Eaton TRIPP LITE U209-005-DB25 User manual

1
Owner’s Manual
Purchased product
may differ from image.
Model:
U209-005-DB25
USB to Serial Adapter
Español 13
Français 25
Deutsch 37
Italiano 49

2
Package Contents
Features
• U209-005-DB25 to Serial Adapter
• DB9 to DB25 Adapter
• Owner’s Manual
• Supports data transfer rates up to
250 Kbps
• External power not required
• Supports remote wake up and power
management
• Premium double-shielded cable
eliminates cross-talk and reduces EMI/RFI
interference

3
System Requirements
• Computer with an available USB port
• Compatible with Windows®, Mac®and
Linux operating systems
• Compatible with Android™ devices
(tablets/phones) with USB Host Mode
(OTG) support and Android OS version 3.2
and above (see the Android compatibility
list le at Tripplite.Eaton.com)
• Android-powered devices will require a
USB Host Mode (OTG) cable such as
Tripp Lite’s U052-06N to connect to the
U209-005-DB25

4
Installation
Note: The following instructions show how to install
the driver on a Windows 7 computer. The installation
steps will be similar for other Windows operating
systems. For non-Windows operating systems,
reference the installation les at Tripplite.Eaton.com.
Compatible Android devices do not require a driver
for use with the U209-005-DB25, but do require that
a terminal server application be downloaded. The
Prolic PL2303GS USB-UART app is recommended
and can be found in the Google Play Store.
1. Without connecting the U209-005-DB25,
power on your computer. Drivers for the
cable can be downloaded from
Tripplite.Eaton.com/support.

5
Installation
2. When the driver installer program
launches, click the Next button to start
installation.

6
Installation
3. The driver installation begins. A
progress bar tracks where you are in the
installation process.

7
Installation
4. Once the installation process is complete,
click the Finish button to close out of the
program.
5. (Optional) Connect the DB9 to DB25
adapter to the U209-005-DB25’s DB9 port.
6. Connect the U209-005-DB25 to an
available USB port on your computer.
Windows will detect the adapter and
assign it a COM port upon completing the
installation.

8
Installation
7. To verify that your adapter has been
successfully installed, navigate to your
computer’s Control Panel and open the
Device Manager screen. The adapter will
appear in the Ports section, with its
assigned COM port next to it.

9
Pinout
1
5
6
9
CONN.2
DB9 FEMALE
DB9/DB25 Adapter Pinout
RS-232 DB9 Pinout
14
13
25
1
CONN.1
DB25 MALE
8
20
2
3
6
4
5
7
22 9
5
8
7
6
2
3
4
1
Conn.1
Pin Assignment
Conn.2

10
3-Year Limited Warranty
We warrant our products to be free from defects in
materials and workmanship for a period of three (3) years
from the date of initial purchase. Our obligation under
this warranty is limited to repairing or replacing (at its
sole option) any such defective products. Visit Tripplite.
Eaton.com/support/product-returns before sending
any equipment back for repair. This warranty does not
apply to equipment which has been damaged by accident,
negligence or misapplication or has been altered or
modied in any way.
EXCEPT AS PROVIDED HEREIN, WE MAKE NO WARRANTIES,
EXPRESS OR IMPLIED, INCLUDING WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE. Some states do not permit limitation or exclusion
of implied warranties; therefore, the aforesaid limitation(s)
or exclusion(s) may not apply to the purchaser.
EXCEPT AS PROVIDED ABOVE, IN NO EVENT WILL WE BE
LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL OR
CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE OF
THIS PRODUCT, EVEN IF ADVISED OF THE POSSIBILITY OF
SUCH DAMAGE. Specically, we are not liable for any costs,
such as lost prots or revenue, loss of equipment, loss of
use of equipment, loss of software, loss of data, costs of
substitutes, claims by third parties, or otherwise.
Use of this equipment in life support applications where
failure of this equipment can reasonably be expected
to cause the failure of the life support equipment or
to signicantly aect its safety or eectiveness is not
recommended.
Warranty

11
FCC Notice, Class B
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1)
This device may not cause harmful interference, and (2)
this device must accept any interference received, including
interference that may cause undesired operation.
Note: This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to part
15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause
harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment o and on, the user
is encouraged to try to correct the interference by one or
more of the following measures:
· Reorient or relocate the receiving antenna.
· Increase the separation between the equipment and
receiver.
· Connect the equipment into an outlet on a circuit dierent
from that to which the receiver is connected.
· Consult the dealer or an experienced radio/TV technician
for help.
Any changes or modications to this equipment not
expressly approved by Eaton could void the user’s authority
to operate this equipment.
Regulatory Compliance

12
Regulatory Compliance
WEEE Compliance Information for Customers and
Recyclers (European Union)
Under the Waste Electrical and Electronic
Equipment (WEEE) Directive and implementing
regulations, when customers buy new electrical
and electronic equipment from Eaton, they are
entitled to:
• Send old equipment for recycling on a one-for-
one, like-for-like basis (this varies depending on
the country)
• Send the new equipment back for recycling when
this ultimately becomes waste
Eaton has a policy of continuous improvement.
Specications are subject to change without notice. Photos
and illustrations may dier slightly from actual products.
Eaton
1000 Eaton Boulevard
Cleveland, OH 44122
United States
Eaton.com
© 2023 Eaton
All Rights Reserved
Publication No.
23-07-723 /
9340E0_RevB
October 2023
Eaton is a registered
trademark.
All trademarks are
property of their
respective owners.
9340E0

13
Manual del Propietario
El producto comprado puede
ser diferente al de la imagen.
Modelo:
U209-005-DB25
Adaptador de USB a Serial
English 1
Français 25
Deutsch 37
Italiano 49

14
Contenido del Empaque
Características
• U209-005-DB25 - Adaptador USB a Serial
• Adaptador DB9 a DB25
• Manual del Propietario
• Admite velocidades de transferencia de
datos de hasta 250 Kbps
• No necesita alimentación externa.
• Admite activación remota y administración
de energía
• Cable premium de doble blindaje que
elimina la diafonía e interferencia por
EMI / RFI

15
Requisitos del Sistema
• Computadora con un puerto USB
disponible
• Compatible con los sistemas operativos
Windows®, Mac®y Linux
• Compatible con dispositivos Android™
(tabletas/teléfonos) con soporte para USB
Host Mode (OTG) y Android OS versión
3.2 y posteriores (consulte el archivo de
la lista de compatibilidad de Android en
Tripplite.Eaton.com)
• Los dispositivos con Android necesitarán
un cable USB Host Mode (OTG) como el
U052-06N para conectarse al
U209-005-DB25

16
Instalación
Nota: Las siguientes instrucciones muestran cómo
instalar el controlador en una computadora con
Windows 7. Los pasos de instalación serán similares
para otros sistemas operativos Windows. Para
sistemas operativos diferentes a Windows, consulte
los archivos de instalación en Tripplite.Eaton.com.
Los dispositivos Android compatibles no requieren
un controlador para su uso con el U209-005-DB25,
pero sí requieren que se descargue una aplicación
de servidor de terminal. Se recomienda la aplicación
Prolic PL2303GS USB-UART, que puede encontrar
en Google Play Store.
1. Sin conectar el U209-005-DB25, encienda
su computadora. Los controladores para
el cable pueden descargarse de
Tripplite.Eaton.com/support.

17
Instalación
2. Cuando se inicie el programa de
instalación del controlador, haga click en
el botón “Siguiente” para comenzar la
instalación.

18
Instalación
3. Comienza la instalación del controlador.
Una barra de avance le indica dónde está
en el proceso de instalación.

19
Instalación
4. Una vez completado el proceso de
instalación, haga click en el botón
“Terminar” para cerrar el programa.
5. (Opcional) Conecte el adaptador DB9 a
DB25 al puerto DB9 de U209-005-DB25.
6. Conecte el U209-005-DB25 a un puerto
USB disponible en su computadora.
Windows detectará el adaptador y
asignará un puerto COM al completar la
instalación.

20
Instalación
7. Para comprobar que el adaptador se ha
instalado correctamente, vaya al Panel
de Control de su computadora y abra la
pantalla del Administrador de Dispositivos.
El adaptador aparecerá en la sección
Puertos, con su puerto COM asignado
junto con él.
