Echomaster DVR-50-AHD User manual
Quick Start Guide
5CH AHD Digital Video Recorder
DVR-50-AHD
DVR-50-G-AHD
2
Quick Start Guide
www.echomaster.com
www.echomaster.com
Introduction
Box ContentsKey Features
u Up to 256GB of ash storage.
u Quad AHD inputs.
u IPC HD 5th channel input.
u Optional external trigger module (DVR-50-TH-CAB)
u Optional GPS (DVR-50-G-AHD)
u Lockable cover.
u DVR module
u GPS Antenna (DVR-50-G-AHD only)
u Power Cable
u GX16-RCA adaptors x 5
u User Manual
Thank you for purchasing the EchoMaster DVR-50-AHD Digital Video Recorder.
This system is specically designed for vehicle video surveillance.
DVR-50-G only
Wiring Diagram
Quick Start Guide
3
www.echomaster.com
Fitting Instructions
When choosing a mounting location please ensure that there is sufcient access to the front door to allow
it to open.
Also ensure that there are no electrical or uid lines behind any panels that are to be drilled that could
become punctured.
Once the mounting location has been decided secure the unit with 4 screws.
Connect the main power harness to +12V, IGN and Ground.
Make all camera connections before powering up the unit.
Connect and route the GPS antenna (DVR-50-G-AHD only) to a position where it has a clear an
unobstructed view of the sky. Any metalwork or large wiring looms above the antenna can obstruct
its operation.
Initial Set-up
Power the unit on with the door closed using the ignition.
Once it is powered up open the door and plug a mouse into the USB port.
Right click the mouse and then click on the icon.
Use the password ‘admin’ and click ‘login’.
You will now have access to all the various features and settings of the unit.
Once initial setup is complete: unplug the mouse, insert the SD card(s), close and lock the door and you
are ready to start using the product.
You will need to download the CEIBA software to a compatible PC to allow
playback. This can be downloaded from the following link:
http://echomaster.com/index.php?controller=attachment&id_attachment=660
You can also download the full Operating manual from the following location:
http://echomaster.com/index.php?controller=attachment&id_attachment=746
4
Quick Start Guide
www.echomaster.com
www.echomaster.com
Dimensions
167.3
157.8
81.6
24.9
146.3
140.1
33.2 50.0
137.3
125.0
54.2
45.4
Specications
DVR-50-AHD / DVR-50-G-AHD
Function Overview Preview, Recording, Playback, Locating
System OS Linux 3.0.8
Control Mode Easy Check, CP4, Mouse
Video Input 4 channels AHD+1 channel 720P
Output 1 channel
Total Resource PAL:
(4x25)FPS WD1+30FPS 720P(IPC) or (4x12)FPS 720P(AHD)+30FPS
720P(IPC)
NTSC:
(4x30)FPS WD1 +30FPS 720P or (4x15)FPS 720P(AHD)+30FPS
720P(IPC)
Video Signal Standard Electrical level: 1Vpp Impedance: 75Ω NTSC/PAL
Audio Input 5 channels (1 channel IPC audio input)
Output 1 channel
Audio Signal Standard Electrical level: 2Vpp Input impedance: 4.7kΩ
Display Display Split 1/4/9
OSD GPS information, alarm, vehicle no, speed, date/time
Operation Interface Semi-transparent GUI
Quick Start Guide
5
www.echomaster.com
Specications (continued)
Recording Video/Audio Compression Video: H.264
Audio: ADPCM
Image Resolution Analog:
PAL: 720P(1280X720), WD1(928X576), WHD1(928X288), WCIF(464X288),
D1(704X576), HD1(704x288), CIF(352x288);
NTSC: 720P(1280X720), WD1(928X480), WHD1(928X240),
WCIF(464X240), D1(704x480), HD1(704x240), CIF(352x240);
Digital: 720P(1280X720),
Image Quality 1-8 levels adjustable (1 is the best)
Recording Mode Boot up/Manual/Schedule/Alarm
Pre-recording 0-60 minutes
Post-recording 0-30 minutes
Mirror/Dual Recording Support
Playback Playback Channel 1 channel by local playback
Search Mode Date/time, channel, event
IPC Ethernet 6-pin M12 (10/100M x 1, PON power supply)
Locating GPS Location tracking, speed detection and time sync
Storage SD Card Max supported 256GB SD card, SD card x 2
Interface USB USB2.0 x 1
RS232 RS232 × 1
Sensor 8 inputs, 2 outputs
Speed 1 channel pulse speed detection
Intercommunication I mic interface
Interface CP4 Optional
Power Input DC8-36V,Ignition signal
Output 5V@500mA
Max Power Consumption 29W
Standby Power Consumption ≈0W
Other Water Proof Rate IP54
Physical
Characteristics
Dimension (L × W × H) 167.3mm x 146.3 mm x 54.1mm
Weight 0.83Kg
Environment Operating Temp -40°C ~ +70°C
Relative Humidity 8%-90% (No Condense)
6
Quick Start Guide
www.echomaster.com
www.echomaster.com
Echomaster is a brand of AAMP Global
www.echomaster.com
15500 Lightwave Drive, Suite 202
Clearwater, Florida 33760
Unit 25, Woolmer Way, Bordon
Hampshire, GU35 9QE, United Kingdom
REV 130617
