Eaton Tripp Lite SmartPro Series Assembly instructions

p/n: 614-40194
Revision 01
SMART2200RM2U
SMART2200RM2UN
SMART3000RM2U
SMART3000RM2UN
SMART750RMXL2U
SMART750RMXL2UN
SMART1000RMXL2U
SMART1000RMX2UN
SMART1500RMXL2U
SMART1500RMXLN
SMART2200RMXL2U
SMART2200RMXLN
SMART3000RMXL2U
SMART3000RMXLN
BP48VRM2U BP72VRM2U
Advanced User Guide
Eaton®Tripp Lite Series SmartPro

Eaton reserves the right to change specifications without prior notice. Eaton is a registered trade ark of Eaton. All other trade arks are
property of their respective co panies.
©Copyright 2022 Eaton, Raleigh, NC, USA. All rights reserved. No part of this docu ent ay be reproduced in any way without the
express written approval of Eaton.
SSaaffeettyy IInnssttrruuccttiioonnss
SAVE THESE INSTRUCTIONS. This manual contains important instructions that should be
followed durin installation and maintenance of the UPS and batteries.
This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to Part 15 of the FCC Rules These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a commercial environment This
equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful interference to radio communications
Operation of this equipment in a residential area is likely to cause harmful interference in which case
the user will be required to correct the interference at his own expense
This is a category C2 UPS product In a residential environment, this product may cause radio
interference, in which case the user may be required to take additional measures
Supplier's Declaration of Conformity of Federal Communications Commission Statement
This device complies with Part 15 of the FCC Rules Operation is subject to the following two
conditions:
1 this device may not cause harmful interference, and
2 this device must accept any interference received, including interference that may cause
undesired operation
For questions regarding this FCC SDoC declaration, contact Eaton Corporation by telephone or
through the Internet
Eaton Corporation 8609 Six Forks Road,
Raleigh, NC 27615, USA
Telephone: [phone]

SSppeecciiaall SSyymmbboollss
The following are examples of symbols used on the product to alert you to important information:
RISK OF ELECTRIC SHOCK - Observe the warning associated with the risk of
electric shock sy bol.
CAUTION: REFER TO OPERATOR'S MANUAL - Refer to your operator's
anual for additional infor ation, such as i portant operating and aintenance
instructions.
Infor ation, advice, help.
Read the docu entation provided.
Disconnect input plug.
Before aintenance, first shut down the UPS then disconnect the AC power
source, internal and external batteries then discharge capacitors by pressing the
ON button and wait 5 inutes.
This equip ent should only be used in a dry indoor environ ent.
Operating range of te perature.
Operating range of hu idity.
The UPS and their batteries ust be kept in a ventilated place.
SSaaffeettyy ooff PPeerrssoonnss
• The system has its own power source (the battery) Consequently, the power outlets may be
energized ven if the systems is disconnected from the AC power source Dangerous voltage
levels are resent within the system It should be opened exclusively by qualified service
personnel
• The system must be properly grounded at all times
• The battery supplied with the system contains small amounts of toxic materials To avoid
accidents, the directives listed below must be observed:
–Servicing of batteries should be performed or supervised by personnel knowledgeable about
batteries and the required precautions
–When replacing batteries, replace with the same type and number of batteries or battery
packs
–Do not dispose of batteries in a fire The batteries may explode

–Batteries constitute a danger (electrical shock, burns) The short-circuit current may be very
high
• Precautions must be taken for all handling:
–Wear rubber gloves and boots
–Do not lay tools or metal parts on top of batteries
–Disconnect charging source prior to connecting or disconnecting battery terminals
–Determine if battery is inadvertently grounded If inadvertently grounded, remove source
from ground Contact with any part of a grounded battery can result in electrical shock The
likelihood of such shock can be reduced if such grounds are removed during installation and
maintenance (applicable to equipment and remote battery supplies not having a grounded
supply circuit)
PPrroodduucctt SSaaffeettyy
• To connect the UPS, instructions and operation described in the manual must be followed in the
indicated order
• CAUTION - To reduce the risk of fire, the unit connects only to a circuit provided with 20 or 30
amperes maximum branch circuit overcurrent protection in accordance with the National Electric
Code, ANSI/NFPA 70 (US installations only)
• Check that the indications on the rating plate correspond to your AC powered system and to the
actual electrical consumption of all the equipment to be connected to the system
• For PLUGGABLE EQUIPMENT, the socket-outlet shall be installed near the equipment and shall
be easily accessible
• Never install the system near liquids or in an excessively damp environment
• Never let a foreign body penetrate inside the system
• Never block the ventilation grates of the system
• Never expose the system to direct sunlight or source of heat
• If the system must be stored prior to installation, storage must be in a dry place
• The admissible storage temperature range is -25ºC to +55ºC without batteries, 0°C to 40°C with
batteries
• The system is not for use in a computer room AS DEFINED IN the standard for the Protection of
Information Technology Equipment, ANSI/NFPA 75 (US installations only)
SSppeecciiaall PPrreeccaauuttiioonnss
• The unit is heavy: wear safety shoes and use vacuum lifter preferentially for handling operations
• All handling operations will require at least two people (unpacking, lifting, installation in rack
system)
• Before and after the installation, if the UPS remains de-energized for a long period, the UPS must
be energized for a period of 24 hours, at least once every 6 months (for a normal storage
temperature less than 25°C) This charges the battery, thus avoiding possible irreversible
damage
• During the replacement of the Battery Module, it is imperative to use the same type and number
of element as the original Battery Module provided with the UPS to maintain an identical level of
performance and safety If there are any questions, don’t hesitate to contact your local Eaton
representative
• All repairs and service should be performed by AUTHORIZED SERVICE PERSONNEL ONLY
There are NO USER SERVICEABLE PARTS inside the UPS

• For potential safety issue on defective UPS : DISCONNECT INTERNAL BATTERY for storage and
transportation

Tripp Lite by Eaton S artPro Advanced User Guide 614-40194—Rev 01 vii
TTaabbllee ooff CCoonntteennttss
11 IInnttrroodduuccttiioonn....................................................................................................................................................................................................................................................................................................11
1 1 Environmental protection 2
1 2 Benefits 3
1 3 Special Precautions 3
22 PPrreesseennttaattiioonn ..................................................................................................................................................................................................................................................................................................55
2 1 Standard installation 5
2 2 Rear panel 6
2 3 Optional accessories 7
33 IInnssttaallllaattiioonn ......................................................................................................................................................................................................................................................................................................99
3 1 Inspecting the equipment 9
3 2 Recommended Positions 10
3 3 Connecting the Internal Battery 13
3 4 EBM Connection 13
3 5 UPS connection 15
3 6 Connection with a FlexPDU (Power Distribution Unit) optional module 16
3 7 Connection with a HotSwap MBP (Maintenance ByPass) optional module 16
3 7 1 UPS Start-Up with the HotSwap MBP Module 17
3 7 2 HotSwap MBP module test 17
44 IInntteerrffaacceess aanndd CCoommmmuunniiccaattiioonn .......................................................................................................................................................................................................................................... 1199
4 1 Control panel 19
4 2 LCD Description 19
4 3 Display functions 22
4 4 User settings 24
4 5 Communication ports 26
4 6 UPS Remote Control Functions 27
4 7 Power Alert Software 30
4 8 Cybersecurity 30
55 OOppeerraattiioonn........................................................................................................................................................................................................................................................................................................ 3311
5 1 Start-up and normal operation 31
5 2 Starting the UPS on battery 31
5 3 UPS shutdown 31
5 4 Operating modes 32
5 5 Return of AC input power 32
5 6 Configuring Battery Settings 32
5 7 Retrieving the event and fault log 33
66 PPSS MMaaiinntteennaannccee................................................................................................................................................................................................................................................................................ 3355
6 1 Equipment Care 35

viii Tripp Lite by Eaton S artPro Advanced User Guide 614-40194—Rev 01
6 2 Storing the Equipment 35
6 3 When to Replace Batteries 35
6 4 Replacing Batteries 35
6 5 Replacing the UPS Equipped with a HotSwap MBP 37
6 6 Recycling the Used Equipment 38
77 TTrroouubblleesshhoooottiinngg .................................................................................................................................................................................................................................................................................. 3399
7 1 Typical Alarms and Faults 39
7 2 Detail Alarm or Fault Code 40
7 3 Silencing the Alarm 41
7 4 Service and Support 41
88 SSppeecciiffiiccaattiioonn aanndd TTeecchhnniiccaall CChhaarraacctteerriissttiiccss.................................................................................................................................................................................................... 4433
8 1 UPS Model List 43
8 2 Extended Battery Module Model List 44
8 3 Weights and Dimensions 44
8 4 Electrical Input 45
8 5 Electrical Input Connections 45
8 6 Electrical Output 46
8 7 Electrical Output Connection 46
8 8 Battery 48
8 9 Environmental and Safety 48
99 GGlloossssaarryy .......................................................................................................................................................................................................................................................................................................... 4499
Table of Contents

Tripp Lite by Eaton S artPro Advanced User Guide 614-40194—Rev 01 ix
LLiisstt ooff FFiigguurreess
Figure 1 Rack Installation Steps 10
Figure 2 Tower Installation Steps 12
Figure 3 LCD Screen — Example 20
Figure 4 Network Card 27
Figure 5 Relay Output Details 30
Figure 6 SmartPro 750 / 1000 / 1500 models 43
Figure 7 SmartPro 2200/3000 models 43

x Tripp Lite by Eaton S artPro Advanced User Guide 614-40194—Rev 01
List of Figures

Tripp Lite by Eaton S artPro Advanced User Guide 614-40194—Rev 01 xi
LLiisstt ooff TTaabblleess
Table 1 2
Table 2 Installation Formats 5
Table 3 Weights and Dimensions 5
Table 4 SmartPro Model – Rear Panel Details 6
Table 5 Smart Pro Optional Accessories 7
Table 6 Package content 9
Table 7 Internal Battery Connection Steps 13
Table 8 Tower EBM Installation Steps 14
Table 9 Rack EBM Installation Steps 14
Table 10 Power Supply Connection Steps 15
Table 11 FlexPDU Connection Steps 16
Table 12 HotSwap MBP Connection Steps 16
Table 13 HotSwap MBP Module Operation 16
Table 14 Control Panel Details 19
Table 15 LED Indicator Details 19
Table 16 LCD Screen – Display Details 20
Table 17 System Operational Status Details 21
Table 18 Menu Map for Display Functions 22
Table 19 User Settings 24
Table 20 RS232/USB Communication Port Connection Steps 26
Table 21 RS232 Communication Port Contact Details 26
Table 22 Communication Card Installation Steps 26
Table 23 Programmable Signal Input Details 27
Table 24 RPO Connections Detail 28
Table 25 Programmable Signal Outputs Details 30
Table 26 Alarm Conditions 39
Table 27 Alarm Codes 40
Table 28 Alarm Fault Codes 40

xii Tripp Lite by Eaton S artPro Advanced User Guide 614-40194—Rev 01
List of Tables

Tripp Lite by Eaton S artPro Advanced User Guide 614-40194—Rev 01 1
CChhaapptteerr 11 IInnttrroodduuccttiioonn
Thank you for selecting an Eaton Tripp Lite Series SmartPro product to protect your electrical equipment
The Eaton Tripp Lite Series SmartPro range has been designed with the utmost care We recommend that you
take the time to read this advanced user guide to take full advantage of the many features of your UPS
(Uninterruptible Power System)
Before installing your Eaton Tripp Lite Series SmartPro, please read the information and safety instructions
provided
Follow the instructions in the quick start guide and if necessary, refer to this advance user guide
To discover the entire range of Eaton Tripp Lite Series products, we invite you to visit our web site at tripplite
com or contact your Eaton Tripp Lite Series local representative
NOTE This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to part 15 of the FCC Rules These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a
commercial environment This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the instruction
manual, may cause harmful interference to radio communications Operation of this
equipment in a residential area is likely to cause harmful interference in which case the
user will be required to correct the interference at his own expense
Changes or modifications not expressly approved by the party responsible for compliance could void the user’s
authority to operate the equipment
This equipment is not intended for use in residential environments and may not provide adequate protection to
radio reception in such environments
Operation of this equipment in a residential environment could cause radio interference
This is a category C2 UPS product In a residential environment, this product may cause radio interference, in
which case the user may be required to take additional measures
UPS employing batteries with min V-2 case are intended for use in computer room as defined in the standard
for the Protection of Information Technology Equipment, ANSI/NFPA 75
UPS employing batteries with HB case are intended not for use in a computer room as defined in the standard
for the Protection of Information Technology Equipment, ANSI/NFPA 75
Supplier's Declaration of Conformity of Federal Communications Commission Statement
This device complies with Part 15 of the FCC Rules Operation is subject to the following two conditions:
1 this device may not cause harmful interference, and

2 Tripp Lite by Eaton S artPro Advanced User Guide 614-40194—Rev 01
2 this device must accept any interference received, including interference that may cause undesired
operation For questions regarding this FCC SDoC declaration, contact Eaton Corporation by telephone or
through the Internet
Eaton Corporation 8609 Six Forks Road, Raleigh, NC 27615, USA
Telephone: [phone]
This UPS can be used in IT/TT/TN power system This UPS complies with the IP20 protection type Protective
class I
Output short-circuit current max RMS & delay time: 90A/80ms; The max peak value: 140A
For 3K LV models, the upstream circuit breaker of UPS for installation must committee the disconnection time
in 0 4s according to requirement of IEC 60364-4-41:2005 Table 41 1
11..11 EEnnvviirroonnmmeennttaall pprrootteeccttiioonn
Eaton Tripp Lite Series has implemented an environmental-protection policy Products are developed according
to an eco-design approach
SSuubbssttaanncceess
This product does not contain CFC and HCFC This product does not contain asbestos This product is
compliant with regulations on the restriction of the use of substances in electrical and electronic equipment
PPaacckkaaggiinngg
To improve waste treatment and facilitate recycling, separate the various packing components
• The cardboard we use comprises over 50% of recycled cardboard
• Plastic bags are made of polyethylene
• Packing materials are recyclable and bear the appropriate identification symbol
Table 1
Materials Abbreviations Number in the symbols
Polyethylene terephthalate PET 01
High-density polyethylene HDPE 02
Polyvinyl chloride PVC 03
Low-density polyethylene LDPE 04
Polypropylene PP 05
Polystyrene PS 06
Follow all local regulations for the disposal of packing materials
EEnndd ooff lliiffee
Eaton Tripp Lite Series will process products at the end of their service life in compliance with local regulations
Eaton Tripp Lite Series works with companies in charge of collecting and eliminating our products at the end of
their service life
Introduction

Tripp Lite by Eaton S artPro Advanced User Guide 614-40194—Rev 01 3
PPrroodduucctt
The product is made up of recyclable materials Dismantling and destruction must take place in compliance
with all local regulations concerning waste At the end of its service life, the product must be transported to a
processing center for electrical and electronic waste tripplite com/support/recycling-program/
BBaatttteerryy
The product contains lead-acid batteries that must be processed according to applicable local regulations
concerning batteries The battery may be removed to comply with regulations and in view of correct disposal
11..22 BBeenneeffiittss
The Eaton Tripp Lite Series SmartPro uninterruptible power system (UPS) protects your sensitive electronic
equipment from the most common power problems, including power outages, voltage sags, impulsive
transients, line noise, and long-term under and over voltage conditions, frequency variations, switching
transients, and harmonic distortion
Power outages can occur when you least expect it and power quality can be erratic These power problems
have the potential to corrupt critical data, destroy unsaved work sessions, and damage hardware - causing
hours of lost productivity and expensive repairs
With the Eaton Tripp Lite Series SmartPro, you can safely eliminate the effects of power disturbances and
guard the integrity of your equipment Providing outstanding performance and reliability, the Eaton Tripp Lite
Series SmartPro’s unique benefits include:
• Standard communication options: one RS-232 communication port, one USB communication port, relay
output contacts
• Optional connectivity cards with enhanced communication capabilities
• Extended runtime with up to four Extended Battery Modules (EBMs) per UPS
• Remote on/off (ROO) and remote power off (RPO)
• Backed by worldwide agency approvals
11..33 SSppeecciiaall PPrreeccaauuttiioonnss
• The unit is heavy: wear safety shoes and use vacuum lifter preferentially for handling operations
• All handling operations will require at least two people (unpacking, lifting, installation in rack system)
• Before and after the installation, if the UPS remains de-energized for a long period, the UPS must be
energized for a period of 24 hours, at least once every 6 months (for a normal storage temperature less
than 25°C) This charges the battery, thus avoiding possible irreversible damage
• During the replacement of the Battery Module, it is imperative to use the same type and number of
element as the original Battery Module provided with the UPS to maintain an identical level of performance
and safety If there are any questions, donʼt hesitate to contact your local EATON representative
• All repairs and service should be performed by AUTHORIZED SERVICE PERSONNEL ONLY There are NO
USER SERVICEABLE PARTS inside the UPS
• For potential safety issue on defective UPS : DISCONNECT INTERNAL BATTERY for storage and
transportation
Introduction

4 Tripp Lite by Eaton S artPro Advanced User Guide 614-40194—Rev 01
Introduction

Tripp Lite by Eaton S artPro Advanced User Guide 614-40194—Rev 01 5
CChhaapptteerr 22 PPrreesseennttaattiioonn
22..11 SSttaannddaarrdd iinnssttaallllaattiioonn
Table 2 Installation Formats
Tower Installation Rack Installation
Table 3 Weights and Dimensions
Description (UPS) Weights (lb / kg) Dimensions (inch / mm) D x W x H
SMART2200RM2U
SMART2200RM2UN
65.3 / 29.6 23.7x17.2x3.4 / 603x438x85.5
SMART3000RM2U
SMART3000RM2UN
74.5 / 33.8 23.7x17.2x3.4 / 603x438x85.5
SMART750RMXL2U
SMART750RMXL2UN
44.5 / 20.2 17.6x17.2x3.4 / 448x438x85.5
SMART1000RMXL2U
SMART1000RMX2UN
44.5 / 20.2 17.6x17.2x3.4 / 448x438x85.5
SMART1500RMXL2U
SMART1500RMXLN
50.7 / 23.0 17.6x17.2x3.4 / 448x438x85.5
SMART2200RMXL2U
SMART2200RMXLN
65.3 / 29.6 23.7x17.2x3.4 / 603x438x85.5
SMART3000RMXL2U
SMART3000RMXLN
74.5 / 33.8 23.7x17.2x3.4 / 603x438x85.5
Description (EBM) Weights (lb / kg) Dimensions (inch / mm) D x W x H

6 Tripp Lite by Eaton S artPro Advanced User Guide 614-40194—Rev 01
Table 3 Weights and Dimensions (Continued)
BP48VRM2U 61.3 / 27.8 17.6x17.2x3.4 / 448x438x85.5
BP72VRM2U 89.1 / 40.4 23.7x17.2x3.4 / 603x438x85.5
22..22 RReeaarr ppaanneell
Table 4 SmartPro Model – Rear Panel Details
SMART750RMXL2U/SMART750RMXL2UN/ SMART1000RMXL2U/
SMART1000RMX2UN/ SMART1500RMXL2U/SMART1500RMXLN 1. UPS
2. Input AC power source
3. Pri ary group (critical equip ent)
4. Outlet group (progra able outlets)
5. USB co unication port
6. RS232 co unication port
7. Relay output contact
8. Connector for ROO (Re ote On/Off) control and RPO
(Re ote Power Off)
9. Slot for optional co unication card
10. Connector for additional External Battery Module
11. Connector for auto atic recognition of an additional
battery odule
12. Ground screw
SMART2200RM2U/SMART2200RM2UN/ SMART2200RMXL2U/
SMART2200RMXLN
SMART3000RM2U/SMART3000RM2UN/ SMART3000RMXL2U/
SMART3000RMXLN
BP48VRM2U - BP72VRM2U
Presentation

Tripp Lite by Eaton S artPro Advanced User Guide 614-40194—Rev 01 7
22..33 OOppttiioonnaall aacccceessssoorriieess
Table 5 Smart Pro Optional Accessories
Part number Description
BP48VRM2U
BP72VRM2U
Extended Battery Module
WEBCARDLXE UPS Web Manage ent Accessory Card SNMP Re ote Monitoring HTML5
Presentation

8 Tripp Lite by Eaton S artPro Advanced User Guide 614-40194—Rev 01
Presentation
