
1. Locking braces
2. Cover
3. Main filter
4. Safety filter
5. Filter housing
1 4 5
Air cleaner
– Check/clean
Fig.13 Air filter
4. Safety filter
Safety filter – Replacement
4
Replace the safety filter with a new one at every 5th
replacement or cleaning of the main filter. The safety fil-
ter cannot be cleaned.
When replacing the safety filter (4), pull out the old filter
from its holder, insert a new one and refit the air cleaner
in the reverse order to the instructions given in the
figure above.

14 CA152 M152EN3
EVERY 50 OPERATING HOURS (Weekly)
Steering joint and steering
cylinder – Lubrication
Fig. 14 Steering joint, left side
Place the roller on a level surface. Switch the
engine off and push in the reserve/parking
brake knob for all checking and adjustments
on the roller, unless otherwise specified.
Allow no one to get near the steering joint
when the engine is running. Danger of
being crushed when steering is operated.
Push the reserve/parking brake knob be-
fore lubricating.
Turn the steering wheel fully to the right to gain access
to all six lubricating nipples on the left side.
Use grease recommended in Lubricant Speci-
fication on page 3.
Wipe all the nipples clean from dirt and grease.
Lubricate each nipple (1) with five strokes of the grease
gun. Make sure that grease penetrates the bearings.
If grease does not penetrate through the bearings, it
may be necessary to relieve the load on the articulated
joint with a hydraulic jack and then repeat the greasing
process.
Steering joint – Lubrication
Steering cylinder
– Lubrication
Fig.16 Steering cylinder, left side
2. Lubricating nipples, cylinder
brackets (x2)
Fig. 15 Steering joint, left side
1. Lubricating nipples,
steering joint (x4)
Wipe nipples clean from dirt and grease.
Lubricateeach nipple (2) with three strokes of the grease gun.
Allow a little grease to remain on the nipples after
greasing. This will prevent contaminants from entering
the nipples.
1
1
2

15CA152 M152EN3
EVERY 50 HOURS OF OPERATION (Weekly)
1
2
1
1
Tires – tire pressure
Wheel nuts – tightening
Fig. 17 Wheels
1. Air valve
2. Wheel nut
Check the tire pressures using a pressure gauge.
If the tires are filled with fluid, the air valve (1) must be
in the “12 o’clock” position during pumping.
The relevant tire pressures are given under the heading
“Specifications”.
Check both tires.
When changing the tires it is important that
both of them have the same rolling radius. This
is necessary to ensure proper functioning of
the anti-slip in the rear axle.
Check the tightening torque of the wheel nuts (2) at 470
Nm (350 lbf.ft). Check both wheels and all the nuts.
(Applies only to new machine or recently fitted wheels.)
Check the safety manual that accompanies
the roller before filling the tires with air.
Never work under the roller with the engi-
ne running. Park on a level surface, chock
the wheels and press the parking brake
control.
Open the engine hood while the unit is running and look
at the sight glass (1) to make sure that no bubbles are
visible on the dryer filter.
Always push the parking brake knob.
The filter is located on the left side in the front of the
engine compartment. If bubbles are visible through the
sight glass, it is a sign that the level of refrigerant is too
low. If so, stop the unit. There is a risk of damage to the
unit if it is run with insufficient refrigerant.
Airconditioning(Optional)
– Inspection
Fig.18 Drying filter
1. Sight glass
Fig.19 Cab
1. Condenser element
In the event of noticeable deterioration of cooling capa-
city, clean the condenser element (1), which is located
at the rear of the cab roof. Also clean the cooling unit
inside the cab.
The system described in this manual is of the ACC
type (Automatic Climate Control)

16 CA152 M152EN3
Always lower the blade to the ground
before leaving or parking the roller.
Make sure that nobody is in the way when
operating the blade.
Lower the blade.
Wipe the nipples clean from grease and dirt, three on
each side of the machine.
Grease each nipple (1) with four strokes of the grease
gun. Ensure that grease penetrates the bearings.
Fig.20 Strike-off blade
1. Lubricant nipples
1
Strike-offblade(Optional)
– Lubrication
EVERY 50 HOURS OF OPERATION (Weekly)

17CA152 M152EN3
EVERY 250 OPERATING HOURS (Monthly)
1
3
2
1
1
Drum
– Checking the oil level
Rear axle differential
– Check oil level Never work under the roller with the engi-
ne running. Park on a level surface. Block
the wheels securely.
Wipe clean and remove the level plug (1) and check
that the oil level reaches the lower edge of the plug
hole. Top off with oil to the right level if the level is low.
Use transmission oil according to the lubricant
specification.
Position the roller with the level plug (1) in the planetary
gears at 9 o’clock.
Wipe clean and remove the level plug (1) and check
that the oil level reaches the lower edge of the plug
hole. Top off with oil to the right level if the level is low.
Use transmission oil according to the lubricant
specification.
Clean and screw in the plug.
Check the oil level in the same way in the rear axle’s
other planetary gear.
Fig.21 Oil level check – differential housing
1. Oil level/Filler plug
Rear axle planetary gears
– Check oil level
Fig.22 Oil level check – planetary gear
1. Oil level/Filler plug
Fig.23 Right side of drum
1. Filling plug
2. Number plate
3. Sight glass
Position the roller on a flat surface so that the filler plug
(1) and number plate (2) on the right side of the drum
are straight up.
Oil level should reach up to the sight glass (3).
Top off as required through the filler plug (1) halfway on
the sight glass.
Clean the magnetic filler plug (1) from any metal parti-
cles before refitting it.
See lubricant specification for the right grade of oil.
Do not overfill with oil, risk of overheating.

18 CA152 M152EN3
Place the roller on a level surface. Switch
the engine off and push in the reserve/
parking brake knob for all checking and
adjustments on the roller, unless otherwise
specified.
Check that air can flow freely through the radiators (1)
and (2).
A dirty radiator should be blown clean with compressed
air, or alternatively cleaned with a high-pressure washer.
Blow or wash the cooler in the opposite direction to that
of the cooling air.
Be careful when using a high-pressure washer
– do not place the nozzle too close to the
radiator.
Use protective goggles when working with
compressed air or a high-pressure washer.
1
2
32
1
4
1
2
EVERY 250 OPERATING HOURS (Monthly)
Fig.24 Radiator
1. Water cooler
2. Hydraulic fluid cooler
Radiator – Check/clean
Bolted joints
– Checking tightening torque
Fig.25 Right side of machine
1. Steering pump
2. Rear axle
3. Engine suspension
4. Wheel nuts
Steering pump against engine (1) 38 Nm (28 lbf.ft).
Rear axle suspension (2) 330 Nm (243 lbf.ft), oiled.
Engine suspension (3). Check that all engine bolts are
tightened.
Wheel nuts (4). Check that all nuts are tightened, 470
Nm (347 lbf.ft), oiled.
(The above applies to new or replaced components
only.)
Check all the rubber elements (1), and replace them all if
more than 25% of the elements on the same side of the
roller have cracks deeper than 10–15 mm (0.4-0.6 in).
Use a knife blade or other pointed tool when carrying
out this check.
Check also that the screw fasteners (2) are tightened.
Fig. 26 Roller, vibration side
1. Rubber element
2. Screw fasteners
Rubber elements and screw
fasteners – Check
