Eaton Ellipse PRO 650 User manual

Installation and
user manual
English - Français
Deutsch - Italiano
Español - Nederlands
Português - Eλληνiκά
Polski - Česky
Slovensky - Slovenija
Magyar - Türkçe
РУCCКИЙ
Svenska - Suomi
Ellipse PRO
650/850/1200/1600
Скачано ссайта интернет магазина https://axiomplus.com.ua/

2
4
2
5
3
1
IEC modelsFR / DIN models
Packaging
Caution!
EN • Before installing the Ellipse, read the booklet 3containing the safety instructions that must be followed.Then
follow the instructions given in this manual 2.
FR • Avant l'installation de Ellipse, lire le livret 3qui présente les consignes de sécurité à respecter. Suivre ensuite
les instructions du présent manuel 2.
DE • Vor Installation des Ellipse die im Heft 3genannten Sicherheitsvorschriften lesen. Anschließend die
Anweisungen im vorliegenden Handbuch 2befolgen.
IT • Prima dell’installazione del Ellipse, leggere attentamente le istruzioni di sicurezza riportate sul libretto 3.
In seguito, attenersi alle istruzioni riportate sul presente manuale 2.
ES • Antes de la instalación del Ellipse, leer el manual 3que presenta las instrucciones de seguridad a cumplir. A
continuación, seguir las instrucciones del presente manual 2.
NL • Lees voordat u het Ellipse gaat installeren eerst de veiligheidsinstructies in boekje 3.
Volg daarna de instructies van deze handleiding 2.
PT • Antes da instalação do Ellipse, ler o caderno 3onde constam as instruções de segurança a respeitar. Depois,
seguir as instruções do presente manual 2.
EL •ΠριντηνεγικατάστασητουEllipse,διαβάστετοφυλλάδιο 3μετιςσυβουλέςασφαλείαςπουπρέπεινατηρείτε.Στη
συνέχεια,ακολουθήστετιςοδηγίεςχρήσηςαυτούτουφυλλαδίου 2.
PL • PrzedzainstalowaniemEllipse,należyprzeczytaćinstrukcję 3,którazawieraniezbędnezalecenia
bezpieczeństwa.Następnienależyzapoznaćsięzzaleceniamizawartymiwniniejszejinstrukcji 2.
CS • PředinstatacízdrojeEllipsesiprostudujtepříručku 3kdenajdetebezpečnostnípředpisy,kteréjetřeba
dodržovat.Dálepostupujtepodlepokynůuvedenýchvpříručce 2.
SL • Predinštaláciouvýpustkysiprečítajteknižku 3,vktorejsúuvedenébezpečnostnépríkazy,ktoréjepotrebné
dodržať.Potompostupujtepodľapokynovtejtopríručky 2.
SK • PredeninstalirateEllipse,preberiteknjižico 3,vkaterisovarnostnanavodila,kijihjetrebaupoštevati.Nato
sleditenavodilomtegapriročnika 2.
HU • AzEllipsetelepítéseelőttolvassaela 3-eskönyvet,melyabetartandóbiztonságielőirásokattartalmazza.
Ezutánkövesseajelen, 2-öskezikönyvutasításait.
TR • Ellipse'in tesisatini yapmadan önce, uyulacakgüvenliktalimatlarini gösteren 3sayilikitapçiğiokuyunuz.Dana
sonra isbu 2sayili ei kitabindaki talimatlara uyunuz.
RU • ПередустановкойИсточникаБесперебойногоПитания(ASI)прочитайтеинструкцию 3справиламипoтехнике
безопасности,которыенеобходимособлюдать.Затемследуйтеуказаниямнастоящегоруководства 2.
AR 3
2
SV • Innan installation av Ellipse, läs instruktionsmanualen 3innehållande säkerhetsinstruktionerna och följ sedan
dem. Följ sedan instruktionerna som ges i denna manua 2.
FI • Lue nämä ohjeet ennen Ellipse asennusta turvallisuusohjeet 3ja käyttöohjeet 2.
Скачано ссайта интернет магазина https://axiomplus.com.ua/

3
Quick start
5
In Out
Internet Modem / Network
Master EcoControl
B
C
A
1200 / 1600
650 / 850
FR / DIN IEC
D
Register warranty at: powerquality.eaton.com
Скачано ссайта интернет магазина https://axiomplus.com.ua/

4
Battery change
• Warning: take care not to inverse the polarity + (red) and - (black) when connecting the battery as this will destroy
the device.
a
b
cd
e
c
be
f
a
d
650 / 850
1200 / 1600
Battery disposal and safety
• Caution. Battery service life is reduced by 50 % for every ten degrees above 25 °C.
• The battery must be replaced exclusively by qualied personnel (risk of shock), with new battery approved by
Eaton to ensure correct operation of the UPS.
• The battery must be disposed of in accordance with applicable regulations.To remove the battery, shut down the
UPS (button 6OFF), remove the power cord and proceed as indicated below "Battery change".
Скачано ссайта интернет магазина https://axiomplus.com.ua/

5
Technical characteristics
Performances tested according to IEC 61643-1 (class 3) standard for 8/20 µs surge wave
(*) Warning: Output cables should not exceed 10 m length.
Ellipse PRO 650 850 1200 1600
• UPS power 650 VA /
400 W 850 VA / 510 W 1200 VA / 750 W 1600 VA / 1000 W
• Nominalinputvoltage 165 V - 264 V, adjustable to 150 V - 284 V
• Input frequency 50/60 Hz (46 - 70 Hz working range)
• Voltage/frequency of battery backup
outlets 19 in battery mode 220 V / 230 V / 240 V +15 % -20 % (50/60 Hz ± 1 Hz)
• Total output current for all outlets 10 A max
• Output current of battery backup
outlets 19 3 A max 3.6 A max 5.5 A max 7.3 A max
• Leakage current 0.4 mA
• Input protection 10 A resettable circuit breaker
• Transfer time 5 ms typical
• Telephone/Data surge protection Tel,ISDN,ADSL,Ethernet
• Sealed lead-acid battery 12 V, 7 Ah 12 V, 9 Ah 2x12V, 7 Ah 2x12V, 9 Ah
• Automatic battery test Once a week
• Average battery life 4 years typical, depending on temperature and number of discharge
cycles
• Operating temperature 0 to 35 °C
• Storage temperature -25 °C to +55 °C
• Operating relative humidity 0 to 85 %
• Operating elevation 0 to 2000 m
• Safety standards IEC62040-1,CEcertied
• Electromagnetic compatibility standards IEC 62040-2, C1*
• Warranty 3 years
• Dimensions (mm/inch) 260 x 82 x 285 / 10.24 x 3.23 x 11.22 275 x 82 x 390 / 10.83 x 3.23 x 15.35
• Weigth (kg/lb) 6.9 / 15.2 7.3 / 16.1 9.7 / 21.4 11.5 / 25.4
AC input source protection, Ellipse PRO: 650 850 1200 1600
• Uoc (common mode / differential mode) 6 kV / 2 kV
• Up (common mode / differential mode) 1.8 kV / 1 kV
• In 3 kA
Dielectric isolation
• AC Ground 1500 Vac, 50 Hz
• AC /TEL 3000 Vac, 50 Hz
• Tel / Ground 1000 Vac, 50 Hz
Temporary overvoltage (TOV)
• Uc 250 Vac
• Ut 430 Vac
Energy dissipation 405 Joules
Скачано ссайта интернет магазина https://axiomplus.com.ua/

6
ENGLISH
1. Operating conditions
• This product is an Uninterruptible Power Supply (UPS) for computers and their
peripherals, television sets, stereo systems and video recorders... It must not be used
to supply other electrical equipment (lighting, heating, household appliances, etc.).
• UPS can be installed in horizontal, vertical position, or placed in Rack 2U (optional kit).
2. Description
AVR
%
Min
Hz
kVA
kW
6
7
8
6ON/OFFbuttonforthe
battery backup outlets
7Scroll down
8ASR LED
LCD
16
15
14
17
11
10
912
13
9UPSON
10 AVR mode
11 Battery mode
12 Internal fault
13 Output load level
14 Battery level
15 Input measurements
16 Output measurements
17 Measuring unit
Outlets
In Out
InternetModem / Network
Master EcoControl
1200 / 1600650 / 850
18
19
20
19
18
20
18 Surge protection outlets
19 Battery backup outlets
20 Protection (circuit breaker)
Скачано ссайта интернет магазина https://axiomplus.com.ua/

7
ENGLISH
3. UPS connections
• Connect the UPS 1to the AC-power system via a wall outlet with an earth connector,
using the supplied cord 4foraUPSwithFR/DINsocketsorwiththesupplycordof
your computer for a UPS with IEC sockets (seegureA).
• Plug critical equipment (computer, monitor, modem, etc.) into the outlets 19 providing
batterybackuppowerandsurgeprotection(seegureB),takingcarenottoexceed
the rated current indicated in amperes.
• Other devices (printer, scanner, fax, etc.) can be connect to the surge protection outlets
18(seegureB).Thesurgeprotectionoutletsarenotbackedupbybatterypowerin
the event of a power outage.
• LeavesufcientspacearoundtheUPSforbetterventilation.
Optional Internet modem / Network connection:
A modem or Ethernet data line can be protected against surges by connecting it via
the UPS. Connect the existing device cable between the wall outlet and the UPS, and
useasimilarcablebetweentheUPSandthedevice,asindicatedingureC(cablenot
supplied).
Optional USB connection:
The UPS device can be connected to the computer using the USB cable 5supplied
(seegureC).
Eaton UPS Companion software is downloadable from powerquality.eaton.com.
Register for the warranty on powerquality.eaton.com.
4. Master and EcoControl outlets operating procedure
Inordertolimitenergyconsumptionofperipherals(scanner,printer)instandbymode,
the Ellipse PRO is equipped with EcoControl outlets that are dependent on the Master
outlet. When the main device supplied by the Master outlet (computer) is shut down, the
EcoControl outlets are automatically deactivated and the peripherals shut down.
Thisfunction(deactivatedbydefault)isvalidatedandconguredusingtheconguration
tool integrated in the software.
Note: when the function is activated, do not connect critical applications to EcoControl outlets.
Threshold setup
A default setup ensures the correct operation of the EcoControl function. However,
depending on the consumption of the main load, the trigger threshold of the EcoControl
functionmayhavetobemodiedusingthecongurationsoftware:
• First, make sure that the function is activated in the "EcoControl Function" tab of the
congurationtool.
• If the peripherals connected to the EcoControl outlets do not switch off when the main
loadisnotinnormaloperation(ex:wheninstandbymode),thedetectionthreshold
value must be set to High.
• If the rated consumption level of the main load is low and the EcoControl outlets shut
down when the main load is operating normally, the detection threshold value must
be set to Low.
Скачано ссайта интернет магазина https://axiomplus.com.ua/

8
ENGLISH
6. Operation
Battery charge
The UPS charges the battery as soon as it is connected to the AC outlet, whether button
6ispressedornot.Whenusedforthersttime,thebatterywillonlyprovideits
maximum performance after it has been charged for 8 hours. It is recommended that
the UPS be permanently connected to the AC power supply to ensure the best possible
performance.
Switching-on the UPS
Press button 6for about 1 second.
Surge protection outlets 18 without battery backup
Equipment connected to these outlets is supplied as soon as the AC cord 4is plugged
in.They are not affected by button 6.
Battery backup outlets 19
Equipment connected to these outlets is supplied as soon as button 6turns green
(seegureD).
These outlets can be turned on even if the UPS is not connected to AC power
(button 6ashes).
5. UPS setting through the LCD
l LCD shut off if no activity for 3 minutes.
5s 2s 2s 2s 2s
(165 - 264 V)
Output voltage Input voltage
tolerance
EcoControl Alarm
(150 - 284 V)
Release scroll down button to select menu
Save the new value
10s 5s 5s
Example of setting
Скачано ссайта интернет магазина https://axiomplus.com.ua/

9
ENGLISH
Problem Diagnostic Solution
1• The battery backup outlets 19
are not supplied with power. • Button 6is not lighted on. • Press button 6and check that
it turns green.
2 • The connected devices are not
supplied when AC power fails. • The devices are not connected to the battery backup outlets 19.• Connect the devices to the
battery backup outlets 19.
3 • AC power is available, but the
UPS operates on battery power. • Circuit breaker 20, located at
the rear of the UPS, has been
tripped by an overload on the
UPS output.
• Disconnect excess equipment
and reset the circuit breaker 20
by pressing the corresponding
button.
4• Green button 6ashesand
audible alarm beeps every 3
seconds.
• The UPS battery backup outlets
19 are overloaded. • Disconnect excess equipment
connected to the battery backup
outlets 19 .
5• Fault sign 12 appear on the LCD
panel and audible alarm beeps
continuously.
• A fault has occurred on the UPS.
The battery backup outlets 19 are
no longer supplied.
• Call after-sales support.
6• Green LED 8is off and the
lteredoutlets18 are supplied.
• Surge protection is no longer
provided. • Call after-sales support.
7 • EcoControl outlets keep powered
when main application (Master
outlet) is stopped.
• EcoControl function is not
activated or not properly set. • Activate or set properly EcoControl function using the
software provided with the
product.
7. Troubleshooting
AC-power disturbance
• If AC power is disturbed or fails, the UPS continues to operate on battery power.
Button 6ashesgreen.Innormalmode,theaudiblealarmbeepseverytenseconds,
then every three seconds when the end of battery backup time is near. In silent mode,
the audible alarm simply beeps once when the UPS transfers to battery power.
• If the power outage lasts longer than the battery backup time, the UPS shuts down
and automatically restarts when power is restored. Following a complete discharge, a
few hours are required to recharge the battery back to full backup time.
Surge protection:
All outlets include surge protection.
Shutdown of the battery backup outlets 19
Press button 6for more than two seconds.
Скачано ссайта интернет магазина https://axiomplus.com.ua/
