Powerware 5110 UPS
U
ser
’
s manua
l
1023922 Revision A
Contents
Introduction
.................................................................................................
4
Features:
...................................................................................................................
4
Unit inspection
.........................................................................................................
4
Requesting for CE-declaration
................................................................................
4
Safety Instructions
......................................................................................
5
Battery connection required before use!
.....................................................
6
Connecting the Battery:
...........................................................................................
6
Installation and Operation:
..........................................................................
6
Typical applications
.................................................................................................
7
Indicators
....................................................................................................
7
Indicator table
.............................................................................................
9
Status Indicators
......................................................................................................
9
LED Indicator Table
..................................................................................................
9
LED Audible Alarm Table
........................................................................................
9
Battery replacement procedure:
..................................................................
9
Troubleshooting
.....................................................................................................
1
2
Specifi cation*:
........................................................................................................
1
3
Service and Support
..................................................................................
1
4

User’s manual
350 - 1500 VA
4
1023922
Revision A
Introduction
The Powerware 5110 uninterruptible power system (UPS) fi lters the input line from
line disturbances and protects your sensitive electronic equipment from fi ve common
power problems such as power failures, power sags, power surges, over-voltage and
under- voltage.
Features:
Processor-controlled voltage regulation (AVR)
Eight outlets:
- Four with surge and backup protection
- Four with surge protection only
Data Line (Internet fax – modem – DSL) or telephone line surge protection
Cold start capability
USB communication port
User-replaceable batteries
Unit inspection
Once you have received the Powerware 5110 UPS product, you should remove the
package and inspect the product for shipping damage. If any damage is found, please
notify the carrier and your dealer. Please keep the shipping carton and the packing
foam in the event the product must be returned to the factory for service.
Requesting for CE-declaration
Can be downloaded from
http://www.powerware.com/Service_support/EMEA_certifi cates.asp
Eaton Power Quality Oy
Koskelontie 13, FIN-02920 Espoo Finland
Phone: [phone]
Fax: [phone]
•
•
•
•
•
•

User’s manual
350 - 1500 VA
5
1023922
Revision A
Safety Instructions
ATTENTION
Maintenance, other than battery replacement must be performed by a
qualifi ed technician. Failure to do so could result in an electrical shock.
Although the unit may be unplugged from utility power, hazardous
voltage still may be present through the battery.”
1. Place the Powerware 5110 UPS indoors in an area that has adequate airfl ow and
is free of excessive dust. Do NOT allow the UPS to be exposed to moisture, rain,
excessive heat, or direct sunlight.
2. Use of the Powerware 5110 UPS product in life support applications, where failure
of this equipment can reasonably be expected to cause failure of life support
equipment or to signifi cantly affect its safety or effectiveness is NOT recommended.
3. Shut off the UPS and disconnect the input power cord from the wall outlet before
replacing the battery.
4. When replacing the battery, use the same number and type of battery
5. Do NOT dispose of battery in a fi re. The battery may explode.
6. Do NOT open or mutilate the battery. They contain an electrolyte that is toxic and
harmful to the skin and eyes.
7. Proper disposal of the battery is required. Please refer to your local laws/
regulations regarding battery disposal.
8. Use tools with insulated handles to replace the battery to avoid personal injury.
Due to energy hazard, please remove wristwatches and jewelry such as rings when
replacing battery.

User’s manual
350 - 1500 VA
6
1023922
Revision A
Battery connection required before use!
Connecting the Battery:
Principal shown below for detailed information how to connect please refer to battery
replacement section.
Installation and Operation:
Following steps explain how to connect and operate the Powerware 5110 UPS.
1. Connect the UPS to a grounded power outlet.
2. Plug your computer, monitor or load to be protected into the “Battery Backup &
Surge Protection” outlets. (These outlets will provide emergency battery backup
power during power outages as well as protection from surges and spikes.)
Do NOT plug LASER PRINTERS into the “Battery Backup” outlets.
Do NOT plug ACCESSORY SURGE strips into the “Battery Backup” outlets.
3. Plug your peripheral equipment or non-critical loads (printer, scanner, fax, speaker,
etc.) into the “Surge Protection” outlets. (These outlets provide surge and spike
protection only, they will NOT provide battery backup power during a utility power
failure).
4. With your equipment turned off, switch on the UPS.
5. When the “On/Off” LED light is illuminated, turn on the connected equipment.
6. Connect your computer to the UPS using USB cable provided.
Install Power management software provided with the UPS

User’s manual
350 - 1500 VA
7
1023922
Revision A
Typical applications
Indicators
1. On/Off/Test Switch
One switch controls power to your equipment and performs a self-test to detect
overload/undercharge.
Turn on the UPS.
Press and hold the switch for more than one second and release the switch after the
beep. The UPS will start.
Turn off the UPS.
Press and hold the switch for more than one second and release the switch. The UPS
will shut down completely.
Perform Self-test.
The UPS will perform self-test for about 4.5 seconds when the UPS is turned on and
the utility power is present.

User’s manual
350 - 1500 VA
8
1023922
Revision A
2. Normal mode (Green)LED
Indicates the UPS is providing mains power to your equipment. When the LED is
blinking the UPS is providing power from the battery.
3. Fault (Red)LED
When blinking, LED could indicate an overload condition or that the battery should
be replaced. When the LED is always on it indicates a short or UPS fault. For details
please see Indicator Table.
4. Battery mode (Yellow)LED
Indicates the UPS is providing battery power to your equipment.
5. Four Battery Backup & Surge Protection Outlets
These three outlets not only provide full time surge protection but also provide
emergency battery backup power.
6. Four Surge Protection Outlets
These Three outlets provide full time protection from surge and spike.
7. Phone/modem/ADSL Protection
Built-in RJ11 jacks protect the Internet, phone or fax line from surges. Connect the line
in from the wall into the jack named “in” and connect the phone, modem, ADSL box to
the jack named “out”
8. USB Communication Port
The provided LanSafe monitoring and shutdown software can be automatically
confi gured to save your fi les and shut down your computer in the event of a prolonged
power outage.
9. Circuit Breaker
The button will protrude when the overload condition occurs. The UPS will switch off
of utility power. If the button protrudes, disconnect some non-essential equipment and
reset the circuit breaker by pushing the button inward.
10. Input Power Connector IEC C13
Plug your load power cable to power your UPS

User’s manual
350 - 1500 VA
9
1023922
Revision A
Indicator table
Status Indicators
The UPS provides both visual and audible status indicators. Visual indicators consist of
three LEDs to represent the following conditions:
On utility power operation
On battery power operation
UPS fault/alarm
LED Indicator Table
On Utility (AC mode)
Green Lighting
On Battery (Backup mode)
Yellow Lighting
Low Battery
Yellow Flashing
Fault/Output Short
Red Lighting
Overload/Check Battery
Red Flashing
LED Audible Alarm Table
On Battery (Backup mode)
Sounding every 5 seconds
Low Battery
Sounding (two beeps) every 5 seconds
Overload
Sounding every 0.5 seconds
Replace battery
Sounding (three beeps) every 30 seconds
Fault or output short circuit
Continuous sounding
Battery over charge
Sounding (three beeps) every 5 seconds
Battery replacement procedure:
1. Shut off the UPS and disconnect the input power cord from the wall outlet.
2. Open battery door.
3. Disconnect used battery. Connect new battery. (It is important that connectors be
fi rmly attached to new batteries.)
4. Close battery door
5. Properly recycle used battery.
•
•
•

User’s manual
350 - 1500 VA
10
1023922
Revision A
5Ah batteries (350VA, 500VA models)
7Ah x 1 battery (700VA models)

User’s manual
350 - 1500 VA
11
1023922
Revision A
7 Ah x 2 batteries (1000 VA models), 9 Ah x 2 batteries (1500 VA models)

User’s manual
350 - 1500 VA
12
1023922
Revision A
Troubleshooting
Symptom
Possible Cause
Action to Take
Powerware 5110 UPS will
not turn on.
UPS is not turned on or
battery is not connected.
Switch on the ON/OFF switch. If the
power is not present, please make
sure your circuit breaker on the
building is not accidentally turned
off.
Circuit Breaker has tripped.
Reduce the amount of equipment
plugged into the “Battery Backup
& Surge Protection” outlets of the
UPS. Next, reset the circuit breaker
by pushing it back in.
Powerware 5110 UPS is
making a continuous sound
and the “Overload” indicator
is light.
The “Battery Backup &
Surge Protection” outlets are
overload.
Reduce the amount of equipment
connected to these outlets.
Powerware 5110 UPS
does not provide expected
runtime.
Due to age the battery does
not hold a full charge.
Charge the battery for at least 8
hours and recheck the battery
runtime
Battery might need to be changed,
look on battery replacement.
Connected equipment’s lose
power while connected to
the Powerware 5110 UPS
The “Battery Backup &
Surge Protection” outlets are
overloaded.
Refer to the Indicator Table
“Powerware 5110 UPS is making a
continuous sound and the Overload
indicator is lit.”
The Powerware 5110 UPS
has depleted the battery.
The Powerware 5110 UPS will turn
off when the battery has been
depleted during the failure of utility
power. Allow UPS to re-charge
before continuing use of the UPS.
Connected equipment is
connected to the wrong
outlet.
Ensure that the equipment you
want to stay powered during a
failure of utility power is plugged
into the “Battery Backup & Surge
Protection” outlets.
The Powerware 5110 UPS
may be faulty.
Please Call your local Powerware
representative for further
troubleshooting.

User’s manual
350 - 1500 VA
13
1023922
Revision A
Specifi cation*:
230V Models
Model
5110 350i USB
5110 500i USB
5110 700i USB
5110 1000i USB
5110 1500i USB
Capacity
350VA / 210W
500VA / 300W
700VA / 420W
1000VA/ 600W
1500VA/ 900W
Input Voltage Range
178~275Vac
Output Voltage Range
207~250Vac
Frequency
50 / 60 Hz auto sensing
Outlets
4 Battery Backup & Surge Protection;
4 Surge Protection only
Lighting / Surge Protection
476 Joules
Transfer Time to Battery/AC
2-6 msec. typical
Battery Type
Sealed and leak proof maintenance free lead-
acid battery
Battery Specifi cation
350VA:12V 5Ah
500VA:12V 5Ah
750VA:12V 7Ah
1000VA:12V 7Ah x 2
1500VA:12V 9Ah x 2
Typical Backup Time
3 – 5 minutes at full rated load
Phone / modem ADSL Protection
RJ11 connector/RJ11 cable
Short Circuit Protection
Resettable Circuit Breaker
Communication Port
USB
Operation Temperature
0� ~ 40�
Operation Relative Humidity
0 to 95% non-condensing
Storage Temperature
-15� ~ 50�
Net Weight
350VA:5.5kg
500VA:5.7kg
700VA:7.7kg
1000VA:11.8kg
1500VA:12kg
Dimensions (WxDxH)
350VA&500VA&700VA: 87x270x 260 (mm)
1000VA &1500VA: 87x270x 384 (mm)
*Due to continuing product improvement programs, specifi cations subject to change without notice

User’s manual
350 - 1500 VA
14
1023922
Revision A
Service and Support
For questions and/or problems, please call your local distributor or the help desk at
one of the following telephone numbers and ask for a UPS technical representative.
United States: 1.800.356.5737, Europe, Middle East, Africa: Local Powerware
representative. Asia: +852.2830.3030, Australia: +61.3.9706.5022
Please have the following information ready
Model number and Serial number
Symptoms of failure or problem
Customer contact information
For additional information please visit us online: www.powerware.com
•
•
•
