Eaton Quickmov SPDQM1 User manual

Specification are subject to change without notice. Copyright 2006 Eaton Power Quality Pty Ltd
Installation Specification – Quickmov Tvss Doc# 510080
Page 1 of 2
Web: http://www.powerware.com.au Phone: 1300 UPS UPS
INSTALLATION SPECIFICATION
Quickmov Surge Diverter SPDQM1
(Point-of-entry, Single-mode, 30kA)
APPLICATIONS
• Multi-storey buildings
• Commercial and Industrial sites
• UPS and Computer systems
• Telecommunication Systems
• Process Control System
FEATURES
• Surge suppression rating of 30kA, 20 times • Protection fail indicator
• Fits any Cutler-Hammer Quicklag™ SWB. • Includes built-in HRC fuse
FUNCTIONAL DESCRIPTION
The QUICKMOV surge diverter is designed to provide point-of-entry protection against surge transients for services
rated at 100A or greater. The unit is intended for installation at the M.E.N. point, or to be used in conjunction with
an SPD50NGi Neutral-Earth protector in non-M.E.N. locations (contact Eaton Powerware for details). One
QUICKMOV per phase is required for multi-phase installations.
Due to inbuilt protection mechanisms, no external fuse or circuit breaker is required. In fact, no other parts, apart
from the Quickmov itself are required for installation - the unit simply installs like a standard QUICKLAG™ device,
except with the free terminal being replaced with a short length of cable. This cable is connected to the Neutral bar
of the switchboard.
The QUICKMOV has been designed in accordance with AS3100, ANSI-IEEE C62.41, IEC61643-1, IEC61000-6-1, 2,
3, 4 and other standards and codes as applicable.
INSTALLATION
• Isolate the incoming power circuit before installation.
• All wiring must be carried out by suitably qualified personnel according to the applicable standards.
1. Remove SWB panel and determine where the unit(s) shall be mounted. Units should be installed so that the
cable length from the Quickmov to the Neutral bar is minimised.
2. Install unit(s) to SWB pan and tighten the busbar terminal screw. Trim the black wire(s) to the minimum length
required to terminate to the neutral bar, leaving no more than 50-60mm slack in the cable.
Always use as short a length of cable as necessary. DO NOT EXTEND CABLE. If cable is too short, move other
devices away to create a space for the Quickmov unit(s). Avoid sharp bends in cables.
3. Connect trimmed cable(s) to neutral bar.
4. Replace SWB panel and restore power.
EARTHING
For proper operation, all surge diverters rely upon a good earth connection. In some installations the existing earth
system may require upgrading. Important things to look for are that the main earth wire (from earth link on
switchboard to ground rod or system) should preferably be 10mm2or greater and must be as short as possible.
Failure to consider the above points can result in improper operation of the unit and possible damage to
the installation.
OPERATION
The status of the QUICKMOV is indicated by a flag visible through the window on the front face of the unit. The flag
changes colour from green to red if the unit is damaged and requires replacement.

Specification are subject to change without notice. Copyright 2006 Eaton Power Quality Pty Ltd
Installation Specification – Quickmov Tvss Doc# 510080
Page 2 of 2
Web: http://www.powerware.com.au Phone: 1300 UPS UPS
INSTALLATION SPECIFICATION
WARRANTY
Eaton Power Quality warrants the Quickmov against faulty parts and workmanship for a period of 12 months from
the date of purchase. If this product fails to operate correctly, please contact your Eaton representative. This
warranty doesn’t cover neglect or intentional misuse. As this product is intended for use in electrically harsh
environments no claim is made of suitability for purpose. This unit is designed to reduce the likelihood of damage,
not prevent it. Please also note that an excessive surge, such as from a direct lightning strike to the site or a power
system fault, may cause damage to the unit and render it inoperable. A unit that has been damaged in this way is
not warrantable.
PHYSICAL AND ELECTRICAL SPECIFICATIONS - QUICKMOV SPDQM1
Operation
Protection mode Single-mode, connected Line-Neutral.
Service type TN-C, TN-CS (for TNS add 1x SPD50NGi protector).
System voltage – Un 220 – 250VAC (380 – 440VAC 3∅) 50/60Hz
Service current 100A or greater. May also be used on smaller systems
– contact Eaton for information.
Test classification Class II (IEC61643-1), Category C3 (ANSI C62.41)
MCOV - Uc 300VAC
TOV (5s) 330VAC
External disconnector requirements None. In-built 100Agl/50kA HRC fuse. Consult Eaton
Powerware for service fault ratings in excess of 50kA.
Operating current <2mA
Power consumption <1W
Surge ratings
Surge current rating In (20 times) 30kA (IEC61643-1, 8/20us)
Surge current MOV rating Ismax (2 times) 60kA (IEC61643-1, 8/20us)
Clamping voltage (DC, 1mA) 470V +/-10%
Residual voltage* @ 3kA (ANSI-IEEE CAT B3) 1.1kV
Residual voltage* @ In (Up) 2.9kV
Energy absorbtion 800J (10/1000us)
* Residual voltage given with neutral cable trimmed to 250mm.
Alarms/indicators
Indicators Flag with window, green indicates normal operation/red
indicates replacement necessary.
Physical
Connections Standard QUICKLAG™terminal for phase connection.
6mm2cable (black) for connection to Neutral bar
(500mm length).
Mounting Standard QUICKLAG™installation. Compatible with all
Cutler-Hammer Quicklag-style switchboards.
Dimensions 25x71x93 mm (W x D x H) Similar dimensions to
standard Quicklag™MCB.
Weight 310g
Operating temperature -10 to 65°C
Humidity 10-90% non-condensing
Standards
Designed in accordance with: IEC61643-1, IEC610006-1,2,3,4 ANSI/IEEE C62.41 AS1768-2003, AS3000,
and AS3100.
Warranty 12 months, manufacturing and materials
NOTES: - Installation must be carried out by suitably qualified personnel.
