Echoflex Installation Guide
Tri-Zone Dimming Controller
Corporate Headquarters Middleton, WI, USA | Phone [phone]
Web echoflexsolutions.com | Email [email protected] | Support support.etcconnect.com
© 2021 Echoflex Solutions, Inc. Trademark and patent info: echoflexsolutions.com/ip
Echoflex intends this document to be provided in its entirety. Product information and specifications subject to change.
8189M2110 Rev A Released 2021-03
Overview
The ELED3 Tri-Zone Dimming
Controller is a wireless controller
with three channels to control
lights in larger spaces based on
room occupancy state, manual
switch operation, ambient light
level and gateway commands.
This document covers installation
of ELED3 Tri-Zone Dimming
Controller models. The Echoflex
Tri-Zone Dimming Controller
ELED3 Configuration Guide is
available for download at
echoflexsolutions.com.
The package contents includes the
controller and the installation guide.
Prepare for Installation
Echoflex recommends paying special attention to the installation
environment.
• High density construction materials and large metal appliances or
fixtures in the space may disrupt wireless reception.
• Mount the controller to an electrical junction box or a panel in a
location and at a height where it is not subject to tampering by
unauthorized personnel.
Supplies required to install the controller (not provided):
• Appropriately sized wire nuts
• Wire insulation
• Small cable ties
High voltage
model shown

Echoflex Installation Guide
Tri-Zone Dimming Controller
Tri-Zone Dimming Controller Page 2 of 8 Echoflex
IMPORTANT SAFEGUARDS
READ AND FOLLOW ALL SAFETY INSTRUCTIONS
.
.
• This product is suitable for use in dry locations where the ambient
temperatures is -5°C to 50°C (23°F to 122°F).
• Do not use outdoors.
• Do not mount near gas or electric heaters.
• Equipment should be mounted in locations and at heights where it is
not subject to tampering by unauthorized personnel.
• The use of accessory equipment not recommended by the
manufacturer may cause an unsafe condition.
• Do not use this equipment for other than its intended use.
• Servicing should be performed by qualified service personnel.
• Pollution Degree: 2.
SAVE THESE INSTRUCTIONS
WARNING: Risk of electric shock! This device utilizes high
voltage and should only be installed by a qualified installer or
electrician. Follow all local codes for installation. Before
terminating the AC power wiring verify that the main breaker
is in the off position and follow the proper lockout/tag out
procedures per NFPA Standard 70E.
AVERTISSEMENT: Risque de décharge électrique! Cette
appareil utilise une haute tension et ne doit être installé que
par un installateur qualifié ou un électricien. Suivez tous les
codes locaux pour l'installation. Avant de raccorder le câblage
du courant alternatif, vérifiez que le disjoncteur principal est
en position d'arrêt et suivez les procédures de Consignation/
Déconsignation prescrites par la norme NFPA 70E.
WARNING: For indoor use only! Must install to an electrical
junction box or wireway.
AVERTISSEMENT: Uniquement pour usage d'intérieur! Doit
être installé sur une boîte de raccordement électrique ou un
chemin de câbles.

Echoflex Installation Guide
Tri-Zone Dimming Controller
Tri-Zone Dimming Controller Page 3 of 8 Echoflex
Installation
All local codes and standard electrical practices should be observed. Ensure
that the junction box is clean and free of obstructions and that all wiring is
installed correctly.
Install the Controller
Mount the controller directly to the exterior of the junction box or panel
either at the electrical load or before the load in the circuit.
Review these instructions completely before installing the controller.
1. Locate the circuit breaker panel and terminate power to the circuit.
2. Remove the cover plate and other hardware from the junction box to
access the wiring.
3. Mount the controller.
4. Refer to the wiring diagram to connect the controller to line power,
neutral, and load wires. Use wire nuts on all connections and
individually cap any bare wires, except the orange antenna wire.
5. Connect the gray and the striped violet wires to the driver or ballast’s
dimming interface.
• Channel 1: violet/red stripe (daylighting with setpoint)
• Channel 2: violet/blue stripe (daylighting with offset from setpoint)
• Channel 3: violet/green stripe (non-daylighting)
6. Replace the electrical box cover plate.
7. Restore power to the circuit.
Note:
Follow applicable NEC and local electrical code
requirements when installing and powering the
controller.
Note:
The Micro USB port is for factory use only. Do not attach
cables or accessories to this port.

Echoflex Installation Guide
Tri-Zone Dimming Controller
Tri-Zone Dimming Controller Page 4 of 8 Echoflex
Wiring Diagram
Wiring Diagrams for Emergency Fixtures
Diagram 1 of 2
Tri-Zone Dimming Controller
Power
LED
Clear
Button
Learn
Button
Learn
LED
Black - Line,
120-277 VAC or 240-347 VAC
@ 50/60 Hz 500 mW max
White - Neutral
Red - Load, switched Hot
Channel 2 - Violet with Green stripe
Gray - Dimming COM
Max. Switching Load
(ELED3) 20 A @ 120-277 VAC, Electronic Ballast or LED Driver
(ELED3H) 20 A @ 240-277 VAC, Electronic Ballast or LED Driver
(ELED3H)16A@347VAC,ElectronicBallastorLEDDriver
Neutral, Hot to LED
Driver #2 and #3
Channel 1 - Violet with Red stripe
Channel 3 - Violet with Blue stripe
Antenna (orange)
Do not cut or cap
Max. Dimming Load: 100 mA sinking
Max. Impulse Voltage: 4000 V
Internal Relay: Type 1.C
Dimming output is Class 1 circuit Independently Mounted Control
for Panel Mount/Surface Mount
Common to LED Driver #2 and #3
0-10 V Dimming to LED Driver #2
0-10 V Dimming to LED Driver #3
Violet - Dimming 0 - 10 V
LED Driver #1
Tri-Zone Dimming Controller
Power
LED
Clear
Button
Learn
Button
Learn
LED
Normal Hot
Normal Neutral
Emergency Hot
Emergency Neutral
Normal
Emergency Load
LED Driver Neutral
LED
Driver
Hot
To LED Driver #2 and #3
Dimming Common to LED Driver #2 and #3
Normal Control Sense
LED Driver
#3
LED Driver
#2
LED Driver
#1
UL924 Emergency
Bypass Relay
(Echoflex Soluons
EREB-AP)
Ch 1 Dimming +
Violet with Red stripe
Ch 3 Dimming + Violet with Blue stripe
To LED Driver #2 and #3
Ch 2 Dimming +
Violet with Green stripe

Echoflex Installation Guide
Tri-Zone Dimming Controller
Tri-Zone Dimming Controller Page 5 of 8 Echoflex
Diagram 2 of 2
Electrical Terminations
Power to the controller is connected between the White (Neutral) and the
Black Line power: ELED3 (120–277 VAC) or ELED3H (240–347 VAC). The
Class 1 power limited dimming lines (gray and striped violet wires) are used
to provide 0–10 V intensity control of a dimming ballast or LED driver. The
orange wire is an antenna. Do not cut, cap or connect this wire. Use only UL
approved wire when making connections to the controller (see table below).
Connection Wire Color Specification
Load Red 14 AWG, 600 V
Neutral White 14 AWG, 600 V
Line Black 14 AWG, 600 V
Dimming 0-10 V Striped Violet 18 AWG, 600 V
Dimming GND Gray 18 AWG, 600 V
Tri-Zone Dimming Controller
Power
LED
Clear
Button
Learn
Button
Learn
LED
LED Driver
#2
LED Driver
#1
LED Driver
#3
LED Emier
#1
LED Emier
#2
LED Emier
#3
Baery Backup
#1
Baery Backup
#2
Baery Backup
#3
LED +
LED -
LED +
LED -
LED +
LED -
LED +
LED -
LED +
LED -
LED +
LED -
Normal Hot
Normal Neutral
ELED3 Load Ctrl
Neutral
Neutral ELED3(H)
Load Control and
Dimming Common
to LED Driver
#2 and #3
Ch 3 Dim +
Ch 2 Dim +
Ch 1 Dim +
Dimming Common
Neutral to Baery
Backup #2 and #3
Hot to Baery
Backup #2 and #3

Echoflex Installation Guide
Tri-Zone Dimming Controller
Tri-Zone Dimming Controller Page 6 of 8 Echoflex
Controller Interface
The controller interface has two tricolor LEDs and two buttons.
Tricolor LEDs
The Power and Learn LEDs can display red, green, or blue. LED color and
combinations indicate which of the three channels is providing information
via blink codes or is in an operational mode. See Blink Codes and
Operations on page 7.
Each of the channels can support occupancy sensors, switches or gateway
commands. A photo sensor can be linked to Channel 1 for daylighting with
setpoint, or to Channel 2 for daylighting with offset from setpoint.
• Red - Channel 1 - primary daylight with setpoint.
• Green - Channel 2 - secondary daylighting with offset from setpoint.
• Blue - Channel 3 - occupancy sensors, switches or gateway
commands. No photo sensor (non-daylighting).
Learn Button
The [Learn] button initiates Link mode for linking switches or sensors in
each of the controller’s channels. See the relevant switch or sensor
documentation for information on linking. Link mode times out after 30
seconds of inactivity.
Repeating the linking process for a device that is already linked to a
controller will unlink it from that controller.
Clear Button
The [Clear] button resets the controller either to its pre-commissioned state
or to its factory default state.
To reset to pre-commissioned state:
1. Press the [Clear] button until the Power and Learn LEDs start blinking.
2. Release the [Clear] button. The LEDs repeat a blink code by color to
indicate the type and number of devices linked to each channel at pre-
commissioning.
To reset to factory default state:
1. Press and hold the [Clear] button until the Power and Learn LEDs start
blinking. Continue to hold for 15 seconds until the LEDs turn solid.
2. Release the [Clear] button. The Power LED displays solid red to indicate
factory default state. All links are removed.

Echoflex Installation Guide
Tri-Zone Dimming Controller
Tri-Zone Dimming Controller Page 7 of 8 Echoflex
Test the Controller
Echoflex provides the controller in either a pre-commissioned state or a
factory default state.
• Pre-commissioned devices are linked, configured, and labelled
according to customer specifications. When powered up, the LEDs
repeat a blink code by color to indicate the type and number of
devices currently linked to each channel. See Blink Codes and
Operations on page 7. To test the relay(s), press the [Learn] button
or use a linked switch.
• In factory default state, when powered up, the Power LED displays
solid red to indicate the controller has no linked devices. To test the
relay(s), press the [Learn] button or link a switch. See relevant switch
documentation.
A maximum of 20 switches or sensors can be linked to one controller.
Blink Codes and Operations
The tables below describe the controller's blink codes and operating activity
for each channel by LED color. Long blinks=type. Short blinks=count.
Red is for Channel 1, Green is for Channel 2, and Blue is for Channel 3.
Blink Codes
*An occupancy sensor linked to any channel will appear to be linked to all three channels.
**A photo sensor linked to Ch1 or CH2 will appear to be linked to both channels.
Description Power LED Learn LED
Factory default
(links only) On solid (red) Off
Switch(es) 1 long blink followed by
short blinks counting switches Off
Occupancy
sensor(s)*
2 long blinks followed by
short blinks counting sensors Off
Photo sensor**
(max 1)
3 long blinks followed by 1
short blink counting sensor
(displays in Ch1 and Ch2)
Off
Central command 4 long blinks followed by
short blinks counting devices Off
Demand response 5 long blinks followed by
short blinks counting devices Off

Echoflex Installation Guide
Tri-Zone Dimming Controller
Tri-Zone Dimming Controller Page 8 of 8 Echoflex
Operations
Compliance and Listings
For complete regulatory compliance information, see the Echoflex Tri-Zone
Dimming Controller datasheet at echoflexsolutions.com.
Activity Power LED Learn LED Relay/Light
Link mode Blink On solid Toggle
Store link ID On 4 seconds On solid On 4 seconds
Clear link ID Off 4 seconds On solid Off 4 seconds
Factory default On solid One blink
(on power-up) On solid
FCC Part 15.231 Contains FCC ID: SZV-STM300U
This device complies with part 15 of the FCC rules. Operation is
subject to the following two conditions: (1.) this device may not
cause harmful interference and (2.) this device must accept any
interference received, including interference that may cause
undesired operation.
IC RSS-210
