Ecoxotic 0-10 Ramp Timer User manual

www.ecoxotic.com Page 1 of 10
Safety Instructions
timer
timer
timer
timer
timer
timer
timer
0-10V Ramp Timer
To avoid injury and possible electrick shock, it is imperative you READ AND FOLLOW ALL
SAFETY INSTRUCTIONS
Important Warnings
This is NOT a page of legalese. It contains important safety information that you should read for future refer-
ence. Remember, you can always find more information on our website.
discard the appliance.
or the timer/controller.
and examine it for the presence of water.
timer
0 Celsius or 32 Fahrenheit.
If an extension cord is necessary, a cord with a rating of at least 15 Amperes should be used. A
cord rated for less Amperes or watts that the fixtures may overheat. Care should be taken to
arrange the cord so that it will not be tripped over or pulled.
Save these instructions
y.

www.ecoxotic.com Page 2 of 10
0-10V Ramp Timer
Instructions
What’s Included:
1 - Ramp Timer LED Controller
1 - Wireless LED Remote Control
1 - 12VDC Power Supply
2 - 3-way Splitters
2 - 36” DC Extension Cables
Important Note:
This 0-10V Ramp Timer is designed for use with Ecoxotic LED products which use a dim-
mable LED driver that accepts a 0-10V dimming signal (such as our Cannon LED pendants.)
Most drivers accept this dimming signal between 1-10V (with 1V=10%, 10V=100%) and there-
fore cannot be dimmed below a 10% intensity. To shut the light completely off, power must
be shut off on the AC side of the driver (either by a standard wall timer or power circuit timer.)
The Ramp Timer can be kept plugged in at all times for 24-hour ramp/dimming and intensity
control.
We recommend not exceeding 6 dimmable LED drivers to be connected to the 0-10V Ramp
Timer, 3 LED drivers per channel.
Warning: This product must be installed by a licensed electrician
Before beginning any work on the electrical installation, be sure that the main breaker
panel is “OFF” to avoid any danger of electrical shock. All mounting of the unit must
be completed before proceeding with electrical hook-up. Where required by local,
state or National Electric Codes the circuit should be equipped with a ground fault
interrupter. As with any electric applicance, failure to electrically ground unit may
result in serious injury or death.

ww.ecoxotic.com P
0-10V Ramp Timer
Instructions
Installation Instructions
The below diagram is a basic guideline for connecting up to 6 dimmable LED drivers to the 0-10V Ramp Timer. If your
LED lighting system consists of two color spectrums (white and blue), we recommend connecting the dimmable LED
drivers for the blue spectrum lights to Channel 1, the dimmable driver for the white spectrum lights to Channel 2.
If using less than 6 units, we recommend not exceeding 3 drivers per channel. The drivers/lights can be installed on either channel.
It is not necessary to use both channels on the 0-10V Ramp Timer.
Please follow the steps on the following pages for detailed installation and programming.
Figure 1
GFCI Outlet
Page 3 of 10

0-10V Ramp Timer
Instructions
1. Install Cannon LED pendants using swivel brackets or hanging kit included with each unit.
2. Mount LED drivers on wall or in a ventilated waterproof enclosure away from direct contact from moisture and/or
water. Connect LED driver to Cannon LED pendant and AC power per the instructions included with each unit.
3. If required, connect dimming cable to Female DC plug included with the driver. Note: Female DC plug is labeled with + and -
terminals and on some units may be pre-installed.
If using a Meanwell LED driver, dimming cables are as follows:
Blue = + (Dim +)
White = - (Dim -)
If using an Inventronic LED driver, dimming cables are as follows:
Yellow = NOT USED
Purple = = (Dim +)
Green = - (Dim -)
NOTE: When using multiple LED drivers, we recommend following the wiring diagram located on Page 3 as
a guideline. Please remember, we do not recommend exceeding three (3) dimmable LED drivers be located on a
single channel. Additional detailed wiring diagrams for different drivers can be found on the following page.
4. Locate controller location near LED drivers or in a location away from direct contact from moisture and/or water.
5. Connect the 12VDC transformer to the female DC plug on the Ramp Timer. Plug 12VDC power supply into a GFCI
approved outlet where power will be kept on 24 hours per day.
6. Connect the male DC plug of Channel 1 or Channel 2 to either a 3-way splitter or directly to Female
DC dimming plug. If using two different color spectrum Cannon LED pendants, we recommend keeping one spectrum
(such as blue) on Channel 1, the other spectrum (such as white) on Channel 2. It is not required to use both Channels
(you will only need to program one.) Please note, 36” extension cables are also included for longer length installations.
Additional extension cables are available (sold separately.)
7. Ensure all cables and connectors are clear of any moisture or water and do not hang or submerge into
the water at any location or point.
8. Remove the plastic wrap from the remote control and remove the clear plastic tab located at the bottom of the
remote to connect the battery. Point remote at the LED controller and press the On/Off red button on the remote
(top right hand corner.) Controller will now be turned on as indicated by the LCD display. Follow instructions on page
for programming.
Blue
White
Yellow (not used)
Purple
Green
Page 4 of 10

0-10V Ramp Timer
Wiring Diagram Guidelines
Channel 1
Channel 2
0-10V
Controller
12VDC
Transformer
Dimming Cable
DC to LED
To AC Timer
or GFCI
LED Driver
To GFCI
(No timer)
DC to LED
LED Driver
Dimming Cable
Channel 1
0-10V
Controller
12VDC
Transformer
To GFCI
(No timer)
Channel 2
To AC Timer
or GFCI
To AC Timer
or GFCI
Typical wiring diagram for wall mount LED drivers. These include Inventronics dimmable LED drives and Meanwell HLG
and ELN dimmable LED drivers.
Typical wiring diagram for circular mounted LED drivers. These include Meanwell HBG dimmable LED drivers.
Page
5 of 10

Pre-programmed Lighting Schedule Guide
The 0-10V Ramp Timer features four pre-programmed lighting schedules. These schedules are located in memory buttons labeled TIMER M1,
TIMER M2, TIMER M3, TIMER M4. To customize any of the settings, please follow the detailed Programming Instructions located on Page 4.
Using the graph and table below, select from any one of the pre-programmed lighting schedules. Once you select a lighting program, simply
press TIMER M1, TIMER M2, TIMER M3 or TIMER M4 and the controller will automatically enter into the selected lighting schedule.
Programming Instructions
Please read the following guides before following the detailed programming
instructions located on the following page.
Programming Feature Guide
The 0-10V Ramp Timer features two independent lighting channels with the following:
- Program on/off times for each channel (dimming down to 10%)
- Adjustable intensity (10-100%) for each channel
- Adjustable ramp up (sunrise) / dim down (sunset) (0-30 minutes)
- Adjustable moonlight duration (0-6 hours)
- On-demand color spectrum adjustment (when using two different color spectrum Cannons)
- On-demand weather simulation including cloud cover, fading moonlight and storm with lightning
- Four memory locations for storing custom lighting schedules (each are pre-programmed by default, see page 3)
0-10V Ramp Timer
Instructions
Page 6 of 10

Default
Wireless Infrared IR Remote Guide
When using your wireless remote, point the remote directly
at the IR sensor located on the 0-10V Ramp Timer. It is
important to have a direct line of sight between the remote
and the controller.
Digital LCD Display Guide
0-10V Ramp Timer
Instructions
Page 7 of 10
6

Detailed Programming Instructions
The following detailed steps will guide you through customizing and programming your 0-10V Ramp Timer.
Please be sure to follow our Quick Installation Guide and set the clock before following the below steps.
Programming Individual Lighting Channels
The 0-10V Ramp Timer features two channels of lighting which can be independently controlled. Channel 1/Line 1 should be connected to your
blue spectrum lights for dawn/dusk/actinic/moon lighting; Channel 2/Line 2 should be connected to your white spectrum lights for daylight.
SUNRISE/SUNSET FADE - The duration of the ramp up and dim down (0-30 minutes)
To reset the memory settings to the factory default, press DEFAULT for 5 seconds (see pg. 5).
Default
This will reset the controller memory for all four memory settings.
Determines what time your lights will begin to ramp up from 10%
Determines what time your lights will begin to ramp down to 10%
The maximum brightness setting (from 10%-100%)
The minimum brightness setting (from 10%-100%)
0-10V Ramp Timer
Instructions
Page 8 of 10

Programming Light Channels continued
Memory Functions
2.
per the programmed moonlight duration time (0-6 hours.)
Press TIMER M1, TIMER M2, TIMER M3, or TIMER M4. SL-1, SL-2, SL-3 or SL-4 will display on the screen.
.
The intensity % can be used as a reference when programming your minimum and maximum settings.
10% to 100%.
to 10% min.
The 0-10V Ramp Timer features five total memory locations.
0-10V Ramp Timer
Instructions
Page 9 of 10

Product Registration
www.ecoxotic.com
Page 10 of 10
To activate your warranty, please visit our product registration page at www.ecoxotic.com
For more information, FAQ’s, installation guides and videos, please visit our website at www.ecoxotic.com
Warranty
Ecoxotic One-Year Limited Warranty
This limited warranty applies only to products that are manufactured by or for Ecoxotic and can be identified by trade name or logo
affixed to it, and sold by an authorized Ecoxotic retailer in the United States to you, the original purchaser of such products (“Products“).
Ecoxotic hereby warrants that Products will be free from defects in materials and workmanship for a period of one (1) year from the date
of original retail purchase (the “Warranty Period“). This warranty does not apply to any product that is not an Ecoxotic Product.
This warranty does not apply to Products (i) that have been damaged by accident, abuse, misuse or misapplication, improper installation,
saltwater corrosion, electrical surges, (ii) that have been modified without the written permission of Ecoxotic or, (iii) for which any Ecoxotic
logos have been removed or defaced.
Please contact Ecoxotic if you discover a defect in any Product. In the event that such Product is defective, as determined by Ecoxotic in its
sole discretion, Ecoxotic’s sole obligation, and your exclusive remedy, shall be for Ecoxotic, at its option, to repair or replace such Product at
no charge to you, provided that you (i) return such Product to Ecoxotic during the Warranty Period, and (ii) provide proof of purchase and
registration of such Product. If the returned Product is not defective or is returned after the Warranty Period, Ecoxotic shall have no
obligation to repair or replace the Product.
EXCEPT AS EXPRESSLY PROVIDED ABOVE OR AS REQUIRED BY LAW, ECOXOTIC PRODUCTS ARE PROVIDED “AS IS,” WITHOUT WARRANTY OF
ANY KIND. THE WARRANTY AND REMEDIES SET FORTH ABOVE ARE EXCLUSIVE AND IN LIEU OF ALL OTHERS, WHETHER ORAL OR WRITTEN.
ALL WARRANTIES IMPLIED BY STATE LAW, INCLUDING IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE, ARE EXPRESSLY LIMITED TO THE LESSER OF THE DURATION UNDER STATE LAW OR THE DURATION OF THE LIMITED WARRANTY
SET FORTH ABOVE. IN NO EVENT SHALL ECOXOTIC BE RESPONSIBLE FOR SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES, INCLUD-
ING, BUT NOT LIMITED TO LOST PROFITS, DOWNTIME, GOODWILL, DAMAGE TO OR REPLACEMENT OF OTHER EQUIPMENT OR PROPERTY,
COSTS OF RECOVERING OR REPLACING ANY ANIMALS, FISH, PLANTS, TANKS OR OTHER AQUARIUM RELATED ITEMS AND/OR EQUIPMENT,
OR PERSONAL INJURY. Some states do not allow the exclusion or limitation of incidental or consequential damages or limitations on the
duration of implied warranties, so the above limitations or exclusions may not apply to you.This warranty gives you specific legal rights,
and you may also have other rights that vary form state to state.
This warranty is not transferable. No person is authorized to change, modify or extend the terms of this warranty in any manner. This
warranty is governed by the laws of the State of California, excluding conflicts of laws principles. Ecoxotic reserves the right to make
changes, additions and improvements to its products from time to time, and has no obligation to replace the exact same model of
Product.
0-10 Ramp Timer
Warranty Information
