EasyPro EXT Series Manual

Reliability You Can Count On!
EXT Series
© 2019 EasyPro, Inc
Pg. 1
I
N
T
H
E
U
S
A
A
S
S
E
M
B
L
E
D
WARNING: Please read completely before you install or operate your new pump! Do NOT allow this pump to become
submerged! Never run dry - Never reverse rotation. Never exceed an internal case pressure of: 100 PSI.
Please ll in for future reference:
MODEL: ______________________________________
SERIAL NUMBER: _____________________________
DATE PURCHASED: ___________________________
* Please ll out the warranty registration card in this manual
Installation and Service Manual
for EXT75, EXT180, EXT300, EXT1500
EasyPro
XXXXXXXXX
S/N: XXXX-XXXXXX
TYPE: END-SUCTION CENTRIFUGAL
MOTOR: NEMA 143JM-215JM
PORT SIZE: 3" FLANGED INLET, 2" FLANGED DISCHARGE
HORSEPOWER: 3/4 HP THROUGH 15 HP
HARDWARE: STAINLESS STEEL
SEAL OPTIONS: STAINLESS STEEL WITH BUNA AND VITON

EXT Series
Reliability You Can Count On! © 2019 EasyPro, Inc
Pg. 2
I
N
T
H
E
U
S
A
A
S
S
E
M
B
L
E
D
ELECTRICAL HOOK-UP
1. Check that supply voltages match the motor’s requirements.
2. Check motor wiring and connect, according to instructions on motor, to match supply voltage.
3. Verify motor rotation with rotation meter. Incorrect rotation can cause serious damage to pump and/or motor. EasyPro does not
recommend checking rotation by quickly switching power on and o because serious damage can occur.
4. Power cord should be protected by conduit or by cable and be of proper gauge. It should be no longer than necessary.
5. Power should be drawn directly from a box with circuit breaker protection or with a fused disconnect switch.
We congratulate you on your choice of the EXT Series Centrifugal Pump! It has been carefully designed using the advantages of today’s
technology and carefully constructed to give you the dependability of yesterday. To insure proper performance, we urge you to carefully
follow the instructions in this manual. If you have any questions, call your nearest distributor or EasyPro for assistance.
INSTALLATION
Please read carefully! When properly installed the EXT Series Pumps will provide dependable trouble-free service.
1. Locate the pump as near the uid source as possible. A ooded suction situation is preferred.
2. Mount motor base to a secure, immobile foundation.
3. The pipe ttings should be self-supported and in neutral alignment with each port. (i.e. Fittings must not be forced into alignment
which may cause premature line failure or damage to the pump volute.)
4. Never restrict the intake. Keep both input and discharge lines as free of elbows and valves as possible. Always use pipe of adequate
diameter. This will reduce friction losses and maximize output.
5. The EasyPro EXT Series pump is not self-priming! It must not be run dry! We recommend a ooded suction installation. Please read
carefully! When properly installed, the EXT Pump will provide dependable, trouble-free service.
6. For additional plumbing tips, review EasyPro’s website: www.EasyPro.com for pond plumbing and pump installation hints.
PUMP
FOOT VALVE
FLOODED SUCTION
WARNING: DO NOT RUN DRY!
WARNING: ALWAYS SHUT OFF ELECTRICAL POWER BEFORE INSTALLATION AND / OR SERVICING THIS PUMP! ALL ELECTRICAL WIRING SHOULD
MEET STATE AND LOCAL ORDINANCES. IMPROPER WIRING MAY NOT ONLY BE A SAFETY HAZARD BUT MAY PERMANENTLY DAMAGE THE
MOTOR AND/OR PUMP! 50 HZ MOTORS AVAILABLE - CONTACT YOUR SUPPLIER FOR INFORMATION.
BALL
VALVE
SUCTION LIFT

Reliability You Can Count On!
EXT Series
© 2019 EasyPro, Inc
Pg. 3
I
N
T
H
E
U
S
A
A
S
S
E
M
B
L
E
D
PUMP END ASSEMBLY
1. Clean and inspect all pump parts (O-rings, seal heads, seal seats, motor shaft, etc.).
2. Place slinger (rubber washer) over motor shaft. Pump/bracket/impeller assembly can now be pulled back from volute.
3. Where applicable, check motor for rotation prior to assembling pump to motor.
4. For metallic seal head assembly installation: apply sealant to the bracket bore ID wall and around the seal case - follow sealant
mfg instructions. We recommend using Gasgacinch®, Perrmatex®, or 3M™1300L. Silicone sealant can also be used. Press seal
head into bracket using a tool that will apply pressure to the seal case shoulder; do not apply pressure to the carbon or silicon
carbide seal head.
5. For seal seat installation: carefully lubricate the seal seat elastomer OD and impeller hub ID with water. Press the seal seat into the
impeller hub making certain that the ceramic is bottomed and sits evenly - the sealing surface should be parallel with the
impeller hub.
6. Align bracket with holes in motor face and mount bracket to motor with four 3/8" ID x 1" OD washers and four 3/8" - 16 x 1" long
stainless steel hex cap screws using 9/16" wrench. (Use 1/2" - 13 x 1" long stainless steel hex head cap screws and 1/2" washers for
frame sizes 213JM and above, using 3/4" wrench.)
7. Assemble
3/16" square x 11/2" long stainless steel key in groove of motor shaft.
8. Assemble
3/8" - 16 x 13/4" long stainless steel threaded rod with hex recess into end of motor shaft, using 3/16" allen wrench.
Threaded rod should extend from shaft approximately .720 +/- .050" (reference Fig. 1 of insert drawing).
9. Carefully clean carbon-graphite and ceramic sealing surfaces with lint-free tissue and alcohol. Do not use silicone lubricants
or grease!
10. Slide impeller on motor shaft, aligned with key.
11. Assemble special impeller washer over threaded rod. Secure with 3/8" - 16 stainless steel hex jam nut using 9/16" long reach socket;
hold impeller while tightening.
12. Lightly grease cap O-ring with silicone grease, assemble cap with O-ring over threaded rod and tighten with 11/16" socket. Do not
over tighten.
13. Assemble large O-ring in groove in bracket. Use silicone grease only if necessary.
14. Assemble volute to bracket using ve 5/16" - 18 x 4" long stainless steel hex head cap screws, ten 5/16" atwashers, ve 5/16"
lockwashers and ve 5/16" - 18 hex nuts. Use three 5/16" - 18 x 11/4" long stainless steel hex head cap screws with at washers,
lockwashers and nuts in the threaded inserts in the volute), using 1/2" wrench.
15. Assemble drain plug in volute drain hole and tighten. Use teon tape or equivalent.
16. Before operating pump, allow a proper cure time for the sealant used in step 4.
17. Note: For assembling a discharge ange, use 5/8" x 21/4" long bolts, narrow washers, and hex jam nuts (provided in the discharge
piping hardware kit).
DISASSEMBLY
1. Shut o power to motor before disconnecting any electrical wiring from the motor.
2. Disassemble volute from bracket by removing the ve 5/16" - 18 x 4" long hex cap screws, and the three 5/16" - 18 x 11/4" hex cap
screws. Pump/bracket/impeller assembly may now be pulled back from the volute.
3. Remove impeller eye ‘cap’ by unscrewing counterclockwise. Remove 3/8" nut using 9/16" socket wrench, unscrew
counterclockwise. Slide impeller o of motor shaft.
4. Remove ceramic piece from impeller. Eye protection is strongly recommended. (If you are replacing the seal)
5. Detach bracket from motor.
6. Remove mechanical seal from bracket by pressing out from the back. Do not dig out from the front! (If you are replacing the seal).

EXT Series
Reliability You Can Count On! © 2019 EasyPro, Inc
Pg. 4
I
N
T
H
E
U
S
A
A
S
S
E
M
B
L
E
D
EasyPro Pond Products
4385 East 110th, Grant, MI 49327
800-448-3873 • 231-834-5537 fax
www.EasyPro.com
Name:________________________________________
Address:______________________________________
City: _______________ State: _____ Zip: __________
Model: _______ Serial Number:__________________
Date purchased: ______Where purchased: ________
Gasgacinch®is a registered trademark of Porter Manufacturing. Noryl®is a registered trademark of the
General Electric Company. Teon®is a registered trademark of DuPont Company.
Activate your warranty by lling out this form and mailing to EasyPro Pond Products
MAINTENANCE
Lubrication
Rotary Seal - requires no lubrication after assembly.
*The pump must be drained before servicing or if stored
below freezing temperatures. Periodic replacement of
seals may be required due to normal carbon wear.
TROUBLE SHOOTING AID
Motor will not rotate
1. Check for proper electrical connections to motor.
2. Check main power box for tripped circuit breaker.
Motor hums or will not rotate
1. Check for proper electrical connections to motor and proper wire size according to local electrical codes.
2. Check for foreign material inside pump.
3. Remove volute and check for impeller rotation without excessive resistance and/or noise.
4. Remove pump and check shaft rotation for excessive bearing noise.
5. Check start switch and/or capacitor.
Pump operates with little or no ow
1. Check to insure that pump is primed.
2. Check for leaking seal.
3. Improper line voltage to motor or incorrect rotation.
4. Check for clogged inlet port and/or impeller.
5. Defective check or foot valve.
6. Check inlet lines for leakage, either uid or air.
7. Verify rotation direction of impeller (see page 2).
Pump loses prime
1. Defective check or foot valve.
2. Inlet line air leakage.
3. Seal leaking.
4. Fluid supply low.
Motor or pump overheats
1. Check for proper line voltage and phase, also proper motor wiring.
2. Binding motor shaft or pump parts.
3. Inadequate ventilation.
4. Fluid being pumped should not exceed 194°F (90°C) for extended periods of time.
