EcoFlow EF DELTA User manual

For Customer Support
Please Contact us at:
[email protected]
User Manual
SOLAR CHARGE
X-STREAM
CHARGE
OVERLOAD
PROTECTION
20A Max
WARNING
1. Keep the product dry and do not expose EF DELTA or the
accessories to high heat.
2. Never disassemble, puncture, subject the unit to a large shock or
crush force, or incinerate the EF DELTA or the accessories.
3. Do not attempt to disassemble the EF DELTA – there are no user
serviceable parts
4.Ensure you recycle and dispose of EF DELTA in accordance with
local regulations.
5. When handling the EF DELTA, pay attention to safety: Handle with
care and ensure you have a firm grip on the product do not drop it.

CONTENTS
1
EF DELTA USE CARE AND SAFETY GUIDE
4
EF DELTA’S FEATURES
LCD DISPLAY
SOLAR PANEL CONNECTION
ENTRY-LEVEL UPS AND SERIES MODE
TECHNICAL SPECIFICATIONS
HOW TO RECHARGE EF DELTA
FAQs
WHAT’S IN THE BOX
OPTIONAL
6
10
11
13
14
14
15
15

To turn ON/OFF EF DELTA, you need to PRESS & HOLD the Power Button. To turn on the AC power
outlet, you need to PRESS & HOLD the AC Button after turning on EF DELTAThis is designed
purposefully: it will save the battery life, so that your EF DELTA’s power is available when you need it.
EF DELTA USE CARE AND SAFETY GUIDE
Congratulations!
You now own the best quality Portable Battery Generator in the world. This pamphlet is short and is
meant to help you. Please take some time to read it before using the product.
This User Guide has been written specifically for EcoFlow Delta units for sale in Australia and is not
applicable to Delta units sold in other countries. It must be read completely and understood prior to
operating or maintaining the EcoFlow Delta (Delta) or (the Product). It contains important information
regarding User safety, its correct use and care. The Delta is a well-designed electrical product capable of
producing both DC power and 240v AC power similar to that produced by household power outlets. The
User must take the same care and precautions when using the Delta as would be taken when using your
normal household power and appliances. Do not allow children to use the Delta. Failure to follow the
operating procedures set out in this user manual could void the product warranty.
NOTICE
Introduction
1
power a free life
WARNING
Read the ENTIRE user manual to become familiar with the features of this product before operating.
Failure to operate the product correctly can result in damage to the product, personal property and
cause serious injury. DO NOT use the product with incompatible components or alter the product in
any way. This User Manual includes instructions for safety, operation and maintenance. It is
important to read and follow all the instructions and warnings in the User Manual prior to assembly,
setup or use, in order to operate the product correctly and avoid damage or serious Injury.
Glossary
The following terms are used in this document to indicate various levels of potential harm when operating
this product and other important information.
The procedures, if not properly followed, can create a possibility of physical property damage BUT little or
no possibility of injury.
NOTICE

2
power a free life
The procedures, if not properly followed, can create the possibility of physical property damage AND a
possibility of serious injury.
CAUTION
The procedures, if not properly followed, can create the possibility of property damage, collateral damage,
or serious injury OR create a high possibility of serious injury.
WARNING
Safety Guidelines
WARNING
To avoid fire, serious injury, or property damage, follow the following safety rules and guidelines
when using, charging, or storing your batteries.
1. DO NOT allow the Delta to come into contact with any kind of liquid. DO NOT leave the Delta out in the
rain, dew or near a source of moisture. DO NOT drop the Delta into water. If the Delta comes into contact
with water, chemical decomposition may occur, potentially resulting in the battery catching on fire, and
possibly leading to an explosion.
2. The Delta Unit is not User Serviceable. DO NOT attempt to disassemble the Delta and never attempt to
replace the internal batteries with Non- EcoFlow batteries. EcoFlow takes no responsibility for any
damage caused by unauthorised disassembly of the Delta or any damage caused as a consequence of
repairs attempted. Repairs may only be conducted by EcoFlow, or its authorised Service agents.
Contact EcoFlow support at support@ecoflow.com for further assistance.
3. DO NOT use or charge a swollen, leaky, or damaged or malfunctioning Delta. If your Delta is functioning
abnormally, contact EcoFlow support at support@ecoflow.com for further assistance.
4. The Delta must only be used at temperatures between 0 and + 45 degrees centigrade. Discharge or
Charging of the Delta should not be undertaken outside these temperature ranges. Use in environments
above 45 degrees centigrade can lead to fire or explosion. Using the Delta below 0 degrees centigrade
will severely reduce the product’s performance. Allow the Delta to return to a normal operating
temperature before use.
5. DO NOT use the Delta in strong electrostatic or electromagnetic environments. Otherwise, the Delta
control board may malfunction and cause a serious damage to the Delta or a serious accident during use.
6. DO NOT disassemble or pierce the Delta in any way. Otherwise, it may leak, catch on fire, or explode.
7. Electrolytes in batteries used in the Delta are highly corrosive. If any electrolytes come into contact with
your skin or eyes, immediately wash the aected area with fresh running water, and then see a doctor
immediately.
8. DO NOT use a Delta if it has been involved in a crash, has been dropped or a suered a heavy impact.
Contact support@ecoflow.com for further assistance
9. If the Delta falls into water during use Do Not touch the Delta or the water, as lethal Voltages may be
present. Only if safe the Delta should be removed form the water as soon as possible and put it in a safe
and open area on a non-combustible surface. Maintain a safe distance from it until it is completely dry.
Delta Use:

9. Never use it again and contact support@ecoflow.com for further assistance. DO NOT heat the Delta in
an attempt to dry it out. Put out any fire using sand or a dry powder fire extinguisher.
10. DO NOT put the Delta in a microwave oven or in a pressurized container.
11. DO NOT place heavy objects on the Delta.
12. DO NOT reverse connect the positive and negative terminals of the DC Charging cable to any charging
source. Any abnormal charging of the battery based on this reverse polarity connection may cause
overheating, explosion, or fire, it will damage the Delta and will void the product warranty.
1. The Delta contains a Lithium Ion battery pack. If the owner wishes to dispose of the Delta it is essential
that this be done only after a complete discharge. DO NOT place the Delta in your regular garbage bin.
Strictly follow your local regulations regarding the disposal and recycling of Lithium Ion batteries.
1. Always use a EcoFlow approved charge cable. EcoFlow takes no responsibility if a battery is charged
using a non EcoFlow charge cable.
2. Never leave a battery unattended during charging. DO NOT charge a battery near fire, other heat
sources, or flammable materials or on flammable surfaces such as carpet or wood.
3. DO NOT charge a battery immediately after a long heavy load, because the battery’s temperature may
be too high. DO NOT charge a battery until it cools down to near room temperature. The battery may be
unable to charge under a tempreature outside the range of 0 to 40℃. The ideal charging temperature
range is 22 to 28 ℃.
Charging the Delta:
1. Keep the Delta out of the reach of children and pets.
2. To ensure the Delta is ready when needed charge the battery for long-term storage.
3. Fully charge and discharge the battery at least once every 3 months to maintain battery health.
4. DO NOT leave a battery near heat sources such as a furnace or heater. DO NOT leave a battery inside of
a vehicle on hot days.
5. Keep the batteries dry. Never store that Delta in a wet location. It is essential that the internal batteries
are not exposed to water or other source of moisture.
6. DO NOT store the Delta for an extended period after fully discharging it. Doing so may over-discharge
the battery and cause irreparable battery cell damage. Doing this will void the warranty
7.Never store the Delta in environments below -20c or above 60c.
Storage and Maintenance:
Delta Disposal:
The Delta is not suitable for taking on an airline flight either as hand or checked luggage, as it contains a
Li-ion battery pack with a capacity above 160Wh, and therefore is prohibited from carriage by airline
regulations
Travel Notice:
3
power a free life

EF DELTA’S FEATURES
7. AC On/O Switch (Press and Hold
for ON/OFF) Ac Output Indicator Light
8. Ventilation Fan Vents (DO NOT Block
or inhibit airflow in any way)
9. 4 Australian 3 Pin AC Outlets.
10. DC Output Outlet and Indicator
9
1
3
6
25
11 12 13
10
7
4
8
ON/OFF
OUTPUT OUTPUT
DC ON/OFF
USB-A FASTCHARGE
ACON/OFF
CAR POWER
This provides information on the charging, discharging and other conditions of the Delta unit.
1. LCD Display
Charge a wide array of devices shuch as your iPhone, Android Phone, Tablet, Go, Pro, Portable Speakers or
anything that needs to be changed through a USB-A Port. The USB-A Output Indicator light will automatically
light up when a USB-A Port is in use.
2. USB-A Output Ports
11. DC Input (Charging) Port. DC Input
from Solar or Car Cigarette Lighter DC
Output
12. 3 Pin AC Input (Charging) Port.
13. Overload Protection/Reset Switch
*EcoFlow has designed dierent AC Output sockets
in accordance with the local regulations of dierent
countries.
1. LCD Display
2. USB – A Ports
3. USB – C Output Ports
4. DC ON/OFF Switch (Press and
Hold to switch ON/OFF DC) DC
Output indicator light
5. Fast Charge USB – A Output Ports
6. Main Power On/O Button
Full Sine Wave
4
power a free life

Charge Computers or other devices requiring USB C charging ports. When the USB-C port is in use the
indicator will light up.
3. USB-C Output Ports
These ports have a higher power output that the regular USA-A ports and will charge devices at twice the
rate.
5. Fast Charge USB-A Output Ports
Press and hold the main power button to switch the Delta on or o. When the Delta is turned on the LCD
display screen will light up. After a period of time (usually 5 minutes) the display screen will enter idle mode
and switch itself o to conserve power. This doesn’t turn o the internal battery and the Delta is still
working. To wake up the display screen briefly press the on/o button and the screen will come to life. The
power indicator light will light up when the Delta senses any of its ports come into use, e.g. a device is
plugged into any of the output ports. If the Delta is left idle with nothing plugged into any of the output
ports for an extended period of time it will switch itself o completely to conserve battery life.
6. Main Power On/O Button
The AC Power Button regulates the flow of AC output from the Delta. Please press and hold the AC button
to enable or disable the flow of AC power. The AC indicator light will be on when the AC power is active but
will turno after 12 hours in idle mode. The output is pure sine wave AC power very closely matching the AC
power output from regular Australian/New Zealand mains power household outlets. It is therefore lethal if
not used correctly and it is essential that users take all the same precautions when using this AC power as
they normally would in a household environment. The Delta uses a power inverter to produce the AC power
and this device consumes battery power just to operate in idle once switched on. It is therefore sensible to
conserve battery life by switching o the AC power and unplugging any AC power cords when AC power is
not required.
7. AC On/O Switch - (Press and Hold for ON/OFF) AC Output Indicator Light
The Delta produces heat internally as it operates to supply power. The Delta fans cool the internal
components including the battery pack by circulating air to prevent overheating. The Delta fans will
operate at dierent speed levels depending on the environmental conditions and the power output load
that the Delta is producing. You will note that the fans are always in operation when the AC power is
activated. This is one of the reasons that the AC power should be turned o when not needed, as this will
prolong battery life.
8. Ventilation Fan Vents (DO NOT Block or inhibit airflow in any way)
These outlets should be used with care and respect. The Delta is capable of producing up to 1800w of AC
power on a continuous basis and higher surge loads for short periods of time. This level of power is
sucient to power many appliances and power tools. This makes Delta a very useful and flexible source of
portable AC power. It does however have design limitations. The Delta may not power certain appliances
9. 2 Australian 3 Pin AC Outlets.
First Press and hold the Power Button (6.) to turn on the Delta unit and then press and hold the DC power
button to turn on the DC power. When finished press and hold the DC button to turn o the DC power. In
certain cases devices may have a very low power draw. In this case the DC power may sleep as it detects a
lack of use. To ensure this doesn’t happen you can connect an another device to charge from to the USB
port and this will keep the Delta awake.
4. DC ON/OFF Switch (PRESS & HOLD to switch ON/OFF) DC Output Indicator
5
power a free life

LCD DISPLAY
i
j
The DC outlet allows users to run 12v items. The DC outlet indicator light will illuminate when this port is in
operation.
10. DC Output Outlet and Indicator.
DC Input from Solar or Car Cigarette Lighter DC Output. The Delta is designed to accept solar inputs of up to
10 amps and not exceeding 65 volts. The Delta has a power input limit of 400w. If you are using the Delta
110w panels, up to 3 panels may be connected in series. It is absolutely essential that the positive and
negative connections from the panel to the Delta charging cable are correctly made. Reverse polarity will
case damage to the DC power input electronics and this is not covered by warranty. If in any doubt, please
seek support from a qualified electrician to ensure damage does not occur. This DC Charging port can also be
used to charge the Delta from a vehicle cigarette lighter DC power outlet of a maximum of 10 amps.
11. DC Input (Charging) Port.
Connect the Delta AC charging cable to this Delta AC input port and the plug to an Australian 240v 50HZ
mains power outlet and the Delta will commence charging. The Delta is capable of charging quickly and will
set the charge rate based on the temperature and state of charge of the internal battery pack. If the Delta
has recently been discharged under high load for an extended period of time the charging function will be
disabled until the internal battery pack returns to a normal temperature. If the Delta will not charge this is
not a defect it is a safety feature, wait until the internal battery pack returns to room temperature and try
again.
12. 3 Pin AC Input (Charging) Port.
The Delta has an entry –level UPS function, so that you can use the Delta as a backup with you household
or portable computer. If the computer is plugged into the Delta while the Delta is plugged into the mains
power it will automatically change from pass-through mode to battery mode should the mains power be
interrupted. The cutover time is approximately 50ms. This is not as quick a cut over time as dedicated UPS
systems and please note that the Delta does not support systems requiring 0ms response times so if this is
the level of uninterrupted power that your computer system requires please don’t use the Delta for this
purpose.
13. Overload Protection/Reset Switch
that have very large start up power loads. This is not a design defect and the Delta will go into overload
protection mode. To reset the Delta disconnect the power cord. DO NOT exceed the 1800w limit by
plugging in Devices that require more than 1800w just to “test” the Delta. Damaged caused by overloading
the Delta is mistreatment and will void the warranty.
6
power a free life

Minute-level accuracy of the amount of charge time left in EF DELTA based on the current output level. Note
this is an approximate calculation and values may vary depending on the battery state of charge as the
Battery approaches either fully charged or fully discharged.
a. Remaining Charge Time
If the ring on EF DELTA’s display screen is flashing, please immediately discontinue using the Delta, switch it o
and contact our Product Experts at support@ecoflow.com.
b. Battery Failure Warning
Shows the remaining battery percentage. If your battery drops below 0%, the battery segment on the screen
will start to blink. When this happens, please immediately recharge your EF DELTA.
c. Battery Level Indicator
Indicates that EF DELTA’s battery temperature is too high. All input and output functions will stop and the
fan will start working. Please unplug the devices connected to the Deltas output ports, bring the EF DELTA
to a cooler location, definitely out of direct sun, and wait for the temperature to be within the working
range before restarting the EF DELTA. Once the internal battery cools down, EF DELTA will resume normal
operation.
Indicates that the battery temperature of EF DELTA is too low and the Delta is too cold to safely discharge
or recharge. All inputs and outputs will stop functioning at this state. Please bring the EF DELTA to a
warmer location and wait for the temperature to be within the working range before restarting the EF
DELTA.
The fan speed of the EF DELTA directly correlates with the load and the ambient temperature. The higher
the load or the ambient temperature, the higher the fan speed will be.
e. Fan Indicator
Shows EF DELTA’s current power input level in watts.
g. Current Input
Shows EF DELTA’s current power output level in watts.
h. Current Output
There are 2 levels of Overload Protection: Software Level: when the power pulled from the AC outlets
steadily exceeds the maximum AC power output, the overload indicator and AC indicator will flash
simultaneously for 15 seconds and the AC output will automatically and immediately be turned o. Other
ports will continue to work; Battery Level: when the power pulled from the AC outlets exceeds the
maximum AC power output, the overload indicator and AC indicator will flash simultaneously for 15
seconds and EF DELTA will automatically and immediately be turned o. Overload warning - There are two
types of overload protection. First level of protection: When any of the DC sockets exceeds the maximum
current limit or the output of any AC sockets exceeds the maximum AC power output (Overload of 1-10%
for 10min; overload of 11-20% for 1min; overload of 21-50% for 10s; overload of 51-100% for 100ms), and the
DC power output exceeds the maximum current, the overload indicator and the indicator of the
corresponding socket will flash at the same time for 15s. Power supply to the socket will be cut o, while
other sockets will continue to work. Second level of protection: When the power output from any DC or AC
i. Overload Warning
f. High Temperature Indicator
d. Low Temperature Indicator
7
power a free life

sockets or the car power outlet exceeds the maximum power output of the battery, the overload indicator
and the indicator of the corresponding socket will flash at the same time for 15s. The EF DELTA will shut
down automatically. Remove the device causing the overload and restart the EF DELTA to resume operation.
Indicate which ports are in use.
j. Port Usage Indicators
EF DELTA display screen indicates various device protection scenarios with dierent icons and their
combinations.
USB-A icon flashes together with Overload icon.
Resume normal operation by pulling out electrical
appliances and waiting for 10 seconds.
USB-C icon flashes together with High-tempera-
ture icon. Resume normal operation of the
interface by cooling down the machine.
Overload icon flashes. Resume the device to
normal operation by pulling out electrical
appliances and restarting.
Recharging time, Exclamation and High-tempera-
ture icons flash together. This happens usually
after a heavy battery use. Recharging can be
resumed after battery is cooled down.
Exclamation and High-temperature icons flash
together. Power supply can be resumed after
battery is cooled down.
Exclamation and Low-temperature icons flash
together. Power supply can be resumed soon
after moving the device to a warmer place.
Recharging time, Exclamation and Low-tempera-
ture icons flash together. Recharging can be
resumed by warming up battery moderately.
Recharging time, Exclamation and Overload icons
flash together. Pull out the plug, restart the device
and replug. If the lights keep flashing, please
contact our product specialists via support@eco-
flow.com.
. Protection Information Instruction
USB-A Overcurrent
Protection
USB-C High Temperature
Protection
Device Overload
High Temperature
Discharge-protection
High Temperature
Recharge-protection
Low Temperature
Discharge-protection
Low Temperature
Recharging-protection
Overcurrent
Recharging-protection
8
power a free life

AC icon flashes. Try to restart the device. If the
light keeps flashing, please contact our product
specialists via support@ecoflow.com.
AC and Overload icons flash together. Resume
operation by pressing ON/OFF to restart AC 10
seconds later. Please note that electrical applianc-
es should be operated within rated power.
AC and High-temperature icons flash together.
The machine will be resumed to normal operation
after it is cooled down.
AC and low-temperature icons flash together.
Recharging can be resumed by warming up EF
DELTA moderately.
AC and Fan icons flash together. Shut down the
device to clean and restart the machine if the fan
is blocked. If the lights keep flashing, please
contact our product specialists via support@eco-
flow.com.
Car and Overload icons flash together. Resume
operation by restarting the device. Please note
that electrical appliances should be operated
within rated power.
When temperature/XT60 Interface is recharging
at a High Temperature, Car and High-temperature
icons flash together. The machine will be resumed
to normal operation after it is cooled down.
Car icon flashes. Try to restart the device. If the
icon keeps flashing, please contact our product
specialists via support@ecoflow.com.
Exclamation and Overload icons flash together.
Resume operation by pulling out electrical
appliances and restarting the device. Please note
that electrical appliances should be operated
within rated power.
Exclamation icon is on. Try to restart the device. If
the light keeps flashing, please contact our
product specialists via support@ecoflow.com.
Exclamation icon is on. Try to restart the device. If
the light keeps flashing, please contact our
product specialists via support@ecoflow.com.
Overcurrent
Discharging-protection
Communication Failure
between Main Board and
BMS
Battery Cells Failure
Communication Failure
between Main Board and AC
Inverter Output Overload
Inverter High
Temperature Protection
Inverter Low
Temperature Protection
Fan Blockage
Car Charger
Overcurrent/Overload
Car Charger High
Temperature Protection
Communication Failure
between Main Board and
MPPT
9
power a free life

XT60 Connector
EF DELTA Charging Port
SOLAR PANEL-21.6V X3
MC4 Connector
EF DELTA
For connection of a single panel, please refer to the instructions of the solar panel. These instructions are
intended for the serial connection of up to three panels and the parallel connection of up to six panels. EF
DELTA accepts DC input of 10-65V. When the input exceeds 65V, EF DELTA will trigger overload protec-
tion. Excessive voltage may cause damage to the product and will void the warranty. Users should follow
all the instructions in the manual, if the number or connection of the solar panels is not compliant with the
specifications, we will not be responsible for providing free repair services for any damage to the product
even during the warranty period.
How to recharge the EF DELTA using solar panels?
Users can connect 1-3 pieces of solar panels (Up to a maximum of 3 panels) in series as shown in the
following picture. Connect one end of the panels to the MC4 port and connect the other end to our MC4 to
XT60 conversion cable. Connect the XT60 cable to the EF DELTA’s XT60 input to charge the device.
1. Serial connection (Recommended)
Users can connect up to 2 sets of solar panels in parallel to the MC4 port as shown in the picture. If you
want to connect 6 solar panels, you can split -them into 2 sets of 3 solar panels connected in series and
connect the 2 sets of solar panels in parallel. Connect them with our MC4 to XT60 conversion cable and
connect XT60 cable to the EF DELTA’s XT60 input to charge the device. The parallel connection cable is an
optional accessory that needs to be purchased separately.
2. Serial and parallel connection (Professional solution)
SOLAR PANEL CONNECTION
10
power a free life

XT60 Connector
EF DELTA Charging Port
* Users have to buy the solar panels and other
parallel connection accessories seperately.
Solar MC4 parallel connection cable
EF DELTA
SOLAR PANEL-21.6V X6
Users can buy universal solar panels with MC4 connections to power EF DELTA, as long as the voltage and
current (10-65V DC, 10A max) comply with the specifications of EF DELTA, the panels will be able to
recharge EF DELTA through the MC4 to XT60 conversion cable. However, EcoFlow will not be responsible
for providing free repair services for any damage to the product caused by the quality issue or improper
operation of the third party solar panels, even during the warranty period. It is essential that users check the
positive and negative connections are correct. Reverse polarity connections are a common mistake, will
damage the Delta and will not be covered by the warranty.
3. EF DELTA supports the use of third party solar panels (DIY solution)
When EF DELTA is used under UPS or multi-machine series mode, EF DELTA's X-STREAM system supports
an entry-level UPS (Uninterruptible Power Supply) function, and you can use the EF DELTA AC socket
while the device is connected to a wall socket with AC power supply (The AC power comes from the grid,
not the battery). When the grid loses power suddenly, the device can automatically switch to EF DELTA
battery power mode in <50ms to ensure your work is uninterrupted provided the needs of your computer
do not require a faster cutover speed. It the responsibility of the user to determine whether this cut over
time is sucient to ensure uninterrupted performance of their system.
Precautions when using EF DELTA UPS and multi-machine series mode
ENTRY-LEVEL UPS AND MULTI – MACHINE
SERIES MODES
11
power a free life

Users can connect the AC charging cable of EF DELTA to the power grid and connect a device to EF
DELTA and turn on the AC switch to automatically enter the entry-level UPS mode. When the external
power is cut o, power will be supplied from the battery immediately to protect connected devices.
1.Entry-Level UPS User Guide
Note: (Before connecting multiple Delta’s together in this mode, All machines must be fully charged)
Users can connect multiple fully-charged EF DELTAs (Up to 3) in series using the AC charging cables to get
continuous power and supply appliances with high output requirements for up to 1.8 hours. In this mode, do
not connect EF DELTA to the power grid using an AC charging cable, or the overcurrent protection (<20A)
may be triggered. Before using this mode of operation connect each EF DELTA to a home power grid and
charge each EF DELTA separately. It is not recommended to charge more than two machines simultane-
ously from the same household power outlet. Otherwise, the excessive load may cause overload/damage
to the home power circuit. To use this function, you need to at first set any of the machines as the master
and the others as Slave 1 and Slave 2. Connect one end of the AC cable to the AC output port of the master
unit and the other end to the input port of Slave 1. Then, connect one end of the AC cable to the AC output
port of Slave 1 and the other end to the input port of Slave 2. After connecting the machines, turn all the AC
switches of the machines on to activate multi-machine series mode. Finally, connect all the appliances to
the AC sockets of the Slave 2 and then you can charge your devices using EF DELTA and enjoy the benefits
of extended powering time.
2 . Multi Machine Series Mode User Guide
Multi-Machines Series Mode is a multi-level power series solution developed based on the UPS function.
It allows users to connect multiple EF DELTAs in series to get continuous power that is multiple times of a
single machine. The principle of use is that when the power of an individual DELTA is used up, the next
DELTA can immediately replace it to ensure uninterrupted power supply. This a entry-level grade UPS
function that does not support 0ms switching.
Note: Do Not connect devices with high uninterrupted power supply requirements. Perform multiple
tests to confirm compatibility before connecting such devices as data servers and workstations with EF
DELTA. EcoFlow will not be responsible for any loss of data or equipment damage caused by customers’
failure to determine the suitability of Delta to support their UPS
12V CAR
AC ON/OFF
Master unit AC on Slave unit AC on
Example 1 ：
100%
12V CAR
AC ON/OFF
100%
12V CAR
AC ON/OFF
12
power a free life

Master unit AC on Slave 1 Slave 2
Example 2 :
100%
12V CAR
AC ON/OFF
100%
12V CAR
AC ON/OFF
100%
12V CAR
AC ON/OFF
Net Weight
Dimension
Capacity Delta 1300 / Delta 1600
Testing and certification
30.9lbs (14kg)
15.7 x 8.3 x 10.6in (40 x 21 x 27cm)
1260Wh 50.4V / 1657.6Wh 51.8V
UL CE FCC RoHS PSE RCM AS/NZS 3820:2009
General Specs
TECHNICAL SPECIFICATIONS
AC Output (x6)/AC Output (x4)
USB-A Output (x2)
USB-A Fast Charge (x2)
USB-C Output (x2)
Car Power Output (x1)
Output
5V DC, 2.4A, 12W Max, per port
5V DC, 9V DC, 12V DC, 2.4A, 28W Max, per port
5V DC, 9V DC, 15V DC, 20V DC, 3A, 60W Max, per port
108.8W, 13.6V DC, 8A max
1800W (Surge 3300W)total, 230Vac (50Hz)
AC Charge Input Voltage
AC Charge Input Power
Solar Charge Input
Car Charger(Example 2)
Input
X-STREAM Charge 1200W max
400W 10-65V DC 10A max
12V/24V DC 10A max
220-240Vac
Cell Chemistry
Cell Type
Discharge Temperature
Charge Temperature
Shelf Life
Life Span
Battery
Lithium-ion
18650
-20-45°C
0-45°C
1 Year (After fully charged)
800 Cycles (60%)
13
power a free life

1200W Max
X-STREAM Charge
(Included)
(Included)
<2 Hours
0-80% charged in 1 hour
Full change in <2 hours
Car Charger
(120W Input)
<10 Hours
AC cable
Example 1 ：
Example 2 :
XT60
Connector
Charging 100% time
required
Everything you need to know about recharging your EF DELTA via AC Cable, car charger or solar charger
(If applicable).
How do I recharge my EF DELTA?
How do I care for EF DELTA?
Yes, EF DELTA can output power while being charged.
EF DELTA is designed for a variety of uses, so EF DELTA needs to be cleaned occasionally. Please use a dry
and non-abrasive cloth to clean the surface. The cleaners that are used for mobile phone or computer
screens can be used to clean EF DELTA, but do not give it a bath! It is important not to expose the Delta to
moisture of any kind.
Can EF DELTA power my devices while it's charging?
HOW TO RECHARGE EF DELTA
FAQs
14
power a free life

EF DELTA Bag
Solar Charge Cable
(MC4 to XT60 Input)
User Manual &
Warranty Card
1.5m Car Charge Cable
(Input)
1.5m AC Cable
(Input)
Car Battery Clamps
(Output)
EF DELTA
*You may purchase these items from www.CPpower.com.au
Do not charge the machine immediately after it is fully discharged (E.g. 1000W keep
40mins or 1500W keep 30 mins). For safety, please wait 2 to 3 hours for the machine to
be cooled down before being charging!
If you attempt to charge the machine immediately after a full discharge, the machine will display
an overheating protection reminder. Please wait 2 to 3 hours for the machine to be cooled down
before recharging it.
WARNING
How do I store EF DELTA?
Please store your EF DELTA in a dry environment without any surrounding abrasive objects. For optimal
battery health, store EF DELTA at room temperature after fully charged. EcoFlow oers a water-resistant,
dustproof case for maximum protection. It is suggested that you keep EF DELTA connected to a power
source, such as a solar panel or a wall plug, when the product is not in use. This can help prolong the
battery life and ensure your EF DELTA is ready to operate at all times. Without any external sources for
power supply during storage, EF DELTA has a shelf life at of approximately a year at a storage temperature
of 25 degrees C.
How do I use EF DELTA safely?
Please use EF DELTA in temperature conditions within its operating temperature range. Using EF DELTA
outside of its optimal operating temperature range can push the machine beyond its safe and eective
limits. Do not expose your Delta to rain and definitely don't submerge your EF DELTA in water. It is not
waterproof and this will void your warranty. If you want to protect EF DELTA against moisture and dust,
use a EF DELTA protector (IP54) or safety box (IP68, which can be purchased from ecoflow.com) Treat EF
DELTA with care.
WHAT’S IN THE BOX
OPTIONAL
15
power a free life
