e2v UNIIQA+ 16k CL User manual

UNIIQA+ 16k CL
Cmos Monochrome Camera
User Manual

UNIIQA+® 16k CL
2 UM UNIIQA+16kCL –REVC –11/14 e2v semiconductors SAS 2014
Summary
1 CAMERA OVERVIEW .................................................................................4
1.1 Features ....................................................................................................................................................... 4
1.2 Key Specifications....................................................................................................................................... 4
1.3 Description .................................................................................................................................................. 5
1.4 Typical Applications.................................................................................................................................... 5
1.5 Models ......................................................................................................................................................... 5
2 CAMERA PERFORMANCES............................................................................6
2.1 Camera Characterization ............................................................................................................................ 6
2.3 Response & QE curves................................................................................................................................ 7
2.3.1 Quantum Efficiency .................................................................................................................................................................7
2.3.2 Spectral Response...................................................................................................................................................................7
3 CAMERA HARDWARE INTERFACE .....................................................................8
3.1 Mechanical Drawings.................................................................................................................................. 8
3.2 Input/output Connectors and LED ............................................................................................................. 9
3.2.1 Power Connector ................................................................................................................................................................... 10
3.2.2 Status LED Behaviour.............................................................................................................................................................11
3.2.3 CameraLink Output Configuration.........................................................................................................................................11
4 STANDARD CONFORMITY .......................................................................... 12
4.1 CE Conformity ............................................................................................................................................ 12
4.2 FCC Conformity .......................................................................................................................................... 12
4.3 RoHs Conformity........................................................................................................................................ 12
5 GETTING STARTED ................................................................................. 14
5.1 Out of the box............................................................................................................................................ 14
5.2 Setting up in the system........................................................................................................................... 14
6 CAMERA SOFTWARE INTERFACE .................................................................... 15
6.1 Control and Interface ................................................................................................................................ 15
6.2 Serial Protocol and Command Format..................................................................................................... 16
6.2.1 Syntax .................................................................................................................................................................................... 16
6.2.2 Command Processing ........................................................................................................................................................... 16
6.2.3 GenICam ready ...................................................................................................................................................................... 16
6.3 Camera Commands................................................................................................................................... 17
6.3.1 Information ............................................................................................................................................................................ 17
6.3.2 Image Format ......................................................................................................................................................................... 19
6.3.3 Acquisition Control................................................................................................................................................................ 21
6.3.4 Gain and Offset..................................................................................................................................................................... 22
6.3.5 Flat Field Correction.............................................................................................................................................................. 25
6.3.5.1 Activation and Auto-Adjust.................................................................................................................................. 27
6.3.5.2 Automatic Calibration .......................................................................................................................................... 28
6.3.5.3 Manual Flat Field Correction................................................................................................................................ 29
6.3.5.4 FFC User Bank Management................................................................................................................................ 30
6.3.6 Look Up Table ........................................................................................................................................................................ 31
6.3.7 Statistics and Line Profile .................................................................................................................................................... 33

UNIIQA+® 16k CL
3 UM UNIIQA+16kCL –REVC –11/14 e2v semiconductors SAS 2014
6.3.8 Privilege Level....................................................................................................................................................................... 34
6.3.9 Save & Restore Settings....................................................................................................................................................... 35
7 APPENDIX A: Test Patterns......................................................................... 36
7.1 Test Pattern 1: Vertical wave..................................................................................................................... 36
7.2 Test Pattern 2: Fixed Horizontal Ramps................................................................................................... 36
7.2.1 In 8 bits (Full) format ............................................................................................................................................................ 36
7.2.2 In 12 bits (Medium) format .................................................................................................................................................. 37
8 APPENDIX B: Timing Diagrams ..................................................................... 38
8.1 Synchronization Modes with Variable Exposure Time ........................................................................... 38
8.2 Synchronisation Modes with Maximum Exposure Time ........................................................................ 39
8.3 Timing Values ............................................................................................................................................ 39
9 APPENDIX C: CameraLink Data Cables.............................................................. 40
10 APPENDIX D: Lenses Compatibility .............................................................. 41
11 APPENDIX E: TROUBLESHOOTING .................................................................. 43
11.1 Camera....................................................................................................................................................... 43
11.2 CommCam Connection ............................................................................................................................. 43
12 APPENDIX F: Command Summary Tables ........................................................ 44
12.1 Device Control ........................................................................................................................................... 44
12.2 Image Format ......................................................................................................................................... 44
12.3 Synchro and Acquisition....................................................................................................................... 45
12.4 Gain & Offset.......................................................................................................................................... 45
12.5 Flat Field Correction .................................................................................................................................. 46
12.6 LUT .......................................................................................................................................................... 46
12.7 Save and Restore ...................................................................................................................................... 47
12.8 Camera Status ....................................................................................................................................... 47
12.9 communication...................................................................................................................................... 47
12.10 Line Profile Average............................................................................................................................... 48
13 APPENDIX G: Revision History ................................................................... 49

UNIIQA+® 16k CL
4 UM UNIIQA+16kCL –REVC –11/14 e2v semiconductors SAS 2014
1CAMERA OVERVIEW
1.1 Features
 Cmos Sensor 16384 Pixels, 5 x 5µm
 Interface : Medium/Full/ Full+ (10 Taps) CameraLink®, 85MHz per Channel
 Line Rate : Up to 50000 l/s
 Data Rate : Up to 850 MB/s
 Bit Depth : 8 or 12bits
 Flat Field Correction
 Look Up Table
 Low Power Consumption : <13W
 Compliant with Standard Lenses of the Market
1.2 Key Specifications
Note : All values in LSB is given in 12 bits format
Characteristics
Typical Value
Unit
Sensor Characteristics at Maximum Pixel Rate
Resolution
16384
Pixels
pixel size (square)
5 x 5
µm
Max line rate –CameraLink Full+ 10 x 85MHz
50
kHz
Max line rate –CameraLink Full 8 x 85MHz
40
Max line rate –CameraLink Medium 4 x 85MHz
20
Radiometric Performance at Maximum Pixel Rate and minimum camera gain
Bit depth
8, 12
Bits
Response (broadband)
112
LSB/(nJ/cm²)
Full Well Capacity
13500
electrons
Response non linearity
0,3
%
PRNU HF Max
3
%
Dynamic range
67,6
dB

UNIIQA+® 16k CL
5 UM UNIIQA+16kCL –REVC –11/14 e2v semiconductors SAS 2014
Functionality (Programmable via Control Interface)
Analog Gain
Up to 12 (x4)
dB
Offset
-4096 to +4096
LSB
Trigger Mode
Timed (Free run) and triggered (Ext Trig, Ext ITC) modes
Mechanical and Electrical Interface
Size (w x h x l)
100 x 156 x 36
mm
Weight
700
g
Lens Mount
M95x1
-
Sensor alignment ( see chapter 4 )
±100
µm
Sensor flatness
±35
µm
Power supply
Single 12 DC to 24 DC
V
Power dissipation - CameraLink
< 13
W
General Features
Operating temperature
0 to 55 (front face) or 70 (Internal)
°C
Storage temperature
-40 to 70
°C
Regulatory
CE, FCC and RoHS compliant
1.3 Description
e2v’s next generation of line scan cameras are setting new, high standards for line rate and image quality. Thanks to
e2v’s recently developed CMOS technology, the camera provides 50 000 lines/s in a 16k pixel format and combines
high response with an extremely low noise level; this delivers high signal to noise ratio even when short integration
times are required or when illumination is limited. The 5μm pixel size is arranged in one single active line, ensuring
optimal spatial resolution in both scanning and sensor directions with off-the-shelf lenses.
1.4 Typical Applications
 Flat Panel Color Filter Inspection
 PCB Inspection
 Solar Cell Inspection
 Glass Inspection
 Print Inspection
1.5 Models
EV71YC1MCL1605-BA0 : 16384 Pixels 5x5µm CameraLink 50kl/s

UNIIQA+® 16k CL
6 UM UNIIQA+16kCL –REVC –11/14 e2v semiconductors SAS 2014
2CAMERA PERFORMANCES
2.1 Camera Characterization
Unit
Gain x1 (0dB)
Gain x2 (6dB)
Gain x4 (12dB)
Min
Typ.
Max
Min
Typ.
Max
Min
Typ.
Max
Dark Noise RMS
LSB
-
1,7
2,2
3,4
4,4
6,8
8,8
Dynamic Range
-
-
2400:1
-
-
1200:1
-
-
600:1
-
Readout Noise
e-
-
5,7
-
-
5,7
-
-
5,7
-
Full Well Capacity
e-
-
13650
-
-
13650
-
-
13650
-
SNR
dB
-
40
-
-
37
-
-
34
-
Peak Response (660nm)
LSB/
(nJ/cm2)
-
137
-
-
274
-
-
547
-
Non Linearity
%
-
0,3
-
-
0,3
-
-
0,3
-
Without Flat Field Correction :
FPN rms
LSB
-
0,4
1,5
-
0,7
1,5
-
0,8
1,5
FPN pk-pk
LSB
-
3,2
15
-
5
15
-
5,6
15
PRNU hf (3/4 Sat)
%
-
0,13
0,25
-
0,1
0,25
-
0,1
0,25
PRNU pk-pk (3/4 Sat)
%
-
1
3
-
0,8
3
-
0,8
3
Test conditions :
Figures in LSB are for a 12bits format.
Measured at exposure time = 50µs and line period = 50µs in Ext Trig Mode (Max Exposure Time)
Maximum data rate
Stabilized temperature 30/40/55 °C (Room/Front Face/Internal)
SNR Calculated at 75% Vsat with minimum Gain.

UNIIQA+® 16k CL
7 UM UNIIQA+16kCL –REVC –11/14 e2v semiconductors SAS 2014
2.3 Response & QE curves
2.3.1 Quantum Efficiency
2.3.2 Spectral Response

UNIIQA+® 16k CL
8 UM UNIIQA+16kCL –REVC –11/14 e2v semiconductors SAS 2014
3CAMERA HARDWARE INTERFACE
3.1 Mechanical Drawings
Z
X
Y
The Step file is available on
the web :
www.e2v.com/cameras

UNIIQA+® 16k CL
9 UM UNIIQA+16kCL –REVC –11/14 e2v semiconductors SAS 2014
3.2 Input/output Connectors and LED
Sensor alignment
Z = -9.4 mm
±100µm
X = 9 mm
±100 µm
Y = 50mm
±100 µm
Flatness
±25 µm
Rotation (X,Y plan)
±0,1°
Tilt (versus lens mounting plane)
50µm
USB Connector
For Firmware
upgrade
Power Connector :
12-24V DC
Multi-Colored LED
for Status and
diagnostic
CameraLink Connector
CL1
CameraLink Connector
CL2

UNIIQA+® 16k CL
10 UM UNIIQA+16kCL –REVC –11/14 e2v semiconductors SAS 2014
3.2.1 Power Connector
Camera connector type: Hirose HR10A-7R-6PB (male)
Cable connector type: Hirose HR10A-7P-6S (female)
Camera side description
Signal
Pin
Signal
Pin
PWR
1
GND
4
PWR
2
GND
5
PWR
3
GND
6
Power supply from 12 to 24v
Power 13W max with an typical inrush current peak of
1,8A during power up
Power up Time : Around 43s (Green Light)
0
0.5
1
1.5
2
0.041 0.042 0.043 0.044
time (s)
Inrush current (A)
Typical
values
Current
consumption
12V
24V
UNIIQA+ CL (normal)
1,06A
0,54A
UNIIQA+ CL (Standby)
0,47A
0,25A

UNIIQA+® 16k CL
11 UM UNIIQA+16kCL –REVC –11/14 e2v semiconductors SAS 2014
3.2.2 Status LED Behaviour
After less than 2 seconds of power establishment, the LED first lights up in ORANGE. Then after a Maximum of 30 seconds,
the LED must turn in a following colour :
Colour and state
Meaning
Green and continuous
OK
Green and blinking slowly
Waiting for Ext Trig (Trig1 and/or Trig2)
Red and continuous
Camera out of order : Internal firmware error
3.2.3 CameraLink Output Configuration
Connector CL1 + CL2
Pixels per Channel
Medium CameraLink Mode
4 Channels 8bits
4 x 85MHz
4 x 4096
4 Channels 12bits
4 x 85MHz
4 x 4096
Full CameraLink Mode
8 Channels 8bits
8 x 85MHz
8 x 2048
Full + CameraLink Mode
10 Channels 8bits
10 x 85MHz
10 x 1638

UNIIQA+® 16k CL
12 UM UNIIQA+16kCL –REVC –11/14 e2v semiconductors SAS 2014
4STANDARD CONFORMITY
The UNIIQA+ cameras have been tested using the following equipment:
A shielded power supply cable
A Camera Link data transfer cable ref. 14B26-SZLB-500-OLC(3M)
e2v recommendsusing the same configuration to ensure the compliance with the following standards.
4.1 CE Conformity
The UNIIQA + cameras comply with the requirements of the EMC (European) directive
2004/108/CE (EN50081-2, EN 61000-6-2).
4.2 FCC Conformity
The UNIIQA + cameras further comply with Part 15 of the FCC rules, which states that: Operation is subject to the
following two conditions:
This device may not cause harmful interference, and
This device must accept any interferencereceived, including interference that may cause undesired operation
This equipment has been tested and found to comply with the limits for Class A digital device, pursuant to part 15 of
the FCC rules. These limits are designed to provide reasonable protection against harmful interference when the
equipment is operated in a commercialenvironment.This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interferenceto radio communications.Operation of this equipment in a
residential area is likely to cause harmful interferencein which case the user will be required to correct the interference
at his own expense.
Warning: Changes or modificationsto this unit not expressly approved by the party responsible for compliance
could void the user's authority to operate this equipment.
4.3 RoHs Conformity
UNIIQA + cameras comply with the requirements of the RoHS directive 2011/65/EU.

UNIIQA+® 16k CL
13 UM UNIIQA+16kCL –REVC –11/14 e2v semiconductors SAS 2014

UNIIQA+® 16k CL
14 UM UNIIQA+16kCL –REVC –11/14 e2v semiconductors SAS 2014
5GETTING STARTED
5.1 Out of the box
The contains of the Camera box is the following :
-One Camera UNIIQA+
5.2 Setting up in the system
The Compliant Lenses and their accessories are detailed in Appendix C
There is no CDROM delivered with the Camera : Both User Manual (this document) and CommCam control
software have to be downloaded from the web site : This ensure you to have an up-to-date version.
Main Camera page : www.e2v.com/cameras
On the appropriate Camera Page (UNIIQA+) you’ll find a download link
first version of CommCam compliant is indicated in the last Chapter
CommCam download requires a login/password :
 Login : commcam
 Password : chartreuse
FOV
Focal Plan
CCD Plan
f
L
w
s
w
f
FOV
L
=

UNIIQA+® 16k CL
15 UM UNIIQA+16kCL –REVC –11/14 e2v semiconductors SAS 2014
6CAMERA SOFTWARE INTERFACE
6.1 Control and Interface
As all the e2v Cameras, the UNIIQA+ CL is delivered with the friendly interface control software COMMCAM.UCL (as
“Ultimate Camera Link”) which is based on the GenICam standard
COMMCAM recognizes and detects automatically all the UCL Cameras connected on any transport layers (Camera Link or
COM ports) of your system.
Once connected to the Camera you have an easy access to all its features. The visibility of these features can be
associated to three types of users: Beginner, Expert or Guru. Then you can make life easy for simple users.
Minimum version of CommCam is 2.2.2 in order to recognize the UNIIQA +

UNIIQA+® 16k CL
16 UM UNIIQA+16kCL –REVC –11/14 e2v semiconductors SAS 2014
6.2 Serial Protocol and Command Format
The Camera Link interface provides two LVDS signal pairs for communication between the camera and
the frame grabber. This is an asynchronous serial communication based on RS-232 protocol.
The serial line configuration is:
 Full duplex/without handshaking
 9600 bauds (default), 8-bit data, no parity bit, 1 stop bit. The baud rate can be set up to 115200
6.2.1 Syntax
Internal camera configurations are activated by write or readout commands.
The command syntax for write operation is:
w <command_name> <command_parameters><CR>
The command syntax for readout operation is:
r <command_name><CR>
6.2.2 Command Processing
Each command received by the camera is processed:
 The setting is implemented (if valid)
 The camera returns “>”<return code><CR>
The camera return code has to be received before sending a new command.
The camera return code has to be received before sending a new command. Some commands are longer
than the others : Waiting for the return code ensure a good treatment of all the commands
Without saturating the buffer of the camera
Table 5-1. Camera Returned Code
Returned code
meaning
>0
(or “>OK”) : All right, the command will be implemented
>3
Error Bad CRC (for write command only)
>16
Invalid Command ID (Command not recognize or doesn't exist)
>33
Invalid Access (the receipt of the last command has failed).
>34
Parameter out of range (the parameter of the last command send is out of range).
>35
Access Failure (bad communication between two internal devices).
6.2.3 GenICam ready
The CameraLink Standard is not yet compliant with GenICam Standard, but as much as possible, each command of the
UNIIQA+ will have its correspondence with the Standard Feature Naming Convention of the GenIcam Standard.
This correspondence is given in parenthesis for each feature/command as the following example :
Vendor name ( DeviceVendorName ) : “e2v”

UNIIQA+® 16k CL
17 UM UNIIQA+16kCL –REVC –11/14 e2v semiconductors SAS 2014
6.3 Camera Commands
6.3.1 Information
These values allow to identify the Camera. They can be accessed in CommCam software in the “Info” section
All these values are fixed in factory and can’t be changed (shaded) except the Camera User ID which can be fixed by the
Customer :
Vendor name ( DeviceVendorName ) : “e2v”
Read function : “r vdnm”;
Returned by the camera : “e2v”, string of 32 bytes (including “/0”)
Cannot be written
Model Name ( DeviceModelName ) : Internal name for GenICam :
Read function : “r mdnm”;
Returned by the camera : String of 32 bytes (including “/0”) :
Cannot be written
Device Manufacturer Info ( DeviceManufacturerInfo ) : Get Camera ID
Read function : “r idnb”;
Returned by the camera : String of 128 bytes (including “/0”)
Cannot be written
Device Version ( DeviceVersion ) : Get Camera Hardware version
Read function : “r dhwv”;
Returned by the camera : String of 32 bytes (including “/0”)
Cannot be written
Device Firmware Version ( DeviceFirmwareVersion ): Get camera synthetic firmware
Read function : “r dfwv”;
Returned by the camera : String of 16 bytes (including “/0”)
Cannot be written
Device SFNC Version : 1.5.0
These Parameters (Major, Minor, Sub Minor) are only virtual ones in order to give the SFNC compliance of the Camera.
Device ID ( DeviceID ) : Camera Factory identifier ID
Read function : “r cust”;
Returned by the camera : String of 128 bytes (including “/0”)
Write function : “w cust <idstr>”
Device User ID ( DeviceUserID ) : Camera user identifier ID
Read function : “r cust”;
Returned by the camera : String of 128 bytes (including “/0”)
Write function : “w cust <idstr>”
Electronic board ID ( ElectronicBoardID ) : Get PcB Board ID
Read function : “r boid”;
Returned by the camera : String of 32 bytes (including “/0”)
Can not be written

UNIIQA+® 16k CL
18 UM UNIIQA+16kCL –REVC –11/14 e2v semiconductors SAS 2014
Device Temperature Selector ( DeviceTemperatureSelector ) : MainBoard
Can not be written
Device Temperature ( DeviceTemperature ) : Get Main Board Temperature
Read function : “r temp”;
Return by the camera : Temperature in Q10.2 format (8 bits signed + 2 bits below comma). Value is between -512 to
511 in °C.
Device Serial Port Selection : Indicates the Serial Port on which the Camera is connected.
Device Serial Port Baud Rate ( ComBaudRate ): Set the Camera BaudRate
Read function : “r baud”;
Returned by the camera : Value of the Baud Rate
Write function : “w baud” <index> with the index as follows :
1 : 9600 Bauds (default value at power up)
2 : 19200Bauds
6 : 57600Bauds
12 : 115200Bauds
Standby Mode ( Standby ) : Activation of the Standby mode of the Camera
Read function : “r stby”;
Returned by the camera : Boolean.
0 : Disable Standby mode (False)
1 : Enable stanby mode (True)
Write function : “w stby <val>”; <val> is 0 or 1.
A standby mode, what for ?
The Standby mode stops all activity on the
sensor level. The power dissipation drops down
to about 6W. During the standby mode, the grab
is stopped
Once the Standby mode turned off, the Camera
recovers in less than 1ms to send images again
from the sensor.
Internal Temperature
25
30
35
40
45
50
55
60
65
70
75
0
5
7
10
20
30
40
50
60
70
80
90
100
110
120
130
140
Time (mn)
°C
Standby Off
Standby On

UNIIQA+® 16k CL
19 UM UNIIQA+16kCL –REVC –11/14 e2v semiconductors SAS 2014
Camera status : Get the Camera status register (32bits Integer)
Read function : “r stat”;
Returned by the camera : 32bits integer :
Bit 0 : ( StatusWaitForTrigger ) : True if no trig received from more than 1sec
Bit 1 : ( StatusTriggerTooFast ) : Missing triggers. Trig signal too fast
Bit 2 : ( StatusSensorConnection ) : True is the Sensor pattern is checked as failed.
Bit 3, 4, 5, 6, 7 : Reserved
Bit 8 : ( StatusWarningOverflow ) : True is an overflow occurs during FFC or Tap balance processing.
Bit 9 : ( StatusWarningUnderflow ) : True is an underflow occurs during FFC or Tap balance processing
Bits 10 : Reserved
Bits 11 : Scrolling Direction : 0 = Forward, 1 = Reverse. Updated only by external CC3 (CameraLink)
Bits, 12, 13, 14, 15 : Reserved
Bit 16 : ( StatusErrorHardware ) : True if hardware error detected
Bits 17 to 31 : Reserved
6.3.2 Image Format
Sensor Width ( SensorWidth ) : Get the physical width of the Sensor. This value is available in the CommCam “Image
Format Control” section :
Read function : “r snsw”;
Return by the sensor : Integer 16384.
Can not be written;
Sensor Height ( SensorHeight ) : Get the physical height of the Sensor. This value is available in the CommCam “Image
Format Control” section :
No Access. Virtual command in xml”; Value always = 1
Width Max ( WidthMax ) : Get the Maximum Width of the Sensor. This value is available in the CommCam “Image Format
Control” section :
No Access. The value is mapped on “SensorWidth”
Height Max ( HeigthMax ) : Get the Maximum height of the Sensor. This value is available in the CommCam “Image Format
Control” section :
No Access. Virtual command in xml”; Value always = 1
Output mode ( OutputMode ) : Set the CameraLink Output mode (refer also to Chap 3. : CameraLink Output Configuration).
This command is available in the CommCam “Image Format Control” section :
Read function : “r mode”;
Returned by the camera : Output mode from 0 to 3 (see table below).
Write function : “w mode” <value> :
detailed in the table below :
Modes
Connector CL1
Mode value
Medium 4 Outputs 8bits
4 x 85MHz 8 bits
0
Medium 4 Outputs 12bits
4 x 85MHz 12 bits
1
Full 8 Outputs 8bits
8 x 85MHz 8 bits
2
Full+ 10 Outputs 8bits
10 x 85MHz 8 bits
3

UNIIQA+® 16k CL
20 UM UNIIQA+16kCL –REVC –11/14 e2v semiconductors SAS 2014
Structure of the Camera Link Channels for interfacing
Medium Mode 4x4096 Pixels at 85MHz each Channel
4 Taps Separate, from Left to Right
FULL Mode 8x2048 Pixels at 85MHz each Channel
8 Taps Separate, from Left to Right
FULL+ Mode 10x1638 Pixels at 85MHz each Channel
10 Taps Separate, from Left to Right :
Output Frequency ( OutputFrequency ) : Get the CameraLink Data Output Frequency. This value is available in the
CommCam “Image Format Control” section :
Read function : “r clfq”;
Return by the Camera : 0 (Frequency = 85MHz)
Can not be written;
Reverse Reading (X) ( ReverseReading ) : Allows to output the line in the Reverse-X direction. This value is available in the
CommCam “Image Format Control” section :
Read function : “r revr”;
Return by the Camera : 0 or 1 (enabled/disabled)
Write function : “w revr <value>”;
“0” : Disabled.
“1” : Enables the reverse reading out (see below for “normal” direction)
Test Image Selector ( TestImageSelector ) : Defines if the data comes from the Sensor or the FPGA (test Pattern). This
command is available in the CommCam “Image Format” section :
Read function : “r srce”;
Returned by the camera : “0” if Source from the Sensor and “1 to 5” if test pattern active
Write function : “w srce” <value> :
“0” : To switch to CCD sensor image
“1” :Grey Horizontal Ramp (Fixed) : See AppendixA
“2” : White Pattern (Uniform white image : 255 in 8Bits or 4095 in 12bits)
“3” : Grey Pattern (Uniform middle Grey : 128 in 8bits or 2048 in 12 bits)
“4” : Black Pattern (Uniform black : 0 in both 8 and 12 bits)
“5” : Grey vertical Ramp (moving)
The test pattern is generated in the FPGA : It’s used to point out any interface problem with the Frame Grabber.
When any of the Test pattern is enabled, the whole processing chain of the FPGA is disabled.
Ch 1
Ch 2
Ch 3
Ch 4
Ch 1
Ch 2
Ch 3
Ch 4
Ch 5
Ch 6
Ch 7
Ch 8
Ch 1
Ch 2
Ch 3
Ch 4
Ch 5
Ch 6
Ch 7
Ch 8
Ch 9
Ch 10
Output Direction
Output Direction
Output Direction
