Eaton®Power Xpert®Gateway (PXGX) UPS Card
Quick Start Instructions
Package Contents
lPower Xpert Gateway (PXGX) UPS Card
lUSB Cable
lQuick Start Instructions
Power Xpert Gateway
PXGX UPS
EMP Upstream Downstream
100100 Act Act Setup
Restart
Status
DHCP
Ident
Power

Help Desk Numbers
United States 1-800-356-5737 or 1-800-843-9433
Canada 1-800-461-9166 ext 260
All Other Countries Call your local service representative
Web Site www.eaton.com/pxgx
NOTE: On the Web site opening page, click Support and select the
Customer Service link for more information.
Eaton, Power Xpert, PredictPulse and X-Slot are registered trademarks of Eaton
Corporation or its subsidiaries and affiliates. Google Chrome is a trademark of
Google Inc. Linux is a registered trademark of Linus Torvalds. Microsoft and
Windows are registered trademarks of Microsoft Corporation. Mozilla and
Firefox are registered trademarks of the Mozilla Foundation. All other trademarks
are property of their respective companies.
©Copyright 2015 Eaton Corporation, Raleigh, NC, USA. All rights reserved. No
part of this document may be reproduced in any way without the express written
approval of Eaton Corporation.

Eaton Power Xpert®Gateway PXGX UPS Card Quick Start Instructions 164950240—Rev 2 1
TABLE OF CONTENTS
Section 1 Installation Checklist ........................................................................ 2
Section 2 Install the Card ................................................................................. 3
Section 3 Connect the Card to the Computer .................................................. 5
Section 4 Install the Driver Software .............................................................. 8
Section 5 Obtain a DHCP-Assigned IP Address ............................................. 13
Section 6 Assign an IP Address Manually ..................................................... 16
Section 7 Disable Browser Compatibility Mode ............................................ 19
Section 8 Register a PredictPulse Subscription ............................................. 21

2 Eaton Power Xpert®Gateway PXGX UPS Card Quick Start Instructions 164950240—Rev 2
Section 1 Installation Checklist
1. Verify that the following items are available:
oPower Xpert Gateway (PXGX) UPS Card package contents (card, cable,
Quick Start Instructions)
oPhillips®screwdriver
oAvailable USB port on a computer running Microsoft®Windows®
oWeb browser (Microsoft Internet Explorer® version 8.0 and higher,
Mozilla®Firefox®, or Google Chrome™ are recommended)
2. If you are going to use Dynamic Host Configuration Protocol (DHCP), provide
your local network administrator with the card's MAC address. The MAC
address is located on either the shipping box label or the label on this card.
oMAC Address _____________________________________________
3. If you are not going to use DHCP to provide any of the settings listed below,
contact your local network administrator for the settings.
In the table below, check the DHCP check box or enter the values for manual
configuration.You will reference this data later in the procedure.
4. If you need e-mail functionality, obtain the SMTP IP address or host name.
If using the SMTP host name, verify that you also have the Name Server IP
address (see Step 3).
oSMTP (mail server) IP Address
or Host Name _______________________________
Item DHCP* Manual Configuration
IPv4 oCard IP Address: ________________________
Netmask: ________________________
Gateway: ________________________
DNS – Name Servers oName Server #1: ________________________
Name Server #2: ________________________
Name Server #3: ________________________
DNS – Domain oDomain: ________________________
* The network administrator normally sets up the DHCP server to provide a static IP address each time
the card makes a DHCP request.

Eaton Power Xpert®Gateway PXGX UPS Card Quick Start Instructions 164950240—Rev 2 3
Section 2 Install the Card
Note: The hot-swappable PXGX UPS card can be installed without turning off
the UPS or disconnecting the load.
To install the PXGX UPS card:
1. Verify that all six DIP switches on the card are in the OFF position (see
Figure 1).
Figure 1. Verify DIP Switches are OFF
2. If not already done, record the MAC address for future reference (see the
“Installation Checklist” on page 2).
3. Remove the X-slot®cover from the UPS. Retain the screws.
Note: If another card is already installed with an attached communication
cable, disconnect the cable and then remove the card.
4. To prevent electrostatic discharge (ESD), place one hand on a metal surface,
such as the UPS panel.
6 5 4 3 2 1
OFF
ON

4 Eaton Power Xpert®Gateway PXGX UPS Card Quick Start Instructions 164950240—Rev 2
5. Slide the card into the open slot and secure with the screws removed in
Step 2 (see Figure 2).
Figure 2. Secure the PXGX UPS Card
6. From your laptop, go to www.eaton.com/pxgx.
7. On the Features tab, click the Download Configuration File link to
download the configuration file.
8. Save the driver configuration file (powerxpert.inf) to the C: drive using the
default location or a folder you select. Note the path of the downloaded file
on your computer. (Never download the file to your desktop.)
Power Xpert Gateway PXGX UPS
EMP Upstream Downstream
100100 Act Act Setup
Restart
Status DHCP Ident Power

Eaton Power Xpert®Gateway PXGX UPS Card Quick Start Instructions 164950240—Rev 2 5
Section 3 Connect the Card to the Computer
To connect the card to the computer:
1. Plug the small connector at the end of the supplied USB configuration cable
into the setup port on the card (see Figure 3).
Figure 3. Install the USB Cable
2. Plug the other end of the USB cable into the USB port on the computer. The
Windows operating system detects new hardware.
Note: If a message indicates that the device driver software was not
successfully installed, click Ignore.
Note: You may see a pop-up message window that shows “Found new
hardware.” This indicates that the hardware installed successfully.
Power Xpert Gateway PXGX UPS
EMP Upstream Downstream
100100 Act Act Setup
Restart
Status DHCP Ident Power

6 Eaton Power Xpert®Gateway PXGX UPS Card Quick Start Instructions 164950240—Rev 2
3. Connect an active Ethernet cable (not supplied) to the Upstream Ethernet
connector on the PXGX UPS card (see Figure 4).
4. If you are connecting to another PXGX UPS card or other Ethernet device,
connect an Ethernet cable (not supplied) to the Downstream Ethernet
connector on the PXGX UPS card.
Figure 4. Install the Ethernet Cable
5. Wait for the power light and status light on the installed card to illuminate.
This takes about two minutes.
6. Open a Web browser and type the default IP address (192.168.200.101).
Power Xpert Gateway PXGX UPS
EMP Upstream Downstream
100100 Act Act Setup
Restart
Status DHCP Ident Power

Eaton Power Xpert®Gateway PXGX UPS Card Quick Start Instructions 164950240—Rev 2 7
7. Did the Power Xpert Gateway software open to the PXGX UPS card page?
lIf yes, the driver has already been installed automatically. Either verify the
IP address assigned through DHCP or manually enter a static (fixed) IP
address for the card’s network connection:
a.To verify the DHCP-assigned IP address, go to page 13.
b.To manually enter a fixed IP address, go to page 16.
lIf no, the driver has not been installed. Go to the next section, "Install the
Driver Software" on page 8 in order to confirm that you have the most
current USB Driver software. If not, you need to install or update the USB
Driver software.

8 Eaton Power Xpert®Gateway PXGX UPS Card Quick Start Instructions 164950240—Rev 2
Section 4 Install the Driver Software
The steps you use to install the driver software depend on your operating system
(OS). This procedure provides instructions for installing driver software on a
Windows 7 OS.
Note: Windows 8 steps are basically the same as Windows 7, although the
dialog displays may differ somewhat.
Note: The PXGX UPS and PXGMS cards use the same driver.
Note: You can use either the Device Manager path or the Devices and Printers
path to browse for the driver software and install it. This procedure uses
the Device Manager.
To install the driver from the Device Manager:
1. Click Start in the Start bar. Type Device in the search box.
2. Select Device Manager from the list above the search box. The Device
Manager opens.
3. Locate RNDIS/Ethernet Gadget under either Other Devices or Network
Adapters (see Figure 5).
lIf you do not see RNDIS/Ethernet Gadget in either list, you do not have a
cable connected to the card. Connect the computer to the card. Go back to
Step 1.
lIf RNDIS/Ethernet Gadget is listed under Other Devices, the driver is not
installed. Go to Step 4.
lIf RNDIS/Ethernet Gadget is listed under Network Adapters, a driver is
installed already, but it may not be the most up-to-date driver. Go to Step 4.
and continue this procedure to ensure the most current driver is installed.

Eaton Power Xpert®Gateway PXGX UPS Card Quick Start Instructions 164950240—Rev 2 9
Figure 5. Update RNDIS/Ethernet Gadget Driver from Other Devices
4. Right-click RNDIS/Ethernet Gadget to display the menu and select Update
Driver Software.
lIf a pop-up message displays, “The best driver is already installed,” click
Close and go to Step 10.
lOtherwise, go to Step 5.
5. Select Browse my computer for driver software (see Figure 6). Click
Next. The next page displays.

10 Eaton Power Xpert®Gateway PXGX UPS Card Quick Start Instructions 164950240—Rev 2
Figure 6. Update Driver Software Window – Search Method
6. Click Browse. The “Browse for Folder” dialog displays. Select the folder that
contains drivers for your hardware. Click OK. The “Browse for driver
software on your computer” page displays.
7. The path to the powerxpert.inf file displays in the Search for driver
software in this location box. Click Browse and navigate to the
powerxpert.inf file you already downloaded. Select the file and click Next
(see Figure 7).
lIf a pop-up message displays, “The best driver is already installed,” click
Close and go to Step 10.
lOtherwise, the software begins to install.

Eaton Power Xpert®Gateway PXGX UPS Card Quick Start Instructions 164950240—Rev 2 11
Figure 7. Update Driver Software Window – Browse for Driver Software
Note: If the message “Windows can't verify the publisher of this driver
software” displays, select Install this driver software anyway
(see Figure 8).
Figure 8. Windows Security Message
8. When the driver software is updated successfully, the message “Windows
has successfully updated your driver software” displays (see Figure 9).

12 Eaton Power Xpert®Gateway PXGX UPS Card Quick Start Instructions 164950240—Rev 2
Figure 9. Update Driver Software Window – Update Successful
9. Click Close.
10. Either obtain the DHCP-assigned IP address or manually enter a fixed IP
address:
lTo obtain the IP address assigned through DHCP, continue to "Obtain a
DHCP-Assigned IP Address" on page 13.
lTo manually enter a static (fixed) IP address for the card’s network
connection, continue to "Assign an IP Address Manually" on page 16.
Note: By default, the PXGX UPS card requests an IP address through DHCP
when connected to a network.

Eaton Power Xpert®Gateway PXGX UPS Card Quick Start Instructions 164950240—Rev 2 13
Section 5 Obtain a DHCP-Assigned IP Address
To obtain the IP address through DHCP:
1. Ensure the PXGX UPS card is still connected to the computer over the USB
cable. Also ensure that the network cable is connected from the PXGX UPS
card Ethernet port to the network connection.
2. If your Web browser already open to the default IP address, go to Step 3.
Otherwise, perform the following:
lOpen your Web browser.
lEnter: 192.168.200.101.
lLog on as administrator. The default username and default password are
“admin.” The PXGX UPS card Web page displays.
Note: If the system is unresponsive and you cannot make any selections, the
browser may be running in compatibility mode. To disable compatibility
mode, go to "Disable Browser Compatibility Mode" on page 19.
3. Select Network from the Configuration menu. The Network page displays
(see Figure 10).
4. Under IPv4, the Automatic Configuration: DHCP Enabled setting
checkbox should be enabled by default. Make sure the checkbox is checked
(enabled) before continuing.
5. Scroll down to Name Service and expand the selection to update the next
two DHCP settings (see Figure 10):
lCheck the checkbox (enable) for Use DHCP (when enabled) to get name
services.
lCheck the checkbox (enable) for Use DHCP (when enabled) to get
domain name.

14 Eaton Power Xpert®Gateway PXGX UPS Card Quick Start Instructions 164950240—Rev 2
6. Click Apply.
Figure 10. Name Service Settings
7. Select Ye s for the message, “Do you want to save the Network
Configuration?”
8. Wait for approximately two minutes for the card to reboot. Initially, all lights
will be lit. You will know the card has finished rebooting when only the top
light (Status) and the bottom light (Power) remain lit.
9. Open a browser and enter the default IP address (192.168.200.101).
10. When prompted, log on as administrator. The default username and default
password are “admin.” The PXGX UPS card Web page displays.

Eaton Power Xpert®Gateway PXGX UPS Card Quick Start Instructions 164950240—Rev 2 15
11. C l i ck Network in the menu list.
12. Does the IP address display?
lIf yes, uncheck (disable) the DHCP Enabled box and select Apply.
Note: At this point, the DHCP address is saved as a static IP address.
lIf no, go to "Assign an IP Address Manually" on page 16 to manually obtain
a static IP address for the PXGX UPS card.
Note: For detailed information, refer to the Eaton Power Xpert Gateway
(PXGX) UPS User’s Guide, which is available through a link on the
Documentation tab on the PXGX UPS product Web page.

16 Eaton Power Xpert®Gateway PXGX UPS Card Quick Start Instructions 164950240—Rev 2
Section 6 Assign an IP Address Manually
To manually assign a static (fixed) IP address for the card:
1. Ensure the PXGX UPS card is still connected over the USB cable and the
network cable is connected from the PXGX UPS card Ethernet port to the
network connection.
2. If your Web browser already open, go to Step 3. Otherwise, perform the
following:
lOpen your Web browser.
lEnter: 192.168.200.101.
lLog on as administrator. The default username and default password are
“admin.” The PXGX UPS card Web page displays.
lGo to Step 3.
Note: If the system is unresponsive and you cannot make any selections, the
browser may be running in compatibility mode. To disable compatibility
mode, go to "Disable Browser Compatibility Mode" on page 19.
3. Select Network from the Configuration menu. The Network page displays.

Eaton Power Xpert®Gateway PXGX UPS Card Quick Start Instructions 164950240—Rev 2 17
Figure 11. Disable DHCP Setting
4. Uncheck the DHCP Enabled checkbox to disable DHCP and allow you to
manually configure the IP address (see Figure 11).
5. Refer to the "Installation Checklist" on page 2 in this book. Enter the IP
address, Netmask, and Gateway addresses in the IPv4 > Manual
Configuration section.
6. Click Apply, then click OK to confirm.
7. Optional. If you are using a host name, or host names, for controlling
access to the card:
lType the server IP address in the Name Server box. (Up to three IP
addresses can be entered.)
lClick Apply. Click OK to confirm.

18 Eaton Power Xpert®Gateway PXGX UPS Card Quick Start Instructions 164950240—Rev 2
8. Open a browser and enter the fixed (static) IP address.
9. Log on as administrator. The default username and default password are
“admin.” When the PXGX UPS card Web page displays, you know the fixed
IP Address is working.
Note: For detailed information, refer to the Eaton Power Xpert Gateway
(PXGX) UPS User’s Guide, which is available through a link on the
Documentation tab on the PXGX UPS product Web page.
