Eaton TRIPP LITE U360-004-IND User manual

1
Important Safety Instructions 2
Features 3
System Requirements 4
Package Contents 4
Powering the Hub 4
Mounting Kit Installation 5
Specifications 9
Warranty 10
Owner’s Manual
Español 12
Français 23
Deutsch 34
Italiano 45
Models:
U360-004-IND
U360-007-IND
U360-010-IND
Industrial-Grade
USB 3.2 Hub

2
Before attempting to connect, operate or adjust this product,
please read the entire Owner’s Manual rst.
Important Safety Instructions
• Always read the safety instructions carefully
• Keep this Owner’s Manual for future reference
• If any of the following situations arise, schedule an appointment
to have your equipment inspected by a service technician:
º The equipment has been exposed to moisture
º The equipment has been dropped and damaged
º The equipment shows obvious signs of breakage
º The equipment is not functioning properly or is not functioning
according to the Owner’s Manual instructions

3
Features
• Increases the number of SuperSpeed USB ports from a single
computer port (4 ports for U360-004-IND model / 7 ports for
U360-007-IND model / 10 ports for U360-010-IND model)
• USB 3.2 compliant with data transfer rates up to 5 Gbps
• Backward compatible with USB 2.0 and 1.x
• Rugged all-metal enclosure designed for use in industrial
applications
• Wall-mount and DIN rail hardware included for secure installation
• USB ports support USB cables with locking connectors
• Three power connection options (source USB port, external
power supply (not included) or 3-wire terminal block)
• Each USB 3.2 port provides up to 900 mA of power
• Overcurrent detection and protection
• ESD protection to +/- 20 kV
• EFT protection to +/- 2.5 kV
• Automatic link and speed detection
• Plug-and-play; no software or drivers required

4
System Requirements
Package Contents
Powering the Hub
DC-In
To power the hub, plug the user-supplied power adapter into the
wall outlet.
Note: The U360-004-IND, U360-007-IND and U360-010-IND are compatible
with listed LPS power supplies from 9V DC to 40V DC. These power supplies use
a 5.5 x 2.1 x 9.5 mm output plug with either a positive tip and a negative sleeve,
or a negative tip and positive sleeve.
• Compatible with all USB-enabled operating systems
• U360-004-IND, U360-007-IND or U360-010-IND Industrial-Grade
USB 3.2 Hub
• USB 3.2 cable
• 3-pin power terminal block
• DIN mounting hardware
• Wall-mount hardware
• Owner’s Manual
Power Terminal
To power the hub using a power
terminal, plug the supplied power
terminal block into the hub according to
the connector’s orientation.

5
Mounting Hardware Installation
The U360-004-IND, U360-007-IND and U360-010-IND hubs can be
placed on a at surface, or mounted using the included wall-mount
brackets or DIN rail hardware. Reference the diagram below when
installing the mounting hardware.
Wall-Mount Hardware Installation
To install the wall-mount brackets, insert the bracket tabs into the
slots on the bottom of the unit aand then pull outward to lock into
place b.
Mounting Kit Installation
a
a
a
a
b
b
b
b

6
DIN rail
Screw (x2)
Mounting Kit Installation
DIN Rail Hardware Installation
Using the included hardware, mount the DIN rail to the side of the
unit.

7
Mounting Kit Installation
Note: The U360-007-IND and U360-004-IND’s dimensions are the same; the
only dierence between the two models is the number of USB ports.
16.00
16.2423.88
15.00
7.50
23.00 23.00
8.00 9.00
32.00
17.50
20.00
69.00 69.00
193.00 176.00 158.00 206.00
17.00
19.00
16.50
19.00
25.00
17.00
14.20
14.20
14.20
14.20
14.20
14.20
34.00
50.00
15.00
9.00
24.00
15.00
80.00
O5.80
Model shown:
U360-007-IND
Dimensions in mm

8
Mounting Kit Installation
16.00
16.2423.88
8.00
7.90
23.00 23.00
8.00 9.00
32.00
17.50
20.00
90.50 90.50
236.00 219.00 201.00 249.00
17.00
19.00
16.50
19.00
25.00
17.40
14.20
14.20
14.20
14.20
14.20
14.20
34.00
50.00
15.00
9.00
24.00
15.00
80.00
14.20
14.20
14.20
O5.80
Model shown:
U360-010-IND
Dimensions in mm

9
Item Description
Ports 4 x USB 3.2 (U360-004-IND model)
7 x USB 3.2 (U360-007-IND model)
10 x USB 3.2 (U360-010-IND model)
ESD Protection +/- 20 kV
EFT Protection +/- 2.5 kV
Transmission Speed Up to 5 Gbps
Power Requirement Bus-power
9-40V DC power supply
3-pin terminal (9-40V DC)
Storage Temperature 14° to 131°F / -10° to 55°C
Operating
Temperature
32° to 104°F / 0° to 40°C
Relative Humidity 5 to 90%
Dimensions, L x W x H 6.2 x 3.1 x 1.3 in. / 158 x 80 x 32 mm
(U360-004-IND and U360-007-IND
models)
7.9 x 3.1 x 1.3 in. / 201 x 80 x 32 mm
(U360-010-IND model)
Enclosure Material Metal
Regulatory Approvals FCC/CE
Specication is subject to change without further notice.
Specications

10
3-Year Limited Warranty
We warrant our products to be free from defects in materials and workmanship for a period of
three (3) years from the date of initial purchase. Our obligation under this warranty is limited to
repairing or replacing (at its sole option) any such defective products. Visit Tripplite.Eaton.com/
support/product-returns before sending any equipment back for repair. This warranty does not
apply to equipment which has been damaged by accident, negligence or misapplication or has
been altered or modied in any way.
EXCEPT AS PROVIDED HEREIN, WE MAKE NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. Some states do
not permit limitation or exclusion of implied warranties; therefore, the aforesaid limitation(s) or
exclusion(s) may not apply to the purchaser.
EXCEPT AS PROVIDED ABOVE, IN NO EVENT WILL WE BE LIABLE FOR DIRECT, INDIRECT, SPECIAL,
INCIDENTAL OR CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE OF THIS PRODUCT, EVEN
IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE. Specically, we are not liable for any costs,
such as lost prots or revenue, loss of equipment, loss of use of equipment, loss of software, loss
of data, costs of substitutes, claims by third parties, or otherwise.
FCC Notice, Class B
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction manual, may cause harmful interference
to radio communications. Operation of this equipment in a residential area is likely to cause
harmful interference in which case the user will be required to correct the interference at his
own expense. The user must use shielded cables and connectors with this equipment. Any
changes or modications to this equipment not expressly approved by Eaton could void the
user’s authority to operate this equipment.
Warranty

11
WEEE Compliance Information for Customers and Recyclers (European Union)
Under the Waste Electrical and Electronic Equipment (WEEE) Directive and
implementing regulations, when customers buy new electrical and electronic
equipment from Eaton, they are entitled to:
• Send old equipment for recycling on a one-for-one, like-for-like basis (this varies
depending on the country)
• Send the new equipment back for recycling when this ultimately becomes waste
Use of this equipment in life support applications where failure of this equipment can reasonably
be expected to cause the failure of the life support equipment or to signicantly aect its safety
or eectiveness is not recommended.
Eaton has a policy of continuous improvement. Specications are subject to change without
notice.
Warranty
Eaton
1000 Eaton Boulevard
Cleveland, OH 44122
United States
Eaton.com
© 2023 Eaton
All Rights Reserved
Publication No. 23-08-069 /
93-3884_RevC
August 2023
Eaton is a registered
trademark.
All trademarks are property
of their respective owners.

12
Instrucciones de Seguridad Importantes 13
Características 14
Requisitos del Sistema 15
Contenido del Empaque 15
Alimentación del Hub 15
Instalación del Juego para Montaje 16
Especificaciones 20
Garantía 21
Manual del Propietario
English 1
Français 23
Deutsch 34
Italiano 45
Modelos:
U360-004-IND
U360-007-IND
U360-010-IND
Hub USB 3.2 de Grado
Industrial

13
Antes de intentar conectar, operar o ajustar este producto,
por favor primero lea el Manual del Propietario completo.
Instrucciones de Seguridad Importantes
• Lea siempre con cuidado las instrucciones de seguridad
• Conserve este Manual del Propietario para consulta futura
• En caso de ocurrir cualquiera de las siguientes situaciones,
comuníquese con un técnico de servicio para que inspeccione el
equipo:
º El equipo ha estado expuesto a humedad
º El equipo se ha caído y dañado
º El equipo muestra obvios signos de fractura
º El equipo no funciona correctamente o no funciona de acuerdo
a las instrucciones descritas en el presente Manual del
Propietario

14
Características
• Aumenta el número de puertos USB SuperSpeed desde un solo
puerto de computadora (4 puertos para modelo U360-004-IND /
7 puertos para modelo U360-007-IND / 10 puertos para modelo
U360-010-IND)
• El USB 3.2 cumple con tasas de transferencia de datos hasta
5 Gbps
• Es compatible con versiones anteriores, como el USB 2.0 y 1.x
• Robusto gabinete totalmente metálico diseñado para uso en
aplicaciones industriales
• Accesorios para instalación en pared y riel DIN para una
instalación segura
• Los puertos USB soportan cables USB con conectores de
seguridad
• Tres opciones de conexión de energía (Puerto USB fuente,
alimentación externa de energía (no incluida) o bloque de
terminales de 3 hilos)
• Cada puerto USB 3.2 proporciona hasta 900 mA de energía
• Detección y protección contra sobrecorriente
• Protección ESD a +/- 20 kV
• Protección EFT a +/- 2.5 kV
• Detección automática de enlace y velocidad
• Conectar y usar; no requiere software ni controladores

15
Requisitos del Sistema
Contenido del Empaque
Alimentación del Hub
Entrada de CD
Para alimentar el hub, enchufe el adaptador de corriente
suministrado por el usuario en la toma en la pared.
Nota: El U360-004-IND, U360-007-IND y U360-010-IND son compatibles con
las fuentes de alimentación LPS listadas de 9V CD a 40V CD. Estas fuentes de
alimentación utilizan una clavija de salida de 5.5 x 2.1 x 9.5 mm ya sea con una
punta positiva y una funda negativa o una punta negativa y una funda positiva.
• Compatible con todos los sistemas operativos habilitados para
USB
• Hub USB 3.2 de Grado Industrial U360-004-IND, U360-007-IND o
U360-010-IND
• Cable USB 3.2
• Bloque de terminales de alimentación de 3 pines
• Accesorios de instalación DIN
• Accesorios para instalación en la pared
• Manual del Propietario
Terminal de Alimentación
Para alimentar el hub usando una
terminal de alimentación, enchufe el
bloque de terminales de alimentación
suministrado en el hub, de acuerdo con
la orientación del conector.

16
Instalación de los Soportes de Montaje
Los hubs U360-004-IND, U360-007-IND y U360-010-IND pueden
colocarse sobre una supercie plana o instalarse usando los
soportes para instalación en pared o los accesorios para riel DIN.
Consulte el diagrama siguiente al instalar los accesorios de montaje.
Instalación de los Soportes para Instalación en Pared
Para instalar los soportes para instalación en pared, inserte las
pestañas del soporte en las ranuras en la parte inferior de la unidad
ay entonces jale hacia afuera para asegurarlos en su sitio b.
Instalación del Juego de Montaje
a
a
a
a
b
b
b
b

17
DIN rail
Screw (x2)
Instalación del Juego de Montaje
Instalación con los Accesorios para Riel DIN
Usando los accesorios incluidos, instale el riel DIN en el costado de
la unidad.

18
Instalación del Juego de Montaje
Nota: Las dimensiones del U360-007-IND y el U360-004-IND son las mismas; la
única diferencia entre ambos es el número de puertos USB.
16.00
16.2423.88
15.00
7.50
23.00 23.00
8.00 9.00
32.00
17.50
20.00
69.00 69.00
193.00 176.00 158.00 206.00
17.00
19.00
16.50
19.00
25.00
17.00
14.20
14.20
14.20
14.20
14.20
14.20
34.00
50.00
15.00
9.00
24.00
15.00
80.00
O5.80
Modelo mostrado:
U360-007-IND
Dimensiones en mm

19
Instalación del Juego de Montaje
16.00
16.2423.88
8.00
7.90
23.00 23.00
8.00 9.00
32.00
17.50
20.00
90.50 90.50
236.00 219.00 201.00 249.00
17.00
19.00
16.50
19.00
25.00
17.40
14.20
14.20
14.20
14.20
14.20
14.20
34.00
50.00
15.00
9.00
24.00
15.00
80.00
14.20
14.20
14.20
O5.80
Modelo mostrado:
U360-010-IND
Dimensiones en mm

20
Especicaciones
Rubro Descripción
Puertos 4 USB 3.2 (modelo U360-004-IND)
7 USB 3.2 (modelo U360-007-IND)
10 x USB 3.2 (modelo U360-010-IND)
Protección ESD +/- 20 kV
Protección EFT +/- 2.5 kV
Velocidad de
Transmisión
Hasta 5 Gbps
Requerimiento de
Energía
Alimentado por Bus
Alimentación de 9-40V CD
Terminal de 3 pines (9-40V CD)
Temperatura de
Almacenamiento
-10° a 55°C [14° a 131°F]
Temperatura de
Operación
0° a 40°C [32° a 104°F]
Humedad Relativa 5 a 90%
Dimensión
(Largo x Ancho x
Alto)
158 x 80 x 32 mm [6.2 x 3.1 x 1.3 pulg.]
(modelos U360-004-IND y U360-007-IND)
201 x 80 x 32 mm [7.9 x 3.1 x 1.3 pulg.]
(modelo U360-010-IND)
Material del
Gabinete
Metal
Aprobaciones
Regulatorias FCC / CE
Especicaciones sujetas a cambio sin previo aviso.
