E-Collar Technologies Easy Educator EZ-900 User manual

Easy Educator EZ-900
Quick Start Guide
E-Collar Technologies, Inc.

Welcome
Thank you for trusting us with your purchase of the 900 Easy Educator
Remote Education Collar.We have made every attempt to provide you
with the most technologically advanced product using the most
stringent quality and manufacturing standards.
We are confident you will be pleased with the results you will attain with
the 900 Easy Educator. Please remember you will get better results with
the use of low level stimulation combined with consistent training tech-
niques. The use of high levels of stimulation should only be used as a last
resort and in life-threatening situations.
Good luck with your training and please feel free to contact us should you
have any questions
* This guide will familiarize you with the basic functions, programming
features and the contents of the 900 Easy Educator.
Additional information and help is available on www.ecollar.com and
e-mail by e-mailing [email protected]. To talk to a live
team member please contact our customer service department,
8 AM to 8 PM E.S.T., 1-855-326-5527 or [phone]. Your total
satisfaction is our only concern.

TABLE OF CONTENTS
3
4
5
6
7
8
10
12
13
14
15
16
Characteristics
Package Contents
Turning ON/OFF the EZ-900 System / Charging Instructions
EZ-900 Functions
LCD Display 1 Dog Mode
Buttons Descriptions and Stimulation Button Assignments
I Mode / Lock and Unlock Stimulation Level
Booster Level Setup / Lost Transmitter Activation
EZ-900 One Dog Default Settings
Expand to Two Dog
Pairing
Warranty and Registration

CHARACTERISTICS
03
1/2 mile Range
Employs Quick Charge Li-Polymer Batteries
Convenient Intensity Dial for Quick Adjustment
Stimulation Levels Adjustable from 0 to 100
Collar Receiver Light for Night Tracking
“Lock and Set” Stimulation Safety Feature
User Adjustable Boosting Levels
Patented “I” Mode Provides Instant Stimulation
Waterproof and Shock Resistant
Easily Expandable to 2 Dogs

PACKAGE CONTENTS
04
Ergonomic Transmitter
- Remote-Sender
Quick Start Owner’s
Guide
Waterproof Collar
Receiver High Quality
Biothane Strap
Test Light 5/8” and ¾” Contact
Points
Contact Point Tool
Lanyard Battery Charger
Easy Educator EZ-900
Quick Start Guide
E-Collar Technologies, Inc.

05
Turn ON/OFF the transmitter by pressing the lower
right button for 1 second.
Turn ON/OFF the collar receiver by placing the red dot on the transmitter on
the red dot on the collar receiver for 1 second.
Turning ON/OFF the EZ-900 System
Please charge the units on or before the
low battery indication. It is best not to wait
until the batteries are fully drained to
avoid damage. To charge insert the micro
USB into the transmitter and the charge
plug into the collar receiver as pictured.
Store with 50% charge in cool dry place.
Low Battery Indication
Transmitter: One bar remaining on the LCD display indicates charging is needed.
Collar Receiver: Yellow light indicates low and red indicates very low battery life.
Charging Instructions

06
Icon
M
M+
C+
C
Stimulation
Others
I
V
T
Function
Momentary Stimulation Send momentary stimulation (volume level)
Momentary Boost Stimulation Send momentary boosting stimulation
(volume + boost Level)
Continuous Stimulation Send continuous stimulation
(max 10 sec, volume level)
Instant Mode Without pressing any button, it will send continuous
stimulation by rotating volume dial. (max 45 sec)
Vibration Sendsvibration (max 30 sec)
Tone Sendstone (max 30 sec)
Continuous Boost Stimulation Sendscontinuous boosting stimulation
(max 10 sec, volume + boost level)
Description
Icon Function
Easy Educator 900 provides 5 types of stimulation sensations, tone, and
vibration.
EZ-900 Functions

07
LCD DISPLAY
1 DOG Mode
Icon
M
M+
C+
C
I
V
T
Number
Description
Momentary Stimulation Short Pulse of Stimulation
Momentary Boost Stimulation Short Pulse of Boosted Stimulation
Continuous Stimulation Up To 10 Seconds of Stimulationㅤ
Instant Stimulation Mode
Stimulation Level Displayed on the LCD,
Must Start From “0”
Vibration Non Stimulation Sensation Similar to a
Vibrating Cell Phoneㅤ
Tone Audible Tone
Stimulation Level 0 to 100(HI) level
Continuous Boost Stimulation Up to 10 Seconds of Boosted Stimulation
Remarks

Buttons Descriptions and
Stimulation Button Assignments
The 900 Easy Educator has 4 control buttons which are assigned to
stimulation, vibration and tone. It also has 2 program buttons for changing
modes(P) and turning the unit ON and OFF. The convenient dial
provides for easy and sight free control of the stimulation level.
08
Volume Dial
Stimulation Level
P-Button
S1-Button
S3-Button
S2-Button
S4-Button ON/OFF-Button

09
Function Description
Power ON/OFF
Night Light
Volume Lock
Stimulation Lock Level
Mode Buttons
Press more than 1 sec to turn ON
Press more than 2 sec to turn OFF
Press more than 1 sec to
Lock/Unlock Stimulation Level
Program
Buttons
ON/OFF
P
Control Buttons Function Possibilities
M / C(I) / V / T
M / C(I) / V / T
M / C(I) / V / T
M / C(I) / V / T
M / C / V / T
S1+S2, S2+S1
S3+S4, S4+S3
It is only activated when first button is M or C
1. To start Instant mode, rotate volume to level 0 and press a button set to continuous
2. To exit from Instant mode, press any button or wait for the 45 second time out.
S1-Button
S2-Button
S3-Button
S4-Button
LCD Display
Booster
Function
Press ON/OFF quickly to activate Light
Toggles (Blinking → Solid → OFF)
Set Stimulation to Level "0"
S1 mode change: P+S1 (M C V T)
S2 mode change: P+S2 (C V T M)
S3 mode change: P+S3 (V T M C)
S4 mode change: P+S4 (T M C V)
"C" mode activates the "I" mode when pushed on level "0"

“I” Instant Stimulation Mode
“I” Instant Stimulation Mode
The "I" mode is a patented feature which allows the stimulation to
increase gradually as determined by the user. The gradual introduction of
stimulation provides a more gentle sensation and removes the startling
effect sometimes associated with applying a constant level of stimulation.
The dog produces less cortisol and learns to avoid the higher levels by
responding quickly to the command. The user has the flexibility of
increasing the stimulation fast if the situation warrants a quick response
from the dog.
How Instant Stimulation “I” Mode Works
How Instant Stimulation “I” Mode Works
1. Change the mode of any S button to Continuous if not already
programmed to “C” mode : The stimulation dial must be turned to
“0” to enter the “I” mode.
2. To start the “I”, push the assigned Continuous button. The display will
flash On to indicate it is on and ready to begin stimulation.
3. Turning the stimulation will now activate the stimulation at the setting
of the dial and continue for 45 seconds.
Returning to “0” will reset the 45 second safety timer.
4. If you do not rotate the dial for 45 seconds the “I” mode will turn off
and the control button will need to be pushed again.
5. Pushing any of the other control buttons will turn off the “I” mode and
therefore require the “I” mode control be pushed again to reactivate it.
6. Again, to exit the Instant Mode, press any control button or wait for
45 seconds.
I Mode / Lock and Unlock
Stimulation Level
10

Lock and Unlock Stimulation Level
Lock and Unlock Stimulation Level
* Important Note: Blinking “1D” Indicates Unlocked Stimulation /
* Important Note: Blinking “1D” Indicates Unlocked Stimulation /
Solid “1D” Indicates Locked Stimulation
Solid “1D” Indicates Locked Stimulation
1. Set the desired stimulation level to be locked by rotating volume dial.
2. Press P (Upper Left) button for more than 1 second.
3. Check LCD display to confirm “1D” icon changes blinking to solid.
4. To unlock, press P button for more than 1 second.
11
Accessories

Booster Level Setup /
Lost Transmitter Activation
12
Lost Transmitter Activation (6 Hour Timer)
1. Change the Stimulation level to “0”
2. Press ON/OFF button and then press P button simultaneously.
3. One short beep will sound confirming the activation of the locator
timer.
4. To deactivate, press ON/OFF button and P button one more time.
5. Two short beeps will sound confirming the deactivation of the locator
timer.
6. The transmitter will start beeping 6 hours from activation so plan your
excursion accordingly.
Booster Level Setup
1. Change the mode of any S button to Momentary if not already
programmed to “M” mode.
2. Change the Stimulation level to “0”
(Stimulation level should be unlocked)
3. Press Momentary button for more than 5 sec and enter into Booster
Level Change Mode.
4. Check LCD displays M+ / C+ icon
5. Rotate the dial to change the booster level.
(The range of booster level is from 1 to 60, default is 5)
6. Press Momentary Button again to exit from Booster Level Change
Mode.

EZ-900 One Dog Default Settings
Factory default setting of EZ-900 is as below. You can change Tone
Mode, Vibration Mode, and Instant Mode by using computer interface tool
which can be downloaded at http://www.ecollar.com
http://www.ecollar.com
Factory Default Setting
S1-Button
S2-Button
S3-Button
S4-Button
Boost Level
Momentary
Continuous
Vibration
Tone
5
Tone Mode
Vibration Mode
Mode – 2
Instant Mode Normal Mode
Mode – 4
13

14
Pairing/Syncing
When you change transmittersor collar receivers they will need to paired/
synced to each other for them to communicate with each other.
Pairing/Syncing (ON/OFF + S3)
1. Turn on the Transmitter.
2. Rotate the intensity dial to “0”.
3. Turn off the collar receiver. Put the red dot on the transmitter
against the red dot on the collar receiver for more than 5 seconds till
the solid green light starts blinking on and off rapidly.
4. Press the ON/OFF button and then press the S3 button (Front Top)
simultaneously.
5. Listen for confirmation sound from the Collar Receiver.
6. Test the collar receiver to make sure it accepted the new transmitter

15
Expand to Two Dog
EZ-900 can be easily expanded to two dog EZ-902.
When you purchase additional Collar Receiver,you can change EZ-900
Transmitter to operate lke an EZ-902, see website for owner's manual.
1. Rotate the intensity dial to “0”.
2. Press the ON/OFF button and then press S3 button (Front Top) &
S4 button (Front Bottom) simultaneously for 5 sec.
3. Three short beep sounds will confirm that S/W is changed to EZ-902
Mode successfully. (2D icon will be appeared at LCD Display)
4. If you want to change back to an EZ-900,press ON/OFF button
+ S1 + S2 for 5 sec.
After expanding to EZ-902, 2nd Collar Receiver should be paired to
Transmitter. For the additional information, please refer to EZ-902
manual which is available at http://www.ecollar.com .
(Press On/Off+S3+S4 for 5 sec)

16
WARRANTY AND REGISTRATION
TTwo Year Full Warrantwo Year Full Warranty:
Your product is covered by our full two year warranty. During the warran-
ty period we will repair and or replace your product for any reason due to
workmanship and component failures. Dog chews and misuse are not
covered by the warranty and are subject to a repair/replacement fee.
To register your Pro Educator please select one of the
following procedures
(1) Go to the “Products” section on www.ecollar.com
www.ecollar.com
and click the “Register Your e-Collar Products” tab and
complete the form
(2) Fill out the provided warranty registration card and
mail it or fax it to us at 1-855-226-5527.
(3) Call us at [phone] and one of our customer
service representatives will register your products
for you, please have your serial number available.

This product is covered by various patents including but not limited to
patents 8757098 and 8833309. Patent is pending on the Instant
Stimulation Feature on this device.
Copyright 2014 E-Collar Technologies, Inc. All Rights Reserved.
CONTACT INFORMATION
E-Collar Technologies, Inc.
2120 Forrest Park Drive
Garrett, IN 46738
Toll-Free 1-855-326-5527
Toll-Free Fax [phone]
International : 001-260-357-0051
www.ecollar.com
[email protected]
[email protected]

IMPORTANT NOTICE
About Contact Points:
Many dogs in our modern society have developed sensitivity to nickel which is a metal
in all stainless steel products. Keep a watchful eye on your dogs skin where the contact
points are touching his/her skin for redness or any signs of irritation. This should be
done hourly at first and slowly transition to once every four hours after a month of daily
wearing of the e-collar. At first notice of redness immediately switch to one of our hypo
allergenic contact points, we offer both nickel free stainless steel and titanium contact
points. Dogs with sensitive skin and certain breeds with known skin sensitivities like Pit
Bull Terriers and Boxers should be switched early in the process as a precautionary
move.
Nickel Free Stainless Steel
Available on www.ecollar.com or by calling 1-855-326-5527

E-Collar Technologies, Inc.
2120 Forrest Park Drive
Garrett, IN 46738-9471
1-260-357-0051 (US & Internationa)
1-855-326-5527 (US Toll Free)
1-855-226-5527 (US Toll Free Fax)
[email protected]
www.ecollar.com
