Echomaster EFS-ODC User manual
INSTALLATION MANUAL
PRODUCT # EFS-ODC
2 3
tel - 866-931-8021
tel - 866-931-8021
Thank you for purchasing the
EchoMaster
EFS-ODC
WHAT’S INCLUDED:
With EFS-ODC, you can add connected cameras to your eet monitoring
system. Featuring interior and exterior facing cameras, it delivers on-demand
live views of your vehicles’ and their surroundings through the EchoMaster eet
application, as well as auto-record to provide a video witness during incidents.
Please ensure you read and understand all aspects of the manual before
installing or using the EchoMaster products.
• EFS-ODC INSTALLATION MANUAL AND QUICK START GUIDE
• EFS-ODC CAMERA
• ODB2 PLUG-IN POWER CABLE
• VARIOUS WINDSHIELD MOUNTING BRACKETS
• INSTALLATION TRIM TUCK STICK
• WIRE TIES
• SPARE SUCTION CUPS
PRIOR TO INSTALLATION
Prior to installation, please note the device’s serial number. This
number will be needed for activation and connection to your
EchoMaster Fleet website. Please follow the instructions in the
included activation card for nal set up.
4 5
tel - 866-931-8021
tel - 866-931-8021
FEATURES
• Broken glass detection
• 2.4-inch(diagonal) LCD touch screen
• Interior and exterior facing camera
• Impact-crash-motion detection
• Anti-theft security oodlight
• Built-in Accelerometer
• Instant video alerts
• Plug and play installation
• 3 Axis accelerometers and gyroscope
• 72 hours of recording while vehicle is off
REQUIRED TOOLS
• Trim stick
• Wire Cutter
• Wire Ties
VEHICLE COMPATIBILITY
The EFS-ODC Camera is intended to be an easy plug and play installation
for passenger vehicles built after 1996 with an OBD communication port.
INSTALLATION GUIDE
INSTALLATION PREPARATION INSTRUCTION
STEP 1:
EFS-ODC
Locate the vehicles ODB2 diagnostic port, the port is located
under the driver’s side lower dashboard area usually below the
steering column.
Part # Description
EFS-OBDYHAR OBD2 Y Cable for discrete installation
EFS-OBDDHHAR OBD2 Dual Head cable for GPS and camera
installations
EFS-9P1HAR 9 Pin Y (Black Transport truck style port)
EFS-9P2HAR 9 Pin Y (Green Transport truck style port)
VEHICLE COMPATIBILITY
EchoMaster also has several accessory installation Harness’s available for
GPS and Camera installation and heavy-duty transport trucks.
6 7
tel - 866-931-8021
tel - 866-931-8021
POWER CONNECTION
STEP 2:
Insert the EchoMaster EFS-ODC power cable into the vehicle’s diagnostic
port rmly pressing to ensure a good connection.
CABLE ROUTING
STEP 3:
Route the EFS-ODC power cable up the driver’s side dashboard towards the
center of the windshield using the Trim stick provided in the kit and tuck the
extra wire into the dashboard and windshield seem.
STEP 4:
Route the power cable wire up the back of the windshield mount pressing
the cable into the groove in the bracket.
Attach the camera to the magnetic mount.
SETTING UP THE CAMERA
STEP 5:
Once everything is connected start the vehicle and allow it to run for 5
minutes allowing the Camera time to connect to the cellular network.
Connect to the EchoMaster eet monitor website and conrm that you can
view the Live video stream feature NOTE: You must associate the device
with a vehicle within the EchoMaster eet monitor website
Cellular 4G LTE
Bluetooth Low Power 4.2
Audio Stereo Mic / Mono Speaker
Languages English
Power 12 - 14 Volts DC
Camera Resolution 1440p Exterior and 720p Interior
Auto Shut Off 72 hours with key off
Operating Temperatures -4° F - 120° F
Internal Video Recording Time 120 Hours
SPECIFICATION CHART
8 9
tel - 866-931-8021
tel - 866-931-8021
1. Login to emeetmonitor.com
ASSOCIATE THE CAMERA WITH A VEHICLE
2. Select Devices from
the left menu
7. In the list of
devices, nd the
device you just
installed. Click the
carrot on the right
side to open that
device, and assign it
to the vehicle you just
added.
8. Once the device
has been assigned,
click back to the Map
view and click on the
camera icon on that
vehicle to ensure that
the camera view is
working.
