E-Collar Technologies Einstein ET-1202A User manual

ET-1202A
Owner's Manual

Welcome to the World of Einstein E-Collar™
Thank you for purchasing the Einstein Remote
Education Collar from E-Collar Technologies, Inc.
We have made every attempt to provide you with the
most technologically advanced product using the
most stringent quality and manufacturing standards.
We are confident you will be pleased with the results
you will attain with the ET-1202A Two Dog Remote.
Please remember you will get better results with the
use of lower stimulation combined with consistent
training techniques. The use of high levels of
stimulation should only be used as a last resort and
in life-threatening situations.
Good luck with your training and please feel free to
contact us should you have any questions.
1-855-326-5527 or 1-855-ecollar
Remote Education Collar
ET-1202A Owner's Manual

02
Einstein Owner's Manual ET-1202A
CHARACTERISTICS
•
•
•
•
•
•
•
•
•
Range : Up to 1200 yards
Momentary and Continuous Stimulations Supported
Education Tone Supported
Employs Ni-MH Rechargeable Batteries
Convenient Intensity Dial for Quick Adjustment
Stimulation Levels Adjustable from 0 to 100
Collar Receiver Light for Night Tracking
Lock and Set Stimulation Feature
Stimulation boosting mode provides instant responses to
emergency situation
Characteristics

03
Einstein Owner's Manual ET-1202A
CONTENTS
•
2 Collar Receivers
•
Lanyard
•
Test Light
•
Contact Point Tool
•
Contact Points 3/4"
Contents
Battery Charger
(For ET-500 Only)
•
Transmitter
•
Owner’s Manual
Battery Charger and
Splitter Cable
•

04
Einstein Owner's Manual ET-1202A
TABLE OF CONTENTS
•
•
•
•
•
•
•
•
•
•
•
•
•
Safety and General Information
Getting Started
Charging the Batteries
Turning Your E-Collar On/Off
The LCD Display Features
Button Functions
Changing the Intensity Level of Stimulation
Lock/Unlock the Stimulation Intensity Level
Indicator Light
Testing Your Einstein
Replacing the Contact Points
Correctly Fitting the Collar
Warranty
05
06
08
10
11
12
15
18
19
20
21
22
23
Table of Contents

05
Einstein Owner's Manual ET-1202A
SAFETY AND GENERAL INFORMATION
•
•
•
•
The Einstein Education Collar complies with all National and
International Standards and Guidelines for human exposure to
radio frequency electromagnetic energy.
Nearly all electronic devices are susceptible to electromagnetic
interference (EMI) if inadequately shielded or designed without
precautions to EMI.
Einstein E-Collar transmitters manufactured by E-Collar
Technologies, Inc. comply with Article 15 of the FCC rules and
operate under Part 95 of FCC regulations.
IMPORTANT NOTICE
Safety and General Information
1.
2.
To avoid Electromagnetic Interference and/or compatibility conflicts,
please turn off your transmitter and collar receiver in any facility where
posted notices instruct you to do so. Never use your equipment in
close proximity of a Hospital or Health Care Facility or enter the facility
without turning off both units.
An FCC license is not needed to operate Einstein E-Collar transmitters.
However, any change or modification made to the transmitter,
including the supplied antenna, without the expressed written approval
of E-Collar Technologies, Inc. could void your authority to operate.

06
Einstein Owner's Manual ET-1202A
TRANSMITTER PARTS
Antenna
Stimulation Level Dial
/ Set and Lock Knob
Stimulation Button (1D, Black)
Stimulation Button (2D, Red)
Indicator Light
(LED Window)
LCD Display
Getting Started
Mode Button
On/Off Magnetic Dot
Light and On/Off Button
Battery Charging Receptacle
and Rubber Cover
Momentary / Continuous
Toggle Switch

07
Einstein Owner's Manual ET-1202A
COLLAR RECEIVER PARTS
Battery Charging
Receptacle and
Rubber Cover
Collar Strap
5/8" Contact Points
Indicator and Tracking Lights
(LED Window)
On/Off Magnetic Dot
Getting Started
THIS D-CLIP IS
NOT TO BE USED
AS A TIE OUT

08
Einstein Owner's Manual ET-1202A
CHARGING THE BATTERIES
Indicator Light will blink “Green” under normal operation. It will flicker
“Red” when stimulation is applied and will blink “Red” when
recharging is required. We recommend you fully charge your e-collar
every six months when not in use to maintain battery life.
Transmitter Battery Charging
Receptacle and Rubber Cover
Collar Receiver Battery Charging
Receptacle and Rubber Cover
Charging the Batteries
Battery Charger and Splitter Cable
Splitter Cable
120 Volt Charger
Wall Outlet
Charging Cable

09
Einstein Owner's Manual ET-1202A
Charging the Batteries
The indicator light will turn solid red during the 10 to 12 hour
charge cycle and stay red even though the unit is fully charged.
•
Battery Care:
It is important to fully charge the batteries and fully discharge them for
the first three uses. After that it is not necessary to fully discharge the
batteries with each use, because NiMH do not exhibit “memory effect”
like other rechargeable battery types. It is recommended that every six
months you recondition the batteries by fully discharging them and then
fully charging them, this will ensure you get the rated 500 charges per
battery.
•

10
Einstein Owner's Manual ET-1202A
TURNING YOUR E-COLLAR ON/OFF
•
To turn the Collar Receiver On or Off :
Position the color dot on the Transmitter close to the color dot on
the Collar Receiver. Two beeps will confirm the collar receiver
has been turned on and a single beep will confirm the unit has
been turned off. Push the tone button to assure the unit is on and
properly functioning.
TRANSMITTER ON/OFF BUTTON
Turning Your E-COLLAR On/Off
Color Dot
COLLAR RECEIVER ON/OFF MAGNETIC SWITCH
•
To turn the Transmitter On or Off :
Press the “L” light button for more
than 2 seconds.
If “L” light button is pressed less
than 0.5 seconds, it will turn
On/Off Tracking lights of Collar
Receiver.

11
Einstein Owner's Manual ET-1202A
THE LCD DISPLAY FEATURES
In 1D mode, the1D icon will blink indicating the stimulation is ready to
be changed. If the 1D icon is solid, it has been locked into a specific
stimulation level as displayed on the LCD. Release the stimulation lock by
clicking down on the rotary dial until the 1D icon begins to blink; now you
can change the stimulation to a new level. The new selected level can be
locked by clicking down on the rotary dial until the 1D icon stops blinking.
In 1D mode, the 2D icon will not be displayed unless it is locked.
In 2D mode, the 2D icon will blink when the stimulation is ready to
be changed.If the 2D icon is solid, it has been locked into a specific
stimulation level as displayed on the LCD. Release the stimulation lock by
clicking down on the rotary dial until the 2D icon begins to blink; now you
can change the stimulation to a new level. The new selected level can be
locked by clicking down on the rotary dial until the 2D icon stops blinking.
In 2D mode, the 1D icon will not be displayed unless it is locked.
Displays the Stimulation Level : “0”means no
stimulation and “HI” means the highest level(100 )
The LCD Display Features
•
•
Press down on the Stimulation Level Knob or press any button to wake up
the LCD display. Please note that if the collar receiver is on, pressing the
stimulation buttons and/or the mode button will trigger the collar receiver.
In Tone mode, the LCD displays "T" as shown in the right
picture and you cannot change the stimulation level.
•

12
Einstein Owner's Manual ET-1202A
BUTTON FUNCTIONS
Button Functions
Stimulation Button (1D, Black)
Stimulation Button (2D, Red)
LCD Display
Mode Button
Light and On/Off Button
Momentary / Continuous
Toggle Switch
Stimulation Level Dial
/ Set and Lock Knob
TRANSMITTER
The ET-1202A transmitter is equipped with four control buttons, one toggle
switch, LCD display, and an adjustable dial. For long range use hold the
transmitter up like the Statue of Liberty and never allow the antenna to touch
anything as it will decrease the range. Power lines and foliage will also reduce
the range.

Einstein Owner's Manual ET-1202A
13
Button Functions
Mode Button “M”
- Mode Button allows the user to change modes, cycling between 1D
Mode to Education Tone Mode, Education Tone Mode to 2D Mode,
2D Mode to Education Tone Mode, and Education Tone Mode to 1D
Mode as shown in the diagram.
- In 1D Mode, you can change the intensity level of 1D by rotating
the dial and locking it. (See “LOCK/UNLOCK THE STIMULATION
INTENSITY LEVEL” for details) The intensity level of 2D will be same
as that of 1D unless it is locked.
- In Education Tone Mode, you can send only an education tone to
each collar receiver. We purposely made it easy to switch back and
forth from Education Tone to stimulation with one button control.
- In 2D Mode, you can change the intensity level of 2D by rotating the
dial and locking it. The intensity level of 1D will be same as that of 2D
unless it is locked.
Stimulation Button (1D)
- In 1D Mode, you can jump to 2D Mode by pressing 2D Stimulation
Button and vice versa.
- In 1D/2D Mode, Sends momentary or continuous stimulation to the
Dog 1 collar receiver based on the selection of toggle switch.
- If the current mode is 2D mode, the mode will be changed to 1D
mode by pressing 1D Stimulation Button.
1 Dog Mode2Dog ModeEducation Tone Mode Education Tone Mode

Einstein Owner's Manual ET-1202A
14
Button Functions
- In Education Tone Mode, Sends an education tone to the Dog 1
collar receiver.
Stimulation Button (2D)
- In 1D/2D Mode, Sends momentary and continuous stimulation to the
Dog 2 collar receiver based on the selection of toggle switch.
- If the current mode is 1D mode, the mode will be changed to 2D
mode by pressing 2D Stimulation Button.
- In Education Tone Mode, Sends an education tone to the Dog 2
collar receiver.
Light Button “L”
- When pressed less than 0.5 seconds, it will turn On or Off the high
intensity night tracking light.
* In 1D Mode, it will turn ON/OFF Dog 1 collar receiver light.
* In 2D Mode, it will turn ON/OFF Dog 2 collar receiver light.
* In Education Tone Mode, Light ON/OFF Function is disabled.
- When pressed for more than 2 seconds, it will turn On or Off the
transmitter.
* After 1.25 seconds of holding down the education tone the collar
will administer a stimulation as long the button remains pressed
providing “Pavlovian Conditioning”.
* After 1.25 seconds of holding down the education tone the collar
will administer a stimulation as long the button remains pressed
providing “Pavlovian Conditioning”.

Einstein Owner's Manual ET-1202A
15
Button Functions
Momentary/Continuous Toggle Switch
- Toggle switch on the backside of the transmitter allows the user to
switch between Momentary Stimulation and Continuous Stimulation.
- If Continuous Stimulation is selected, pressing stimulation buttons
(1D or 2D) will send stimulation to the collar receiver for the duration
of the button being pressed. After 10 seconds the Over-Stimulation
feature will stop the stimulation until the button is released and
pressed again.
Boosting Function
(Stimulation Button for Dog 1 or Dog 2 plus Mode Button)
- The boosting function is accomplished by first pressing either Dog
1 or Dog 2 stimulation buttons and then simultaneously pressing the
Mode Button. The boosted stimulation will be administered as long as
both buttons remain pressed.
- The boosted stimulation intensity is 25 levels higher than current
stimulation setting.
- If the current level is 75 or higher, the boosted stimulation level will
be 100 (HI).
- This is an useful function in situations where additional stimulation is
required for proper control of the dog.

Einstein Owner's Manual ET-1202A
16
CHANGING THE INTENSITY LEVEL OF STIMULATION
Rotating clockwise increases the
stimulation level and conversely,
rotating counter-clockwise lowers
the stimulation level.
It is highly recommended that the user practices changing levels and
modes before putting the collar receiver on the dog.
Setting the correct stimulation level for your dog is very important. To
set your “conditioning” stimulation level, put the collar receiver (see
page 22 for proper fitting technique) on your dog. Let him/her get
used to the collar receiver for a couple of hours. While watching your
dog, turn the level to “0” and press the stimulation button (1D/2D).
Slowly turn the stimulation up at a rate of approximately 2-3 levels
per second. When your dog first perceives the stimulation, usually
between 15 and 40, release the button. This is your “conditioning”
stimulation level. You may need to add a few levels later as your dog
becomes more conditioned to the stimulation. The “conditioning”
stimulation is used when the trainer wants to use the stimulation in
continuous mode.
Changing the Intensity Level of Stimulation

Einstein Owner's Manual ET-1202A
CHANGING THE INTENSITY LEVEL OF STIMULATION
For example, if you want your dog to come to you and heel, you can
hold the button down until your dog comes and heels or if jumping is
an issue, you can hold the button down anytime their front paws are
off the ground. Your dog will learn that he/she controls the stimulation.
Setting the “Corrective” stimulation level is a little more difficult due
to the wide differences in temperaments and stimulation tolerance
among the many breeds of dogs. On average, it is normally 20 to 40
levels higher than the “Conditioning” level. This higher level will only
be used in “Momentary” mode as not to over-stimulate your dog.
This mode is used for stopping unwanted behaviors such
as chewing, digging, street-running, excessive barking, and
aggressiveness, etc. It is important to apply the “Momentary” stimulus
at the exact time of the unwanted behavior. Additional pulses may
be used to reinforce the command if compliance is not immediate.
A treat is recommended after compliance. If a treat is not available,
verbal positive reinforcement is acceptable.
Changing the Intensity Level of Stimulation
17

Einstein Owner's Manual ET-1202A
18
CHANGING THE INTENSITY LEVEL OF STIMULATION
IMPORTANT TRAINING TIP
E-Collars should be used to reinforce commands your dog already
knows. It is not a replacement for basic leash obedience training, but
a tool to allow you to better communicate to your dog.
For best results, use the least amount of stimulation required to get
compliance from your dog. A calm and consistent approach to
training will always produce better long term results. It is highly
recommended that aggressive dogs be taken to a professional trainer
for evaluation before e-collar use.
There are many different e-collar training techniques recommended
by a variety of professional trainers. We beleive you, the owner of the
dog, can best determine the most successful technique for your dog.
YouTube has many videos demonstrating these varying techniques
by simply searching "e-collar training" or "remote dog training
techniques".
Good Luck with your training!
Changing the Intensity Level of Stimulation

Einstein Owner's Manual ET-1202A
LOCK/UNLOCK THE STIMULATION INTENSITY LEVEL
How to Lock/Unlock the Stimulation Level
This feature is useful when controlling two dogs simultaneously and
you want to have different stimulation levels for each dog.
In 1D Mode, you can see the 1D icon is blinking on the LCD display.
Set the desired stimulation level and then push down on the top of the
stimulation dial until you see “1D” icon stop flashing.
If the stimulation level doesn’t change when you rotate the stimulation
knob, you have successfully locked the stimulation level of Dog 1.
Change the mode to 2D Mode by pressing the Mode Button twice
and repeat the previous step. The “2D” icon light on the bottom
portion of the LCD display will stop flashing. when you have
successfully locked the stimulation level of Dog 2.
To unlock the stimulation level simply press the stimulation knob
again and it will unlock the stimulation level of the dog selected by
the mode button.
Dog 1
Dog 2
Lock/Unlock the Stimulation Intensity Level
19
