Ecolink CS-232 User manual

CS-232 Wireless Contact with External Input
Installation Instructions
Operating Temperature: 32°-120°F (0°-49°C)
Operating Humidity: 5-95% RHnon condensing
Compatible with ClearSky 345MHz receivers
Supervisory signal interval: 60 min(approx.)
Specifications
Frequency: 345MHz
Battery: 3V lithium CR2032
Battery life: 3-5 years
Magnet gap: 5/8th inch max
Normally Closed external contact input
Enrolling
To enroll the sensor, set your panel into program mode, refer to your specific alarm panel manual
for details on these menus.
When prompted by the panel:
•Touch the magnet to the side of the sensor that has three white lines. This will send a
signal to the control panel as loop 2. Repeat as required.
•Connect the provided external wire, and short the wires together. This will send a signal
to the control panel as loop 1. Repeat as required.
Alternately, the 7 digit serial number printed on the back ofeach unit can be manually entered
into the panel.
Mounting
Included with the contact isdouble sided tape for the contact and the magnet. For reliable
bonding ensure the surface is clean and dry. Apply the tape to the sensor and then to the desired
location. Apply firm pressure for several seconds. Itisnotrecommended to mount the tape at
temperatures below 50°F, although after 24 hours thebond will hold at low temperatures.
One side ofthe sensor is marked with 3 lines; this indicates the location of the reed switch. The
magnet should be mounted facing this side ofthe sensor, and itmust beno further than 5/8 of an
inch from the sensor. An external contact may also be connected to the CS-232 with the supplied
wiring connector.
Replacing the Battery
When the battery is low a signal will besent tothecontrol panel. To replace the battery:
1. Slide the top cover to disengage it from the sensor, then remove it to reveal the battery.
2. Replace with a CR2032 battery ensuring the + side of the battery faces towards you.
3. Re-attached the cover, ensure the Top (as marked on the inside of the cover) points away
from the battery. You should hear a click when the cover engages properly.
Note: Removing the cover will trigger a zone tamper signal to the control panel.

FCC Compliance Statement
This equipment has been tested and found to comply with the limits for Class B digital devices, pursuant
to Part 15of the FCC Rules. This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) This device may not cause harmful interference and
(2) this device must accept any interference received, including interference that may cause undesired
operation.
These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates uses and canradiate radio frequency energy and, ifnotinstalled
and used in accordance with the instruction manual, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular
installation. Ifthis equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the useris
encouraged to try to correct the interference by one ormore of the following measures:
•Re-orient or relocate the receiving antenna
•Increase the separation between the equipment and receiver
•Connect the equipment to an outlet on a different circuit from the receiver
•Consult the dealer or an experienced radio/TV contractor for help.
Warning: Changes or modifications not expressly approved by Ecolink Intelligent Technology Inc. could void
the user’s authority to operate the equipment.
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the
following two conditions: (1) this device may not cause interference, and (2) this device must accept any
interference, including interference that may cause undesired operation ofthe device.
C’et appareil est conforme la norme d'Industrie Canada exempts de licence RSS. Son fonctionnement est
soumis aux deux conditions suivantes: (1) c’et appareil ne peut pas provoquer d'interférences, et(2) c’et
appareil doit accepter toute interférence, y compris les interférences qui peuvent causer un mauvais
fonctionnement de ladispositif.
FCC ID:XQC-CS232 IC: 9863B-CS232
Warranty
Ecolink Intelligent Technology Inc. warrants that for a period of 1year from the date of purchase that this
product is free from defects in material and workmanship. This warranty does not apply todamage caused by
shipping orhandling, ordamage caused by accident, abuse, misuse, misapplication, ordinary wear, improper
maintenance, failure to follow instructions or asa result of any unauthorized modifications.
If there is a defect in materials and workmanship under normal use within the warranty period Ecolink
Intelligent Technology Inc. shall, atits option, repair or replace the defective equipment upon return of
the equipment tothe original point ofpurchase.
The foregoing warranty shall apply only to the original buyer, and is and shall be in lieu of any and all other
warranties, whether expressed orimplied and of all other obligations or liabilities onthe part of Ecolink
Intelligent Technology Inc. neither assumes responsibility for, nor authorizes any other person
purporting to act on its behalf to modify or to change this warranty, nor to assume for it any other warranty or
liability concerning this product.
The maximum liability for Ecolink Intelligent Technology Inc.under all circumstances for any warranty issue
shall be limited to a replacement ofthe defective product .Itis recommended that the customer check their
equipment on a regular basis for proper operation.
© 2020 Ecolink Intelligent Technology Inc. PN CS232 R1.03 REV D
DATE: 10/29/2020
2055 Corte Del Nogal
Carlsbad, California 92011
1-855-632-6546
www.discoverecolink.com
