ECOWITT GW1100 User manual

1
Wi-Fi Weather Station Gateway
with Temperature, Humidity and
Barometric Sensor
Operation Manual
Model: GW1100
Thank you for purchasing this GW1100 Wi-Fi
Weather Station Gateway, with built-in
temperature, humidity and barometric sensor. It
can also handle all the Ecowitt sensors developed.
By upgrading firmware, future sensors developed
can also be hosted, and this made the gateway an
extremely flexible Ecowitt ecosystem possible.
To ensure the best product performance,please re
ad this manual and retain it for future reference.

2
Table of Contents
1 TABLE OF CONTENTS...............................2
2 UNPACKING................................................. 3
3 OVERVIEW................................................... 5
3.1 WI-FIGATEWAY....................................... 5
3.2 FEATURES..................................................6
4 SET UP GUIDE............................................ 12
4.1 WI-FIGATEWAY INTRODUCTION............12
4.1.1 LED Indicators................................ 13
4.1.2 Button functions...............................14
5 PUBLISH TO INTERNET WEATHER
SERVICES...................................................15
5.1 GATEWAY WI-FICONFIGURATION..........16
6 REGISTER WEATHER SERVICES
ACCOUNT AND VIEWING DATA ON
WEATHER SERVICES WEBSITE......... 34
7 TROUBLESHOOTING GUIDE.................42
8 SPECIFICATIONS...................................... 49
9 WARRANTY INFORMATION................. 51

3
1 Unpacking
Open your weather station box and inspect that
the contents are intact (nothing broken) and
complete (nothing missing). Inside you should
find the following:
QTY
Item Description
1
USB Wi-Fi Gateway
1
USB extension cable for
powering the gateway
1
Cable clip
1
User manual (this manual)
Table 1: Package content
If any component is missing from the package, or
broken, please contact our Customer Service
department to resolve the issue.
Note: The gateway must be plugged into a USB
(2.0 or later) port for its power supply. The USB
extension cable (USB type A - Male straight to

4
female straight; included) should be used so that
the gateway is sitting further from AC adapters
which is a heat source as well as EMI
interference source. The using of this USB
extension cable will make the gateway performs
better in terms of radio signal reception, and
measures indoor temperature, humidity more
accurate.
Note: You may download the online PDF version
manual of this product for better reading
experience:
1. Go to our website: www.ecowitt.com
2. Go to “Support” and click “Manual &
Firmware”
3. Search for “GW1100”
4. Download the manual

5
2 Overview
2.1 Wi-Fi Gateway
Figure 1: Wi-Fi Gateway

6
2.2 Features
•Attached temperature, humidity and
atmospheric pressure 3-in-1 probe sensor.
•Collects sensor data from various supported
wireless sensors.
•Additional/optional sensors:
•One WH32 outdoor temperature and
humidity sensor
•One WH40 self-emptying rain gauge sensor
•One WS68 wireless anemometer
•Up to 8 WH31 multi-channel temperature
and humidity sensors or 8 WN30 multi-
channel temp sensors
•Up to 8 WH51 soil moisture sensors
•Up to 4 WH41/WH43 PM2.5 air quality
sensors

7
•One WH45 PM2.5/PM10/CO2/temperature
and humidity all-in-1 sensor
•Up to 4 WH55 Water leak sensors
•One WH57 Lightning sensor
•Up to 8 WN34 Temp Sensors
•Up to 8 WN35 leaf wetness sensors
•Calculates dew point for outdoor sensor
(cloud upload supported)
•Pushes sensor data to cloud weather services:
•https://www.ecowitt.net
•https://www.wunderground.com
•https://www.weathercloud.com/
•https://www.wow.com
•Custom sites using either Wunderground or
Ecowitt protocol. Contact the Customer
Support department for assistance.

8
•Mobile application (WS View)
•View collected live data.
•Manage sensor calibration setup.
•Manage sensor selection.
•Data storage service on Ecowitt server:
https://ecowitt.net
•Data storing resolution:
by day: 5 minutes average
by week: 30 minutes average
by month: 4 hours average
by year: 1 day average
•Stores data for past three months with 5-
minute intervals
•Stores data for past one year at 30-minute
intervals

9
•Stores data for past two year at 4-hour
intervals
Note: All the optional sensors supported can be
found on our website: www.ecowitt.com.
Make sure to select the model of the units
with the same RF frequency as your
gateway (the frequency is different for
various countries because of regulations).
Note: www.ecowitt.net hosts all the sensor
supported, however, it is not necessary
true to other data hosting services. For
example, the Wunderground only accepts
outdoor sensor data, therefore it will not
display the following sensor data on their
website:
•Indoor temperature and humidity (from the
GW1100 built-in 3-in-1 sensor)

10
•Multi-channel temperature and humidity
(from the WH31 sensor) or Multi-channel
temp (from WN30 sensor)
•Soil moisture (from the WH51 sensor)
•PM2.5 data (from the WH41/43 sensor).
•Lightning data (from the WH57 sensor)
•Water leakage condition (from the WH55
Sensor)
•Water/Soil temp (from WN34 sensor)
•PM2.5/PM10/CO2/temperature and humidity
data (from the WH45 Sensor)
•Leaf wetness sensor(from WN35 sensor)
To view and record all the sensors data remotely,
we recommend you to use the Ecowitt server.

11
Attention:
Our product is continuously changing and
improving, particularly online services and
associated applications. To download the latest
manual and additional help, please contact us at
[e-mail] or
[e-mail] (EU/UK).

12
3 Set up Guide
3.1 Wi-Fi Gateway Introduction
See Figure 2 to help you identify elements of the
gateway.
Figure 2: Gateway Introduction
1. Factory Default Reset Button
2. RF Status Indicator Light (Blue)
3. Wi-Fi Status Indicator Light (Red)
4. USB Connector for system power supply
5. Temperature, humidity and barometric 3-in-1 sensor
Table 2: Gateway parts identification

13
3.1.1 LED Indicators
RF (Blue): Indicates the status of RF
communication with the station.
Flash (each): Indicates one packet of RF data
from a sensor was received.
Off (steady): Indicates none RF data received.
Wi-Fi (Red): Indicates the status of the Wi-Fi
connection.
Off : Wi-Fi connection to router failed;
On: GW1100 was provisioned to router and
has data sent to any one of the cloud data
hosting successfully.
Flash slowly: GW1100 connected to WiFi
router, but failed to publish data to any of the
weather service on cloud.
Flash rapidly: GW1100 was in factory reset
default state. It has never been configured for
router and weather server.

14
3.1.2 Button functions
The black button is used for the reset mode:
Reset Mode: Hold the black button for about 5
seconds will reset the gateway to factory default
reset state. All the history data, Wi-Fi settings,
calibration and sensor labeling etc. are all lost
and need to be set again.

15
4 Publish to Internet Weather
Services
The supported services are shown in the below
table.
Service
Description
Weather
Underground
Site: https://wunderground.com
provides local & long-range
weather forecasts, weather
reports, maps & tropical weather
conditions for locations
worldwide.
WOW
Site:
https://wow.metoffice.gov.uk
A UK based weather observation
website.
Weather
Cloud
Site: https://weathercloud.net
A large network of weather
stations reporting data in real time
from all over the world.
Ecowitt
Weather
Site: https://www.ecowitt.net
Ecowitt’s new weather server that
can host a bunch of sensors that
other services don’t support at
this time.
Table 3: Supported weather services

16
4.1 Gateway Wi-Fi Configuration
1. Power up device.
2. Go to your computer’s or phone’s Network
Settings page, find GW1100 AP in Network
Settings page or WLAN page.
Figure 3: Configure screen 1

17
3. Connect the AP, but please note you may wait
about 60 seconds to connect this device, it may
pops up a prompt ‘This WLAN network has no
Internet access. Connect anyway? CANCEL |
CONNECT’, see Figure 4, choose CONNECT
always.
Figure 4: Configure screen 2

18
4. After connected to the AP successfully, you
can see the networked state is connected. If
needed( to prevent automatically switching to
mobile network for some user’s case), the mobile
network service should be turned off.
Figure 5: Configure screen 3 (show on
phone)

19
Figure 6: Configure screen 4 (show on
computer)

20
5. Open your browser, type 192.168.4.1 in the
browser address search bar and enter.
Figure 7: Configure screen 5
6. See Figure 8 to login directly, do not
enter password.
Figure 8: Configure screen 6
