Ebac BD-150 User manual

BD-150 OWNERS MANUAL Page 1 of 12
Drawing No. :- TPC161
Issue :- 2
Date :- 23/06/03
EBAC MODEL BD-150 (1024500)
INDUSTRIAL DEHUMIDIFIER
OWNER’S MANUAL

BD-150 OWNERS MANUAL Page 2 of 12
Drawing No. :- TPC161
Issue :- 2
Date :- 23/06/03
INTRODUCTION
Designed for a wide range of applications, the BD-150 dehumidifier is a super high capacity
industrial unit which provides fast and efficient drying.
The BD-150 has a number of special features:
•Super high efficiency rotary compressor
•Temperature-sensitive microprocessor controlled defrost system
•Exterior epoxy powder-coated finish
•Rugged trolley for portability
•Extra long power cord
The fan draws the moist air through the inlet grille on the back of the unit, then through the cold
evaporator coil, which cools the air below its dew point. Moisture forms on the evaporator coil
and is collected in the condensate tray, which is equipped with a permanent drain. The cooled
air then passes through the hot condenser coil where it is reheated using the same energy
removed during the cooling phase, plus the additional heat generated by the compressor. The air
is, therefore, discharged from the dehumidifier at a slightly higher temperature with a lower
absolute humidity than that which entered. Continuous circulation of air through the
dehumidifier gradually reduces the relative humidity within the area.
The BD-150 dehumidifier is a rugged, reliable drying unit designed to operate effectively over a
broad range of temperature and humidity conditions.
The unit incorporates a welded and galvanized steel chassis and is finished in an epoxy coating
for resilience to damage caused by rough handling.

BD-150 OWNERS MANUAL Page 3 of 12
Drawing No. :- TPC161
Issue :- 2
Date :- 23/06/03
SPECIFICATIONS
MODEL: BD-150
HEIGHT: 36”
WIDTH: 24”
DEPTH: 25”
WEIGHT: 165 lb
AIRFLOW: 1114 CFM
POWER SUPPLY: 115V/ 60Hz/ 1 ph
FINISH: Powder-coated Epoxy
OPERATING RANGE: 41°F – 100°F
REFRIGERANT: R-22 (19 oz)

BD-150 OWNERS MANUAL Page 4 of 12
Drawing No. :- TPC161
Issue :- 2
Date :- 23/06/03
OPERATION
The following procedures should be followed to test the BD-150 for correct operation:
1. After unpacking, examine all external features to confirm damage-free shipment.
Report all defects and damage at once. Connect the power cable to a grounded 15
Amp electrical outlet. Connect a 12.5 mm inside diameter hose to the condensate
outlet pipe (positioned centrally, beneath the air inlet grille). Secure the hose using a
worm drive clip. The hose should at no point be raised higher than the outlet pipe.
Failure to observe this requirement will result in flooding of the dehumidifier.
2. Check dehumidification process as follows:
CAUTION: DO NOT REMOVE COVERS WHEN UNIT IS IN
OPERATION.
A. Place unit on a level surface.
B. Press the start button, DO NOT hold in this button for more than 1 second. The
unit will run.
C. Check that air is being delivered through the front outlet grille and the
compressor is running.
D. After 15/20 minutes an even coating of ice should cover the evaporator coil
(temperature below 68°F), droplets of condensate water should cover the evaporator
coil (temperature above 68°F)
E. After 45 minutes +/- 5 minutes, the dehumidifier will operate in the defrost mode
and the evaporator coil will clear of any ice. After 4 minutes +/- 1 minute, the
dehumidifier unit will again operate in the dehumidifier mode.
F. Allow the dehumidifier unit to run for a further 15/20 minutes and observe the
frosting/droplets on the evaporator coil.
If, after carrying out the above procedures, the unit does not appear to function properly, refer to
the Trouble Shooting section, which follows, or contact the Factory Service Center.
CAUTION: Once the unit has been switched off, wait at least five
minutes before restarting.

BD-150 OWNERS MANUAL Page 5 of 12
Drawing No. :- TPC161
Issue :- 2
Date :- 23/06/03
ROUTINE MAINTENANCE
WARNING: ENSURE THAT THE POWER CORD TO THE MACHINE
HAS BEEN DISCONNECTED BEFORE CARRYING OUT
ROUTINE MAINTENANCE.
To ensure continued full efficiency of the dehumidifier, maintenance procedures should be
performed as follows:
1. Replace or clean the inlet air grille as required. Clean the surface of the evaporator
and condenser coils by blowing the dirt out from behind the fins with compressed air.
Hold the nozzle of the air hose away from the coil to avoid damaging the fins.
Alternatively, vacuum clean the coils.
WARNING: DO NOT STEAM CLEAN REFRIGERATION COILS.
2. Check that the fan is firmly secured to the motor shaft and that the fan rotates freely.
The fan motor is sealed for life and therefore does not need oiling.
3. To check the refrigerant charge, run the unit for 15 minutes and briefly remove the
top cover. The evaporator coil should be evenly frost coated across its surface. At
temperatures above 70°F, the coil may be covered with droplets of water rather than
frost. Partial frosting accompanied by frosting of the thin capillary tubes, indicates
loss of refrigerant gas or low charge.
4. Check all wiring connections.
IF ANY OF THE PRECEDING PROBLEMS OCCUR,CONTACT THE EBAC SERVICE CENTER PRIOR TO
CONTINUED OPERATION OF THE UNIT TO PREVENT PERMANENT DAMAGE.

BD-150 OWNERS MANUAL Page 6 of 12
Drawing No. :- TPC161
Issue :- 2
Date :- 23/06/03
REPAIRS
1. Should an electrical component fail, consult the Factory Service Center to obtain the
proper replacement part.
2. If refrigerant gas is lost from the machine, it will be necessary to use a refrigeration
technician to correct the fault. Contact the Factory Service Center prior to initiating
this action.
Any competent refrigeration technician will be able to service the equipment. The
following procedure must be used:
a. The source of the leak must be determined and corrected.
b. The machine should be thoroughly evacuated before recharging.
c. The unit must be recharged with refrigerant measured accurately by weight.
d. For evacuation and recharging of the machine, use the crimped and brazed
charging stub attached to the side of the refrigerant compressor.
The charging stub should be crimped and rebrazed after servicing. NEVER allow
permanent service valves to be fitted to any part of the circuit. Service valves
may leak causing further loss of refrigerant gas.
3. The refrigerant compressor fitted to the dehumidifier is a durable unit that should
give many years of service. Compressor failure can result from the machine losing its
refrigerant gas. The compressor can be replaced by a competent refrigeration
technician.
Failure of the compressor can be confirmed by the following procedure:
a. Establish that power is present at the compressor terminals using a voltmeter.
b. With the power disconnected, check the continuity of the internal winding by
using meter across the compressor terminals. An open circuit indicates that the
compressor should be replaced.
c. Check that the compressor is not grounded by establishing that a circuit does not
exist between the compressor terminals and the shell of the compressor.

BD-150 OWNERS MANUAL Page 7 of 12
Drawing No. :- TPC161
Issue :- 2
Date :- 23/06/03
TROUBLESHOOTING
SYMPTOM CAUSE REMEDY
Unit inoperative 1. No power to unit
1. Check the power from power supply
panel
Little or no airflow
1. Loose fan on shaft
2. Fan motor burnt out
3. Dirty refrigeration coils
4. Loose electrical wiring
5. Fuse blown or circuit breaker
tripped
1. Tighten fan
2. Replace the fan motor
3. See Routine Maintenance Section
4. Check the wiring diagram to find
fault and repair
5. Replace the fuse or reset the
circuit breaker
Little or no water extraction
1. Insufficient air flow
2. Compressor fault
3. Loss of refrigerant gas
1. Check all of the above
2. Contact the Factory Service Center
3. Contact the Factory Service Center
Little or no defrost when
required
1. Faulty timer
2. Faulty by-pass valve
1. Contact the Factory Service Center
2. Contact the Factory Service Center
Unit vibrates excessively
1. Loose compressor
2. Damaged fan
1. Tighten the nuts on the compressor
mounts
2. Replace fan
Water flooding inside the
machine
1. Drain pipe blocked/frozen
2. Drain pipe too high
3. Crimped or blocked tubing
1. Clear the obstruction
2. Ensure that no section of the
drain hose is above the level of the
water outlet
3. Straighten, clear, or replace tubing
Ebac Industrial Products, Inc.
700 Thimble Shoals Blvd, Suite 109
Newport News, VA. 23606-2575
Tel: [phone] Fax: [phone]
Website www.ebacusa.com

BD-150 OWNERS MANUAL Page 8 of 12
Drawing No. :- TPC161
Issue :- 2
Date :- 23/06/03
BD-150
SPARE PARTS LIST
NUMBER DESCRIPTION PART NUMBER QUANTITY
1 Compressor (AK5512E) 3020116 1
2 Compressor Overheat Protector 3031728 1
3 Compressor Capacitor 3036337 1
4 Condenser Coil 3020727 1
5 Evaporator Coil 3020732 1
6 Filter Dryer 3020904 1
7 Fan Motor Assembly 3035774 1
8 By-pass Valve 3020810 1
9 Electronic Timer 1600500 1
10 Rotary Switch 3030555 1
11 Terminal Block 3031460 1
12 Solenoid Coil 3030420 1
13 Contactor 3034393 1
14 Power Cord 3035148 27ft
15 Drain Tray 1025305 1
16 Worm Drive 3086116 1
17 Drain Tubing 3944110 25ft
18 Trolley 1026004 1
19 Wheel 3050116 2
20 1” Starlock Washer 3082601 2
21 1” Starlock Washer Cap 3082602 2

BD-150 OWNERS MANUAL Page 9 of 12
Drawing No. :- TPC161
Issue :- 2
Date :- 23/06/03
LIMITED WARRANTY
Our products carry a one-year unconditional warranty against any defects in workmanship or
material. This warranty will cover all parts and labor required to repair your Ebac product. This
warranty is invalid if the unit has been abused, damaged, whether intentional or accidental, or if
any modifications have been made to the unit.
THE FOREGOING WARRANTY IS EXCLUSIVE AND IS ISSUED IN LIEU OF ALL
OTHER WARRANTIES (WHETHER WRITTEN, ORAL, OR IMPLIED) INCLUDING THE
WARRANTY OF MERCHANTABILITY AND THE WARRANTY OF FITNESS FOR A
PARTICULAR PURPOSE. EBAC INDUSTRIAL PRODUCTS, INC. DISCLAIMS ANY
LIABILITY FOR CONSEQUENTIAL DAMAGES, LOST PROFITS, OR INCIDENTAL
DAMAGES FOR BREACH OF ANY WRITTEN OR IMPLIED WARRANTY WITH
RESPECT TO THE FOREGOING DESCRIBED MERCHANDISE.
For Your Records: Model: ____________________
S/N: ______________________
Date Received: ______________
SAVE THIS SECTION FOR YOUR RECORDS
CLIP AND RETURN THIS CARD
PLEASE NOTE WARRANTY REGISTRATION
To ensure that your Ebac
Dehumidifier is accorded
the full coverage
provided by this
warranty, please
complete and mail this
card at your earliest
convenience.
Thank You
DATE
MODEL ___________ S/N ________________ RECEIVED ________________
OWNER __________________________________________________________
ADDRESS ________________________________________________________
CITY __________________________ STATE ________ ZIP _______________
COMMENTS ______________________________________________________
_________________________________________________________________
Ebac Industrial Products.
700 Thimble Shoals Boulevard, Suite 109, Newport News, Virginia. 23606-2575
