EASTMAN BAT Setup guide

EASTMAN
THE EASTMAN
Instructions &
Illustrated Parts List
CAUTION
®
779 Washington St., Buffalo, N.Y. 14203-1396 U.S.A. • [phone] • Fax [phone] or [phone]
Manufacturers of Eastman Cloth Cutting and Cloth Spreading Machines
Website: WWW.EastmanCuts.com
WARNING
Safety glasses must be worn at all times when
operating or servicing this equipment.
Bat
R
Machine Equipped
With
Sharp Blade
Your new Bat is designed to replace hand held shears for
increased performance and capacity with a minimum of
maintenance and service. Equipped with a 4" high speed
round blade, the Bat will cut even the most difficult to cut
fabric.
TO OPERATE MACHINE
Raise the knife guard up just enough to allow the fabric in
over the pressure foot an make contact with the blade.
Press and hold button to activated ON/OFF switch. If cutter
does not perform properly check battery packs. Be sure the
battery packs are properly charged and installed.
TO SHARPEN KNIFE
Take the machine out of material to be cut. To obtain a fine,
keen edge on the blade, while machine is running press
lightly on sharpener button (63C3-21) with a constant
pressure. Hold for 10 seconds, then release.
WARNING
Before performing any of the following procedures, make
sure the battery power pack has been removed.
LUBRICATION
Follow this procedure yearly for intermittent use, or every
six months for continuous use. Remove emery wheel
(541C1-22) and wipe away any grit deposits. Apply a light
coat of Eastman Lubriko Grease (242C2) to parts and
reassemble.
KNIFE REPLACEMENT
Remove battery pack from Bat. Lay Bat on its side with knife
facing up. Insert a pin or allen wrench into knife hole. With
Spanner Wrench (954C1-12), turn lock nut (4C1-81) coun-
terclockwise. Remove lock nut. CAREFULLY lift out
WORN SHARP KNIFE and DISCARD WITH CARE. Install
new Eastman knife with bevel facing outward. Reverse
procedure to secure new knife.
EMERY WHEEL REPLACEMENT
Remove battery pack from Bat. With Bat on its side (knife
facing up). Remove knife lock nut and knife. Hold sharpener
bushing (21C5-4) with suitable wrench. Remove sharpener
button (63C3-21) and spring. Sharpening stone and bush-
ing assembly can then be removed from sharpener bracket
(663C1-3). Remove retaining ring from shaft of sharpening
stone and remove stone. To Install, assemble in reverse
order.
OPTIONAL BALL TIP
A ball tip (109C5-1) for cutting loosely woven materials,
additional support and cutting accuracy is optional. To
install ball tip to shear plate (726C1-36) gently push ball tip
in place as illustrated.
Model BAT
Form C-1583
From the library of: Diamond Needle Corp

2
EASTMAN
Form C-1583
Bat Illustrated
Parts List
Limited Warranty. Eastman warrants to the buyer that the Bat shall be free from defects in materials or workmanship for a period of 90 days
commencing on the date of invoice. Any goods or parts claimed by the buyer to be defective must be returned to Eastman, freight charges prepaid,
within the 90–day warranty period. If Eastman determines that the goods or parts are defective in materials or workmanship, Eastman's sole obliga-
tion under this warranty shall be, at Eastman's sole option, to repair or replace the defective goods or parts or to provide to the buyer a credit equal
to the portion of the purchase price allocable to the defective goods or parts. This warranty shall not apply if defects are caused by product misuse or
neglect, if the machine has been altered or modified by the buyer, or if other than genuine Eastman belts, emery wheels, knives or parts are used in
the machine. THIS WARRANTY IS THE ONLY WARRANTY APPLICABLE TO THIS PURCHASE. SELLER DISCLAIMS ALL OTHER WARRANTIES,
EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE.
Limitation of Liability. Eastman's liability to the buyer, and the buyer's remedies from Eastman, whether in contract, negligence, tort, under any
warranty or otherwise, shall be limited to the remedies provided in the foregoing Limited Warranty. In no event shall Eastman have any responsibility
or liability to the buyer for (a) any special, indirect, incidental, or consequential damages, including, but not limited to, loss of use, revenue, or profit,
even if Eastman has been advised of the possibility of such damages, or (b) any claim against the buyer by any third party. The price stated for the
product sold is a consideration for limiting Eastman's liability.
ITEM PART NO. DESCRIPTION QTY.
1 79C2-61 Caution Decal 1
2 632C1-14 Motor & Housing 1
3 236C1-166 Bat Decal 1
4 206-34 Jam Hex Nut, 1/4-20 2
5 CH-107 Spring 2
6 20C13-56 Setscrew, #6-32 x 3/4 1
7 12C15-95 Flat Washer, #6 2
8 25C4-146 Knife Guard 1
9 20C5-21 Thumb Nut, Guard 1
10 726C1-36 Shear Foot Assembly 1
11 331-34-34 Hex Bolt, 1/4-20 x 2.25 1
12 331-34-34 Hex Bolt, 1/4-20 x 2.25 1
13 80C1-59 1 Knife, Round 1
* 80C1-59 2 Knife, Round, High Speed 1
14 4C1-81 Lock Nut 1
15 95C5-12 Spanner Wrench 1
16 637C1-12 Sharpener Assembly 1
17 541C1-22 Sharpening Stone 1
ITEM PART NO. DESCRIPTION QTY.
18 12C15-57 Spring Washer 1
19 21C5-4 Sharpener Bushing 1
20 18C6-23 Retaining Ring 1
21 636C1-3 Sharpener Bracket 1
22 34C10-131 Sharpener Spring 1
23 63C3-21 Sharpener Button 1
24 300C12-2 Screw, #8-32 x 1/4 1
*25 109C5-1 Ball Point 1
26 287C1-3 Battery, 3.6 Volt, Gold 2
27 288C1-2 Battery Charger, 110v 1
* 288C3-3 Battery Charger, 220v-2 prong 1
* 288C3-4 Battery Charger, 220v-3 prong 1
*28 109C5-1 Ball Point 1
29 17C11-1 Knife Removal Pin 1
30 580C1-227 Switch, Main Power 1
* Indicates Optional Items
From the library of: Diamond Needle Corp

3
®
Form C-1583
To order replacement parts call Customer Service at [phone]. Please specify model and serial num-
ber of machine along with part number, description and quantity of parts in order.
* Indicates Optional Parts
From the library of: Diamond Needle Corp

EASTMAN
Printed in U.S.A. 5/2005
Form C-1583 ©2001 Eastman Machine Company
®
779 Washington St., Buffalo, N.Y. 14203-1396 U.S.A. • [phone] • Fax [phone] or [phone]
Manufacturers of Eastman Cloth Cutting and Cloth Spreading Machines
Website: WWW.EastmanCuts.com
3.6 Volt Versa-Pak Batteries and Chargers
This instruction manual covers the VP130 two-port chargers and
VP100 batteries. Note: VP100 batteries are NiCd cells. See
charging instructions below:
Important Safety Instructions (For Battery and Charger)
WARNING: When using electric tools, basic safety precau-
tions should always be followed to reduce the risk of fire, electric
shock, and personal injury, including the following:
READ ALL INSTRUCTIONS
Do not store -or- carry battery such that metal objects can
contact exposed metal end. For example, do not place bat-
tery in aprons, tool boxes, pockets, drawers, desk, etc… with
loose nails, screws, keys, etc…without battery cap. Battery
could short circuit causing fire, burns, or damage to the bat-
tery.
Battery caps are provided for use when carrying batteries -or-
while battery is stored in a pocket, tool box, drawer, etc…
Remove cap before placing battery in charger -or- tool.
Never attempt to open the battery for any reason. If the housing
of the battery breaks -or- cracks, immediately discontinue use
and do not recharge.
Do not incinerate the batteries as they can explode in a fire. A
small leakage of liquid from the battery cells may occur under
extreme usage, charging, or temperature conditions. This
does not indicate a failure. However, if the outer seal is broken
and this leakage contacts your skin:
a.) Wash quickly with soap and water;
b.) Neutralize with a mild acid such as vinegar -or- lemon
juice.
c.) If the battery liquid gets in your eyes, flush them with clean
water for a minimum of ten (10) minutes and seek immediate
medical attention.
Medical Note: The liquid is a 25-35% solution of potassium
hydroxide.
Charge batteries only with Versa-Pak battery charger.
Do not use charger in wet –or- damp conditions. It is intended
for indoor use only. Do not use near sinks, tubs, etc… Do not
immerse in water.
Do not use the charger for any uses other than charging Versa-
Pak batteries. Other batteries may explode.
Do not operate charger with a damaged cord –or- plug…have
them replaced immediately.
Do not operate charger if it has received a sharp blow, been
dropped, or otherwise damaged in anyway; contact your quali-
fied Eastman representative for service.
Do not disassemble charger; contact your qualified Eastman
representative when service -or- repair is required. Incorrect
assembly may result in risk of electric shock -or- fire. There are
no consumer serviceable parts inside.
For best results, do not charge batteries when they -or- the air
temperature is BELOW +40 degrees Fahrenheit -or- ABOVE
+105 degrees Fahrenheit.
The charger is designed to operate on standard household
electrical power. Do not attempt to use it on any other voltage.
Be sure your power supply agrees with the nameplate marking.
Unplug charger when not in use.
Do not abuse charger cord. To reduce the risk of damage to the
electric plug and cord, never carry charger by cord –or- sharply
pull it to disconnect from receptacle. Keep charger cord from
heat, oil, and sharp edges.
Use only charger supplied by Eastman to recharge.
Important Charging Notes:
While charging, the charger transformer may hum with the
batteries and charger becoming warm. This is a normal
condition and does not indicate a problem.
If a battery does not charge properly – 1.) Check current at
receptacle by plugging in a lamp –or- other appliance; 2.)
Check to see if receptacle is connected to a light switch that
turns power off when you turn out the lights; 3.) Move charger
and batteries to a surrounding air temperature between +40 to
+105 degrees Fahrenheit; 4.) If the receptacle and tempera-
ture are satisfactory, and you do not get proper charging, take
–or- send the batteries and charger to your local Eastman
representative for service.
The batteries should be recharged when they fail to produce
sufficient power on jobs that were easily performed previously.
DO NOT CONTINUE to use the machine with its batteries in a
depleted condition.
SAVE THESE INSTRUCTIONS
Charging Procedure (VP130 Two Port Charger plugs directly
into the Wall Outlet)
Insert the metal end of the Versa-Pak battery into the charger.
The indicator light will glow indicating that charging is taking place
and will remain on as long as the battery is in the charger.
Continuous charging is not a safety concern.
NOTE: Your Versa-Pak batteries are sent in an uncharged
condition. Before attempting to use them for the first time, they
must be charged for 6 hours for conventional NiCd batteries
(silver label) and 9 hours for NiMH batteries (gold label). Subse-
quent charging will require 3-6 hours for silver labeled and 6-9
hours for gold-labeled batteries.
The RBRC Seal
The RBRC (Rechargeable Battery Recycling Corporation) Seal
on the NiCd battery (or battery pack) indicates that costs to
recycle the battery (or battery pack) at the end of its useful life
have already been paid. In some areas, it is illegal to place spent
NiCd batteries in the trash –or- municipal solid waste streams.
The RBRC program provides an environmentally conscious
alternative.
RBRC in cooperation with other battery users, has established
programs in the United States and Canada to facilitate the
collection of spent NiCd batteries. Help protect our environment
and conserve natural resources by returning the spent NiCd
battery to your local recycling center. You may also contact your
local recycling center for information on where to drop off the
spent battery, or call 1-800-8-Battery.
