EASY COOPS Chicken Coop Plan 20x40 User manual

20'x40' Chicken Coop Plan
Up to 50 chickens

Compare Free vs. Premium plan
Free plan Premium edion
Pages
81
 0 0
 0 0
 0 0
 0 0
 0 0
 0 0
 0 0
 0 0
 0 0
TRY PREMIUM
22

20´x40´ chicken coop material list
Site Preparation
•Concrete
•Bricks
Bottom Frame
•Pressure-Treated Lumber
•Plywood
Walls Exterior Siding
•Pressure-Treated Lumber
•Wood siding boards
Walls Frames
•Pressure-Treated Lumber
Top Frame
•Pressure-Treated Lumber
Shed’s Roof
•Pressure-Treated Lumber
•Pressure-Treated Board
•Plywood
•Building paper
•Asphalt shingles
•Metal drip edge
Fasteners & Hardware
•Corner braces
•Galvanized nails
•Wood screws
Front/Side Shed's Window
•Pressure-Treated Lumber
•Window beading
•Glass

STEP 1
Framing the Coop's Floor
1.1 Assemble the frame using 1 1/2" x 7 1/4" pressure-treated lumber. You will need two
boards cut to 11'-9 1/4" that will be the rim joists and two boards cut to 8'-6 1/4" that will be
the joists.
1.2 Secure the beams with 3" wood screws.
1.3 Using a speed square or carpenter's square, check the corners to make sure they are 90°.
1 1/2"1 1/2"
11'-9 1/4"
1 1/2"8'-6 1/4"1 1/2"
1'-2 3/4"
7 1/4"

STEP 2
Framing the Floor
2.1 Assemble the frame using 1 1/2" x 7 1/4" pressure-treated lumber.
You will need eight boards cut to 8'-6 1/4" that will be the joist.
2.2 Secure the beams with 3" wood screws.
2.3 Using a speed square or carpenter's square, check the corners to make sure they are 90°.
7 1/4"
1'-2 3/4"
1 1/2"
8'-6 1/4"
1 1/2"
11'-9 1/4"
1'-1 3/4"11"
7 x 1'-2 1/2"

STEP 3
Assemble Front Wall Frame
3.1 Using 1 1/2" x 3 1/2", 1 1/2" x 5 1/2" and 3 1/2" x 3 1/2" pressure-treated lumber, construct front
wall frame using the drawing below as a reference. You will need ten boards cut to 6'-4" and two boards
cut to 5'-10 1/2" that will be studs, two boards cut to 4'-6 3/4" that will be the boom beams, one board
cut 11'-9 1/4" that will be the top beam and two boards cut to 2'-11" that will be the door header.
3.2 Connect the beams with 3" wood screws.
3.3 Using a speed square or carpenter's square, check the corners to make sure they are 90°.
3 1/2"
2 1/2"
1'-2 1/2" 1'-2 1/2" 1'- 1/4" 2'-11" 1'- 1/4" 1'-2 1/2" 1'-2 1/2"
2 1/2"
3 1/2"
2'-8"
5'-10 1/2"
1 1/2"
6'-4"
1 1/2"
4'-6 3/4" 4'-6 3/4"
5 1/2"
11'-9 1/4"

STEP 4
Assemble Back Wall Frame
4.1 Using 1 1/2" x 3 1/2", 1 1/2" x 5 1/2" and 3 1/2" x 3 1/2" pressure-treated lumber, construct back
wall frame using the drawing below as a reference. You will need four boards cut to 6'-4", six boards
cut to 4'-9", four boards cut to 2'-11 1/2" and two boards cut to 1'-2" that will be studs, one board cut to
11'-9 1/4", two boards cut to 3'-6 3/4" and one board cut to 3'-5 3/4" that will be the boom beams, one
board cut 11'-9 1/4" that will be the top beam, four boards cut to 1'-11" that will be the window headers,
two boards cut to 1'-8" that will be rough sills and two boards cut to 1'-4" that will be cripple studs.
4.2 Connect the beams with 3" and 5" wood screws.
4.3 Using a speed square or carpenter's square, check the corners to make sure they are 90°.
3 1/2" 8 1/2" 10 3/4" 10 3/4" 8 1/2" 10 3/4" 1'-2 1/2" 1'-1 1/2" 8 1/2" 10 3/4" 10 3/4" 8 1/2" 3 1/2"
3 1/2" 3 1/2"
11'-9 1/4"
1 1/2"
6'-4"
1 1/2"
1'-4"
1'-11"
5 1/2"
2'-11 1/2"
1'-8"
1'-2"
3'-6 3/4" 3'-5 3/4" 3'-6 3/4"
4'-9"
1'-3 1/2"
1'-4"
5 1/2"
4'-9"
1'-8"
2'-11 1/2"
1'-8"
1'-11"
1'-2"
11'-9 1/4"

STEP 5
Assemble Left Side Wall Frame
5.1 Using 1 1/2" x 3 1/2", 1 1/2" x 5 1/2" and 3 1/2" x 3 1/2" pressure-treated lumber, construct left wall
frame using the drawing below as a reference. You will need six boards cut to 4'-9", two boards cut to 6'-4",
two boards cut to 2'-11 1/2", one board cut to 1'-3 1/2" and one board cut to 1'-2" that will be studs, one
board cut to 8'-2 1/4" and one board cut to 7'-11 1/4" that will be the boom beams, one board
cut 8'-2 1/4" that will be the top beam, two boards cut to 1'-11" that will be the door header, one board cut
to 1'-8" that will be rough sill and one board cut to 1'-4" that will be cripple stud.
5.2 Connect the beams with 3" and 5" wood screws.
5.3 Using a speed square or carpenter's square, check the corners to make sure they are 90°.
5" 1'-2 1/2" 1'- 1/4" 10 3/4" 10 3/4" 1'- 1/4" 1'-2 1/2" 5"
8'-2 1/4"
1 1/2"
4'-9"
3 1/2"
1'-3 1/2"
1 1/2"
1'-4"
1'-11"
2'-11 1/2"
1'-8"
1'-8"
1'-2"
5 1/2"
3'-10" 3 1/2" 3'-10"
8'-2 1/4"
7'-11 1/4"
6'-4"

STEP 6
Assemble Right Side Wall Frame
6.1 Using 1 1/2" x 3 1/2" pressure-treated lumber, construct right side wall frame using the drawing below
as a reference. You will need eight boards cut to 6'-4" that will be studs, one board cut to 1'-2 1/2" that will
be chicken door header and two boards cut to 8'-2 1/4" that will be top and bottom beams.
6.2 Connect the beams with 3" and 5" wood screws.
6.3 Using a speed square or carpenter's square, check the corners to make sure they are 90°.
9 3/4" 1'-2 1/2" 1'-2 1/2" 1'-2 1/2" 1'-2 1/2" 1'-2 1/2" 4 1/4"
1 1/2"
6'-4"
1 1/2"
1'-2 1/2"
8'-2 1/4"

STEP 7
Assemble Aviary's Top Frame
7.1 Using and 3 1/2" x 3 1/2" pressure-treated lumber, provide the main top frame for aviary using the
drawing below as a reference. You will need two boards cut to 8'-5", two boards cut to 5'-11", one board
cut to 8'-2 1/4" and six boards cut to 10'-1 3/4".
7.2 Using 1 1/2" x 3 1/2" pressure-treated lumber, provide the inner frame for aviary using the drawing
below as a reference. You will need six boards cut to 9'-8 1/2", two boards cut to 4'-7 3/4" and two boards
cut to 4'-10 1/2".
7.3 Using 1 1/2" x 3 1/2" pressure-treated lumber, provide the cross braces using the drawing below as a
reference. You will need eighteen boards cut to 1'-5 1/2" (node B on page 28). Cut the corners in 45
degrees to fit studs and top beams.
7.4 To connect 8'-5" beams to the coop's frame and for connection of 8'-2 1/4" beam from both sides use
3"x3" corner braces (node D on page 28). To connect other top beams between themselves use half lap
connection (nodes B, C on page 28).
7.5 Connect the beams with 5" wood screws.
10'-1 3/4"10'-1 3/4"
10'-1 3/4"
10'-1 3/4"
5'-11"8'-2 1/4"
8'-5"
5'-11"
10'-1 3/4"10'-1 3/4"
9'-8 1/2"9'-8 1/2"
4'-7 3/4"
4'-10 1/2"
4'-10 1/2"
4'-7 3/4"
8'-5"

Assemble the Roof Frame
8.1 Using 1 1/2" x 5 1/2" pressure-treated lumber, cut thirty two rafters 6'-2 3/4" long according to the
dimensions in drawings below.
8.2 Using 1 1/2" x 3 1/2" pressure-treated lumber, cut fourteen collar ties 5' long according to the
dimensions in drawings below.
8.3 Using 1 1/2" x 5 1/2" pressure-treated board cut two boards 10 3/4" long and thirteen boards cut to
1'-2 1/2" long that will be ridge boards according the illustration below.
8.4 Connect the beams with 3" and 5" wood screws.
10 3/4"13 x 1'-2 1/2"10 3/4"
19'-6"
STEP 8

Install Plywood for the Roof
9.1 Cut sheets of 5/8" plywood for the roof sheathing using the drawing below as a guide.
You will need two 4' x 6'-5 3/4" sheets, four 4' x 8" sheets and four 2'-5 3/4" x 8' sheets.
9.2 Secure the plywood with 2" wood screws.
STEP 9
4'
4'2'-5 3/4"
6'-5 3/4"
8'8'

STEP 10
Install Plywood for the Left Wall Nesting Box
10.1 Cut sheet of 5/8" plywood for the nesting box sheathing using the drawing below as a guide.
You will need two 1' x 4'-4 3/4" sheets for the floor and six 1'-1 1/2" x 1'-4 1/2" sheets for inner
partitions.
10.2 Secure the plywood with 1" wood screws.

STEP 11
Install Plywood for the Back Wall Nesting Box
11.1 Cut sheet of 5/8" plywood for the nesting box sheathing using the drawing below as a guide.
You will need two 1' x 4' sheets and one 1' x 3'-9 1/4" sheet for the floor and nine 1'- 1 1/2" x 1'-4
1/2" sheets for inner partitions.
11.2 Secure the plywood with 1" wood screws.
11'-9 1/4"
1'-1 1/2"
4'
3'-9 1/4"
4'

STEP 12
Assemble and Install Front Door
12.1 Build the door frame using 3/4" x 3 1/2" pressure-treated lumber.
You will need two boards cut to 5'-11 1/2" that will be the vercal girts, two boards cut to 2'-1/2" that will
be the horizontal girts and one board cut to 5'-9" that will be cross brace.
12.2 Prepare the 5/8" plywood sheet with dimensions 2'-7 1/2" x 5'-11 1/2" for the door according to the
drawing.
12.3 Use 3/4" x 2 1/2" pressure-treated lumber for the door trim and fasten with 2" wood screws.
You will need two boards cut to 2'-2 1/2" and two boards cut to 5'-11 1/2".
12.4 Using 1/4" x 3/4" pressure-treated lumber, cut and install a starter course 2'-2 1/2" long using
node E on page 47 as a reference.
12.5 For the exterior siding on the door, use 1/2" x 6" wood siding boards and the illustration below as a
reference. Assemble siding shields with 2" galvanized nails.
12.6 Install three 3" door hinges using 6x1" wood screws.
Finish the door installation by attaching 6" door pull and 3" surface bolt (see nodes G, H).
H ( 1 : 8 )
G ( 1 : 8 )

STEP 13
Coop's Roof Sheathing Installation
13.1 You will need 265 Sq Ft of building paper and asphalt shingle roofing.
13.2 Cover the plywood and drip edge with building paper. Try to install sheets with 1"
overlapping. Use 2" nails to secure the sheets.
13.3 Install asphalt shingle roofing using an industrial stapler.
20'- 1/4"
6'-6"
20'- 1/4"
Building paper layer
Shingles layer

STEP 14
Assemble and Install Windows
You will need to prepare three windows.
14.1 Using 1 1/2" x 1 1/2" pressure-treated lumber, assemble the outer frame for the window as shown in
the drawing below. You will need four boards cut to 1'-7 1/2" that will be the vercal and horizontal girts.
Cut the recesses in each beam for splicing connection and mill a recess for the glass.
14.2 Prepare and install 1'-5 1/4" x 1'-5 1/4" glass into inner frame groove and fasten it by window
beading from four sides. Use 1/2" galvanized nails.
14.3 Insert window into wall openings and connect them with 3" wood screws to the wall beams.

STEP 15
Mesh Wall Installation
15.1 Cover the walls with 1/4" wire mesh with the help of industrial stapler. You will need 1100 sq ft.
4'-6 3/4"4'-8 1/2"4'-8 1/2"4'-6 3/4"
5
'
-
7
1
/
2
"
2'-3 1/4"
2'-3 1/4"
2'-4 1/2"
3'-3"
3'-8 1/2"
3'-7 3/4"
3
'-
1
0
"
3
'
-
1
0
"
8'-3 3/4"
1'-2 3/4"
3'-7 3/4"
3'-8 1/2"
3'-3"
3'-11"
4'-6 3/4"
4'-8 1/2"
4'-8 1/2"
4'-6 3/4"
4
'
-
6
3
/
4
"
4
'
-
8
1
/
2
"
4
'
-
8
1
/
2
"
4
'-
6
3
/
4
"

STEP 16
Assemble The Roost
16.1 Assemble the roost using 1 1/2" x 1 1/2" and 1 1/2" x 2 1/2" pressure-treated material.
You will need four boards cut to 5'-3" that will be the stringers and eight boards cut to 4'-1/2" that will be
treads.
16.2 Connect the beams with 2" wood screws.
16.3 Install the roost at the walls and to the collar tie with the help of 1 1/2" x 2 1/2" beam.
You will need to cut one 5'-6 3/4" board.
5'-6 3/4"
4'- 1/2"4'- 1/2"

STEP 17
Final Touches
Now that your chicken coop is all done, you are ready to decorate it any way you want using your favorite
paint, stain, or preservave.
