EASEWELL EW-16003SP Product guide

EW-16003SP
EASEWELL MASSAGE CHAIR
Manual Book
Please read this manual carefully before using the product,
and keep the operation manual in good condition for reference.

FCC CAUTION
IC WARNING
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject
to the following two conditions: (1) this device may not cause interference, and (2) this device
must accept any interference, including interference that may cause undesired operation of the
device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio
exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne
doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage
radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement.
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.The device
is compliance with RF exposure guidelines, user can obtain Canadian information on RF
exposure and compliance. The equipment should be installed and operated with minimum
distance 20cm between the radiator and your body.
Le présent appareil est conforme
Après examen de ce materiel aux conformité ou aux limites d'intensitè de champ RF,
Les utilisateurs peuvent sur l'exposition aux radiofréquences et la conformité and compliance
d'acquérir. Installation et mise en oeuvre de ce matériel devrait avec échangeur distance
minimale entre 20 cm ton corps.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
Any changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment o and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit dierent from that to which the receiver is
connected.
—Consult the dealer or an experienced radio/TV technician for help.
The equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment,
This transmitter must not be co-located or operating in conjunction with any other antenna or
transmitter.
The equipment should be installed and operated with minimum distance 20cm between the
radiator and your body.

CONTENTS
EW-16003SP MASSAGE CHAIR
Thank you for purchasing this product, please read this manual in detail before
you use it to learn the correct use of this product. Please pay special attention
to important safety warnings and keep the operation manual in good condition
for reference.
Important Safety Warnings...................................................................................
Chair Installation........................................................................................................
Names of Parts and Function.............................................................................
Before Each Massage.............................................................................................
Adjustment Method of Chair...............................................................................
Automatic Massage Programs.............................................................................
Basic Massage Methods .......................................................................................
Manual Massage Mode...........................................................................................
Air Pressure Mode..................................................................................................
Other Functions........................................................................................................
Cleaning and Storage............................................................................................
Troubleshooting.......................................................................................................
Maintenance & Warranty…….......…….......…….......…….......…….......……................
Product specification…….......…….......…….......…….......…….......…….......................
3
7
12
14
15
16
19
21
22
24
25
26
27
28

đŏ(!/!ŏ.! ŏ0$%/ŏ/"!05ŏ,.!10%+*ŏ.!"1((5ŏ!"+.!ŏ/0.0%*#ŏ
to use product.
đŏ$!ŏ,.!10%+*/ŏ/$+3*ŏ$!.!ŏ.!ŏ0+ŏ.!)%* ŏ5+1ŏ* ŏuse this
product properly to prevent you and others from being hurt
or damaged.
Caution:
Indicates that there is a warning or an attention
(The example on the left shows general warnings
and cautions.)
Indicates prohibited behavior
(The example on the left shows forbidden to
disassemble)
Indication of mandatory and instructional content
(The example on the left shows unplugging)
Please keep it in a place where you can check it at any time.
EXAMPLE OF ICON
If used incorrectly, the user may be harmed, or the
items may be harmed or damaged, which includes the
damage to houses, household property, livestock, and
pets.
The appliance has a heated surface. Persons insensitive
to heat must be careful when using the appliance.
Important Safety Warnings
3

The following people must consult your doctor
before using:
đŏPatients with cancers
đŏMaternal or menstrual period
đŏHigh fever
đŏPatients with acute illness (painful)
đŏPatients with osteoporosis
đŏPatients with perceptual disturbance
đŏAnemia
đŏUsers of cardiac rhythm devices or other implanted devices
đŏSpine abnormalities or curvatures
đŏPeople receiving treatment or feeling physically abnormal
đŏFor use in previously treated or injured areas
đŏPeople who need quiet
đŏPeople with severe blood circulation disorders on the feet
đŏSometimes cause physical abnormalities
đŏCardiopath
Please unplug the power immediately when the product is unable to operate
or abnormal, and ask the seller to check and repair to avoid electric shock,
leakage, short circuit and fire.
When massaging around the neck, please pay attention to the movement of
the massage roller and do not over-massage. This may cause accidents or
injuries.
Please make sure that the chair cover is not damaged before use. (If it is
damaged, stop using it immediately, unplug the power, and request repair.)
In order to avoid injury or electric shock due to the damaged chair cover.
When lifting/declining the seat back and legrest, please make sure that there
are no people, objects or pets on the back and under the legrest to avoid any
injuries.
ATTENTION
4

Before using, please make sure that you are not wearing any accessories to
avoid injury.
Move the chair stably to avoid scratching the surface.
Please check the position of the massage rollers before you use it to avoid
accidents or injuries.
Please control the massage time within 15 minutes. In addition, please control
the massage time of the same part within 5 minutes. Continuous massage for
too long may cause muscle and nerve pain. It is recommended to control the
massage time within 30 minutes for 1 day.
If you have or feel any abnormalities during massage, please stop using
immediately.
After use, please turn o the power switch to prevent accidents caused by
children playing around.
Please use it in a horizontal place to avoid malfunctions and accidents.
Be careful not to trip over the remote-control cable to avoid accidents or
injuries.
If the power cord or plug is damaged, stop using it immediately to avoid
electric shock, short circuit and sparks.
Do not allow children to use it alone and keep young children away.
Do not allow children to play on the chair to avoid injury or malfunction.
Do not use other therapeutic equipment while using this machine.
Do not use near open flames, such as a stove. Do not use while smoking. Do
not use on heating appliances, such as electric blankets, as it may cause a
fire.
Be sure to insert the power plug all the way, and make sure that no pins or
garbage are stuck on the plug. It may cause electric shock, short circuit and
fire.
Do not fall asleep during the massage as unconscious massage may cause
injury or discomfort.
Do not use it for any purpose other than massage to avoid malfunction or
accident.
Take care of the power cord. Do not damage, re-process, forcibly bend,
stretch, twist, stick, or tighten the power cord. In addition, do not place under
the heavy objects, especially do not get caught in or pinch the power cord
during moving. Otherwise, the power cord may be damaged, causing electric
shock or sparks.
Do not use a power source other than 110v(50-60Hz) to avoid electric shock or sparks.
5

Do not place it in a humid place such as a bathroom, as it may cause electric
shock, fire, failure, and rust.
With the exception of service technicians, no one should disassemble, repair,
or modify the chair. Doing so may cause fire or electric shock.
In the event of a power failure, please immediately turn o the power switch
and disconnect the power plug from the outlet to avoid accidents when the
power is reapplied.
When unplugging the power plug, please hold the plug part on the front side
and do not pull the power cord. It may cause electric shock or short circuit,
which may cause fire.
When the chair is not in use, please unplug the power plug from the socket,
as the dust and moisture will cause wires to age and cause a leakage fire.
When performing maintenance, please unplug the power plug from the
socket. In addition, do not insert or remove the plug with wet hands, as it
may cause electric shock and injury.
Do not use it when wearing hard objects, such as hair accessories, in case of
injury.
Do not put your head and hands under the legrest and under the chair to
avoid accidents or injuries.
Do not use on elbows, knees, head, abdomen. Do not sandwich your hands
and feet between the massage rollers to avoid injury and discomfort.
Do not seat more than two people on the chair at the same time to avoid
injury or malfunction.
Do not use the chair right after a meal to avoid discomfort.
Do not move the chair when carrying people or objects to avoid injury or
malfunction.
Do not drop the chair or hit it with strong force to avoid injury or malfunction.
Do not move the casters or drag the chair on the surface that is easy to be
scratched, such as wooden floors or carpets.
Do not sit on the backrest, armrest, or legrest to avoid injury or malfunction.
Do not wipe with gasoline, diluent, etc. Do not spray insecticide to avoid
electric shock and sparks.
Do not pull the leather too hard. Do not puncture it with force or sharp
objects to avoid injury and malfunction.
This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety. Children should
be supervised to ensure that they do not play with the appliance.
6

Chair Installation
Main Body
Remove main body and accessories from the packing box
Accessories
Left/Light Side Panel Remote Control Bracket
Foot Massager Headrest Backrest Cover
Manual Book Kits Power Cord
7

*Figure ②Installation position
of push rod linkage on the footrest.
*Figure ①Installation position
of the foot machine.
Step 2
Installation of Foot Massager
Installation of Remote Control Bracket
Manual screw
Chair Installation
Installation Guideline
I, Installation of Foot Massager
1, Align the foot machine with the connecting holes on both sides of the seat and
insert rivets and plug. * Figure ①
2, Use rivets and plug to dock the seat bottom putter with the foot machine
putter. *Figure ②
3, Install air bags into the air inlet connector (TWO connectors) which must be
connected with the corresponding colors and fix with wire hardness. Then connect
THREE wires, and use the zipper cloth to cover after connecting.
4, Connect the seat cushion to the zipper on the footrest.
1, Use the M5 L-shaped hexagonal
wrench to lock the Hand-controlled
hexagon nut to the remote control
bracket.
2, The mobile phone holder and its
cover are attached to the remote
control bracket by using 4x16 round
head flat tail screw.
3, Use manual screw to fix the
control box seat
4x16 round head
flat tail screw
Hand-controlled
hexagon nut
Step 3
8

Chair Installation
Power cord of
LOGO board
Installation of side panels
Step I
1, Align the holes of the inner panel with the mounting holes of the seat frame by
locking 5 screws. Figure ①(M6x20 hexagon socket screw*1, M6x20 round head
screw*5)
2, Install air bags into the air inlet connector which must be connected with the
corresponding colors; then connect the wire to the air valve plate, and fix it tightly
with a wire harness after the connection. Figure ②
※The left side connecting line needs to be wound from the inside to the armrest
cover first.
※After connecting the wire with the inner lamp cover terminal of the upper cover on
the armrest, lock and fix it with a fixed button. Figure ③
Figure ①
M6x20 hexagon socket screw
M6x20 round head screw
Figure ②Figure ③
Air valve signal
adapter
Air valve signal line
9

※Be sure to install it securely, otherwise it may fall o and cause
injury or malfunction
Chair Installation
Step two
3, After the installation of the inner panel is completed, install the outer
panel should push the fixed latch firstly from front to back, then use
3.5x16 round head pointed tail lock.
3.5x16 round head pointed tailsliding direction
Step Three
4, When installing the upper cover of the left armrest, install the hand
controller bracket first, and then slide into the fixed mortise.
5, After positioning, 2 armrest cover screws (M4x25) are locked on the
front and ends from bottom to top.
The side plate assembly is a mother side buckle From inside to outside, buckle the male
side and the mother side to the bottom
sliding direction
Armrest cover screws(M4x25)
From inside to outside, buckle the common side
and the mother side to the bottom
Attention
10

Chair Installation
Massage Chair Placement
Please place the massage chair in a flat place, and space should be left around the
chair.
When placing the massage chair, be sure to leave enough space around the chair
so that the legs and backrest of the chair can rise and fall freely.
It is recommended to place a cushion under the product to avoid damage to the
ground or carpet. At least 10cm
At least 70cm
Moving the Chair
Chair Installation
Please Note!
Casters
As shown on the picture below, tilt the chair back about 45° and use the casters to
push forward or backward carefully to the appropriate position.
đŏ+ŏ*+0ŏ)ove the massage chair while someone is lying on the massage chair.
đŏ+ŏ*+0ŏ(%"0ŏ0$!ŏ/!0ŏ* ŏ(!#.!/0ŏ3$%(!ŏ)+2%*#ċ
đŏ$!*ŏ)+2%*#Čŏ,(!/!ŏ,(!ŏ0$!ŏ+*0.+((!.ŏ+*ŏ0$!ŏ/!0ŏcushion to prevent it from
falling to the ground.
11

Names of parts and function
Speaker and mood lightening
Waist and back heating
Armrest
Air pressure massage for arms
Quick Zoom Buttons
Adjust the intensity quickly
Quick Adjust Buttons
Adjust the position quickly
Lateral Hip Air Bags
Air pressure for lateral hip
Seat
Air pressure and
heating for hip and thigh
Leg & Calf
Air pressure and
heating for leg/calf
Foot roller
and vibration
Headrest
Please turn to the back side
while massage
Shoulder
Air pressure massage for
shoulder
Backrest
massage the entire back
Hand Controller
USB Charging Port
Mobile Phone Rack
Calf Shiatsu
Kneading massage for calf
Power input
socket
Power Switch
Power Cord
Removeable
washable cloth
covers
Massage chair
12
Massage Position
Massage area
Shoulder
Back
Waist heating
Lateral Hip
Back of calf
Calf shiatsu
Back of Ankle
Waist
Foot Rollers
Arm
Hip heating
Thigh
Calf heating
Calf rollers
Instep
Footrest
anti-pinch
Back anti-pinch

Hand Controller Key Functions
Home Page
Timing Display
and adjustment
Massage Mode
Display
Neck & Shoulder
Adjustment
Air-pressure
Adjustment
Manual Mode
Fault Number Display
Setting
Fixed Point
Adjustment
Air Bag action real-time display
Air Pressure Mode
Seat Posture
Adjustment
21 types of manual
massage programs
For Manual mode only
Foot Roller
and Vibration
13 types of air
massage programs
ON/OFF Pause
Stop all the massage
Automatic
Modes
6 Automatic massage
programs for choice:
Release Tiredness
Deep Shiatsu
Recover
Relax
Soft Knead
Stretching and
Relaxation
5 languages & Screen
brightness adjustment
Back and Waist Heat
Leg and Foot heating
0OPUIFCBDLBOEXBJTU
IFBUJOHGVODUJPO
0OPUIFMFHBOEGPPU
IFBUJOHGVODUJPO
Hand Controller
Calf Shiatsu
roller function.
Massage Strength
Adjustment 7 levels
13

14
1. Plug the power plug into the
socket
1. Check the surroundings
2. Turn on the power switch
(It is located below the back of
the seat.)
đŏConfirm that there are no people, no pets, and no objects
around the back of the massage chair or below the legrest.
đŏCheck the power cord, remote control cord, and power
plug for damage. Also check if the power plug is stuck with
hair or dust.
đŏBefore sitting down, please confirm the position of the
massage rollers are located in the storage position
(gathered at the bottom of the backrest).
đŏBefore sitting down, please also confirm the position of
the legrest. If the legrest is in the raised status, forcibly
sitting down can cause injuries.
In this case, press the quick button to lower the footrest.
2. Check the massage chair status
đŏ%"0ŏ0$!ŏ'ŏ, ŏ* ŏ%*/,!0ŏ0$!ŏ'ŏ+2!.ŏ* ŏ+0$!.ŏ
parts for damage.
- Even if the damage is small, stop using it immediately,
unplug the power plug, and entrust repair.
Connect to the Power
Items to Check
ϡʳPress the on/o button, the backrest will also be reset.
Before Each Massage

Adjustment method of Chair
Ԧis Zero Gravity
Ԧis Cradle
Ԧis Lie Down
Ԧis get up
Sitting Posture Adjustment
1. Press to enter the sitting posture adjustment interface, there are 4 sitting modes:
2. The best position can be adjusted by long pressing the 6 direction buttons.
3. After selecting the best position, touch the button to confirm. If you do not select within 10 seconds,
this page will exit.
A. Hand Controller - Sitting Posture Adjustment Interface
Back Higher/Back lower
Calf Higher/Calf lower
Leg Extention
3. The button, can be used after product is turned on, press this button, the chair will be adjusted to
zero gravity state.
4. The button, can be used after product is turned on, press this button, the chair will start the back
push rod, simulate the cradle state.
5. The button and button, can be used after product is turned on, press these buttons, the chair
will start the air pressure, respectively open the stretching, twisting mode.
2. Press button, it will pause all the actions of the massage chair, and the screen will appear pause
interface; press again to restart.
1. Press button, you can turn on or turn o the massage chair. When turn on the massage chair,
adjusting the seat to a comfortable angle by default and lifting your feet.
(you can modify this feature in the setting interface)
6. , press these 4 buttons, can adjust the corresponding sitting posture.
B. Quick Adjust Buttons
Zero gravity Cradle On/O Calf Higher
Stretch Twist Pause
Back Higher
Calf Lower Back lower
Please do not sit on the backrest, armrests, legrest, shoulders to prevent the user or massage
chair from tipping over, resulting in an accident or injury.
When laying down the back of the chair or lowering the legrest, please make sure that there
are no people, no pets, and no objects behind and below the legrest. Otherwise it will cause
an accident.
Please Note!
15

Quick Start
- Connecting the power of the chair.
- Pressing the on/o button located
on the back of the chair next to the
electrical plug.
- Remove shoes and sit in the chair.
- Press the button, the initial touch
screen displays as below.
đŏAfter selecting the preferred program, touch the button to
confirm. If you do not select within 10 seconds, this page will exit.
1. Touch the auto mode on the screen to select the preferred program.
đŏ6 Automatic massage programs for choice: Release Tiredness,
Recover, Relax, Deep Shiatsu, Soft Knead, Stretching and Relaxation.
đŏWhen the automatic mode is selected for the first time after power
on, the massage chair will perform a shoulder/neck position detection
and a back-curve test, also detect the leg at the same time.
2. Shoulder position detection and back curve detection.
đŏ$!*ŏ0$!ŏ0!/0ŏ%/ŏ+),(!0! Čŏ0+1$ŏ0$!ŏ100+*ŏŏŏŏŏŏ0+ŏ+*ü.)ċŏ"ŏ5+1ŏ +ŏ*+0ŏ+*ü.)ŏ3%0$%*ŏ
10 seconds, this page will exit.
- It will be re-detected when the back load is not detected four times in a row.
đŏ$+1( !.ŏ !0!0%+*ŏ,#!ŏ/ŏ/$+3*ŏ+2!Čŏ"0!.ŏ !0!0%*#ŏ0$!ŏ/$+1( !.Čŏ5+1ŏ*ŏ,.!//ŏ0$!ŏ1,ŏ
and down arrow for suitable adjustment, then press the OK key to confirm.
đŏ1.%*#ŏ0$!ŏ+ 5ŏ/$,!ŏ !0!0%+*Čŏ0$!ŏ !0!0%+*ŏ(%#$0ŏ%* %0!/ŏ0$!ŏ1..!*0ŏ !0!0%+*ŏ,+/%0%+*ċ
- When no one is seated on the massage chair or when the body shape cannot be detected,
the "Body detection in error " page appears. At this time, touch the “Confirm"button on the
screen to re-test.
Automatic Massage Programs
16

7, Back and Hip Heat: touch to turn on or turn on the heat function for back and buttocks.
Automatic Massage Programs
3. After detection is complete. The touch screen will show your back curve as shown
on the right. Then the chair will start the massage program.
4. The touch screen displays the automatic program currently in the massage.
5.Under the automatic program, the massage position can be selected from 3 options: full
body, shoulder & neck, waist & hip.
6, Neck & Shoulder adjustment: you can adjust neck & shoulder massage position when the
touch panel shows below.
Timing Display and adjustment
Home Page
Massage position
Massage mode display
Neck & Shoulder
Adjustment
Back & Hip heating
Calf & Feet heating
Air pressure adjustment
Foot roller
Setting
Massage Roller
Position
Air pressure
inflation status
Massage strength
adjustment
Calf Shiatsu & Roller
massage
17

Automatic Massage Programs
8. Calf and Feet heat: touch to turn on or turn on the heat function for calf and feet.
9. Air-pressure Adjustment: touch to increase the pressure, and touch to decrease the
pressure. When the intensity is reduced to 0, the air pressure function is turned o. When
the pressure intensity is increased from 0 to 1, the Master Recommended mode is turned
on by default.
10. Air pressure inflation status: It can display the current air massage position.
11. Air pressure inflation status: It can display the current air massage position.
12. 3D massage strength: touch to increase the massage intensity and touch to
decrease the massage intensity. There are 7 levels of intensity and they can be adjusted
under both manual mode and automatic mode.
13. Foot Roller: touch to turn on or turn o the foot roller function.
14. Calf Shiatsu & Roller: touch to turn on or turn o the calf shiatsu and roller functions.
15. Timing Display and adjustment: display the massage remaining time after power-on.
Touch this position to call up the timing adjustment interface. The preset time is 15 minutes
after power on. After the massage finished, the massage rollers will return to storage position,
but the chair posture will not be reset. If the remaining time is displayed as 0 minutes, touch
within 1 minute to reset the time. Otherwise, it will shutdown after 1min.
16. Settings:
đŏ$!.!ŏ.!ŏĆŏ(*#1#!/ŏ0+ŏ$++/!ŏ".+)ċ
đŏ10+ŏ"++0ŏ(%"0ŏ1,Čŏ0+ŏ$++/!ŏ3$!0$!.ŏ10+)0%((5ŏ(%"0ŏ0$!ŏ"++0ŏ"0!.ŏ,.+ 10ŏ%/ŏ01.*! ŏ+*ċ
đŏ10+ŏ/0+.#!Čŏ0+ŏ$++/!ŏ3$!0$!.ŏ0+ŏ/0+.#!ŏ"0!.ŏ,.+ 10ŏ%/ŏ01.*! ŏ+ûċ
đŏ.!!*ŏ(1)%**!Čŏ"+.ŏ.%#$0*!//ŏ/!00%*#/Čŏŏ0+0(ŏ+"ŏĈŏ(!2!(/ċ
đŏ),(%#$0Čŏ0+ŏ$++/!ŏ)//#!ŏ$%.ŏ(1!0++0$ŏ(%#$0/ŏ* ŏėĘŏ(+#+ŏ(%#$0/ċŏ$!*ŏ
touch this screen, bluetooth light and Logo light will be turned on, there are 15 kinds of
bluetooth lights to choose. When bluetooth light is o, Logo light will turn o.
đŏ+1$ŏŏŏŏŏŏ+.ŏāĀ/ŏ +!/ŏ*+0ŏ0+1$ŏ0$!ŏ/.!!*Čŏ3%((ŏ!4%0ŏ0$%/ŏ,#!ċ
17. After the program finishes, the massage rollers automatically return back to the storage
position.
18. Please turn o the power after use.
18

Basic Massage Methods
Touch the manual mode on the screen to select the preferred program.
Basic Methods
Knead Up
Bottom-up kneading massage
Knead Down
Kneading massage from top to bottom
Rolling
Rolling massage and stretch the spine
Tapping
Tapping rhythmically, relieve muscle soreness
Circular
Kneading while tapping, eliminates fatigue with
fine movements
Deep Knead 1
From bottom to top massage muscles
Deep Knead2
Knead muscles powerfully from top to bottom
Neck Relax
Relax the neck area
Waist Relax
Relax the Waist
Shiatsu
Strength is concentrated on a fixed spot to massage
đŏ*! ŏ,ŏŇŏăčŏ+00+)ġ1,ŏ'*! %*#ŏ)//#!ŏ3%0$ŏ6++)ŏ%*ĥ+10ŏ)//#!ŏ)+2!)!*0/
đŏ*! ŏ+3*ŏŇŏăčŏ*! %*#ŏ)//#!ŏ".+)ŏ0+,ŏ0+ŏ+00+)ŏ3%0$ŏ6++)ŏ%*ĥ+10ŏ)//#!ŏ
movements
đŏ,,%*#ŏŇŏăčŏ0,,%*#ŏ.$50$)%((5ŏ3%0$ŏ6++)ŏ%*ĥ+10ŏ)//#!ŏ)+2!)!*0/
đŏ%.1(.ŏŇŏăčŏ*! %*#ŏ3$%(!ŏ0,,%*#Čŏ!(%)%*0!/ŏ"0%#1!ŏ3%0$ŏü*!ŏ)+2!)!*0/Ďŏ3%0$ŏ
zoom in/out massage movements
đŏ*! ŏ,ŏŇŏ0.!0$čŏ1/$%*#ŏĒŏ,1((%*#ŏ".+)ŏ+00+)ŏ0+ŏ0+,ŏ3$%(!ŏ'*! %*#ŏ)1/(!/
đŏ*! ŏ+3*ŏŇŏ0.!0$čŏ1/$%*#ŏĒŏ,1((%*#ŏ".+)ŏ0+,ŏ0+ŏ+00+)ŏ3$%(!ŏ'*! %*#ŏ)1/(!/
đŏ,,%*#ŏŇŏ0.!0$čŏ1/$%*#ŏĒŏ,1((%*#ŏ".+)ŏ+00+)ŏ0+ŏ0+,ŏ3$%(!ŏ0,,%*#ŏ.$50$)%((5
đŏ%.1(.ŏŇŏ0.!0$čŏ1/$%*#ŏĒŏ,1((%*#ŏ".+)ŏ+00+)ŏ0+ŏ0+,ŏ3$%(!ŏ'*! %*#ŏ* ŏ0,,%*#
đŏ*! ŏ,ŏŇŏ!."!0čŏ0.0%*#ŏ".+)ŏ0$!ŏ1,,!.ŏ'Čŏ"+1/ŏ+*ŏ'*! %*#ŏ.+1* ŏ/$+1( !./0
đŏ,,%*#ŏŇŏ!."!0čŏ0.0%*#ŏ".+)ŏ0$!ŏ1,,!.ŏ'Čŏ"+1/ŏ+*ŏ0,,%*#ŏ.$50$)%((5ŏ.+1* ŏ
shoulders
đŏ!(4ŏ0$!ŏ3%/0ŏŇŏ!."!0čŏ+1/ŏ+*ŏ'*! %*#ŏ* ŏ)//#!ŏ0$!ŏ3%/0ŏ3%0$ŏ.$50$)%ŏ
movements
3 Special Massage Methods – 3D, Stretch and Perfect
19
Table of contents
Popular Massager manuals by other brands

HoMedics
HoMedics Body Revitalizer VM-180 Instruction manual and warranty information

Panasonic
Panasonic EP574 - MASSAGE LOUNGER operating instructions

Ogawa
Ogawa Master Drive LE user manual

HoMedics
HoMedics SBM-600H-EU instruction manual

truMedic
truMedic InstaShiatsu user manual

BCP
BCP SKY6280 instruction manual
