Ebac WRD-5000 Installation guide

Whole Room Dryer
10290MG-US
USER MANUAL
Drawing No. :- TPC345
Issue :- 2
Date :- 05/01/12
SPECIFICATIONS
Model WRD-5000
Part Number 10290MG-US
Height 11.5” (290 mm)
Width 23.5 (600 mm)
Depth 23.5 (600 mm)
Weight 40 lbs (18Kg)
Power 400W
Voltage 115 V
Airflow 2950 cfm (5000M³/h)
Fan Speed 1520rpm
Fan Blade Diameter 15.75” (400mm)
Noise Level <70dbA
IP Rating IP22
SAFETY PRECAUTIONS
WARNING- THIS FAN IS NOT FLAMEPROOF
♦DO NOT ALLOW CHILDREN TO PLAY WITH OR AROUND THE UNIT.
ENSURE THE UNIT IS INACCESIBLE TO CHILDREN WHEN NOT
ATTENDED.
♦DO NOT USE THIS UNIT IN AN ENVIRONMENT CONTAINING FLAMMABLE
FUMES
♦DO NOT USE THIS UNIT IF THE CABINET OR POWER CORD IS DAMAGED
♦DO NOT INSERT OBJECTS INTO ANY OF THE GRILLES ON THE MACHINE
♦DO NOT COVER OR OBSTRUCT AIRFLOW FROM THE GRILLES
♦DO NOT OPERATE THE UNIT WITH THE COVERS REMOVED
♦DO NOT ATTEMPT ANY REPAIRS SHOULD THE UNIT FAIL TO OPERATE
♦DO NOT STAND ON THE UNIT
♦DO NOT LIFT THE UNIT WHEN SWITCHED ON
♦DO CHECK THE PLUG ON THE EQUIPMENT MATCHES THE SUPPLY
♦DO USE THE UNIT FOR THE PURPOSE FOR WHICH IT WAS DESIGNED
♦DO ENSURE THE POWER CORD AND SUPPLY IS EARTHED CORRECTLY
♦DO USE A RESIDUAL CURRENT DEVICE “RCD” WHERE POSSIBLE
♦DO KEEP THE UNIT DRY. NEVER USE A HOSE OR PRESSURE WASHER
TO CLEAN THE UNIT.
CONTACT DETAILS
Telephone: [phone] Ebac Industrial Products Inc.
Fax: [phone] Thimble Shoals Blvd, Suite 109
Web: www.eipl.co.uk Newport News, VA. 23606-2575
Email: [email protected]

INTRODUCTION
The user manual tells you how to operate the WRD-
5000. Please read
thoroughly before operating the unit. If you have any questions please
contact our Customer Service Department at the address shown at the
back of this section or phone [phone]
IMPORTANT
Your WRD-5000 is packed in a plastic wrapping –
please ensure that it is
disposed of safely and where it will not be a danger to small children.
UNPACKING
Carefully remove the unit from its transit box and wrapping, and visually
check for any signs of transit damage. If there are any sign
s of damage
DO NOT attempt to operate the unit, call your supplier for advice. Retain
the packaging for further use, or dispose of it considerately.
OPERATION
The WRD-
5000 should only be operated in the horizontal position and with
the unit standing on a firm, level floor.
The WRD-5000
is designed to blow large quantities of air across wet
surfaces to speed up the drying process. The WRD-5000
should be
positioned in the centre of the area to be dried. Connect the power cord to
a suitable supply and the unit is ready for operation.
SWITCHING ON
The WRD-5000
ON/OFF switch is located on the side of the unit. To start
the fan, set the switch to the ON position (I). Since the WRD-
5000 has a
considerably high suction, always ensure that the inlet grille is kep
t free of
any obstruction during operation.
SWITCHING OFF
Set the ON/OFF switch to the OFF position (0)
. Turn off the power and
disconnect. Do not use the supply cord to adjust or move the unit. Use the
handle provided.
The unit is fitted with rubber feet
to allow it to be stored in the vertical
position.
ELECTRICAL CONNECTIONS
IMPORTANT
The wires in the mains lead are coloured in accordance with the following
code:
GREEN & YELLOW…………EARTH
WHITE………………………...NEUTRAL
BLACK...………………………LIVE
As the colours
of the wires in the mains lead of this appliance may not
correspond with the coloured markings identifying the terminals in your
own plug, proceed as follows.
The wire which is coloured Green and Yellow must be connected to the
terminal marked E or by the
Earth Symbol or coloured Green or Green and
Yellow. The wire which is coloured White
must be connected to the
terminal in the plug marked with the letter N. The wire which is coloured
Black must be connected to the terminal which is marked with the letter L .
You must safely dispose of the non rewireable plug once it has been
removed from the flexible cord. It is dangerous to attempt to inset the plug
into any electrical socket.
If the supply cord is damaged it must be replaced by qualified Ebac
personnel or other similar qualified persons in order to avoid hazard.
SERVICE
Always turn off the power and unplug the unit before removing any guards.
This machine should be serviced by qualified Ebac personnel or other
persons having technical competence in se
rvicing electrical equipment
following the instructions in the Ebac Service Manual.
WARNING
–
THIS APPLIANCE MUST BE EARTHED
