EasyPro TB Series Operation and maintenance manual

High Head
TB Series Waterfall Pumps
Instructions for Operation • Safety • Warranty
Designed for use with higher head pressure
TB8000 • TB8002 • TB12000 • TB14500
Thank you for purchasing the TB series waterfall pump.
This instruction manual explains the product operations
and gives important precautions regarding its safe use. In
order to use the product to maximum benet, be sure to
read the instructions thoroughly and follow them carefully.
Specications
• 3" outlets
• Automatic thermal overload protection
• Double silicone carbide mechanical seals with
100,000 hour life expectancy
• TB8000 available as 230v or 115v, TB12000 and TB14500 available
as 230v only
• Two year limited warranty
• A minimum of 20' head pressure required for TB12000 abd TB14500
70'
60'
50'
40'
30'
20'
10'
0'
1000 2000 3000 4000 5000 6000 7000 8000 9000 10000 11000 12000 13000 14000
TB14500
TB12000
TB8000
GPH
GPM
FeetofHead
|
20
|
40
|
60
|
80
|
100
|
120
|
140
|
160
|
180
|
200
|
220
Beyondoperatingcapacity Bestefficiency
Replacement Parts
No. Description Material
1 Cord B Series Pumps
2 Motor Casing Stainless Steel 304
3 Motor Cover Die Casting FC-200
4 Bearing NBR
5 Motor Shaft Stainless Steel 403
6 Mechanical Seal Silicone Carbide & Ceramic
7 Impeller Die Casting FC-200
8 Pump Base Die Casting FC-200
9 Handle Stainless & NBR
10 Discharge PE & Die Casting FC-200
10
9
8
7
6
5
4
3
2
1
800-448-3873 • Grant, Michigan
www.easypropondproducts.com • [e-mail]
5454 • 5/16
Limited Warranty:
• Pump is warranted against any
mechanical or material defects for
a period of two years from date of pur-
chase
• This warranty does not cover acci-
dental damage to the product due to
abuse or negligence by the consumer.
• An RMA number must be obtained by
calling EasyPro Pond Products at 800-
448-3873 and be included on package
before returning for warranty.
Return warranty items to:
EasyPro Pond Products, 4385 East 110th, Grant, MI 49327
Be sure to include RMA number, original receipt, name, return ad-
dress and phone number in package.
• In the event of a warranty claim, please return the pump postage
prepaid with the original receipt for repair or exchange. No warranty
claims will be honored without the original receipt.
• The manufacturer or supplier shall not be held liable for any damag-
es caused by defective components or materials of this pump; or for
loss incurred because of the interruption of service; or any conse-
quential/incidental damages and expenses arising from the produc-
tion, sale, use or misuse of this product.
• The manufacturer or supplier shall not be held liable for any loss of
sh, plants or any other livestock as a result of any failure or defect
of this product.
• This pump must stay submerged entirely when operating. If used
in skimmer, the debris net must be kept clean to ensure adequate
water ow to the pump. Running pump low on water will cause over-
heating and premature failure which is not covered under warranty.
• If you experience a failure of your pump, please check the following
before returning to us:
1. Remove lter housing, clean and inspect impellar and surrounding
chamber, reassemble and test pump;
2. Verify electrical supply.
Return warranty
pumps to:
EasyPro
Pond Products
4385 East 110th
Grant, MI 49327
Be sure to include RMA
number, original receipt,
return address and phone
number in package!

Volts/ Max Max
Model HP Max Amps Weight Head Flow
TB8000 1 115/10.9 43 lbs. 40' 8000 GPH
TB8002 1 230/5.5 43 lbs. 40' 8000 GPH
TB12000 2 230/9.7 64 lbs. 60' 12000 GPH
TB14500 3 230/14.5 72 lbs. 72' 14500 GPH
Units have 30' power cords
Safety & Electrical Connections
WARNING: Verify that the voltage and frequency of the electric
pump shown on nameplate correspond to those available on mains.
• The installer must make sure that the electric system is grounded in
accordance with local ordinances.
• The plug and connections should be protected from water/rain. Be-
fore using the pump, always inspect it visually (especially power cable
and plug).
• Do not use the pump if it is damaged. If the pump is damaged, have it
inspected by a qualied service center only.
• Make sure electric connections are protected from all water and mois-
ture. Protect plug and the power cable from heat, oil or sharp edges.
WARNING: The power cable must be replaced by qualied per-
sonnel only.
Grounding: The plug of the power cable has a double grounding contact,
so that grounding can be performed by simply inserting the plug.
Overload Protection: EasyPro pumps have a built in thermal protection
switch. The pump stops if an overload condition occurs. The motor re-
starts automatically after it has cooled down.
Prior to Operation
Check the following points upon receipt of your pump:
• Is the pump exactly what you ordered? Check nameplate.
• Has any damage occurred during shipment?
• Are any bolts or nuts loose?
• Have all necessary accessories been supplied?
• We recommend that you keep a spare pump on hand in case of emer-
gencies. Keep this instruction manual in a place for future reference.
Installation
Limitations:
This series of pumps are suitable to pump water and also can be used
both for permanent and temporary installation. The pump can be placed in
a sump pit, then can pump dirty water containing suspended solid parti-
cles up to 1/2" diameter.
WARNING: The pump cannot be used for sea water, chlorinated
water and ammable, corrosive, explosive or dangerous liquids.
Installation:
WARNING: Do not work on pump until power is unplugged.
Do not cut o ground pin or use an adapter tting.
Do not use an extension cord
Must be used on a GFCI protected outlet
Do install the strainer prior to using if you want to let the pump run as a
sump pump.
The pump power cord should be connected to a separately fused,
grounded line with a minimum capacity of 15 amps. It can be connected
to non- fuse breaker at the recommended amps. Never touch the pump
when it is plugged in.
1. Before installing or servicing this pump, be certain pump power
source is disconnected. Contact a qualied licensed electrician for
disconnecting electrical service prior to pump removal.
2. Installation and electrical wiring must adhere to state/local codes and
must be completed before priming pump. Check appropriate commu-
nity agencies, or contact local electrical and pump professionals.
3. Call an electrician when in doubt. Pump should be connected to
a separate 15 amp circuit breaker or 15 amp fuse block. Note that,
plugging into existing outlets may cause low voltage at motor, causing
blown fuses, tripping of motor overload or burned out motor.
4. A permanent ground connection from pump to the grounding bar at
the service panel is mandatory. For maximum safety, connect pump
to a circuit equipped with a Ground Fault Circuit Interrupter device
when you position the pump’s grounding wire.
5. Voltage of power supply must match the voltage of the pump.
WARNING: Must be vented in accordance with local plumbing
codes. EasyPro pumps are not designed for and CANNOT be
installed in locations classied as hazardous.
WARNING: The following may cause severe damage to pump and
will void warranty:
• Using an extension cord
• Cutting o the ground pin or using an adapter tting
• Working on pump or switch while plugged in
• Removing motor housing, unscrewing impeller or otherwise removing
impeller seal
• Pumping chemicals or corrosive liquids including chlorinated or salt
water
• Pumping gasoline or other ammable liquids
• Piping: Plastic PVC pipe, drain hose, galvanized steel or copper pipe
may all be used. All piping must be clean and free of all foreign matter
to prevent clogging. Be sure to seal the thread connection with tape
seal when you are using the pipe tting to connect the ange.
TB High Head Pump Trouble Shooting
Humming • Line circuit breaker is o, fuse is burned or loose
• Pump cord is not making contact in receptacle
• Float (optional) is stuck, it should operate freely
• May have air lock
Running, no water • Check valve (optional) is installed backwards
• Discharge shut-o valve closed
• Inlet or impeller clogged
• Pump is air-locked, start and stop several times
by plugging and unplugging cord, check for
clogged vent hole, may need to disconnect and
reinstall pump.
• Inlet holes in pump base are clogged, remove pump
and clean the openings.
• Vertical pumping distance is too high or the pipe
size is too small, reduce vertical distance or
increase the pipe size ttings.
Running, very • Pump is air-locked, start and stop several times by
little water plugging and unplugging cord, check for clogged
vent hole
• Vertical pumping distance is too high or the pipe
size is too small
• Inlet or impeller clogged/damged
• Low water conditions with pump sucking air
GFCI breaker • Fuse size or circuit breaker may be too small.
tripping • Motor stator may be defective
• Pump impeller or inlet is partially clogged with de-
bris
Motor briey • Low water conditions, pump overheating
starts and stops • Inlet or impeller clogged
• Improper power supply
• Motor stator may be defective
