EasyPro PA6SW Operation and maintenance manual

Thank you for your purchase of an EasyPro shallow water pond aeration system. EasyPro complete aeration
systems are designed to be an energy ecient way to aerate, de-stratify and circulate water in ponds. The in-
crease in oxygen levels provided by an aeration system is benecial to any pond but especially to ponds with
sh. These kits are ideal for ponds up to seven feet deep.
Each aeration system is powered by a quiet, continuous duty compressor and includes tubing, air diuser and
parts to assemble.
Safety and Electrical
Warning - Risk of electrical shock. For your protection always unplug the unit from its power source
before installing or servicing.
Warning - This compressor is solely intended to pump air. It is not for use with oil, solvents or any petro-
leum products (gasoline, diesel, etc.).
• Always use a properly grounded AC outlet. Keep plug end from moisture and do not attempt to plug in a
wet plug.
• Avoid using extension cords to operate compressor.
• Provide a “drip loop” for the line cord. This is a loop in the cord below the level of the receptacle or plug
that prevents water from traveling along the cord into the receptacle.
• Be sure that a Ground Fault Circuit Interrupter (GFCI) is installed in the branch circuit supplying the
aquarium, fountain or pond equipment.
• Unit should be installed horizontally and above the height of water surface.
• Do not submerse compressor. Do not place compressor where it could fall into water.
• Do not operate if power cord is damaged.
• Use extreme caution when operating in winter. Danger due to thin ice can cause drowning. Unseen cur-
rents can cause thin ice in areas long distances away from diuser operation. Provide adequate warning
for others using a pond with a diused aeration system.
• Always wear a Coast Guard approved life vest when working in or near water and follow all safety guide-
lines.
Note: EasyPro Pond Products is not responsible for losses, injury or death as a result of failure to follow these
safety warnings, misuse or abuse of equipment.
PA6SW • PA8SW
Aeration Kit
Instructions for Operation • Safety • Warranty
PA6SW PA8SW

General Instructions
Compressors have weather resistant housing, but we strongly suggest that you protect them from the ele-
ments in some way. DO NOT place your compressor in low spots or any place water may puddle. Flooded
compressors are not covered under warranty.
1. Place compressor on level surface above the water level.
2. Compressor must be protected and housed from extreme elements. Place compressor in shaded area
that is free from excessive dust or moisture.
3. Assemble the diusers by threading rubber membrane diusers into provided PVC assembly. Use zip
ties to secure diuser/PVC assembly to plastic underlay. Attach a brick (not included) to the diuser
base to sink assembly to the bottom of the pond.
4. Attach Quick Sink tubing to barbed outlet of diuser assembly and secure with hose clamp.
5. Unroll the tubing and install diuser into pond. This will allow you to trim tubing to length at the com-
pressor. Lower diusers in the pond where circulation is maximized.
6. Connect the rubber elbow to the compressor with pinch clamps.
7. Connect the end of airline to outlet of the compressor and secure with provided hose clamp. For PA8SW
with a manifold system, connect the manifold to the compressor, then the ends of airline runs to mani-
fold system and secure with provided hose clamps.
8. Plug compressor into 120v AC GFCI protected outlet.
Shallow Water Pond Aeration Kit Features:
Kit Maximum Compressor Maximum CFM Maximum*
Part # Pond Size Warranty** (cubic feet per minute) Recommended Depth
PA6SW 3/8 Acre 2 Years 2.5 cfm 7 feet
PA8SW 3/4 Acre 2 Years 5.2 cfm 7 feet
Pond shape, depth and condition aect actual maximum pond size.
*Compressors may perform in slightly deeper water, but this is the recommended maximum depth. With deeper water
and longer tubing runs the rubber diaphragms will wear out sooner and require replacement more frequently as a wear
item. For longer tubing runs an increase in the diameter of the tubing may be necessary to be sure the overall maximum
pressure of the compressor is not surpassed.
**See compressor instructions for warranty details
PA6SW
PA8SW
DM4
Diuser Assembly
Use only supplied short section of
tubing to connect compressor to
splitter. Do not use longer tubing.

Operation
• Compressors are designed for continuous operation. It is not uncommon for these compressors to run
24 hours per day for four to ve years. The typical maintenance required is replacement of the dia-
phragms when needed. All compressors have oil-less motors. Never oil or lubricate the motors.
• Because it can take hours for maximum circulation to be achieved it is recommended to run these sys-
tems continuously.
• If you are installing this system at a time when your pond is already stratied (warm on the surface, cold
on bottom) you should be careful when rst starting the aeration system. If stagnant water on the pond
bottom is stirred up too fast, a temporary increase in oxygen demand will occur and, in rare cases, a sh
kill could result. If your pond is severely stratied, you should only run your system one to two hours the
rst day. Each day after that increase then run time by one to two hours during the rst week and run
continuously after that. This will slowly mix the bottom water without a sudden depletion of oxygen.
Winter Operation
If operated in the winter time there are a few considerations to make.
• You must clearly mark with warnings that there is open water or thin ice. Many states will require this by
law.
• Be sure the tubing is buried leading into the pond. If not, ice can form around the tubing, kinking it or
possibly shearing it o. This is rare but has occurred.
• It becomes critical to protect the compressor from excess snow and water entering the compressor
from the bottom due to ooding or melting snow. A cabinet or shelter is recommended. Be sure that
adequate air ventilation is provided or compressor will fail prematurely.
• If lines become frozen, rubbing alcohol can be run down the frozen line to thaw it out.
Maintenance
1. Always unplug unit before service, cleaning or any maintenance.
2. Over time the compressors may need to have the diaphragms replaced. See chart below for compressor
repair kits.
3. If not operated in the winter, disconnect the compressor, cover ends of tubing and store compressor out
of the elements.
4. Diusers may need regular cleaning in certain water conditions. This may be every two to ve years.
Troubleshooting
Loss of air output but unit is running:
• Check to make sure the air lter has not been blocked or clogged by dust.
• Check to make sure lines are not kinked or plugged. If used in winter time, line may have ice in the line.
A small amount of rubbing alcohol can be run down the air line to thaw the ice.
• Inspect the diusers to ensure they are clean. Replace or clean as necessary.
• Inspect compressor diaphragms. Replace as necessary.
Shallow Water Pond Aeration Kit Components:
Kit Compressor
Part # Compressor Tubing -
1
/
2
" ID Diuser(s)* Repair Kits
PA6SW EPW6 50' Quick Sink DM4 EPW6RK
PA8SW EPW10 100' Quick Sink Two DM4 EPW10RK
*Replacement 6" rubber membrane diusers are part number RAD650. A DM4 assembly includes four RAD650 rubber
membrane diusers.

800-448-3873 • Grant, Michigan
www.easypropondproducts.com • [e-mail]
7870 • 6/16
Limited Warranty:
• Compressors in PA-SW series kits have two year limited warranty (see owners manual for complete warranty information)
• Quick sink tubing and diusers have ve year limited warranty
Other items included in this kit that are not listed above are considered wearable items and are not covered under this warranty. Limited warranty only
covers properly installed and maintained units.
The limited warranty does not cover normal wear and tear, nor any deterioration suered through overloading, improper use, negligence or accident.
Similarly, any modication made by the purchaser to the product will cause the warranty to be null and void.
All returned items will be inspected to determine cause of failure before warranty is approved.
Limited warranty does not cover any cost associated with the installation or removal of the product subject to warranty claim.
A Return Authorization (RA) number must be obtained by calling EasyPro Pond Products at 800-448-3873. It is your responsibility to pay the return
shipping charges. Be sure to include the RA number, original receipt (in the form of an invoice or sales receipt), name, return address and phone num-
ber inside of the package. No warranty claims will be honored without the original receipt.
Ensure the product is properly packaged and insured for the replacement value. Damage due to improper packaging is the responsibility of the
sender.
The manufacturer or supplier shall not be held liable for any damages caused by defective components or materials of this product; or for loss in-
curred because of the interruption of service; or any consequential/incidental damages and expenses arising from the production, sale, use or misuse
of this product.
The manufacturer or supplier shall not be held liable for any loss of sh, plants or any other livestock as a result of any failure or defect of this product.
Beautify your pond with these great products from EasyPro!
