Easylife EL5820 User manual

10-in-1 Steam Mop
INSTRUCTION MANUAL
Model No. EL5820
Please read carefully before use and keep for future reference
Imported and distributed by Easylife Group Ltd, London NW1 0JP
Customer service: 0871 855 6100
For more innovative products from Easylife please visit:
www.easylifegroup.com
IN5820-1 © 2014 Easylife Group Ltd Customer service: 0871 855 6100
For more innovative products from Easylife please visit:
www.easylifegroup.com
PANTONE 072 C
PANTONE 123 C
DISPOSAL
• Pleaserespecttheenvironment!
• Disposeofthepackagingaccordingtothelocalrecyclingregulations.
• Disposeoftheapplianceattheendofitslifespanaccordingtoenvironmentalconsiderations.
DECLARATION OF CONFORMITY
Easylife Group Ltd
11-13King’sTerrace
London
NW1 0JP
Declaresthatthefollowingproduct
EL5820 10-in-1 Steam Mop
AreinconformitywiththeprovisionsofthefollowingECDirectives,includingallamendmentsandwith
nationallegislationimplementingthesedirectives:
LowVoltageDirective2006/95/EC
EMCDirective2004/108/EC
Thefollowingstandardsareapplied:
EN60335-2-10:2003+A1:2008
EN60335-2-54:2008
EN60335-1:2012
EN62233:2008
EN50564:2011
ThisproductcarriestheCEMark.
WARNING
Thisproductisintendedfordomesticuseonly.
TECHNICAL SPECIFICATION
Handle:Spiltdesign,steambuttoninhandleWaterTank:Removable,360mlcapacity
Voltage:220-240VOutputPower:1500WWaterproofLevel:IPX4
SteamOutput:Fulltankwilllastaround20minutesintermittentuse.
Steam
through
101
cleaning
jobs

PANTONE 072 C
PANTONE 123 C
Customer service: 0871 855 6100
For more innovative products from Easylife please visit:
www.easylifegroup.com
2
Dear Customer
Thankyouforpurchasingthe10-in-1SteamMop.
Just 360ml of water (and no harmful detergents) and 25 seconds - that’s all it takes
to generate 20 minutes of continuous steam in the new versatile 10-in-1 Steam Mop.
Then it’s time to make short work of steam cleaning and sanitising oors, carpets
windows, hob, sinks and more. The triangular-shaped head rotates 180oto
get into every nook and cranny and then at the touch of a button, it instantly
transforms into a powerful hand-held steamer. Use this for tackling everything from
ovens and hobs, sinks, tiles and windows, to soft furnishings, upholstery, clothing,
curtains, pet bedding and car interiors. Complete with optional 6 piece accessory
kit (EL5829) to make hand-held use so much more efcient and versatile. When
nished, it folds to half its height for easy storage in a cupboard. With 1500w mains
power, 360ml detachable easy-ll water tank, its complete with a 15ft (480cm) extra-
long lead for ‘clean anywhere’ steam power. Measures: H118cm x W31cm.
6 piece accessory kit includes 135cm exible hose, big squeegee, direction nozzle,
shoulder strap, handle clip and steam cloth.
IMPORTANT SAFETY INSTRUCTIONS
WARNING:Readallsafetywarningsandallinstructions.Failuretofollowthewarningsandinstructions
listedbelowmayresultinelectricshock,reand/orseriousinjury.
WARNING:Whenusingelectricalappliances,basicsafetyprecautions,includingthefollowing,
shouldalwaysbefollowedtoreducetheriskofre,electricshock,personalinjuryand
materialdamage.
• Readthisentiremanualcarefullybeforeusingtheappliance.
• Theuseofanyaccessoryorattachmentortheperformanceofanyoperationwiththisapplianceother
thanthoserecommendedinthisinstructionmanualmaypresentariskofpersonalinjury.
• Retainthismanualforfuturereference.
• Donotdirectsteamatpeople,animals,electricalappliancesorelectricaloutlets.
• Donotexposetorain.
• Donotimmersetheapplianceinwater.
• Donotleavetheapplianceunattended.Keepchildrenawayfromunitwhileinuse.
• Donotleavetheapplianceconnectedtoanelectricaloutletwhennotinuse.
• Neverpullthepowercordtodisconnecttheappliancefromthesocket.Keeptheappliancecordaway
fromheat,oilandsharpedges.
• Donothandlethesteamcleanerwithwethands.
• Donotpullorcarrybythecord,donotusethecordasahandle,closethedooronthecord,pullcord
aroundsharpcornersorexposecordtoheatedsurfaces.
• Donotuseapplianceinanenclosedspacelledwithvapourgivenoffbyoil-basepaintthinner,some
moth-proongsubstances,ammabledust,orotherexplosiveortoxicvapours.
• Donotuseonleather,waxpolishedfurnitureoroors,syntheticfabrics,velvetorotherdelicate,
steam-sensitive materials.
• Donotuseonanyunsealedhardoorsurfaces.Additionally,onsurfacesthathavebeentreatedwith
waxorsomeno-waxoors,thesheenmayberemovedbytheheatandsteamaction.Itisalways
recommendedtotestonanisolatedareaofthesurfacetobecleanedbeforeproceeding.Wealso
recommendthatyouchecktheuseandcareinstructionsfromtheoormanufacturer.
• Neverputde-scaling,aromatic,alcoholicordetergentproductsintothesteammop,asthismay
damageitormakeitunsafeforuse.
• Ifthecircuitbreakeractivateswhileusingthesteamfunction,discontinueproductuseimmediately.
• Theapplianceemitsveryhotsteamtosanitizetheareaofuse.Thismeansthatthesteamheadand
cleaningpadsgetveryhotduringuse.
• Alwayswearsuitableshoeswhenusingyoursteammopandwhenchangingtheaccessorieson
your steam mop.
• Donotwearslippersoropen-toedfootwearwhenusingthesteammop.
• Thelidmaybecomehotduringuse.
• Careshouldbetakenwhenusingthisappliance.DONOTtouchanypartswhichmaybecomehot
duringuse.
• Thisapplianceisnotintendedforusebypersons(includingchildren)withreducedphysical,sensory
ormentalcapabilities,orlackofexperienceandknowledge,unlesstheyhavebeengivensupervision
orinstructionconcerningtheuseoftheappliancesbyapersonresponsiblefortheirsafety.
• Childrenshouldbesupervisedtoensurethattheydonotplaywiththeappliance.
Itisimportantforyoutoreadandunderstandthismanual.Theinformationitcontainsrelatestoprotecting
YOURSAFETYandPREVENTINGPROBLEMS.Thesymbolsbelowareusedtohelpyourecognize
thisinformation.
DANGER:Indicatesanimminentlyhazardoussituationwhich,ifnotavoided,willresultindeathor
seriousinjury.
WARNING:Indicatesapotentiallyhazardoussituationwhich,ifnotavoided,couldresultindeathor
seriousinjury.
CAUTION:Indicatesapotentiallyhazardoussituationwhich,ifnotavoided,mayresultinminoror
moderateinjury.
NOTICE:Usedwithoutthesafetyalertsymbolindicatesapotentiallyhazardoussituationwhich,ifnot
avoided,mayresultinpropertydamage.
• Additionalresidualrisksmayarisewhenusingthetoolwhichmaynotbeincludedintheenclosed
safetywarnings.Theseriskscanarisefrommisuse,prolongeduse,etc.
• Evenwiththeapplicationoftherelevantsafetyregulationsandtheimplementationofsafetydevices,
certainresidualriskscannotbeavoided.Theseinclude
• Injuriescausedbytouchinganymovingparts.
• Injuriescausedbytouchinganyhotparts.
• Injuriescausedwhenchanginganypartsoraccessories.
• Injuriescausedbyprolongeduseoftheappliance.Whenusinganyapplianceforprolongedperiods
ensureyoutakeregularbreaks.

FUNCTIONS (continued)
ACCESSORIES
 WindowSqueegee/
 GarmentSteamingTool
Small and Medium
 RoundBrushes
 AngleNozzle
 GroutCleaner
 ScrapingTool
 MicrobreCloth
 MicrobreFloorCleaner 
PARTS
 A MainBody
 B Handle
 C WindowSqueegee
 D SmallRoundBrush
 E MediumRoundBrush
F Accessory Adaptor
 G AngleNozzle
 H GroutCleaner
 I ScrapingTool
 J MeasuringCup
 K MicrobreFloorCleaner
 L MicrobreCloth
M Steam Head
 N CarpetGlider
FUNCTIONS
1.MEDIUMROUNDBRUSH(E)–Multi-purposemediumbrushcleansovenracks,BBQs
2.SMALLROUNDBRUSH(D)–Multi-purposesmallbrushcleanstiles,sinks,taps
3.MICROFIBREFLOORTILECLEANER(K)–Picksupdustandallergens,killsbacterialinbetween
tilegrout
4.MICROFIBREFLOORWOODCLEANER(K)–Picksupdust,killsbacterialinbetweenoorslats
5.MICROFIBREFLOORCARPETCLEANER(K)–Picksupdust,removesstains,rejuvenates
carpetbres
6.WINDOWSQUEEGEE(C)–Streakfreewindow,glassandmirrorcleaning
7.ANGLENOZZLE(G)–Cleansinkholes,smallgapsandhardtoreachcorners
8.MICROFIBRECLOTH(L)–Liftsgreaseandstubbornstainsfromclothesandfabrics
9.SCRAPINGTOOL(I)–Steamandscrapeawaydriedondirtintightspaces
10.GROUTCLEANER(H)–Cleangroutbetweenoorandwalltiles
Showerglass,doors,mirrors,
glass,removingsoapscumand
grime.Garmenttoolforremoving
creases,tableclothsetc.
Oven,microwaves,stovetops,
showers,baths,taps,tilegrout,
fridges,etc.
Stovetops,taps,tilegrout,
microwaves,sinks,hardto
reachplaces.
Cleaningallgroutlines,sanded
or non-sanded
Scrapingbakedonfood,grime
andgrease.Removingresidue
orotherdifcultsubstances.
Forusewhensteaming
garments,tablecloths,etc.
Forgeneralcleaningofhard
oorsandrefreshingcarpets
PANTONE 072 C
PANTONE 123 C
Customer service: 0871 855 6100
For more innovative products from Easylife please visit:
www.easylifegroup.com
Function 1
Function 6
Function 3
Function 8
Function 2
Function 7
Function 4
Function 9
Function 5
Function 10

FIG. 3
FIG. 4
PANTONE 072 C
PANTONE 123 C
Customer service: 0871 855 6100
For more innovative products from Easylife please visit:
www.easylifegroup.com
Attaching the steam head
Slidethebottomendofmainbody(A)intothehandlecavity(B)andclickintoplace.Themainbody(A)
caneasilyberemovedfromthehandlecavity(B)carefullyliftingthelockcatch(6).
Attaching a cleaning pad
Carefullyremovethecarpetglider(N)fromthesteamhead(M)bypullingthetwobarb-clipsonthe
carpetgliderandseparatingthetwoparts.
Placeamicrobreoorcleaner(K)overthegrippersonallthreesides.
Replacethecarpetglider(N)overthesteamhead(M)andmicrobreoorcleaner(K)andclick
into place.
Attaching the Steam Head
Insertthesteamhead(M)intothehandle(B)(asshowninFig2),pleaseensurethatthebarbconnector
onthesteamheadisinthecorrectpositionwhenconnectingthetwoparts.Onceconnectedthetwo
partswillclickintoplace.
OPERATION
1.Fillingthewatertank
Methodone:Openthewatertankbyturningtheknobanti-clockwiseandll360mlofwaterusingthe
measuringcup(J).Replacetheknobbyturningclockwisetoclosewatertank(seeFig3).
Methodtwo:Removethewatertankfrommainbody,openthewatertankbyturningtheknobanti-
clockwise.Fillthewatertankfromatapthethenreplacetheknobbyturningitclockwise
(seeFig4).
2.Pluginthesteammopintothemainsoutlet.
3.WhenyouswitchtheapplianceontheindicatorLEDlightswillturnredattheeachsideofwatertank,
thiswillindicatethewaterinthetankispre-heating.
4.Itwilltakeapproximately25secondsforpreheatingtocomplete.Oncethesteammopisreadytouse
thewatertankwillglowblue.
FIG. 2
COMPONENTS
 1 SpindleButton
2 Handle
 3 CordHolder
 4 HandleSteamButton
5 Steam Head Spindle
 6 LockCatch
 7 MainBodySteamButton
 8 PowerCord
 9 PowerSwitch
 10 IndicatorLight
11 Water Inlet
 12 SteamControlKnob
 13 WaterTankCap
 14 WaterTankButton
 15 WaterTank
ASSEMBLY
WARNING:Beforeattemptinganyofthefollowingoperations,makesurethattheapplianceisswitched
offandunpluggedandthattheapplianceiscoldandcontainsminimalornowater.
Handle
Pushthespindlebutton(1)andfullyextendthehandle(2)untilitclicksintoplaceSeeFig1.
FIG. 1

PANTONE 072 C
PANTONE 123 C
Customer service: 0871 855 6100
For more innovative products from Easylife please visit:
www.easylifegroup.com
Ifyoursteammopbeginstoproducesteammoreslowlythanusualorstopsproducingsteam,youmay
needtoremovelimescale.Limescalecandevelopovertimeonthemetalpartsandgreatlyaffectthe
mop performance.
Itisnecessarytoremovelimescaleonregularbasisevery25-50timesyouuseafulltankofwaterorat
leastonceamonth,especiallyinareaswithhardwater.Thefrequencyoflimescaleremovaldepends
uponthehardnessofyoutapwaterandhowoftenyouusethesteammop.
Using cleaning solution
1.Prepareasolutionof1/3whitevinegarand2/3tapwaterandaddtothewatertank.
2.Secureandpositiontheunittoensuresteamreleasedisaimedawayfromtheoororsurrounding
objectsandsurface.Plugtheunitin,turntheunitONbypressingthepowerswitch,andallowtheunitto
producesteamunitthevinegar/watersolutioninusedup.
3.Repeattheaboveprocedureasmanytimesasnecessaryunitanormalsteamowrateisachieved.
4.Fillthewatertankwithfreshwaterandrinseoutthoroughly.
5.Fillthewatertankwithfreshwater,attachtotheunitandreleasesteamthroughthesystemunitthe
watertankisempty.
WARNING:Don’tleavethesteamerunattendedduringthelimescaleremovalprocessand/orwhile
in use.
NOTICE:Preformatestcleanonasuitableisolatedareaaftereachlimescaleremovaltoensurethat
thereisnodebrisleftinthesystem.
Cleaning blocked steamer accessories
• Duetothehighmineralcontentofwaterinsomeareas,youmaynoticethatlesssteamcomesout
fromtheHand-Heldsteameraccessories.Thismaybecausedbycalciumbuildupinsidethetip
ofthenozzle.Werecommendusingaspraylubricant.Sprayasmallburstortwoofthelubricant
insidethetipoftheJetnozzle.Aftersprayinglubricantinsidethecomponent,tillthesteamerwith
wateraccordingtothedirectionsandrunacontinuousjetofsteamthroughtheaffectedaccessory
forseveralminutestoremovethedepositoncethesteampathwayisclear,aimthesteamerata
neutralsurfaceorcleaningclothtomakesurenodebrisisemitted.
• Thisproductcontainsnoserviceableparts.Donottrytorepairityourself.Anyservicingthatrequires
disassemblyotherthancleaningmustbeperformedbyaqualiedappliancerepairtechnician.
ALL servicing should be done by an authorized service representative.
Cleaning Microbre Floor Cleaner
Machinewashableon“warm”setting.Alwaysuseamilddetergent.Forbestcareresultslayattodry.
IMPORTANT:Allowthesteamertofullycooldownbeforeperforminganymaintenanceor
troubleshootingchecks.
IMPORTANT:Neverusebleachorfabricsoftenerwhenwashingthemicrobreoorcleaner.
ASSEMBLY (continued)
5.Whenthewatertankisfullitwillmaintainsteamforapproximately20minutes.Ifthewatertankis
lowtheindicatorlightsonthewatertankwillglowredandthelightswillashtopointoutyouneed
toaddwater.
6.Pressthesteambutton(4)toactivatethesteam.
7.Youcancontrolthevolumeofsteambyturningthesteamcontrolknob(12)Clockwisetoincrease
theamountofsteamandanti-clockwisetoreduceit.
Using the hand steam cleaner
Pushthelockcatch(6),removethemainbody(A)outofholder.
Installtheaccessoryadaptorofyourchoiceatthetopofmainbody(A)untilitclicksintoplace(please
refertotheaccessoriestablefortheappropriateattachment.
Forthefollowingattachmentsitisnecessarytousetheaccessoryadapter(F)toconnectthese:
Inserttheaccessoryadapter(F)tothemainbody(A)bypushingrmlysothetwopartsconnect
together.Inordertoconnecttheaccessoryattachmenttotheaccessoryadaptersimplypushandturn
clockwisetolockintoplace.Inordertoremovesimplyturnanti-clockwise.
Smallandmediumscrubbrushes(D&E),AngleNozzle(G),GroutCleaningTool(H)andScrapingTool
(I),seeFig5below.
CLEANING AND MAINTENANCE
YOUR WARRANTY WILL BE VOID IF THIS IS IGNORED:
 Inareasofhardwateritisrecommendedthatdistilledwaterisused.Hardwaterwillimmediately
 reducetheperformanceofyourSteamMopandprolongedusewillcausepermanentdamageto
 themechanism,renderingitun-useable.Thiswillrenderyourwarrantyvoid.AnySteamMop
 returnedwillbethoroughlycheckedbyourtechniciansforcompliance.
PLEASEMAKESURETHATTHEAPPLIANCEISDISCONNECTEDFROMTHEMAINSPOWER
OUTLETWHENCLEANINGTHEMOPANDACCESSORIES.DRAINANYREMAININGWATERIN
THETANKANDCLEANTHETANKAFTEREVERYUSE.
Pleaseusedetergenttocleantheaccessories(JetNozzleandRoundBrush)whentheyaredirtythen
washwithcleanwateranddry
How to descale the Water Tank
Tocleancalciumdeposits/limescalethatbuildsupinsidethewatertank,addoneortwotablespoons
ofwhitevinegartoafullwatertank.Closethewatertankcapandthenshakethecontents.DONOT
TURNTHESTEAMERON.
FIG. 5

Customer service: 0871 855 6100
For more innovative products from Easylife please visit:
www.easylifegroup.com
Storage
• Afterthesteamerisusedturnpoweroffandthenunplugthepowercord.
• Takeoutthewatertankandemptytheresidualwaterinthetankandcleantheexternalsurface
withadryclothuntilthesteammopcoolsdown.
• Removethecleaningpadandwashitsothatitwillbereadyfornextuse.
• Hangthepowercordaroundthecordhold,pressspindlebuttonandfoldtheholder.Thenrotate
thecordhold180°topreventcordfromdropping.
• Storetheapplianceinaprotected,dryarea.Keepwaterfunnelandmeasuringcupforfutureuse.
• Keepoutofreachofchildren.
NOTICE:Afterusingthemop,removewaterfromthetankbyholdingdownthepowerbuttonsothe
watertankiscompletelyempty.
TROUBLESHOOTING
USETROUBLESHOOTINGGUIDEASAFIRSTSTEPTORESOLVEANYPROBLEMSYOUMAY
BEEXPERIENCING.
TOREDUCERISKOFPERSONALINJURY-UNPLUGSTEAMERBEFORESERVICINGAND
ALLOWTOCOOL.
PROBLEM POSSIBLEREASON POSSIBLESOLUTION
Reducedsteamornosteam Watertankmaybeemptyorlow Fillwatertanktoitsmaxlevel
  Steamnozzlemaybeblocked Cleansteamnozzle
  Thereisnopowertothe Makesuretheapplianceis
  appliance pluggedin
  Steamisnotcomingoutasrequired Turnthesteamknob 
   clockwisetoincreasethe
volume of steam
Appliancewillnotturnon Fusemayhaveblown Replacefuseand/orreset
   circuitbreakerinyourhome
  Powercordnotpluggedin Trypluggingapplianceintoa
   workingcircuit
Foldsforeasystorage
Canalsobeusedasahandheldcleaner
Lockcatch
Simplyslidethelockcatchupandgently
liftthemainbodyfromthehandlecavity
Main body
Handle cavity
