Eagle Signal B506 User manual

1
Introduction
Your Eagle-Signal brand B506 1/16 DIN timer is a powerful instrument which can be
field configured to fit a wide variety of applications. The secondary setpoint can be
used for a second time output, combining the function of two timers in a single
package, or as a batch counter to track the amount of completed cycles. 1 ms
resolution with transistor outputs make this unit well suited for high speed
processes.
Inside this manual you will find complete information on the Control mode, which
deals with viewing and changing the available setpoints, and Program Mode which is
used to configure the basic operation of the timer, as well as set a variety of other
useful features.
Also found in this manual are detailed timing diagrams and descriptions of the
available operating functions to aid you in determining how to properly configure the
unit to solve your application. Additionally included are key product specifications,
warranty procedures and ordering
information should you require additional
units or accessories.
Should you require any additional
assistance with the installation and
operation of this product, please call our
toll free application support line at 1-800-
234-8731.
• 17 Different, field programmable, modes of
operation
• Batch Count function with timed or
latched output
• Dual setpoints in many modes
• Simple button per digit interface
• Timing resolution down to 1 ms
• Programmable security levels prevent
unauthorized setpoint or program changes
• High Visibility LED display of both time
value and setpoint
• Available with relay or solid state outputs
• IEC IP65 rated front panel
• Repeatability of 0.01%
• Inhibit input halts timing without
resetting the cycle
Features
Technical Manual
702118-0001
B506
High
Performance
LED Timer
Index
Overview
Panel Mounting page 2
Wiring Connections page 2
Operation
Front Panel page 3
Control Mode page 4
Configuration
Program Mode page 5 - 7
Timing Diagrams page 8- 12
Program Flow Chart page 13
General
Specifications page 14
Ordering Information page 14
Notes Sheet page 15
Warranty page 16
Eagle Signal brand

2
To wire the unit, an 11 pin socket is required. The
unit can either be DIN rail mounted or panel
mounted using the supplied mounting bracket.
For panel mounting, place the unit in the cutout,
then slide the bracket forward over the rear of the
unit so that the tabs catch in the grooves on the
housing and the bracket is as far forward as
possible. Tighten the panel mount screws until
there is a snug fit against the panel. Do not
overtighten.
48mm
8mm
66mm
81mm
Warning: Do Not connect a coil in parallel with the start
signal for the B506, as pictured at left. Such a
connection will cause the start signal to be
continuously active. This situation also applies to the
Reset and Inhibit inputs.
111
2
3
45678
9
10
AC Power
AC Power
WIRING
INSTALLATION
O V E R V I E W
111
2
3
45678
9
10
Power
Reset
Start
Neutral
(–) L1
(+)
Output #1
(Timed)
Inhibit
Output #2
(Timed or Batch)
111
2
3
45678
9
10
Start Reset
Inhibit
Power
B506-2001/2 B506-2051/2

3
4 3 2 1
EAGLE SIGNAL
EP
1234
1234
H
M
S
IN
O1
O2
P2 B
Time Range Indicator
Illuminates to show the time base: H for
hours, M for minutes, S for seconds.
Multiple indicators will be illuminated
when the time base is Hours:Minutes or
Minutes:Seconds. During timing
operation the illuminated LED will flash.
Illuminates to display when an input or output is
active: "IN' for the start input, "O1" and "O2" for
the timed outputs.
I/O Status Indicators
Preset 2 Indicator
Primary Display
In Control Mode: Displays the
current time value associated with
the displayed preset or the batch
value (if configured).
In Program Mode: Displays the
Parameter Description.
Each of the number keys is used to
increment the value of the
corresponding digit of the preset or
parameter value.
Numeric Keys
Illuminates to indicate that the Batch Count
Value and Batch Preset are being displayed.
Batch Indicator
Illuminates to indicate that Preset 2 is being
shown on the lower display.
In Control Mode: Depressing the key will scroll the display
among the preset and batch displays. Holding the key
down for 3 seconds will shift the unit into Program Mode.
With the "E" key, resets the displayed value
In Program Mode: Depressing the key will scroll the
display from one parameter to the next. Holding the key
down for 3 seconds will shift the unit to Control Mode.
Program Key
In Control Mode: Displays the settable
value used to trigger the timed
output(s) and the batch count (if
configured).
In Program Mode: Displays the current
selection for the chosen parameter.
Set Value
Edit Key
In Control Mode: With "P" key, resets the displayed value.
In Program Mode: Scrolls between the applicable choices for the
currently displayed parameter.
O P E R A T I O N
FRONT PANEL OPERATION

4
Preset 1 Display
4 3 2 1
EAGLE SIGNAL
EP
0000
25:00
H
M
S
IN
O1
O2
P2 B
4 3 2 1
EAGLE SIGNAL
EP
0000
25:01
H
M
S
IN
O1
O2
P2 B
4 3 2 1
EAGLE SIGNAL
EP
0000
25:11
H
M
S
IN
O1
O2
P2 B
2
1
Pressing the numeric keys will cause the corresponding digit to increment by a value of
one (i.e. the "1" key increments the rightmost digit, the "2" key the 2nd digit from the
right, etc.). It is not necessary to press any other keys to enter the change, the new set
point value will become effective immediately.
P
Please Note that based on the Operating Mode and Output 2 selection, Preset 2 may not be an
available display.
4 3 2 1
EAGLE SIGNAL
EP
0000
0028
H
M
S
IN
O1
O2
P2 B
4 3 2 1
EAGLE SIGNAL
EP
0000
0017
H
M
S
IN
O1
O2
P2 B
Preset 2 Display
4 3 2 1
EAGLE SIGNAL
EP
0000
0018
H
M
S
IN
O1
O2
P2 B
1 2
Top display: Time Value for P2 Operation
Bottom display: Preset 2
Annunciators: Time Range & P2
P
Please Note that based on the Operating Mode and Output 2 selections, Batch may not be an
available display.
Batch Display
4 3 2 1
EAGLE SIGNAL
EP
0000
0100
H
M
S
IN
O1
O2
P2 B
4 3 2 1
EAGLE SIGNAL
EP
0000
0101
H
M
S
IN
O1
O2
P2 B
4 3 2 1
EAGLE SIGNAL
EP
0000
0111
H
M
S
IN
O1
O2
P2 B
2
1
Changes are made in the same manner as for Preset 1 (detailed above).
Top display: Time Value for P1 Operation
Bottom display: Preset 1
Annunciators: Time Range
Changes are made in the same manner as for Preset 1 (detailed above).
O P E R A T I O N
CONTROL MODE
Top display: Batch Count Value
Bottom display: Batch Count Preset
Annunciators: Batch

5
• Enter the Program Mode by holding down the "P" key for 3 seconds
• Press the "P" key to move the top display from one parameter to the next
• Press the "E" key to scroll the bottom display through the available choices for that parameter
• While in Program Mode, the unit will halt operation. Changes only become effective after return
ing to Control Mode by holding down the "P" key for 3 seconds
For 3 Seconds
P
P
P E r C
Operating Function: Determines how output 1 will operate in relation to the Preset 1. Choices are:
• On Delay (OndL)
• Off Delay (OFdL)
• Interval 1 (int1)
• Interval 2 (int2)
• On/Off Delay (OnOF)
• Delay/Interval (dint)
• Accumulative (ACC)
F u n c
o u t 2
P 2
P
P 2 0
AbS
A complete explanation, with timing
diagrams, of each function can be found
on page 8.
C O N F I G U R A T I O N
PROGRAM MODE
Preset 2 Operation: Determines how Preset 2 will operate in relation to Preset 1. The available
choices vary based upon the selected "Operating Function":
For On-Delay and Accumulative:
• Absolute (AbS): Preset 2 is input as an absolute value, and the unit operates like two
independent On-Delay timers.
• Prewarn (PrE): Preset 2 is set as a value relative to Preset 1. The input value for P2 is equal to
the amount of time that Output 2 will activate prior to Output 1. Ex: If P1 = 20 seconds, and P2
equals 5, then output 2 will activate 15 seconds (20 - 5), after the timing cycle is initiated.
Note: The following parameter will only appear if "Output 2" is set to Preset 2.
Note: The following parameter will not appear if "Operating Function" is set to Off
Delay, Delay/Interval or On/Off Delay. In these instances Output 2 automatically
defaults to Batch Count.
Output 2 Operation: Determines the functionality of the 2nd output. Choices are:
• Preset 2 (P2): The unit will function as a dual setpoint timer, with output 2 linked to
Preset 2.
• Batch Count (bC): Output 2 will be activated after a preset amount of Operations is
completed. The preset value is input in the Batch Count screen in Control Mode.

6
C O N F I G U R A T I O N
For Interval 1 and Interval 2:
Begin Together (bt): Preset 2 is set as an independent time interval which will begin timing and
activate Output 2 upon initiation of the start signal .
End Together (Et): Preset 2 is set as a value relative to Preset 1. The timing sequence for P2 will
initiate at the appropriate time so that the timing sequences for P1 and P2 will end
simultaneously and Output 1 and Output 2 will deactivate together.
Sequential (SE): Preset 2 is set as an indepedent time interval which will begin its timing
sequence upon completion of the P1 interval.
P
P
P
P
P
0 0 0 0
bct
t r n 1
d E c 1
t r n 2
d E c 2
Note: The following parameter will only appear if "Output 2" is set to Batch Count.
Batch Count Output: Sets the duration of Output 2, within a range from 1 second to 9999
seconds. A setting of 0000 will latch the output until a reset signal is received
Time Range 1 : Sets the unit of measure for the time values that will be used for Preset 1. The
choices will not appear on the bottom display, but will be signified with the annunciator lights.
Choices are:
• Seconds
• Minutes
• Hours
• Minutes:Seconds
• Hours:Minutes
Note: The following parameter will not appear if "Minutes:Seconds" or
"Hours:Minutes" is chosen for Time Range 1.
Decimal Position for Time Range 1: Determines the resolution of the selected time range.
Settable from 0000 to 0.000
Note: The following parameter will only appear for those configurations that
provide a Preset 2 display.
Time Range 2 : Sets the unit of measure for the time values that will be used for Preset 2. The
choices will not appear on the bottom display, but will be signified with the annunciator lights.
Choices are:
• Seconds
• Minutes
• Hours
• Minutes:Seconds
• Hours:Minutes
Note: The following parameter will not appear if "Minutes:Seconds" or
"Hours:Minutes" is chosen for Time Range 2.
Decimal Position for Time Range 2: Determines the resolution of the selected time range.
Settable from 0000 to 0.000.

7
C O N F I G U R A T I O N
Timing Direction: Determines whether the time values for Preset 1 and 2 will increment from
zero and change the state of the output at the set value (uP) or decrement from the set value and
change the state of the output at zero (dn).
P
t d i r
u P
Power Reset Enable: After a loss of power, the unit can be programmed to either reset upon
reapplication of power (On) or continue from the point of power interruption (OFF).
P
Front Panel Reset Enable: When active (On), the timing operation can be reset in Control Mode by
simultaneously pressing the "E" and "P" keys. If inactive (OFF), the timing operation can only be
reset through the remote input.
P
P
Security Level: 4 different levels of security are available:
0 = Full Access
1 = SP Locked Out
2 = Access to Program Mode only by holding the "P" key for 10 seconds
3 = SP Locked Out and access to Program Mode only by holding the "P" key for 10
seconds
P r S t
O n
F r S t
O n
S L u L
0

8
C O N F I G U R A T I O N
TIMING DIAGRAMS
On Delay - Absolute On Delay - Prewarn
P1
P2
Start
Out 1
Out 2
Reset
P1
P2
Out 1
Start
Reset
Out 2
Activates Deactivates
On completion of P2 or
Reset
Preset 1
Timing
Preset 2
Timing
Output 1
Output 2 Prior to completion of P1 by
the amount of time set in P2
On leading edge of start
signal
Prior to completion of P1 by
the amount of time set in P2
Upon completion of P1 On Reset
On Reset
On completion of P1 or
Reset
Activates Deactivates
On leading edge of start
signal
On leading edge of start
signal
Upon completion of P1
Upon completion of P2
Preset 1
Timing
Preset 2
Timing
Output 1
Output 2
On completion of P1 or
Reset
On completion of P2 or
Reset
On Reset
On Reset
P1 must be set to a value greater than P2. An Inhibit input will halt all timing
functions, but leave the outputs in their current state. If the start input is applied
during Reset, a new timing cycle will begin on the trailing edge of the Reset
signal.
An Inhibit input will halt all timing functions, but leave the outputs in their current
state. If the start input is applied during Reset, a new timing cycle will begin on
the trailing edge of the Reset signal.

9
C O N F I G U R A T I O N
On Delay w/Batch On Delay/Interval w/Batch
P1 P2 P1 P2
BT
P1
1 2
Out 1
Start
Out 2/
Batch
Reset
P1 P1
1 2
Out 1
Start
Out 2/
Batch
Reset
Activates Deactivates
On completion of P1 or
Reset
On Reset, only after the Batch
Count Preset is reached
On completion of P1 or
Reset
On completion of P1
Preset 1
Timing
Batch
Count
Output 1
Output 2 When the Batch Count value
equals the Batch Preset On completion of Batch
Output time or Reset
On leading edge of start
signal
Accumulates on activation of
Output 1
Activates Deactivates
Preset 1
Timing
Preset 2
Timing
Batch
Count
On leading edge of start
signal
On activation of Output 1
Output 1 On completion of P1
Output 2 When the Batch Count value
equals the Batch Preset On completion of Batch
Output time or Reset
Accumulates on falling edge
of Output 1
On completion of P2 or
Reset
On completion of P1 or
Reset
On Reset, only after the Batch
Count Preset is reached
On completion of P1 or
Reset
An Inhibit input will halt all timing functions, but leave the outputs in their current
state. A reset signal is not required to start a new P1 cycle. The Remote Reset
will only reset the Batch Count value after the Batch Preset has been reached,
however, the Batch Count value can be reset at anytime via Front Panel Reset.
An Inhibit input will halt all timing functions, but leave the outputs in their
current state. If the start input is applied during Reset, a new timing cycle will
begin on the trailing edge of the Reset signal. The Remote Reset will only reset
the Batch Count value after the Batch Preset has been reached, however, the
Batch Count value can be reset at anytime via Front Panel Reset.
Interval 1 - Begin Together Interval 2 - Begin Together
P1
P2
Out 1
Start
Reset
Out 2
P1
P2
Out 1
Start
Out 2
Reset
Activates Deactivates
On completion of P1, or
Reset
Preset 1
Timing
On completion of P2 or
Reset
On completion of P1 or
Reset
Preset 2
Timing
Output 2
Output 1
On leading edge of start
signal
On leading edge of start
signal
On leading edge of start
signal
On leading edge of start
signal On completion of P2 or
Reset
Operates the same as the Interval 1- Begin Together mode, except the start
input does not have to be sustained to continue operation. An Inhibit input will
halt all timing functions, but leave the outputs in their current state.
Activates Deactivates
On completion of P1, deasser-
tion of the Start Signal or Reset
Preset 1
Timing
Preset 2
Timing
Output 2
Output 1
On leading edge of start
signal
On leading edge of start
signal
On leading edge of start
signal
On leading edge of start
signal
On completion of P2, deasser-
tion of the Start Signal or Reset
On completion of P2, deasser-
tion of the Start Signal or Reset
On completion of P2, deasser-
tion of the Start Signal or Reset
An Inhibit input will halt all timing functions, but leave the outputs in their
current state.

10
C O N F I G U R A T I O N
Interval 1 - End Together Interval 2 - End Together
P2
P1
Out 1
Start
Out 2
Reset
Out 1
Start
Reset
Out 2
P2
P1
Activates Deactivates
On completion of P1, deasser-
tion of the Start Signal or Reset
Preset 1
Timing On leading edge of start signal
Preset 2
Timing Prior to completion of P1 by
the amount of time set in P2 On completion of P2, deasser- tion of the Start Signal or Reset
On leading edge of start
signal On completion of P1, deasser-
tion of the Start Signal or Reset
Output 2 Prior to completion of P1 by
the amount of time set in P2 On completion of P2, deasser-
tion of the Start Signal or Reset
Output 1
Activates Deactivates
On completion of P1, deasser-
tion of the Start Signal or Reset
Preset 1
Timing On leading edge of start signal
Preset 2
Timing Prior to completion of P1 by
the amount of time set in P2 On completion of P2, deasser- tion of the Start Signal or Reset
Output 1 On completion of P1, deasser-
tion of the Start Signal or Reset
Output 2 Prior to completion of P1 by
the amount of time set in P2 On completion of P2, deasser-
tion of the Start Signal or Reset
An Inhibit input will halt all timing functions, but leave the outputs in their
current state. Operates the same as the Interval 1-End Together mode, except the start input does not have to be sustained to continue operation. An Inhibit input will halt all
timing functions, but leave the outputs in their current state.
On leading edge of start
signal
Interval 1 - Sequential Interval 2 - Sequential
P2
P1 P1
Start
Reset
Out 2
Out 1
P2
P1 P1 P1
Out 2
Reset
Out 1
Start
Activates Deactivates
On completion of P1, deasser-
tion of the Start Signal or Reset
Preset 1
Timing On leading edge of start signal
Preset 2
Timing On completion of P2, deasser-
tion of the Start Signal or Reset
Output 1 On completion of P1, deasser-
tion of the Start Signal or Reset
Output 2 On completion of P2 On completion of P2, deasser-
tion of the Start Signal or Reset
On completion of P1
On leading edge of start
signal
Activates Deactivates
On completion of P1, or Reset
Preset 1
Timing On leading edge of start signal
Preset 2
Timing On completion of P2, or Reset
On leading edge of start
signal On completion of P1 or Reset
Output 2 On completion of P2, or Reset
Output 1
On completion of P1
On completion of P2
Operates the same as the Interval 1-Sequential mode, except the start input
does not have to be sustained to continue operation. An Inhibit input will halt all
timing functions, but leave the outputs in their current state.
An Inhibit input will halt all timing functions, but leave the outputs in their
current state.

11
C O N F I G U R A T I O N
Interval 2 - Batch
Interval 1 - Batch
P1 P1
BCT
Start
Reset
Out 2/
Batch
Out 1
1 2
Reset
Out 2/
Batch
P1 P1
BCT
P1
1 2
Start
Out 1
Activates Deactivates
On completion of P1, deasser-
tion of the Start Signal or Reset
Preset 1
Timing On leading edge of start signal
Batch
Count On trailing edge of Output 1
On leading edge of start
signal On completion of P1, deasser-
tion of the Start Signal or Reset
Output 2 When the Batch Count Value
equals the Batch Preset
Output 1
On Reset
On completion of the Batch
Count Time or Reset
It is not necessary to reset the timer to begin a new interval, however reset is
required to set the batch count value back to 0. An Inhibit input will halt all
timing functions, but leave the outputs in their current state.
It is not necessary to reset the timer to begin a new interval, however reset is
required to set the batch count value back to 0. An Inhibit input will halt all
timing functions, but leave the outputs in their current state.
Activates Deactivates
On completion of P1 or Reset
Preset 1
Timing On leading edge of start signal
Batch
Count On trailing edge of Output 1
On leading edge of start
signal On completion of P1 or Reset
Output 2 When the Batch Count Value
equals the Batch Preset
Output 1
On Reset
On completion of the Batch
Count Time or Reset
Off Delay - Batch Count
Out 1
Start
Reset
Out 2/
Batch
P1 P1
BCT
Activates Deactivates
On completion of P1 or Reset
Preset 1
Timing On trailing edge of start signal
Batch
Count On trailing edge of Output 1
On leading edge of start
signal On completion of P1 or Reset
Output 2 When the Batch Count Value
equals the Batch Preset
Output 1
On Reset
On completion of the Batch
Count Time or Reset
It is not necessary to reset the timer to begin a new interval, however reset is
required to set the batch count value back to 0. An Inhibit input will halt all
timing functions, but leave the outputs in their current state. Start signals will be
accepted while the Batch Count Output is active.

12
C O N F I G U R A T I O N
Any transition of the start signal will effect the timing operation: During the
timing cycle for P1 a transition will cause P1 to restart. A transition of the start
signal after P1 has completed will cause P2 to begin. Any transition of the start
signal prior to the completion of P2 (and the deactivation of Output 1) will cause
P2 to restart. An Inhibit input will halt all timing functions, but leave the outputs
in their current state.
On/Off Delay - Batch Count
Out 1
Start
Reset
Out 2/
Batch
P1 P2 P1 P2
P1-T
Activates Deactivates
On change of state of the start
signal or reset
Preset 1
Timing On change of state of the start signal
Preset 2
Timing On change of state of the
start signal after P1 has
elapsed
On change of state of the start
signal after P2 is active, or
Reset
Accumulates on falling edge
of Output 1
Batch
Count
Output 2 When the Batch Count value
equals the Batch Preset On completion of Batch
Output time or Reset
On expiration of the Batch
Count Time or Reset
On completion of P1 On completion of P2 or Reset
Output 1
t1 t2 t3
t1 + t2 + t3 = P1
t4
t1 + t2 + t3 + t4 = P2
Start
Out 1
Reset
Out 2
Activates Deactivates
Preset 1
Timing
Preset 2
Timing
Output 1
Output 2
On leading edge of each
start signal
On leading edge of each
start signal
On completion of P1
On completion of P2
On completion of P1 or
Reset
On completion of P2 or
Reset
On Reset
On Reset
t1 t2 t3
t1 + t2 + t3 = P1
t2' t3
t2' + t3 = P2
Start
Out 1
Out 2
Reset
Activates Deactivates
Preset 1
Timing
Preset 2
Timing
Output 1
Output 2
On completion of P1 or
Reset
On completion of P2 or
Reset
On Reset
On Reset
On leading edge of each
start signal
Prior to completion of P1 by
the amount of time set in P2
On completion of P1
Prior to completion of P1 by
the amount of time set in P2
It is not necessary to reset the timer to begin a new interval, however reset is
required to set the batch count value back to 0. An Inhibit input will halt all
timing functions, but leave the outputs in their current state. Start signals will be
accepted while the Batch Count Output is active
t1 t2 t1 t2
Start
Reset
Out 1
Out 2/
Batch
Activates Deactivates
On completion of P1 or Reset
Preset 1
Timing On leading edge of each start signal
Batch
Count On leading edge of Output 1
On completion of P1 On Reset
Output 2 When the Batch Count Value
equals the Batch Preset
Output 1
On Reset, only after the Batch
Count Preset is reached
On Reset, only after the Batch
Count Preset is reached
Accumulative - Absolute
Accumulative - Prewarn
Accumulative - Batch

13
C O N F I G U R A T I O N
PROGRAMMING OVERVIEW
Func
out2
P20
bct
trn1
dEc1
out2
=
P2
trn2
dEc2
tdir
PrSt
FrSt
SLuL
Yes**
No*
OFdL,OnOF,dint
bc
P2
H:M or M:S
H:M or M:S
* If Delay/Interval or On/Off are selected as the Operating Function, Out2 is
automatically set to Batch. However, the P2 setting is still available, and the
second time range is available.
** For the Interval 1 & Interval 2 modes, a second time range will not appear if
the Preset 2 operation is set to End Together. This is also true for the On Delay
and Accumulative Modes if Prewarn is the selection for Preset 2 Operation.

14
GENERAL
Operation
Supply Voltage: 85 - 264 VAC 50/60Hz, or 24 VAC/VDC
Power Consumption: < 10 VA max @ 240 VAC, 200 mA @ 24
VDC
Time Ranges: Hours, Minutes, Seconds, Hours:Minutes,
Minutes:Seconds
Resolution: Settable from XXXX to X.XXX for Hours,
Minutes, and Seconds ranges
Repeat Accuracy: + 0.01%
Display: Dual line, 4 digit, 7 segment LED - 8mm
high
Memory: Nonvolatile retains settings when power is
disengaged
Electrical Service Life: 100,000 cycles at full load
Mechanical Service Life: 10 million cycles at min. load
Environmental
Front Panel Rating: IEC IP65
Operating Temperature: 0°to 55°C (32°to 131°F)
Storage Temperature: -40°to 90°C (-40°to 194°F)
Humidity: 5% to 95% RH non-condensing
Approvals: UL, CUL recognized - File #97337, CE
certified
ORDERING INFORMATION
Inputs
Start: NPN or Dry Contact
Reset: NPN or Dry Contact
Inhibit: NPN or Dry Contact
Activation Time: 4 ms (B506-2XX2), 21 ms (B506-
2XX1)
Impedance: 10 KΩ
Outputs
Relay (B506-200X): 2 SPDT (5 amp) - 15 ms max latency
Transistor (B506-205X): NPN Open Collector - 30 VDC, 30
mA max, opto isolated
Physical
Dimensions: 48mm x 48mm, 85mm deep
Mounting: Panel Mounting 45mm x 45mm
cutout or DIN rail
Wiring Connection: Via 11 pin plug in socket
Weight: 100 grams (3.5 ounces)
ORDERING INFORMATION
SPECIFICATIONS
Description Model #
High Performance Timer, Relay Out, 90-240 VAC B506-2001
High Performance Timer, Relay Out, 24 VDC/AC B506-2002
High Perf Timer NPN trans Out, 90-240 VAC B506-2051
High Perf Timer, NPN trans Out, 24 VAC/DC B506-2052
Description Model #
11 Pin Socket - DIN Rail Mount 60SR2P06
11 Pin Socket - Outward facing terminals PBT-03172

15
GENERAL
NOTES

16
GENERAL
Printed in U.S.A.
#702118-0001
Sept. 1997
Revision none
1675 Delany Road
Gurnee, IL 60031–1282
Phone: [phone]
Fax: [phone]
Danaher Controls
Standard B506 products manufactured by the Company are
warranted to be free from defects in workmanship and material for
a period of two years from the date of shipment, and products
which are defective in workmanship or material will be repaired or
replaced, at the option of the Company, at no charge to the Buyer.
Final determination as to whether a product is actually defective
rests with the Company. The obligation of the Company hereunder
shall be limited solely to repair and replacement of products that
fall within the foregoing limitations, and shall be conditioned upon
receipt by the Company of written notice of any alleged defects or
deficiency promptly after discovery within the warranty period, and
in the case of components or units purchased by the Company, the
obligation of the Company shall not exceed the settlement that the
Company is able to obtain from the supplier thereof. No products
shall be returned to the Company without its prior consent.
Products which the Company consents to have returned shall be
shipped F.O.B. the Company's factory. The Company cannot assume
responsibility or accept invoices for unauthorized repairs to its
components, even though defective. The life of the products of the
Company depends, to a large extent, upon the type of usage thereof,
and THE COMPANY MAKES NO WARRANTY AS TO FITNESS OF ITS
PRODUCTS FOR SPECIFIC APPLICATIONS BY THE BUYER NOR AS
TO PERIOD OF SERVICE UNLESS THE COMPANY SPECIFICALLY
AGREES OTHERWISE IN WRITING AFTER THE PROPOSED USAGE
HAS BEEN MADE KNOWN TO IT.
THE FOREGOING WARRANTY IS EXCLUSIVE AND IN LIEU OF ALL
OTHER WARRANTIES EXPRESSED OR IMPLIED, INCLUDING, BUT
NOT LIMITED TO ANY WARRANTY OF MERCHANTABILITY OR OF
FITNESS FOR A PARTICULAR PURPOSE.
WARRANTY

X-ON Electronics
Largest Supplier of Electrical and Electronic Components
Click to view similar products for Veeder Root manufacturer:
Other Similar products are found below :
0166726-006 0195316-051 0116425-007 RFMT00R RFMV00 RFXDC10 RFXP10 RFXS00 RFXT00 C342-0462 C346-0422 C628-20052
C628-20300 C628-40050 C628-41002 C628-41300 C628-70002 C628-81002 C628-90000 C628-91002 S628-20300 A103-A14 RFMSK00
RFMT00 RFMV00R RFXD00 RFXD10 RFXS10 C342-1562 C342-3462 C346-0513 C628-20000 C628-20002 C628-21350 C628-40000
C628-40052 C628-41302 C628-51002 C628-60002 VC773-342 0317680-001 0703006-003 0726845-001 0727245-001 0743425-003
0743425-005 0743797-001 0744386-211 0745815-001 0779526-201
